Welcome!

Dear Customer,

Thank you for choosing the Hotpoint product. We want your product, manufactured with

high quality and technology, to offer you the best efficiency. Therefore, carefully read this

manual and any other documentation provided before using the product.

Keep in mind all the information and warnings stated in the user’s manual. This way, you

will protect yourself and your product against the dangers that may occur.

Keep the user’s manual. If you give the product to someone else, give the manual with it.

The warranty conditions, usage and troubleshooting methods for your product are

provided in this manual.

The symbols and their descriptions in the user’s manual:

Hazard that may result in death or injury.

Important information or useful usage tips.

Read the user’s manual.

Hot surface warning.

NOTICE Hazard that may result in material damage to the product or its environment.

EN / 3

Table of Contents

1 Safety Instructions........................ 4

1.1 General Safety ............................... 4

1.2 Electrical Safety............................. 5

1.3 Product Safety............................... 6

1.4 Intended Use.................................. 8

1.5 Child, Vulnerable Persons and

Pet Safety.......................................

1.6 Transportation Safety ................... 8

2 Environmental Instructions.......... 9

2.1 Waste Directive.............................. 9

2.1.1 Compliance with the WEEE Dir-

ective and Disposing of the

Waste Product ...........................

2.2 Package Information..................... 9

3 Your product ................................. 10

3.1 Product Introduction ..................... 10

3.2 Product Accessories..................... 10

3.3 Technical Specifications............... 12

4 Using the Hood ............................. 13

5 Maintenance and Cleaning .......... 16

5.1 General Cleaning Information....... 16

5.2 Aluminium Filter ............................ 16

5.3 Hood Lamp .................................... 17

5.4 Carbon Filter (Usage without a

flue) ................................................

6 Troubleshooting ........................... 17

EN / 4

1 Safety Instructions

• This section includes the

safety instructions necessary

to prevent the risk of personal

injury or material damage.

• If the product is handed over

to someone else for personal

use or second-hand use pur-

poses, the user’s manual,

product labels and other relev-

ant documents and parts

should also be given.

• Our company shall not be held

responsible for damages that

may occur if these instructions

are not observed.

• Failure to follow these instruc-

tions shall void any warranty.

• Always have the installation

and repair works made by the

manufacturer, the authorised

service or a person that the im-

porter company shall desig-

nate.

• Use original spare parts and

accessories only.

• Do not repair or replace any

component of the product un-

less it is clearly specified in the

user’s manual.

• Do not make technical modific-

ations on the product.

1.1 General Safety

• This product can be used by

children 8 years of age and

older, and people who are un-

derdeveloped in physical, sens-

ory or mental skills, or who

have lack of experience and

knowledge, as long as they are

supervised or trained about the

safe use and hazards of the

product. Children should not

play with the appliance. Clean-

ing and user maintenance

must not be made by children

without supervision.

•Poisoning Danger! While the

appliance is operating, air is

drawn from the whole house. If

adequate ventilation is not

provided, air flow occurs and

the waste and toxic gases re-

leased as a result of combus-

tion in the house are reab-

sorbed. Do not operate the

product together with products

that provide air circulation and

may emit toxic gas (wood, gas,

oil and coal stoves, boilers, wa-

ter heaters, etc.).

• Have the adequacy of your

building's ventilation and flue

system checked by authorized

persons.

EN / 5

• This product is not intended

for use by persons (including

children) with limited physical,

sensory or mental capacity or

without knowledge or experi-

ence, unless supervised or in-

structed by the individual re-

sponsible for their safety. Chil-

dren should be supervised to

ensure that they do not play

with the product. Cleaning and

user maintenance must not be

made by children without su-

pervision.

• Installation and repair proced-

ures must always be per-

formed by Authorised Service

Agents. The manufacturer can-

not be held responsible for any

damages that may arise due to

operations made by unauthor-

ized persons.

• Do not operate the product if it

is defective or has any visible

damage.

• Ensure that the product func-

tion knobs are switched off

after every use.

• If the product is handed over

to someone else for personal

use or second-hand use pur-

poses, the user’s manual,

product labels and other relev-

ant documents and parts

should also be given.

• Call the authorized service for

the installation of the product

to be used. The warranty term

starts after this process.

• Product must be installed by a

qualified person in accordance

with the regulations in force

for the warranty to be applic-

able.

1.2 Electrical Safety

• To have your product ready for

use, first provide the place of

installation and have the elec-

trical installation made. Then,

call the nearest Authorised

Service.

• If the product has a failure, it

should not be operated unless

it is repaired by an Authorised

Service Agent. There is the risk

of electric shock!

• Do not plug your hood in until it

is mounted.

• If your product has plug, never

touch the plug with wet hands!

Never unplug by pulling on the

cable, always pull out by hold-

ing the plug.

• The appliance power should be

cut off during installation,

maintenance, cleaning and re-

pair processes.

