HP NC370F Manual de usuario

HP NC370F PCI-X Multifunction Gigabit

Server Adapter User Guide

June 2007 (Third Edition)

Part Number 389196-00C

The information contained herein is subject to change without notice. The only warranties for HP products and

services are set forth in the express warranty statements accompanying such products and services. Nothing herein

should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors

or omissions contained herein.

Microsoft, Windows, and Windows NT are U.S. registered trademarks of Microsoft Corporation. Intel, Pentium,

and Itanium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States

and other countries. UNIX is a registered trademark of The Open Group. Linux is a U.S. registered trademark of

Linus Torvalds.

HP NC370F PCI-X Multifunction Gigabit Server Adapter

June 2007 (Third Edition)

Part Number 389196-00C

HP NC370F PCI-X Multifunction Gigabit Server Adapter iii

Contents

About this guide

Technician notes............................................................................................................................................v

Where to go for additional help....................................................................................................................vi

Telephone numbers................................................................................................................................vi

Chapter 1

Introduction

Overview ................................................................................................................................................... 1-1

LED indicator............................................................................................................................................ 1-2

Chapter 2

Installing the adapter

Overview ................................................................................................................................................... 2-1

Electrostatic discharge precautions ........................................................................................................... 2-1

Installing the adapter in a server................................................................................................................ 2-2

Connecting the network cable ................................................................................................................... 2-2

Appendix A

Regulatory compliance notices

Regulatory model number........................................................................................................................ A-1

European Union regulatory notice............................................................................................................ A-1

Korean notice ........................................................................................................................................... A-2

Class B equipment ............................................................................................................................. A-2

BSMI notice ............................................................................................................................................. A-2

Laser compliance...................................................................................................................................... A-2

Appendix B

Electrostatic discharge

Overview ...................................................................................................................................................B-1

Grounding methods ...................................................................................................................................B-1

Appendix C

Specifications

HP NC370F PCI-X Multifunction Gigabit Server Adapter specifications ...............................................C-1

HP NC370F PCI-X Multifunction Gigabit Server Adapter v

About this guide

Use this guide for reference when installing the HP NC370F PCI-X Multifunction Gigabit

Server Adapter.

WARNING: To reduce the risk of personal injury from electric shock and hazardous

energy levels, only authorized service technicians should attempt to repair this

equipment. Improper repairs can create conditions that are hazardous.

Technician notes

WARNING: Only authorized technicians trained by HP should attempt to repair this

equipment. All troubleshooting and repair procedures are detailed to allow only

subassembly/module-level repair. Because of the complexity of the individual boards

and subassemblies, no one should attempt to make repairs at the component level or

to make modifications to any printed wiring board. Improper repairs can create a safety

hazard.

WARNING: To reduce the risk of personal injury from electric shock and hazardous

energy levels, do not exceed the level of repairs specified in these procedures.

Because of the complexity of the individual boards and subassemblies, do not attempt

to make repairs at the component level or to make modifications to any printed wiring

board. Improper repairs can create conditions that are hazardous.

CAUTION: To properly ventilate the system, you must provide at least 7.6 cm (3.0 in.) of

clearance at the front and back of the server.

CAUTION: The computer is designed to be electrically grounded (earthed). To ensure proper

operation, plug the AC power cord into a properly grounded AC outlet only.

NOTE: Any indications of component replacement or printed wiring board modifications may void any

warranty.

About This Guide

vi HP NC370F PCI-X Multifunction Gigabit Server Adapter

Where to go for additional help

HP updates networking software frequently to include new functionality and features.

Complete the following steps to get the latest drivers, firmware, and documentation.

1. Go to the HP website (http://www.hp.com).

2. Click Support and Troubleshooting Information from the left menu bar.

3. Type the product name in the for product box and press Enter. For example, type

NC370T.

4. Download the drivers, firmware, or documentation as needed.

HP contact information

For the name of the nearest HP authorized reseller:

•In the United States, refer to the HP US service locator webpage

(http://www.hp.com/service_locator).

