Processor(s)

Four full-length PCI

Three 5.25" Optical drive bays

Two half-length PCI

On/Off Button

2-Way Motherboard

Hard disk drives

Power supply

One full-length AGP 8x Slot

10.

Memory DIMMs

At A Glance

Up to two HP PA-8900 dual core processor modules (2-way standard; 4-way optional)

2 or 4-way 1.0 GHz PA-8900 with 3.0 MB L1 cache (1.5MB per core)

2 or 4-way 1.0 GHz PA-8900 with 3.0 MB L1 cache (1.5 MB per core) and 64 MB shared L2 cache

2 or 4-way 1.1 GHz PA-8900 with 3.0 MB L1 cache (1.5 MB per core) and 64 MB L2 cache

HP zx1 chipset with 400 MHz system bus

6.4 GB/s effective processor bandwidth

8.6 GB/s memory bandwidth

3.5 GB/s I/O bandwidth

80 ns memory access latency

Enterprise-class operating systems: HP-UX 11i v1

ECC PC2100 DDR-266 memory, expandable to 32 GB

Four Internal 3 1/2 inch drive bays; up to 1.2TB of SCSI or 160GB IDE hard drive storage

Integrated 10/100/1000 Mbps Base-T Ethernet

AGP 8X Pro 150 watts max power graphics interface

Six PCI slots*

Three external bays 5 1/4 inch drive bays

DVD-ROM, DVDRW or CD-RW Optical Drive

Full Independent Software Vendor (ISV) certification and support for leading technical applications

Protected by HP Services, including a one-year limited warranty. Certain restrictions and exclusions apply.

NOTE:

Accessory card slots have various configurations. See details in "Standard Features" area.

QuickSpecs

HP c8000 Workstation

Overview

DA - 12134 North America — Version 12 — May 25, 2007

Page 1

Processor

Up to two 2-way (dual core) HP PA-8900 processor modules (1.0 or 1.1 Ghz)

Operating System

HP-UX 11i version 1 TCOE (Technical Computing Operating Environment)

HP-UX 11i version 1 MTOE (Minimal Technical Operating Environment)

Cache Memory

3.0 MB L1 on-chip cache (1.5 MB per processor core)

PA-8900 – 64 MB L2 cache (optional shared)

Memory

Maximum of 32 GB ECC PC2100 DDR-266 memory (8 DIMMs)

Network Controller

Integrated 10/100/1000 Mbps Base-T Ethernet

Removable Storage

48X/32X/48X CD-RW Drive

16X/48X DVD-ROM with +R and –R Read

16X DVD+RW Drive

Expansion Slots

I/O (Total)

Seven available slots

PCI – 32-bit/33 MHz

2 half-length 3.3V 32-bit/33 MHz PCI

PCI – 64-bit/33 MHz

1 full-length 3.3V 64-bit/33 MHz PCI

PCI – 64-bit/66 MHz

2 full-length 3.3V 64-bit/66 MHz PCI-X

PCI – 64-bit/133 MHz

1 full-length 3.3V 64-bit/133 MHz PCI-X

AGP 8X Pro

1 slot – 150W

Expansion Bays

(Total/Available)

7 total/7 available

Internal

Four 3.5-inch bays

External

Three accessible 5.25-inch bays

Storage

Removable Media

DVD-ROM, DVD+RW, or CD-RW Drive

Hard Drive

80 GB Ultra/ATA100 IDE Drive (7200 rpm)

73, 146 or 300 GB Ultra320 SCSI (10K rpm)

73 GB Ultra 320 SCSI (15K rpm)

Drive Controller(s)

Integrated Ultra320 SCSI controller

Integrated Ultra/ATA100 IDE controller

QuickSpecs

HP c8000 Workstation

Standard Features

DA - 12134 North America — Version 12 — May 25, 2007

Page 2

Interfaces

USB 1.1

Five (2 front, 3 rear)

Serial

Two 9-pin DIN connectors (rear)

Ultra320 SCSI

Internal and optional external (rear) connector

Network interface

One RJ-45 connector (rear)

Microphone Jack

1 (optional audio card)

Line-In Jack

1 (optional audio card)

Line-Out Jack

1 (optional audio card)

Graphics

–

One of the following

ATI FireGL T2-128 (dual display)

ATI FireGL X3-256 (dual display)

Audio

16-bit stereo full-duplex – uses half-length slot (optional card)

Input Devices

HP 104/105 key keyboard, available in 21 localized layouts

HP three-button optical mouse

HP three-button optical scroll mouse

HP SpaceBall 3D Input Device

HP SpaceMouse 3D Input Device

HP SpacePilot 3D Input Device

Power Supply

650W maximum output

Service and Support

Standard limited warranty: 1-year, next business day, onsite

Hardware support upgrades available: 3 Years Next Business Day Onsite, 3 Years Same

Business Day Onsite, and 3 Years 24 x7 Onsite.