• In order to prevent any hazard

from occurring, in case of

damage, the electrical cable

must be replaced by the manu-

EN / 6

facturer, the manufacturer's

service centre or a similar

qualified person.

• If the cable is damaged, con-

tact our nearest service centre

and have a new one installed.

• If your product has plug, do not

make electrical connections by

disconnecting the plug during

installation. Connections made

by cutting off render the

product warranty void and

pose a danger to user safety.

• Do not install the mains cord

near the heaters. The cable

might melt, causing a fire.

• If your product does not have a

cable, only use the connecting

cable described in the "Tech-

nical specifications" section.

• Any work on electrical equip-

ment and systems should only

be carried out by authorised

and qualified persons.

• In case of any damage, switch

off the product and disconnect

it from the mains. To do this,

turn off the fuse at home.

• Make sure that fuse rating is

compatible with the product.

• Never wash the appliance by

spraying or pouring water on it!

There is the risk of electric

shock!

1.3 Product Safety

• Height between the bottom

surface of your hood and the

top surface of the oven should

be no less than 650 mm for

gas ovens and 500 mm for

electrical ovens.

• (For Model B-C) In electrical

ovens, the highest perform-

ance in the product is achieved

by leaving a height of 550 mm.

• Do not touch the lamps of your

hood after operating the hood

for a long time. Hot lamps may

burn your hand.

• Do not operate the appliance

without an oil entrapment fil-

ter. Do not remove the filters

while the appliance is operat-

ing.

• Do not create a high flame un-

der the product. Otherwise, the

oil in the oil trap filter may ig-

nite, causing a fire.

• Run the product after placing

the cooking pots, pans, etc. on

the ovens. Otherwise, rising

heat may deform some parts

of your product.

• Turn off the oven before taking

the cooking pots, pans, etc.

from the ovens.

• Do not keep easily flammable

materials under your hood.

EN / 7

• Do not expose the appliance to

open flame. It may cause the

oil accumulating in the filter to

catch fire. Do not operate the

appliance without a filter.

• Do not leave your cooker unat-

tended while cooking fried

foods, oils may catch fire while

cooking, and hot oil may cause

fire. Therefore pay attention to

the clothes and curtains.

• If cleaning is not performed in

a timely manner, the hood may

present a risk of fire.

• (For Models A and B) Run your

hood for another 15 minutes

after the cooking or frying pro-

cess to clean the kitchen air

thoroughly of the odours and

vapours generated during

cooking.

• Adequate ventilation must be

available in the room when gas

or other fuel-burning appli-

ances are used at the same

time while the oven hood with

a cooker is being used. (Not

applicable for only the appli-

ances that discharge air back

into the room).

• Gas or fuel oil burning appli-

ances, such as room heaters,

which share the same environ-

ment with the hood, must be

fully insulated from the ex-

haust of this product or they

must be hermetical.

• If there is another appliance

operating with fuel oil or

gaseous fuels in the environ-

ment, adequate ventilation of

the environment is required.

• If there is another appliance

operating with energy other

than electrical energy in the

same environment with the

hood, the negative pressure in

the room should be at most

0.04 mbar so that the exhaust

of the other appliance is not

drawn back into the room by

the hood.

• Do not connect to flues with

heating stove connection, flues

where waste gas is disposed

from or flues with rising

flames. Comply with local reg-

ulations on purging the out-

flow.

• Use pipes with a diameter of

120 mm when connecting a

flue to your product. The pipe

connection should be as short

as possible and with few

bends.

• Easily flammable and com-

bustible materials should not

be hung on the hood handles.

• Our company shall not be re-

sponsible for problems that

arise for not observing any of

the warnings above.

EN / 8

• There is a risk of fire if clean-

ing is not carried out in accord-

ance with the instructions.

• There should not be open fire

under the hood. (for example:

flambe)

•Caution: Accessible parts can

heat up when used with a

cooker.

• It is recommended to clean the

filter once a month under nor-

mal usage.

1.4 Intended Use

• This product is designed for

home use. Commercial use

will void the guarantee.

• The manufacturer assumes no

responsibility for any damage

due to misuse or mishandling.

• The service life of the product

you have purchased is 10

years. Manufacturer shall

provide the required spare

parts for the product to per-

form as defined during this

period.

1.5 Child, Vulnerable

Persons and Pet Safety

• Keep children away from the

product when it is running.

• Children should not play with

the product. Cleaning and user

maintenance should not be

performed by children unless

there is someone overseeing

them.

• This product should not be

used by people with limited

physical, sensory or mental ca-

pacity (including children), un-

less they are kept under super-

vision or receive the necessary

instructions.

• The packaging materials are

dangerous for children. Keep

the packaging materials out of

the reach of children or sort

them into waste according to

waste instructions.

• Electrical products are danger-

ous for children and pets. Keep

children away from the

product while it is operated

and do not let them play with

the product.

1.6 Transportation

Safety

• Disconnect the product from

the mains before transporting

the product.

