Hotpoint HTM16BBR Manual de usuario

HTM16BBR – Hotpoint® 15.8 Cu. Ft. Top-Freezer Refrigerator

Specification Created 1/04

410444

R

Listed by

Underwriters

Laboratories

R

®

Overall

Dimensions

Height with hinge (in.) A 64-3/4

Height without hinge (in.) B64-1/4

Depth without doors (in.) C 25-7/8

Depth with doors (in.) D29-1/8

Depth plus handle with doors closed (in.) E31

Depth with doors open 90° (in.) F54-7/8

Width with doors closed (in.) G28

Width with door open 90° with door handle (in.) 30-1/2

Air

Clearances

Each side (in.) 3/4

Top (in.) 1

Back (in.) 1

Note: Before installing, consult installation instructions packed with

product for current dimensional data.

Total volume and shelf

area are calculated by

the Association of Home

Appliance Manufacturers’

standards.

Front View Top View

A

G

E

C

F

'94 TMNF Refer

B

D

H

Specification Created 1/04

410444

HTM16BBR – Hotpoint® 15.8 Cu. Ft. Top-Freezer Refrigerator

Features and Benefits

• Silver Metallic Exterior

• Upfront Temperature Controls – Are positioned up front, close at hand, for maximum convenience

and ease of use

• Adjustable Wire Shelves – Provide strong support and slide out with ease

• Vegetable/Fruit Crispers – For easy storage of your fruits and vegetables

• Tall bottle door storage – Is designed to hold upright bottles and containers

• NeverClean™ Condenser – Condenser coils are encased, so they don’t require cleaning in normal

operating environments

• Deluxe Quiet Design – Significantly reduces operating noise

• Model HTM16BBRSA – Silver metallic

®

HTM16BBR
