HP Z8 G4 Manual de usuario

QuickSpecs

HP Z8 G4 Workstation

Overview

c05527763 —DA - 15956 Worldwide —Version 3 —November 1, 2017

Page 1

HP Z8 G4 Workstation

Front view

Integrated Front Handle

Front I/O Entry: 4 USB 3.1 Gen1 (Left-most Port has

Charging Capability)

Front I/O Premium: 2x USB 3.1 Gen1, 2x USB 3.1 Gen2 Type-

C™ (Left-most Type-A Port has Charging Capability)

Note: Premium Front IO is shown on Photography

Dedicated 9.5mm Optical Drive Bay

Power Button

HDD Activity LED

Media Card Reader

1 Headset

QuickSpecs

HP Z8 G4 Workstation

Overview

c05527763 —DA - 15956 Worldwide —Version 3 —November 1, 2017

Page 2

Internal view

24 DIMM Slots for DDR4 ECC Memory

12.

Slot 1: PCIe Gen3 x4 –Transforms to PCIe Gen3 x8

when 2nd CPU is installed

Slot 2: PCIe Gen3 x16

Slot 3: PCIe Gen3 x16 –Available ONLY when 2nd

processor is installed

Slot 4: PCIe Gen3 x16

Slot 5: PCIe Gen3 x4

Slot 6: PCIe Gen3 x16 - Available ONLY when 2nd

processor is installed

Slot 7: PCIe Gen3 x4

2 External 5.25” Bays and Slimline Optical

10.

4 Internal 3.5” Bays

11.

2 Intel® Xeon® Processors (Skylake SP) family

13.

2 sSATA, 8 SATA (AHCI) Ports

14.

3 USB 2.0 Internal Ports, 1 USB 3.0 Gen1 Internal Port

QuickSpecs

HP Z8 G4 Workstation

Overview

c05527763 —DA - 15956 Worldwide —Version 3 —November 1, 2017

Page 3

Rear view

15.

Choice of 1125W or 1450W, 90% Efficient Power Supplies

16.

Rear I/O:

Rear Power Button

6 USB 3.0 Gen1

1 Serial

PS/2 keyboard and mouse

2 RJ-45 to integrated Gigabit LAN

1 Audio Line-In (can be retasked as microphone)

1 Audio Line-Out

Optional: 2 10GbE LAN ports

QuickSpecs

HP Z8 G4 Workstation

Overview

c05527763 —DA - 15956 Worldwide —Version 3 —November 1, 2017

Page 4

Overview

Form Factor

Minitower

Operating Systems

Preinstalled:

Windows 10 Pro 64 for Workstations

HP Linux-ready (minimal OS ready for customer OS installation)

Red Hat® Enterprise Linux® Desktop Workstation (Paper license with 1 year support; no

preinstalled OS)

Supported:

Windows 7 Professional 64-bit (downgrade media available by request from HP Support)*

Red Hat® Enterprise Linux® Desktop 7.4

SUSE Linux® Enterprise Desktop 12 SP3

Ubuntu 16.04 LTS

Notes: For detailed OS/hardware support information for Linux®, see:

http://www.hp.com/support/linux_hardware_matrix

*Windows 10 is preinstalled. Windows 7 media is only available upon request from HP Customer

Support. You may only use one version of the Windows software at a time. Switching between versions

will require you to uninstall one version and install the other version.

Available Processors

Name

Cores

Clock

Speed

(GHz)

Cache

(MB)

Memory

Speed

(MT/s)

Hyper-

Threading

Featuring

Intel® vPro™

Technology

Intel® Turbo

Boost

Technology1

TDP

(W)