•In other locations, refer to the HP website (http://www.hp.com).

For HP technical support:

•In North America:

•Call 1-800-HP-INVENT (1-800-474-6836). This service is available 24 hours a day, 7 days

a week. For continuous quality improvement, calls may be recorded or monitored.

•If you have purchased a Care Pack (service upgrade), call 1-800-633-3600. For more

information about Care Packs, refer to the HP website (http://www.hp.com).

•Outside North America, call the nearest HP Technical Support Phone Center. For telephone

numbers for worldwide Technical Support Centers, refer to the HP website

(http://www.hp.com).

HP NC370F PCI-X Multifunction Gigabit Server Adapter User Guide 1-1

Introduction

Overview

The HP NC370F PCI-X Multifunction Gigabit Server Adapter is a high-performance, stand-

alone Ethernet adapter with a controller chip that delivers 1000 Mb/s Ethernet over fiber

cabling. For best performance, install the adapter in a 64-bit/133MHz, PCI-X slot. The

adapter provides failover capabilities with other Gigabit and 10/100 adapters installed in the

workstation or server.

The HP NC370F PCI-X Multifunction Gigabit Server Adapter supports current standards for

IEEE 802.3z 1000 Base-SX and PCI specifications (PCI bus specification 2z and PCI-X

specification 1.0a). Manageability support is provided by ASF 1.0 using systems with SM

Bus 2.0 interfaces.

The HP NC370F PCI-X Multifunction Gigabit Server Adapter is a supported option for

selected HP ProLiant servers. In addition to features that have shipped with other server

adapters, the NC370F adapter also supports Receive Side Scaling, TCP/IP Offload Engine

(TOE), iSCSI, and Remote Direct Memory Access (RDMA). For details about each of these

advanced features and for other information regarding the latest functionality, features, and

operating system support for this server adapter, refer to the networking page at

(http://h18004.www1.hp.com/products/servers/networking/index-nic.html).

Introduction

1-2 HP NC370F PCI-X Multifunction Gigabit Server Adapter User Guide

LED indicator

The adapter has a single fiber LC port and LED indicator for activity/link.

Figure 1-1: NC370F PCI-X Multifunction Gigabit Server Adapter

The HP NC370F PCI-X Multifunction Gigabit Server Adapter LED indicator operates as

described in the following table.

Table 1-1: LED operation for the HP NC370F PCI-X Multifunction Gigabit Server

Adapter

LED Status Description

Off No link to the adapter is established. The adapter is not

receiving power or the cable connection is not established.

On When green, link to the adapter is established. The adapter is

receiving power and the cable connection is secure.

LNK/ACT

Flashing The adapter is receiving direct packets or broadcast packets for

this specific adapter. When sending packets, the LNK/ACT light

is also flashing due to network acknowledgements received.

HP NC370F PCI-X Multifunction Gigabit Server Adapter User Guide

2-1

Installing the adapter

Overview

This chapter describes installation precautions, how to install the adapter, and how to attach

the fiber network cable.

WARNING: To avoid the risk of personal injury or damage to the equipment, consult

the safety information and user documentation provided with the equipment before

attempting installation of the adapter.

Many servers are capable of producing energy levels that are considered hazardous.

Users should not remove enclosures, nor should they bypass the interlocks provided

for removal of these hazardous conditions.

Installation of this adapter should be performed by individuals who are both qualified in

the servicing of computer equipment, and trained in the hazards associated with

products capable of producing hazardous energy levels.

This server adapter is intended for use with UL Listed ITE equipment having

instructions on adding and removing components such as PCI and PCI-X devices.

NOTE: Before removing the cover of the server, refer to the HP documentation for the proper methods

for installing a PCI card and avoiding electric shock hazards.

Electrostatic discharge precautions

A discharge of static electricity from a finger or other conductor can damage components on

the adapter. This can make the adapter inoperable. In addition to the following information,

refer to Appendix B for more precautions.

