Using Headphones

You must change audio settings to

hear sound through the headphone

connector on the front of the

DVD/CD-RW drive, and in some

software programs you must also

change audio settings.

You can’t use the headphone

connector to listen to digital

soundtracks of video files, such as

those in a DVD-ROM movie. The

headphone connector produces

sound only for audio files (music

CDs, .wav, mp3, and .cda files).

Changing audio settings

1 Click Start on the taskbar.

2 Click My Computer.

3 Right-click the DVD/CD-RW

drive icon.

4 Click Properties.

5 Select the Hardware tab.

6 Under All disk drives, select the

DVD/CD-RW drive icon, and

then click the Properties

button.

7 Click the Properties tab and

uncheck Enable digital CD

audio for this CD-ROM

device.

8 Click OK twice.

9 Restart the PC.

10 Continue with the instructions

provided for your specific

software.

Using headphones with

MusicMatch Jukebox

After you complete the previous

procedure, you can use the

headphone connector to listen to

audio files using the MusicMatch

Jukebox program.

Note: MusicMatch Jukebox may not be

included with your PC model,

depending on your

country/region.

Using headphones with

Windows MediaPlayer

1 Follow the procedure in the

section, “Changing audio

settings.”

2 Click Start on the taskbar.

3 Choose All Programs, and

then click Windows Media

Player.

Filename: c3adhpj.doc Title: Addendum [3-column 1 or 2 pages]

Template: HP-Print2K.dot Author: JimL Last Saved By: JimL

Revision #: 9 Page: 2 of 2 Printed: 11/06/02 01:03 PM

4 Place the cursor over the toolbar

just past the top of the Media

Player window until the menu

bar appears.

5 Click Tools, and then click

Options.

6 Select the Devices tab.

7 Select DVD/CD-RW Drive,

and then click the Properties

button.

8 Under Playback, select

Analog.

9 Click OK twice.

10 Restart the PC.

Using headphones

with RealOne Player

1 Follow the procedure in the

section, “Changing audio

settings.”

2 Click Start on the taskbar.

3 Choose All Programs, Real,

RealOne Player, and then

click RealOne Player.

4 Click the Tools menu, and then

click Preferences.

5 Click the +next to the CD or

DVD category to expand the list.

6 Select Advanced CD.

7 In the Advanced CD window,

select Analog.

8 Click OK, and then close the

RealOne window.

9 Restart the PC.

Note: RealOne Player may not be

included with your PC model,

depending on your

country/region.

Controlling

headphone volume

Volume for the PC and the

headphones are controlled

separately.

■ Control the headphone volume

by using the volume wheel next

to the headphone connector.

■ Control the PC

speaker volume by

clicking the volume

icon on the taskbar

and then adjusting the slider bar

or by using the volume controls

on the keyboard.
