HP LCD Speaker Bar Instrucciones de uso
1.
On/Off and volume knob
6.
Mounting tabs/screw holes
2.
Power LED indicator
7.
Release tab
3.
Headphone jacks
8.
Audio input cable
4.
Left and right speakers
9.
USB cable
5.
Security cable provision
Models
Part Number: NQ576AA
Introduction
Because we recognize that your monitor is the center of your computing world, HP offers a variety of optional products (each sold
separately) designed to complement our monitors and enhance the overall computing experience.
The HP LCD Speaker Bar lets you add stereo audio output to your HP flat panel monitor without taking up any additional desk space.
The HP LCD Speaker Bar is an excellent choice for improving the quality of multimedia presentations, streaming online video or Web-
based seminars. It attaches easily to the bottom of the monitor to bring audio support features such as high-quality speakers and an
external headphone jack right to the desktop.
The Speaker Bar is conveniently powered through a USB port located either on the PC or monitor (if the monitor has an integrated USB
hub), so there are no power cords or AC adapters to be concerned about. This lightweight, elegantly-designed sound bar is fully
supported by HP Technical Support when used with an HP system.
Key features and benefits
Delivers two watts of total RMS output for a quality business audio experience
Designed to easily attach and visually complement selected models of current and future HP LCD monitors (see compatibility
chart below)
Secures to the monitor with a Kensington lock slot
Tested and qualified with HP Business Desktop and LCD monitors
Compatibility
The HP LCD Speaker Bar is designed to integrate with all ProDisplay, EliteDisplay, and Performance series HP business LCD monitors.
QuickSpecs
HP LCD Speaker Bar
Overview
DA - 13393 North America — Version 2 — April 25, 2013
Page 1
Service and support
Your Option Limited Warranty is a one (1) year (HP Option Limited Warranty Period) parts replacement warranty on any HP-branded or
Compaq-branded options (HP Options). If your HP Option is installed in an HP Hardware Product, HP may provide warranty service
either for the HP Option Limited Warranty Period or the remaining Limited Warranty Period of the HP Hardware Product in which the HP
Option is being installed, whichever period is the longer but not to exceed three (3) years from the date you purchased the HP Option.
QuickSpecs
HP LCD Speaker Bar
Overview
DA - 13393 North America — Version 2 — April 25, 2013
Page 2
Audio
Sound Output
1.3 watts RMS per channel @ 10% Total Harmonic Distortion (THD)
Frequency Response
200 Hz to 20 kHz
Sound Pressure Level
86 dB +/-3dB (0.1watt/0.1 meter) averaged at 600, 800, 1200, 1500 Hz
Input: 180 mV; Output: volume max
Driver unit impedance
6 ohms
Controls
On/Off/Volume Control
Yes, side of Speaker Bar
Stereo Headphone Jack
Yes, two
Mechanical
Dimensions
(H x W x D)
Packaged:
2.9 x 13.8 x 3.2 in (7.30 x 35.00 x 8.20 cm)
Unpackaged:
2.8 x 13.0 x 2.4 in (6.98 x 32.92 x 6.05 cm)
Weight
Packaged:
1.18 lbs (539 g)
Unpackaged:
0.78 lbs (358 g)
HP Lock Ready
Yes
Power
USB powered; 5V (DC), 0.5 amp
Option kit contents
Speaker Bar with captive USB (power) cable and color-coded audio cable; 1/8-
inch stereo mini
Cable lengths
USB Power
(including
connector)
70.9 in (180 cm)
Audio Cable
70.9 in (180 cm)
Cabinet and grill color
Black
© 2013 Hewlett-Packard Development Company, L.P.
HP shall not be liable for technical or editorial errors or omissions contained herein. The information is provided as is without warranty
of any kind and is subject to change without notice. The warranties for HP products are set forth in the express limited warranty
statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. All performance
specifications are provided by the component manufacturer. Performance specifications represent component manufacturer averages
and actual performance may vary.
QuickSpecs
HP LCD Speaker Bar
Technical Specifications
DA - 13393 North America — Version 2 — April 25, 2013
Page 3