Intel® Xeon® Platinum 8180

processor

2.5GHz

38.50

2666

YES

3.8GHz

205

Intel® Xeon® Platinum 8160

processor

2.1GHz

33.00

2666

YES

3.7GHz

150

Intel® Xeon® Gold 6152

processor

2.1GHz

30.25

2666

YES

3.7GHz

140

Intel® Xeon® Gold 6154

processor

3.0GHz

24.75

2666

YES

3.7GHz

200

Intel® Xeon® Gold 6148

processor

2.4GHz

27.50

2666

YES

3.7GHz

150

Intel® Xeon® Gold 6142

processor

2.6GHz

22.00

2666

YES

3.7GHz

150

Intel® Xeon® Gold 6136

processor

3.0GHz

24.75

2666

YES

3.7GHz

150

Intel® Xeon® Gold 6140

processor

2.3GHz

24.75

2666

YES

3.7GHz

140

Intel® Xeon® Gold 6134

processor

3.2GHz

24.75

2666

YES

3.7GHz

130

Intel® Xeon® Gold 6132

processor

2.6GHz

19.25

2666

YES

3.7GHz

140

Intel® Xeon® Gold 6130

processor

2.1GHz

22.00

2666

YES

3.7GHz

125

Intel® Xeon® Gold 6128

processor

3.4GHz

19.25

2666

YES

3.7GHz

115

Intel® Xeon® Gold 5120

processor

2.2GHz

19.25

2400

YES

3.2GHz

105

Intel® Xeon® Gold 5118

processor

2.3GHz

16.50

2400

YES

3.2GHz

105

QuickSpecs

HP Z8 G4 Workstation

Overview

c05527763 —DA - 15956 Worldwide —Version 3 —November 1, 2017

Page 5

Intel® Xeon® Gold 5122

processor

3.6GHz

16.50

2666

YES

3.7GHz

105

Intel® Xeon® Silver 4116

processor

2.1GHz

16.50

2400

YES

3.0GHz

Intel® Xeon® Silver 4114

processor

2.2GHz

13.75

2400

YES

3.0GHz

Intel® Xeon® Silver 4112

processor

2.6GHz

8.25

2400

YES

3.0GHz

Intel® Xeon® Silver 4108

processor

1.8GHz

11.00

2400

YES

3.0GHz

Intel® Xeon® Bronze 3106

processor

1.7GHz

11.00

2133

YES

N/A

Intel® Xeon® Bronze 3104

processor

1.7GHz

8.25

2133

YES

N/A

1The specifications shown in this column represent the following: (all core maximum turbo steps, one

core maximum turbo steps). Turbo boost stepping occurs in 100MHz increments. Processors that do

not have turbo functionality are denoted as N/A.

Available Processors

Disclaimers

When ordering two processors, the second processor must be the same as the first. Intel processor

numbers are not a measurement of higher performance. Processor numbers differentiate features

within each processor family, not across different processor families. See:

http://www.intel.com/products/processor_number/ for details.

Multicore is designed to improve performance of certain software products. Not all customers or

software applications will necessarily benefit from use of this technology. Performance and clock

frequency will vary depending on application workload and your hardware and software

configurations. Intel’s numbering, branding and/or naming is not a measurement of higher

performance.

Color

Black

Convertibility

Expansion Slots (see

system board section for

more details)

Slot 1:

PCIe Gen3 x4 - Transforms to PCIe Gen3 x8 when 2nd CPU is installed

Slot 2:

PCIe Gen3 x16

Slot 3:

PCIe Gen3 x16 - Available ONLY when 2nd processor is installed

Slot 4:

PCIe Gen3 x16

Slot 5:

PCIe Gen3 x4

Slot 6:

PCIe Gen3 x16 - Available ONLY when 2nd processor is installed

QuickSpecs

HP Z8 G4 Workstation

Overview

c05527763 —DA - 15956 Worldwide —Version 3 —November 1, 2017

Page 6

Slot 7:

PCIe Gen3 x4

Note: The PCIe x4 and PCIe x8 connectors above are open ended, allowing a PCIe x16 card to be seated

in the slot.

Note: Thunderbolt™ 3 PCIe card support available the first half of 2018

Expansion Bays (see

storage section for more

details)

4 internal 3.5" bays (All 4 include acoustic dampening rail assemblies)

2 external 5.25" bays (175mm depth limit)

1 dedicated 9.5mm slim optical disk drive bay

Front I/O

Base: 4 USB 3.1 Gen1 Type-A connector. Left most connector has charging capability, 1

Combo Headset, 1 Optional Media Card Reader

Premium: 2 USB 3.1 Gen1 Type-A connector. Left most connector has charging capability, 2

USB 3.1 Gen2 Type-C™connector, 1 Combo Headset, 1 Optional Media Card Reader

Internal I/O

Internal Slot 1 CPU1: PCIe Gen3 x8 - always available

Internal Slot 2 CPU2: PCIe Gen3 x8 - available when 2nd CPU is installed

2 USB 2.0 ports available with a single 2x5 header

1 USB 2.0 port available with a 1x6 header

1 USB 3.1 Gen1 and 1 USB 2.0 port available with a 2x6 header

Notes: The 2x5 header can be converted to a standard (Type-A) USB 2.0 connector through the use of

one HP Internal USB Port Kit (EM165AA). This port kit uses one half of the 2x5 header.

