User Guide

HP L156v 15” and L176v 17” LCD

Monitors

Document Part Number: 432558-001

July 2006

This guide provides information on setting up the monitor,

installing drivers, using the on-screen display menu,

troubleshooting and technical specifications.

The information contained herein is subject to change without notice.

Microsoft, MS-DOS, Windows, and Windows NT are trademarks of

Microsoft Corporation in the U.S. and other countries.

Adobe, Acrobat, and Acrobat Reader are trademarks or registered

trademarks of Adobe Systems Incorporated.

The only warranties for HP products and services are set forth in the

express warranty statements accompanying such products and services.

Nothing herein should be construed as constituting an additional warranty.

HP shall not be liable for technical or editorial errors or omissions

contained herein.

This document contains proprietary information that is protected by

translated to another language without the prior written consent of

Hewlett-Packard Company.

ÅWARNING: Text set off in this manner indicates that failure to

follow directions could result in bodily harm or loss of life.

ÄCAUTION: Text set off in this manner indicates that failure to follow

directions could result in damage to equipment or loss of information.

User Guide

HP L156v 15” and L176v 17” LCD Monitors

First Edition (July 2006)

Document Part Number: 432558-001

User Guide iii

Contents

1 Product Features

L156v Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1

L176v Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1

2 Safety and Maintenance Guidelines

Important Safety Information. . . . . . . . . . . . . . . . . . . . . . 2–1

Maintenance Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . 2–2

Cleaning the Monitor. . . . . . . . . . . . . . . . . . . . . . . . . 2–3

Shipping the Monitor. . . . . . . . . . . . . . . . . . . . . . . . . 2–3

3 Setting Up the Monitor

Installing and Removing the Base . . . . . . . . . . . . . . . . . . 3–1

Power Cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–2

Connecting the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . 3–2

Adjusting the Viewing Angle. . . . . . . . . . . . . . . . . . . . . . 3–3

4 Operating the Monitor

General Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1

Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1

L156v Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–2

L176v Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–3

OSD Lock Function. . . . . . . . . . . . . . . . . . . . . . . . . . 4–3

How To Adjust a Setting . . . . . . . . . . . . . . . . . . . . . . . . . 4–4

Adjusting the Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–4

Software and Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–7

iv User Guide

Contents

The Information File . . . . . . . . . . . . . . . . . . . . . . . . . 4–7

The Image Color Matching File . . . . . . . . . . . . . . . . 4–8

Installing the .INF and .ICM Files. . . . . . . . . . . . . . . . . . 4–8

Installing from the CD. . . . . . . . . . . . . . . . . . . . . . . . 4–8

Downloading from the Worldwide Web. . . . . . . . . . 4–9

Plug and Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–9

Plug & Play DDC2B Feature. . . . . . . . . . . . . . . . . . . 4–9

A Troubleshooting

Solving Common Problems . . . . . . . . . . . . . . . . . . . . . . . A–1

Error Messages and Possible Solutions. . . . . . . . . . . A–2

Using the Worldwide Web. . . . . . . . . . . . . . . . . . . . . . . . A–3

Preparing to call Technical Support. . . . . . . . . . . . . . . . . A–3

B Technical Specifications

L156v Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B–1

L176v Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B–4

Recognizing Preset Display Resolutions . . . . . . . . . . . . . B–6

L156v Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B–6

L176v Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B–7

Entering User Modes. . . . . . . . . . . . . . . . . . . . . . . . . B–8

C Agency Regulatory Notices

Federal Communications

Commission Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–1

Modifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–2

Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–2

Declaration of Conformity for Products Marked with the FCC

Logo (United States Only). . . . . . . . . . . . . . . . . . . . . . . . C–2

Materials disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–3

ENERGY STAR Compliance . . . . . . . . . . . . . . . . . . . . . C–3

Power Cord Set Requirements. . . . . . . . . . . . . . . . . . . . . C–3

User Guide 1–1

Product Features

The flat panel display has an active matrix, thin-film transistor

(TFT), liquid crystal display (LCD). The monitor features

include:

