HP Bt500 Manual de usuario
English 1
Welcome to the HP bt500
The HP bt500 Bluetooth USB 2.0 Wireless Printer Adapter
(HP bt500) uses Bluetooth wireless technology to connect
devices without needing a cable. The HP bt500 can be used
with both printers and Windows computers.
When attached to a Bluetooth-enabled printer, the
HP bt500 allows you to print to the printer from Bluetooth
devices, such as camera phones, PDAs, digital cameras, and
Bluetooth-enabled computers (Windows and Mac).
NOTE: Check the documentation for your printer to verify
the devices you can use to print to it.
TIP: Check www.hp.com/go/Bluetooth for valuable
information concerning your HP bt500.
When attached to a Windows computer, the HP bt500 allows
you to link many Bluetooth devices with your computer,
such as digital cameras, camera phones, headsets, printers,
PDAs and PIMs, and network access points.
Get more information
The CD contains a User Guide with
detailed information about conguring
and using your HP bt500, technical
specications, and regulatory
information.
•
•
English_Opal_Printer-4x6-standal1 1English Opal Printer-4x6-standal1 1 4/30/2007 12:18:55 PM4/30/2007 12:18:55 PM
2 HP Bluetooth USB 2.0 Wireless Adapter
Connect to a printer
Generally, the sending device (camera, PDA, computer, etc.)
sends a signal and discovers the nearby Bluetooth printing
devices and displays their Bluetooth device names. Then, you
simply print or send to that printer name.
Tip: The printer’s default Bluetooth device name can be
found in the printer’s Bluetooth menu or user guide.
For most devices, the default settings will allow you to print
without making any changes. However, a Bluetooth device
may be set to be visible or invisible and may have security
settings established. If you have diculty printing to your
printer, consult the user guide for your printer.
Installation and setup
Follow these instructions to install and set up your HP bt500
with a printer. More detailed setup instructions can be found in
the user guide for your printer.
Locate the host USB port on your printer or all-in-one. It
will usually be located in the front and is shaped like the
USB port on your computer. It may be called a camera or
Pictbridge port.
1.
English_Opal_Printer-4x6-standal2 2English Opal Printer-4x6-standal2 2 4/30/2007 12:19:13 PM4/30/2007 12:19:13 PM
English 3
Remove the cap from the HP bt500 and insert it in the port.
LED behavior
The LED on the HP bt500 provides information about its
current state.
On steady—This is the default state and means the device is
installed and has power.
Rapid blinking—A sending device is “Discovering” the
HP bt500.
Blinking—The HP bt500 is receiving data.
2.
English_Opal_Printer-4x6-standal3 3English Opal Printer-4x6-standal3 3 4/30/2007 12:19:13 PM4/30/2007 12:19:13 PM
4 HP Bluetooth USB 2.0 Wireless Adapter
Connect to a computer
To use your HP bt500 with a computer you must install and
congure the software. If you are familiar with Bluetooth
devices, follow these instructions for initial installation and
conguration. Detailed setup instructions are in the User Guide
on your CD.
Insert the CD.
The installation should start automatically. If it does not,
browse to your CD and double-click setup.exe.
Follow the instructions on the screen.
When you have installed the software, right-click on
the Bluetooth icon in the system tray and congure the
software.
Important: The User Guide on the CD contains detailed
information on installing the software and conguring your
HP bt500 with your computer and many Bluetooth devices.
1.
2.
3.
English_Opal_Printer-4x6-standal4 4English Opal Printer-4x6-standal4 4 4/30/2007 12:19:14 PM4/30/2007 12:19:14 PM
English 5
English_Opal_Printer-4x6-standal5 5English Opal Printer-4x6-standal5 5 4/30/2007 12:19:14 PM4/30/2007 12:19:14 PM
6 HP Bluetooth USB 2.0 Wireless Adapter
English_Opal_Printer-4x6-standal6 6English Opal Printer-4x6-standal6 6 4/30/2007 12:19:14 PM4/30/2007 12:19:14 PM
English 7
English_Opal_Printer-4x6-standal7 7English Opal Printer-4x6-standal7 7 4/30/2007 12:19:14 PM4/30/2007 12:19:14 PM