The 1x6 header can be converted to a standard (Type-A) USB 2.0 connector through the use of one HP

Internal USB Port Kit (EM165AA). This port kit uses 5 pin positions on the header.

The 2x6 header can be converted to a standard (Type-A) USB 2.0 connector

through the use of one HP Internal USB Port Kit (EM165AA). This port kit

uses one half of the 2x6 header.

Rear I/O

6 USB 3.1 Gen1 (aka USB 3.0), 1 Serial, PS/2 keyboard and mouse, 2 RJ-45 to integrated Gigabit LAN, 1

Audio Line-In (can be retasked as microphone), 1 Audio Line-Out

Optional: 2 RJ-45 to 10GbE LAN ports

Interfaces Supported

10 channel SATA 6.0 Gb/s interface

Factory integrated RAID available for SATA drives (RAID 0, 1, 5, and 10)

Internal USB 3.1 Gen1, USB 3.1 Gen2, USB 2.0

On-board RAID Support

SATA RAID 0 Striped Array Configuration

SATA RAID 1 Mirrored Array Configuration

SATA RAID 10 Striped/Mirrored Configuration

SATA RAID 5 Parity Array Configuration

Chassis Dimensions (H x

W x D)

Footprint:

H: 17.5" [444.5mm]

W: 8.5" [215.9mm]

D: 21.7" [551.2mm] (measured to the rear of service panel)

Maximum:

H: 17.5" [444.5mm]

W: 8.5" [215.9mm]

D: 21.85" [555.2mm] (measured to the embossment for the rear chassis fans)

Packaged Dimensions

H: 25" (636mm)

W: 13.1" (332mm)

D: 28.9" (734mm)

QuickSpecs

HP Z8 G4 Workstation

Overview

c05527763 —DA - 15956 Worldwide —Version 3 —November 1, 2017

Page 7

Rack Dimensions

Weight

Exact weights depend upon configuration (System weight only).

Minimum: 22.4kg (49.4lbs.)

Typical: 23.7kg (52.2lbs.)

Maximum: 31.7kg (70lbs.)

Temperature

Operating: 5° to 35°C (40° to 95°F)

Non-operating: -40° to 60°C (-40° to 140°F)

Humidity

Operating: Operating: 10% to 85% RH, non-condensing, 35° C maximum wet bulb

Non-operating: 10% to 90%, non-condensing, 35° C maximum wet bulb

Maximum Altitude (non-

pressurized)

Operating: 3,048m (10,000ft)

Non-operating: 9,144m (30,000ft)

Note: Above 1524 m (5,000 feet) altitude, maximum operating temperature is reduced by 1° C (1.8° F)

per 305 m (1,000 feet) elevation increase

Power Supply

Choice of:

1125W/100V/15A 90% Efficient wide-ranging, active Power Factor Correction

The power delivery system includes four 6+2-pin graphics power cables.

1450W/100V/15A 90% Efficient wide-ranging, active Power Factor Correction

The power delivery system includes four 6+2-pin graphics power cables.

1700W/200V/10A 90% Efficient wide-ranging, active Power Factor Correction

The power delivery system includes four 6+2-pin graphics power cables.

Notes: The 1125W/100V/15A (1450W at 200V Input Voltage) power supply can also supply 1275W of

output power when the input voltage is greater than 105V. If the input voltage is less than 105V, but

greater than 90V for any reason, the maximum power that can be drawn is 1125W. An uninterruptible

power supply (UPS) is highly recommended if 1275W output power is desired.

The 1125W Power Supply can also supply 1450W of output power when the input voltage is greater

than 200V under all conditions.

The 1450W/100V/15A (1700W at 200V Input Voltage) power supply can also supply 1550W of output

power when the input voltage is greater than 105V. If the input voltage is less than 105V, but greater

than 90V for any reason, the maximum power that can be drawn is 1450W. An uninterruptible power

supply (UPS) is highly recommended if 1550W output power is desired.

The 1450W Power Supply can also supply 1700W of output power when the input voltage is greater

than 200V under all conditions.