NOTE:

Certain restrictions and exclusions apply. Consult the customer support center for details.

QuickSpecs

HP c8000 Workstation

Standard Features

DA - 12134 North America — Version 12 — May 25, 2007

Page 3

When buying a basic system, you have many configuration options. Base System includes Ultra320 SCSI, 10/100/1000BT

LAN, 2 serial, 5 USB, 1 AGP-8X slot, 3 PCI slots, 3 PCI-X slots, and all required power cords. Base system does not include

processor, RAM, disks or graphics.

HP c8000 Workstation

base system Processor

2-way 1.0 GHz PA-8900 with 3 MB L1 cache (1.5 MB per processor core)

2-way 1.0 GHz PA-8900 with 3 MB L1 cache and 64 MB L2 cache

2-way 1.1 GHz PA-8900 with 3 MB L1 cache and 64 MB L2 cache

Second Processor

2-way 1.0 GHz PA-8900 with 3 MB L1 cache and 64 MB L2 cache

2-way 1.1 GHz PA-8900 with 3 MB L1 cache and 64 MB L2 cache

Operating System

HP-UX 11i version 1 TCOE (Technical Computing Operating Environment)

HP-UX 11i version 1 MTOE (Minimum Technical Operating Environment)

Graphics Card

ATI FireGL T2-128 (128MB, dual display, AGP 8X)

ATI FireGL X3-256 (256 MB, dual display, AGP 8X)

Memory

1 GB PC2100 DDR-266 SDRAM memory kit (2x512MB DIMMs)

2 GB PC2100 DDR-266 SDRAM memory kit (2x1GB DIMMs)

4 GB PC2100 DDR-266 SDRAM memory kit (2x2GB DIMMs)

8 GB PC2100 DDR-266 SDRAM memory kit (2x4GB DIMMs)

Monitors

HP L1955 19-inch TFT Flat Panel Display - Analog/Digital

HP LP2065 20-inch TFT Flat Panel Display - Analog/Digital

HP LP2465 24-inch TFT Widescreen Flat Panel Display (1920x1200 resolution)

Internal hard disks

(minimum 1)

Ultra320 SCSI Drives

(max. 4)

73 GB Ultra320 SCSI 10,000 rpm

146 GB Ultra320 SCSI 10,000 rpm

300 GB Ultra320 SCSI 10,000 rpm

73 GB Ultra320 SCSI 15,000 rpm

UltraATA IDE Drives

(max. 2)

80 GB Ultra/ATA100 IDE Drive (7200 rpm)

Storage Controllers

External Ultra320 SCSI Connector Option

Ultra320 SCSI Adapter for HP-UX, 2-channel

Fibre Channel Adapter, 2GB, for HP-UX

QuickSpecs

HP c8000 Workstation

Configure-to-order Options (custom configurations)

DA - 12134 North America — Version 12 — May 25, 2007

Page 4

Optical Drive

16X DVD-ROM Drive

16X DVDRW Drive

48X CD-RW Drive

Rack and Tower

Options

(must order 1)

Workstation Rack Kit

Workstation Tower Kit

QuickSpecs

HP c8000 Workstation

Configure-to-order Options (custom configurations)

DA - 12134 North America — Version 12 — May 25, 2007

Page 5

Operating Systems

HP-UX 11i version 1 TCOE (Technical Computing Operating Environment)

B6821AA

HP-UX 11i version 1 MTOE (Minimal Technical Operating Environment)

B6845AA

2nd Processor

2-way 1.0 GHz PA-8900 with 3 MB L1 cache and 64 MB L2 cache

AB675A

2-way 1.1 GHz PA-8900 with 3 MB L1 cache and 64 MB L2 cache

AB676A

NOTE:

The second processor must be the same as the first.

