DB Series Ice Maker

Installation & Maintenance Manual

The manual covers the following models

DB175A, DB215A, DB255A

DBice APP QR Code

Concent

1. Features------------------------------------3

2. Size& App earance ---------------------3

3. Critical Parameter-------------------------4

4. Unpacking-----------------------------------4

5. Installation Location----------------------4

6. Leveling Adjustment---------------------4

7. Water supply/Purge---------------------5

7 . 1 W a t e r/ s u p p l y - - - -- - - - ---------------5

7 . 2 P u r g e - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5

8. Po w e r S up p ly - - -- - -- - - -- - - -- - -- - ------ - - 5

9. Clean after Installation-----------------5

10. Check after Installation ----------------5

11. Op eration-------------- ------------------6

11.1 Coustomer operation---------------6

11.2 Service----------------------------- 9

11.3 Advanced Setup-----------------11

12. Operation inspection-----------------11

13. Regular cleaning-----------------------12

14. Condenser cleaning--------------------12

15. Cleaning & Sanitation--------------- --12

15.1 Cleaning process ---------------------13

15.2 Disinfection process ----------------13

15.3 Rinse process-------------------------13

15.4 Parts removal -----------------------------14

16.Out of use/Winterization-----------------15

17.Maintenance-------------------------------15

18.DBice ap p ------------------------------16

安全提示

2/ 16 File No：JT190100004 Version：A

Note：Subsequent updated versions of this manual will not be noticed, thank you.

Safety TipsConcent

When operates and maintains an ice maker ,be sure to pay attention to the safety tips in the manual.

Ignoring these tips may result in personal injury and ice maker damage.

In this manual, you will see the following forms of security tips：

Please keep this manual well

The manual is an integral part of the product, please keep it properly. Be sure to read carefully the

warnings, notices and important matters described in this manual, because these warnings, notices and

important matters provide the installer/user with important information needed for proper installation,

continuous and safe use and maintenance of the product. Please keep this manual for reference when

necessary.

WARNING

Potential personal injury. Personal injury may be caused if the machine is not installed, used or

modified without permission according to this manual.

IMPORTANT

It is very important to install, use and maintain the ice machine correctly to keep the output of ice

machine and reduce the failure rate. Please read and understand this manual, which contains

valuable installation, use and maintenance information. If you encounter problems not covered in

this manual, you can contact our company or our repairer at any time.

NOTICE

The adjustment, maintenance and cleaning in this manual are not covered by the warranty.

安全提示

File No：JT190100004 Version：A 3/ 16

Note：Subsequent updated versions of this manual will not be noticed, thank you.

Features

1. Features

DB series ice maker are with several patent control

system, it could be simply operated, suitable for

different water quality conditions;

The key components are from international

renowned brands, which ensures reliability in

harsh environments;

Parts which contacted with water using food-grade

plastic and stainless steel for outer shell, which

ensures food safety and excellent rust resistance.

2. Size and Appearance

Size（Unit：cm）

Appearance

E(max)

DB95A

DB125A

DB175A

112

DB215A

112

DB255A

112

安全提示

4/ 16 File No：JT190100004 Version：A

Note：Subsequent updated versions of this manual will not be noticed, thank you.

Critical Parameter

3. Critical Parameter

4. Unpack

Before unpacking, check the anti-tilt sign is in good

condition, the outer packing of the machine is in

good condition, and the machine model is

consistent with what you have purchased.

Take out accessories and documents, check for its

consistency with packing list.

If there is any discrepancy or damage, please

contact our company/distributor directly

5. Installation Location

The ice maker is not suitable for outdoor usage,

the installation location should not be closed to

heat source or be exposed under direct sunlight.

The normal working ambient temperature should

be ranged between 10°C～38°C, the water

temperature should be between 5°C～32°C. If the

ice-making machine operates beyond the above

normal temperature range for a long time, its

ice-making capacity may be affected.

Ice makers should be installed on solid, flat

ground.

Ice makers should be placed near drinkable water

supply. It is recommended that distance between

ice makers be less than one meter.

Do not block the ventilation window of the ice

maker. There should be enough air convection

space around the ice maker.

The ice maker can not work at sub-zero

emperatures, to prevent supply line failures, empty

the ice maker when the temperature is below

zero(see“Ice machine stop / winter”)

安全提示

File No：JT190100004 Version：A 5/ 16

Note：Subsequent updated versions of this manual will not be noticed, thank you.

Water Supply

Warning

The power supply must be reliably grounded

and the wiring used must comply with the laws

and regulations of the country and region where

the ice maker is used.