The Z8 G4 power supply efficiency reports can be found at these links:

1125W –Link:

https://plugloadsolutions.com/psu_reports/HP%20Inc_DPS-

1125BB%20A_1125W_ECOS%204825_Report.pdf

1450W –Link:

https://plugloadsolutions.com/psu_reports/HP%20Inc_DPS-

1450AB%20A_1450W_ECOS%204826_Report.pdf

Workstation ISV

Certifications

See the latest list of certifications at

http://www.hp.com/united-states/campaigns/workstations/partnerships.html

QuickSpecs

HP Z8 G4 Workstation

Supported Components

c05527763 —DA - 15956 Worldwide —Version 3 —November 1, 2017

Page 8

Processors

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

Intel® Xeon® processor Scalable family

Intel® Xeon® Platinum 8180 processor

1XM54AA

Intel® Xeon® Platinum 8160 processor

1XM56AA

Intel® Xeon® Gold 6152 processor

1XM57AA

Intel® Xeon® Gold 6154 processor

1XM58AA

Intel® Xeon® Gold 6148 processor

1XM59AA

Intel® Xeon® Gold 6142 processor

1XM61AA

Intel® Xeon® Gold 6136 processor

1XM62AA

Intel® Xeon® Gold 6140 processor

1XM64AA

Intel® Xeon® Gold 6134 processor

1XM66AA

Intel® Xeon® Gold 6132 processor

1XM67AA

Intel® Xeon® Gold 6130 processor

1XM68AA

Intel® Xeon® Gold 6128 processor

1XM69AA

Intel® Xeon® Gold 5120 processor

1XM70AA

Intel® Xeon® Gold 5118 processor

1XM71AA

Intel® Xeon® Gold 5122 processor

1XM72AA

Intel® Xeon® Silver 4116 processor

1XM73AA

Intel® Xeon® Silver 4114 processor

1XM74AA

Intel® Xeon® Silver 4112 processor

1XM75AA

Intel® Xeon® Silver 4108 processor

1XM76AA

Intel® Xeon® Bronze 3106 processor

1XM77AA

Intel® Xeon® Bronze 3104 processor

1XM78AA

*Multi-Core is designed to improve performance of certain software products. Not all customers or

software applications will necessarily benefit from use of this technology. 64-bit computing system

required. Performance will vary depending on your hardware and software configurations. Intel’s

numbering, branding and/or naming is not a measurement of higher performance.

Monitors /

Displays

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

HP Z Display Z22n G2

1JS05AA

HP Z Display Z23n G2

1JS06AA

HP Z Display Z24i G2

1JS08AA

HP Z Display Z24n G2

1JS09AA

HP Z Display Z24nf G2

1JS07AA

HP Z Display Z27n G2

1JS10AA

HP Z Display Z27s (4K display)

J3G07AA

Supported by all operating systems available from HP

Screen size measured diagonally

QuickSpecs

HP Z8 G4 Workstation

Supported Components

c05527763 —DA - 15956 Worldwide —Version 3 —November 1, 2017

Page 9

Storage / Hard Drives

SAS Hard Drives

SAS Hard Drives for HP Workstations

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

HP 300GB 15k SAS SFF

L5B74AA

NOTE: SAS controller add-in card required

SATA Hard Drives

Factory

Configured

Option Kit

Option

Kit Part

Number

Support

Notes

SATA (Serial ATA) Hard Drives for HP Workstations

500GB SATA 7200RPM 6Gb/s 3.5” HDD

LQ036AA

500GB SATA 7200RPM 6Gb/s OPAL2 SFF 3.5” HDD

D8N29AA

1TB SATA 7200RPM 3.5” HDD

LQ037AA

1TB SATA 7200RPM Ent 3.5” HDD

W0R10AA

2TB SATA 7200RPM HDD

QB576AA

4TB SATA 7200RPM Ent 3.5” HDD

K4T76AA

NOTES:

Up to (5) 3.5-inch 7200 rpm SATA drives: 500 GB, 1.0, 2.0, 4.0 TB; 20TB max total