Memory

(DDR-SDRAM)

1 GB (2 x 512 MB) PC2100 DDR SDRAM Upgrade Kit

A8087B

2 GB (2 x 1 GB) PC2100 DDR SDRAM Upgrade Kit

A8088B

4 GB (2 x 2 GB) PC2100 DDR SDRAM Upgrade Kit

A8089B

8 GB (2 x 4 GB) PC2100 DDR SDRAM Upgrade Kit

AB662A

NOTE:

Memory sold in pairs.

Graphics

ATI FireGL T2-128 (128 MB, dual display, AGP 8X)

AB638A

ATI FireGL X3-256 (256 MB, dual display, AGP 8X)

AB668A

Optical Drives

48X CD-RW Drive

A8683B

16X DVD-ROM Drive

A8682B

16X DVDRW Drive

AB615A

Hard Drives

Ultra320 SCSI Drives

(max. 4)

73 GB Ultra320 SCSI 10,000 rpm

AB628A

146 GB Ultra320 SCSI 10,000 rpm

AA614A

300 GB Ultra320 SCSI 10,000 rpm

AB663A

73 GB Ultra320 SCSI 15,000 rpm

A7214B

UltraATA IDE Drives

(max. 2)

80 GB Ultra/ATA100 IDE Drive (7200 rpm)

AB680A

Conversion Kit

SCSI Cable Conversion Kit; IDE to SCSI

AB640A

IDE Cable Conversion Kit; SCSI to IDE

AB641A

Storage Controllers

Ultra320 SCSI Adapter for HP-UX, 2-channel

A7173A

PCI 2GB Fibre Channel Adapter

A6795A

External SCSI Cable Connector

(enables 68-pin high density SCSI connector on rear panel of workstation)

AB642A

QuickSpecs

HP c8000 Workstation

After-Market Options/Standalone Accessories

DA - 12134 North America — Version 12 — May 25, 2007

Page 6

Backup Devices

HP DAT40i Internal DDS4 tape drive

C5686B

HP DAT40e External DDS4 tape drive

C5687C

HP DAT72i Internal DAT72 tape drive

Q1522A

HP DAT72e External DAT72 tape drive

Q1523A

HP Ultrium 232 Tape Drive Internal

DW064A

HP Ultrium 232 Tape Drive External

DW065A

Communications

1000BaseTX PCI LAN Adapter for HP-UX (Available 0D1 only. For field add-

on/standalone, use A6825A)

A6825A

1000BaseSX (Fibre) PCI LAN Adapter for HP-UX

A6847A

PCIX 4-Port 1000 Base-TX LAN Adapter

AB545A

PCI 2GB Fiber Channel Adapter

A6795A

8-Port Serial MUX Adapter

A6748A

2-Port Serial Adapter

AD278A

Software Applications

and Compilers

HP C++/ANSI C Developers Bundle

B9007AA

Rack Options

c8000 Tower to Rack Conversion Kit

AB626A

c8000 Rack to Tower Conversion Kit

AB625A

Input Devices

Keyboard Kit, USB, PC-104/105, Carbon black

– Includes USB keyboard and 3-button mouse. Must choose localization option

A4983D

USB scroll mouse

064

Delete keyboard

053

Spaceball 5000, Serial Interface

AB602A

SpaceMouse, Serial Interface

AB677A

HP SpacePilot USB 3D Input Device

AB681A

Other

System C13 power cord only

A4199A

System C13 and monitor C13 power cords

A4199B

Remote Workstation Receiver Software Module

DM498A

QuickSpecs

HP c8000 Workstation

After-Market Options/Standalone Accessories

DA - 12134 North America — Version 12 — May 25, 2007

Page 7

Monitors

HP L1955 19-inch TFT Flat Panel Display - Analog/Digital

PD974A5

(Americas)

HP LP2065 20-inch TFT Flat Panel Display - Analog/Digital

EF227A5

(Americas)

EF227A4

(EMEA, APJ)

HP LP2465 24-inch TFT Widescreen Flat Panel Display

EF224A5

(Americas)

EF224A4

(EMEA, APJ)

NOTE: AssetControl

features are accessible with HP workstations featuring Intelligent

Manageability.

QuickSpecs

HP c8000 Workstation

After-Market Options/Standalone Accessories

DA - 12134 North America — Version 12 — May 25, 2007

Page 8

ECC Registered PC2100 DDR-266 memory

Memory must be installed in pairs of the same size. Memory upgrade kits come in pairs.

This chart does not represent all possible memory configurations. Peak bandwidth: up to 8.5 GB/s.