• Do not put other items on the

product and carry the product

upright.

• When you need to transport

the product, wrap it with

bubble wrap packaging mater-

ial or thick cardboard and tape

it tightly. Secure the product

EN / 9

tightly with tape to prevent the

removable or moving parts of

the product and the product

from getting damaged.

• Check the overall appearance

of the product for any damage

that may have occurred during

transportation.

2 Environmental Instructions

2.1 Waste Directive

2.1.1 Compliance with the WEEE Dir-

ective and Disposing of the

Waste Product

This product complies with EU WEEE Dir-

ective (2012/19/EU). This product bears a

classification symbol for waste electrical

and electronic equipment (WEEE).

This product has been manu-

factured with high quality parts

and materials which can be re-

used and are suitable for recyc-

ling. Therefore, do not dispose

of the waste product with nor-

mal domestic and other wastes at the end

of its service life. Take it to a collection

point for the recycling of electrical and elec-

tronic equipment. You can ask your local

administration about these collection

points. Disposing of the appliance properly

helps prevent negative consequences for

the environment and human health.

Compliance with RoHS Directive:

The product you have purchased complies

with EU RoHS Directive (2011/65/EU). It

does not contain harmful and prohibited

materials specified in the Directive.

2.2 Package Information

Packaging materials of the product are

manufactured from recyclable materials in

accordance with our National Environment

Regulations. Do not dispose of the pack-

aging waste with the household or other

wastes, take it to the packaging material

collection points designated by the local

authorities.

EN / 10

3 Your product

3.1 Product Introduction

1 Hood body 2 Hood glass lid

3 Damper 4 Aluminium filter

5 Lamp 6 Lamp

7 Aluminium filter lock 8 Control panel

* Dependent on the model. It may not be avail-

able on your product.

3.2 Product Accessories

Depending on the product model, the sup-

plied accessory varies. All accessories de-

scribed in the user’s manual may not be

available in your product.

Wall mounting part

Tabla de contenidos

Idiomas:

Otros manuales de Campana de ventilación de Hotpoint

Hotpoint

Hotpoint HTN41 Manual de usuario

Hotpoint

Hotpoint HX901X Manual de usuario

Hotpoint

Hotpoint HXC9.8AT Manual de usuario

Hotpoint

Hotpoint HPHV 62FLT BL Manual de usuario

Hotpoint

Hotpoint kitchen think HD70X Instructions for and... Manual de usuario

Hotpoint

Hotpoint LI2JDA Manual de usuario

Hotpoint

Hotpoint HHB6.7AD Manual de usuario

Hotpoint

Hotpoint PHBS9.8CLTDK Manual de usuario

Hotpoint

Hotpoint HE61 Manual de usuario

Hotpoint

Hotpoint HHC6.7AB Manual de usuario

Hotpoint

Hotpoint 4773326 Manual de usuario

Hotpoint

Hotpoint UIF 9.3F LB X Manual de usuario

Hotpoint

Hotpoint HD90X Manual de usuario

Hotpoint

Hotpoint HTS93G Manual de usuario

Hotpoint

Hotpoint HHC6.7AB Manual de usuario

Hotpoint

Hotpoint LI2SNA Manual de usuario

Hotpoint

Hotpoint HC9X Manual de usuario

Hotpoint

Hotpoint HXB9.8LTI Manual de usuario

Hotpoint

Hotpoint HTC95 Manual de instrucciones

Hotpoint

Hotpoint HNP 6.5 CM X/HA Manual de usuario

Hotpoint

Hotpoint HD 93 X Manual de usuario

Hotpoint

Hotpoint HS9EIX Manual de usuario

Hotpoint

Hotpoint HDI 93 X Manual de usuario

Hotpoint

Hotpoint RN328HSA Manual

Manuales populares de Campana de ventilación de otras marcas

emmeti

emmeti RECUPA MED A-140 Guía

Nibe

Nibe F135 Manual de usuario

Kuppersberg

Kuppersberg INTRO 60 Instrucciones de instalación y mantenimiento

Zephyr

Zephyr Spruce AK9834BS Guía de instalación

Hisense

Hisense MH6INBG Manual de usuario

Miele

Miele DA 1255 Manual de usuario

Broan

Broan 46000 Manual de usuario

GE Profile PV977 Instrucciones originales

FALMEC

FALMEC FFRIA24W5FS Manual de usuario

Whirlpool

Whirlpool RH2600XL-1 SERIES Manual de usuario

Küppersbusch

Küppersbusch DX ISLA Manual de usuario

ETNA

ETNA AV360RVS Manual de usuario

JUNO

JUNO JDF603E6 Manual de usuario

Miele

Miele DA 6708 D Manual de usuario

Tricity Bendix

Tricity Bendix LE 150 Manual

AEG

AEG X68163BV1 Manual de usuario

AEG

AEG 125 D Manual de usuario

Smeg

Smeg KSEV97X Manual de usuario