QuickSpecs

HP Z8 G4 Workstation

Supported Components

c05527763 —DA - 15956 Worldwide —Version 3 —November 1, 2017

Page 10

SATA Solid State Drives

Factory

Configured

Option Kit

Option

Kit Part

Number

Support

Notes

HP Solid State Drives (SSDs) for Workstations

HP 256GB SATA SSD

A3D26AA

HP 512GB SATA SSD

D8F30AA

HP 1TB SATA SSD

F3C96AA

HP 2TB SATA SSD

Y6P08AA

HP 256GB SATA SED OPAL2 SSD

G7U67AA

HP 512GB SATA SED OPAL2 SSD

N8T26AA

HP 240GB SATA Enterprise SSD

T3U07AA

HP 480GB SATA Enterprise SSD

T3U08AA

PCIe Solid State Drives

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

PCIe SSDs for HP Workstations

HP Z Turbo Drive 256GB MLC Z8G4 SSDModule

1PD50AA

HP Z Turbo Drive 512GB MLC Z8G4 SSDModule

1PD51AA/AT

HP Z Turbo Drive 1TB MLC Z8G4 SSDModule

1PD52AA/AT

HP Z Turbo Drive 256GB TLC Z8G4 SSDModule

1PD53AA

HP Z Turbo Drive 512GB TLC Z8G4 SSDModule

1PD54AA/AT

HP Z Turbo Drive 1TB TLC Z8G4 SSDModule

1PD55AA

HP Z Turbo Drive 256GB SED Z8G4 SSDModule

2SA34AA

HP Z Turbo Drive 512GB SED Z8G4 SSDModule

2SA36AA

HP Z Turbo Drive 256GB MLC Z8 G4 SSD Kit

1PD44AA

HP Z Turbo Drive 512GB MLC Z8 G4 SSD Kit

1PD45AA/AT

HP Z Turbo Drive 1TB MLC Z8 G4 SSD Kit

1PD46AA

HP Z Turbo Drive 256GB TLC Z8 G4 SSD Kit

1PD47AA

HP Z Turbo Drive 512GB TLC Z8 G4 SSD Kit

1PD48AA/AT

HP Z Turbo Drive 1TB TLC Z8 G4 SSD Kit

1PD49AA

HP Z Turbo Drive 256GB SED Z8 G4 SSD Kit

2SA33AA

HP Z Turbo Drive 512GB SED Z8 G4 SSD Kit

2SA35AA

HP Z Turbo Drive Quad Pro

HP Z Turbo Drive Quad Pro 2x256GB PCIe SSD

N2M98AA

HP Z Turbo Drive Quad Pro 2x512GB PCIe SSD

N2M99AA

HP Z Turbo Drive Quad Pro 2x1TB PCIe SSD

T9H99AA

HP Z Turbo Drive Quad Pro 256GB SSD module

N2N00AA

HP Z Turbo Drive Quad Pro 512GB SSD module

N2N01AA

HP Z Turbo Drive Quad Pro 1TB SSD module

T9J00AA

Otros manuales para Z8 G4

Otros manuales de De oficina de HP

HP Series 37 Manual de usuario

HP Pavilion t400 - Desktop PC Manual de usuario

HP Pavilion t600 - Desktop PC Manual de usuario

HP 280 G2 Small Form Factor Business Instrucciones de montaje

HP A320m - Pavilion - 256 MB RAM Instrucciones de instalación

HP Pavilion a6000 Manual de usuario

HP Pavilion t600 - Desktop PC Manual de usuario

HP ZX2000 Manual

HP Vectra VE 5/xx Series Manual de usuario

HP TouchSmart IQ800 - Desktop PC Manual de usuario

HP Compaq Presario Manual de usuario

HP ZX2000 Manual de usuario

HP Zhan 86 Pro G1 Instrucciones de instalación

HP Compaq Presario Manual de usuario

HP dx2358 - Microtower PC Manual de usuario

HP VECTRA XW Manual de usuario

HP Pavilion 200-5020 Manual de usuario

HP Pavilion t400 - Desktop PC Instrucciones de instalación

HP A320m - Pavilion - 256 MB RAM Manual de usuario

HP TouchSmart IQ700 - Desktop PC Instrucciones de funcionamiento

HP Kayak XU800 Series Cómo utilizar

HP dx7400 - Microtower PC Manual de usuario

HP ProDesk 400 G6 MT Instrucciones de montaje

HP ZX2000 Manual de instrucciones

Manuales populares de De oficina de otras marcas

Asus

Asus E210 Series Manual de usuario

Dell

Dell Inspiron 600m Manual de usuario

Dell

Dell Inspiron 3662 Manual de usuario

TotalFlow

TotalFlow uFLO Manual de usuario

Logitech

Logitech MK320 Manual de usuario

Dell

Dell XPS 730 H2C Manual de usuario

Sony

Sony Vaio Series Manual de usuario

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manual de usuario

Alto

Alto MD 250 Manual de usuario

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series Manual de usuario

Sony

Sony VAIO VGX-TP1 Series Manual de usuario

Asus

Asus Eee Box B204 Manual de usuario

Dell

Dell Optiplex 9010 All In One Manual de usuario

Everex

Everex eXplora Manual de usuario

Lenovo

Lenovo ThinkCentre M75e Manual de usuario

Dell

Dell Alienware Area-51 R4 Manual de usuario