To prevent electrostatic damage, observe the following precautions:

•Always properly ground yourself when touching a static-sensitive component or

assembly.

•Avoid hand contact by transporting and storing parts in static-safe containers.

•Keep electrostatic-sensitive parts in their containers until they arrive at static-free

locations.

•Place containers on a grounded surface before removing the contents.

•Avoid touching pins, leads, or circuitry.

Installing the adapter

2-2 HP NC370F PCI-X Multifunction Gigabit Server Adapter User Guide

Installing the adapter in a server

Refer to the HP ProLiant server documentation for additional information on how to safely

install a PCI card in the server.

WARNING: If the server is not PCI Hot Plug compliant, power it down and unplug the

power cord from the power outlet before removing the server cover. Failure to do so

may damage the adapter or server.

1. Remove the power cord and server cover. Then remove the expansion slot cover from a

PCI/PCI-X slot.

WARNING: To reduce the risk of personal injury from hot surfaces, allow the internal

system components to cool before touching them.

2. Firmly seat the adapter in the PCI/PCI-X slot and secure the expansion slot cover.

Figure 2-1: Installing the adapter in a server

3. Replace the server cover and plug in the power cord.

Connecting the network cable

The HP NC370F PCI-X Multifunction Gigabit Server Adapter uses an LC fiber port. This

port supports multimode fiber with a maximum cable length dependent on the fiber type,

mode, and cable size. Refer to Appendix C for the maximum cable length.

To insert the LC connector into the adapter port, line up the slot on the fiber connector with

the adapter and gently push until the retainers click into place.

Tabla de contenidos

Otros manuales de Adaptador de HP

HP FlexFabric 10Gb 2-port 533FLR-T Instrucciones de uso

HP 3COM Etherlink III 3C590 PCI 10BT Manual de usuario

HP NC552SFP Manual de usuario

HP StorageWorks XP10000 - Disk Array Manual de servicio

HP Q6274A Manual de instrucciones

HP Integrity BL860c Manual de instrucciones

HP 381513-B21 - Smart Array P800 Controller... Manual de usuario

HP VL600 - Vectra - 128 MB RAM Manual de usuario

HP 347786-B21 - 8 Internal Port SAS HBA Manual de usuario

HP NC550m Instrucciones de uso

HP Photosmart 7100 Manual de usuario

HP StorageWorks A7298A Manual de usuario

HP 530SFP+ Manual de usuario

HP Model 744 - VME Workstation Instrucciones de instalación y mantenimiento

HP NC364T Manual de usuario

HP D5970A - NetServer - LCII Manual de usuario

HP NC364m Instrucciones de uso

HP 70590A Manual

HP A6826A Manual de usuario

HP P3410A - NetRAID 1M RAID Controller Hoja de instrucciones

HP ScanJet 100 Manual de usuario

HP 90W Manual de usuario

HP AH226A - Smart Array E500/256MB Controller... Instrucciones de instalación

HP NC7771 Manual de usuario

Manuales populares de Adaptador de otras marcas

PCB Piezotronics

PCB Piezotronics 090B274 Manual de usuario

Auvidea

Auvidea J20 Manual del producto

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manual de usuario

Akribis

Akribis ITF-21-BISS-MIT Manual de usuario

Tenda

Tenda W54U Manual de usuario

ROHO

ROHO AGILITY Manual de usuario

PROLiNK

PROLiNK WN2001 Manual de usuario

Hawking

Hawking HUF2 Manual de usuario

Airlink101

Airlink101 AWLC4030 Manual de usuario

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manual de usuario

Philips

Philips SWA4554S/10 Manual de usuario

JVC

JVC TS-C9D2B Manual de instrucciones

NETGEAR

NETGEAR A6100 Manual de usuario

D-Link

D-Link DWA-121 Manual de usuario

Philips

Philips SWA2037 Manual de usuario

Basalte

Basalte 0610-20 Manual de usuario

Yealink

Yealink EHS40 Manual de usuario

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manual de usuario