MINIMUM MEMORY

1 GB (2 x 512 MB)

MAXIMUM MEMORY

32 GB (8 x 4 GB)

Memory

Slot 0A

Slot 0B

Slot 1A

Slot 1B

Slot 2A

Slot 2B

Minimum

1 GB

512 MB 512 MB

Maximum

32 GB

4 GB 4 GB 4 GB 4 GB 4 GB 4 GB

Memory

Slot 3A

Slot 3B

Minimum

1 GB

Maximum

32 GB

4 GB 4 GB

QuickSpecs

HP c8000 Workstation

Memory

DA - 12134 North America — Version 12 — May 25, 2007

Page 9

Drive Bay Locations

Drive Support

Quantity Supported

Position Supported

Controller

Optical Drives

DVD-ROM Drive

Up to 2

1, 2, 3

Integrated EIDE

CD-RW Drive

Up to 2

1, 2, 3

Integrated EIDE

DVDRW Drive

Up to 1

1, 2, 3

Integrated EIDE

Maximum 3 Optical Drives supported.

Hard Drives

Ultra320 SCSI Drives

1-inch

Up to 4

4, 5, 6, 7

68-pin interface connector

plus four-pin standard power

connector

73 GB Ultra320 SCSI (10K

rpm)

146 GB Ultra320 SCSI (10K

rpm)

300 GB Ultra320 SCSI (10K

rpm)

73 GB Ultra320 SCSI (15K

rpm)

UltraATA IDE Drives

Up to 2

4, 5, 6, 7

NOTE:

This configuration

reduces the number of optical

drives supported to a

maximum of two.

80 GB Ultra/ATA100 IDE

Drive (7200 rpm)

Maximum Storage

Capacity

1.2 TB (SCSI)

160 GB (IDE)

QuickSpecs

HP c8000 Workstation

Storage

DA - 12134 North America — Version 12 — May 25, 2007

Page 10

Otros manuales para C8000 - Workstation - 0 MB RAM

Tabla de contenidos

Otros manuales de De oficina de HP

HP 280 G4 Manual

HP dx7300 - Microtower PC Manual de uso y cuidado

HP Pavilion t134 Manual de usuario

HP Z800 - Workstation - 6 GB RAM Manual de usuario

HP TouchSmart 600-1000 - Desktop PC Manual de usuario

HP Compaq Presario Hoja de especificaciones

HP Vectra VLi 8 Manual de usuario

HP Net PC 20 Instrucciones de uso

HP Vectra VL5 5 Manual de usuario

HP SR5605F - Compaq Presario - 1 GB RAM Manual de uso y mantenimiento

HP Pro 3010 - Microtower PC Guía de configuración

HP Pro 1005 Manual de usuario

HP vectra vl420 Manual de usuario

HP Pavilion Elite m9400 - Desktop PC Instrucciones de instalación

HP 742n - Pavilion - 512 MB RAM Manual de usuario

HP Pro 3000 MT Manual de operación y mantenimiento

HP ProLiant xw2x220c - Blade Workstation Manual de servicio

HP Pavilion w5500 - Desktop PC Manual de usuario

HP 300-1020 - TouchSmart - Desktop PC Manual de usuario

HP TouchSmart Series Instrucciones de instalación

HP Compaq Presario Manual de usuario

HP 268 Pro G1 MT Manual

HP s5120f - Pavilion - Slimline Manual de instrucciones

HP Pavilion u700 - Desktop PC Manual de usuario

Manuales populares de De oficina de otras marcas

Asus

Asus E210 Series Manual de usuario

Dell

Dell Inspiron 600m Manual de usuario

Dell

Dell Inspiron 3662 Manual de usuario

TotalFlow

TotalFlow uFLO Manual de usuario

Logitech

Logitech MK320 Manual de usuario

Dell

Dell XPS 730 H2C Manual de usuario

Sony

Sony Vaio Series Manual de usuario

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manual de usuario

Alto

Alto MD 250 Manual de usuario

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series Manual de usuario

Sony

Sony VAIO VGX-TP1 Series Manual de usuario

Asus

Asus Eee Box B204 Manual de usuario

Dell

Dell Optiplex 9010 All In One Manual de usuario

Everex

Everex eXplora Manual de usuario

Lenovo

Lenovo ThinkCentre M75e Manual de usuario

Dell

Dell Alienware Area-51 R4 Manual de usuario
