This wall area

must be free of

pipes or wires

Countertop

Hot

water

line on

left

2Plumbing and electrical

service must enter

inside shaded area

24" From wall

24" MIN.

90°

19" MIN. from wall

24"

MIN.

34" to 34-3/4"

Underside

of countertop

to floor

5 5

90°

Electrical

wiring on

right

Electrical

wiring is

3" from

cabinet

25-3/4

MAX.

21-1/2

3-1/4 4 (Adjustable)

34 MIN.

adj. to 35

24-3/4

23-3/8

Electrical Rating

Voltage AC............................................... 120

Hertz........................................................ 60

Total connected load amperage............. 8.6

Calrod®heater watts max................... 500

For use on adequately wired 120-volt, 15-amp circuit

having 2-wire service with a separate ground wire.

This appliance must be grounded for safe operation.

Note: Dishwasher must not be installed more than

10 feet from sink for proper drainage. All plumbing

and electrical work must be in accordance with

local codes. Dishwasher includes drain hose and

leveling legs.

Installation Information: Before installing, consult

installation instructions packed with product for

current dimensional data.

Dishwasher Dimensions (in inches)

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

Listed by

Underwriters

Laboratories

HDA3500/3540N – Hotpoint Built-In Dishwasher

Specification Created 4/07

450153

Access insert

Panel Thickness

Door insert

Front

Panel

Dishwashers Installation

(Pub. 1-G003 pg. 131B) May 12, 1993

Wood Insert Cut-Out Dimensions (in inches)

GE/Hotpoint/RCA

1-1/2 1/2

When using GPF325

1/4" custom dishwasher

door and access panel kit.

When using GPF375

3/4" custom dishwasher

door and access panel kit.

1/4

3/4

Panel

Thickness

Kit A B C

GPF325 18-7/8" 23-9/16" 3-11/16" 1/4"

GPF375 18-15/16" 23-5/8"* 4-1/4" to

3-3/4"**

3/4"

* Bottom of panel must be notched 1-1/2" x 1/2" to clear across panel

** Adjustment required to match adjacent cabinet fronts due

to leveling leg adjustment, 4" nominal

Features and Benefits

• 5-level PowerScrub™ wash system with PowerShower - 5 wash levels and redesigned

wash arms direct water precisely for a quiet and efficient clean.

• 100% water filtration with ExtraFine™ filter - Clean water helps deliver clean dishes.

• Hot PreWash Option - Preheats water before the main wash cycle for excellent

performance time after time

• QuietPower™ motor - Runs quietly and efficiently to keep the kitchen peaceful and quiet

• Push-button controls - Operate with ease

• Pots and Pans Cycle - Scours off baked-on food with a wall of water

• Piranha™ Hard Food Disposer - Grinds leftover food into small particles that are easily

washed away

• Model HDA3500NWW – White on white

• Model HDA3500NBB – Black on black

• Model HDA3500NCC – Bisque on bisque

• Model HDA3540NSA – Silver metallic

HDA3500NWW/BB/CC

HDA3600NWW/BB/CC

HDA3500/3540N – Hotpoint Built-In Dishwasher

Specification Created 4/07

450153