L156v Model

■38.1cm (15") TFT Color LCD Monitor

■Crisp, clear display for Windows

■Recommened resolutions: 1024 x 768 @60Hz

■EPA ENERGY STAR®

■Ergonomic design

■Space saving, compact case design

■Power cord, signal cable, audio cable

■Software and documentation CD includes an information file

(INF), Image Color Matching file (ICM), and product

documentation

L176v Model

■43.2cm (17") TFT Color LCD Monitor

■Crisp, clear display for Windows

■Recommended resolution: 1280 X 1024 @60Hz

■EPA ENERGY STAR®

1–2 User Guide

Product Features

■Ergonomic design

■Space saving, compact case design

■Power cord, signal cable, audio cable

■Software and documentation CD includes an information file

(INF), Image Color Matching file (ICM), and product

documentation

User Guide 2–1

Safety and Maintenance

Guidelines

Important Safety Information

A power cord is included with your monitor. If another cord is

used, use only a power source and connection appropriate for this

monitor. For information on the correct power cord set to use with

your monitor, refer to the “Power Cord Set Requirements” section

in Appendix C.

ÅWARNING: To reduce the risk of electric shock or damage to your

equipment, do not disable the power cord grounding feature. This

equipment is designed to be connected to a grounded (earthed)

power outlet that is easily accessible to the operator. The grounding

plug is an important safety feature.

ÅWARNING: For your safety, be sure that the power outlet you plug

the power cord into is easily accessible and located as close to the

equipment as possible. When you need to disconnect the power to

the equipment, unplug the power cord from the power outlet by

grasping the plug firmly. Never pull on the cord.

2–2 User Guide

Safety and Maintenance Guidelines

ÄCAUTION: For the protection of your monitor, as well as your

computer, connect all power cords for your computer and its

peripheral devices (such as a monitor, printer, scanner) to some form

of surge protection device such as a power strip or Uninterruptible

Power Supply (UPS). Not all power strips provide surge protection;

the power strips must be specifically labeled as having this ability.

Use a power strip whose manufacturer offers a Damage Replacement

Policy so you can replace your equipment if surge protection fails.

Maintenance Guidelines

To enhance the performance and extend the life of your monitor:

■Do not open your monitor cabinet or attempt to service this

product yourself. Adjust only those controls that are covered

in the operating instructions. If your monitor is not operating

properly or has been dropped or damaged, contact your HP

authorized dealer, reseller, or service provider.

■Use only a power source and connection appropriate for this

monitor, as indicated on the label/back plate of the monitor.

■Be sure the total ampere rating of the products connected to

the outlet does not exceed the current rating of the electrical

outlet, and the total ampere rating of the products connected

to the cord does not exceed the rating of the cord. Look on the

power label to determine the ampere rating (AMPS or A) for

each device.

■Install your monitor near an outlet that you can easily reach.

Disconnect the monitor by grasping the plug firmly and

pulling it from the outlet. Never disconnect the monitor by

pulling the cord.

■Turn your monitor off when not in use. You can substantially

increase the life expectancy of your monitor by using a screen

saver program and turning off the monitor when not in use.

Safety and Maintenance Guidelines

User Guide 2–3

■Slots and openings in the cabinet are provided for ventilation.

These openings must not be blocked or covered. Never push

objects of any kind into cabinet slots or other openings.

■Do not drop your monitor or place it on an unstable surface.

■Do not allow anything to rest on the power cord. Do not walk

on the cord.

■Keep your monitor in a well-ventilated area, away from

excessive light, heat or moisture.

■When removing the monitor base, you must lay the monitor

face down on a soft area to prevent it from getting scratched,

defaced, or broken.

Cleaning the Monitor

1. Turn off the monitor and the computer.

2. Unplug the monitor from the wall outlet.

3. Clean the monitor plastics with a clean cloth dampened with

water.

4. Clean the monitor screen with an antistatic screen cleaner.

ÄCAUTION: Do not use benzene, thinner, ammonia, or any other

volatile substances to clean your monitor or the screen. These

chemicals may damage the cabinet finish as well as the screen.

Shipping the Monitor

Keep the original packing box in a storage area. You may need it

later if you move or ship your monitor.

2–4 User Guide

Safety and Maintenance Guidelines