6. Leveling Adjustment

Screwing home four adjustable parts of the legs

first, and then screwing the legs into ice maker

bottom plate；

Moving ice maker to installation place. Adjusting

legs to ensure the ice maker is leveling.

7. Water supply/Purge

7.1Water supply

With local potable water quality, determining if a

water treatment system is needed to prevent

sediment formation, filtering out impurities and

removing bleach smell .

Please install water supply pipe according to

below instruction :

Don't connect ice maker to hot water pipe；

Water supply pressure range is 1bar～5bar.

Using water pressure regulator for water

supply pressure over rang.

Individual water faucet must be installed for

ice maker.

7.2Purge

When installing drain hose, follow these guidelines

to be sure all purged water flowing into gully drain：

The main gully drain capacity shall be enough for

all drain water:

The drain hose of the water-cool condenser

and the drain hose of ice bin should be placed

separately

About 2.5 centimeters drop needed for each

one meter additional drain hose and must not

be bent

8. Power supply

The voltage, frequency and capacity of the power

supply shall be consistent with the nameplate of

the machine.

±10% fluctuation of rated power voltage is

allowed.

Individual circuit breakers must be installed for the

ice maker.

Warning

Ice makers must be connected to

potable water supply.

Note

Do not put hard object under legs for

leveling ice maker. Make sure the four legs

touching the ground steadily to prevent

vibration during operation.

安全提示

6/ 16 File No：JT190100004 Version：A

Note：Subsequent updated versions of this manual will not be noticed, thank you.

Operation

9. Clean after Installation

After the ice maker is installed, clean the shell,

liner and ice scoop with a clean wet cloth or

sponge;

10. Check after installation

After the ice maker is installed, check against the

following information before operation.

Is ice maker placed levelly？

Have you removed all the transportation seals？

Are all the water and electricity connected well？

Is the supply voltage consistent with the rated

voltage on the nameplate?

Is the ice maker properly grounded?

Are there adequate air Spaces around the ice

maker?

Is the ambient temperature of the ice maker

between 10°C and 38°C?

Does the water inlet temperature remain between

5°C and 32°C?

Are the ice maker and refrigerator cleaned?

11. Operation

11.1 Coustomer operation

11.1.1 Language option

Press SETUP->LANGUAGE，Enter the language

setting interface, slide up and down to select the

required language

11.1.2 MAKING ICE/STOP

Press MAKING ICE icon, start ice machine, press

the icon again, stop and enter stand-by mode.

11.1.3 Ice thickness adjust：

Press SETUP-> USER SETUP - > ICE

THICKNESS ADJUST icon to enter the ice

thickness setting interface; press + or - to increase

or decrease the ice thickness(+or-represents the

安全提示

File No：JT190100004 Version：A 7/ 16

Note：Subsequent updated versions of this manual will not be noticed, thank you.

Operation

minutes of increase or decrease in ice making

time)

11.1.4 Energy saving setting：

11.1.4.1 Ice making mode：It is applicable to

winter or off-season, when less ice needed) press

SETUP - > USER SETUP - >ICE MAKING MODE icon

to enter the interface; slide up and down to select the

ice making mode

2 / 3 : ice maker working 2 hours and

then stop 3 hours, the ice making

capacity is 40% of the original;

2/4：ice maker working 2 hours and then

stop 4 hours, the ice making capacity is

30% of the original;

ON/OFF，Ice maker keep working till ice

full of ice bin, ice production 100%；

3/1：ice maker working 3 hours and then

stop 1 hours, the ice making capacity is

75% of the original;

3/2：ice maker working 3 hours and then

stop 2 hours, the ice making capacity is

60% of the original;

11.1.4.2Energy saving mode setting：（Turn on

and off the ice maker by timer, use the low price of

electricity to make ice, and reduce the use cost. Or

close drain function to save portable water and

increasing ice production）Press SETUP->USER

SETUP->ENERGY SAVE icon,

TIMER ON, XX h XX m later, the ice maker starts

to make ice;

TIMER OFF, XX h XX m, the ice maker stop

making ice;

Water save, YES: water purge in each ice

making cycle; No: no purge.（No purge setting

can save water and increase ice production

where with good water quality.）

11.1.4.3 Reduce the water draining time

(According to the water quality, reduce the draining

time by 0 ~ 15 seconds). This can reduce ice making

time, and increasing ice production.

This function is key word protected, shall be operated

by Professional maintenance person.

Press SETUO -> ADVANCE SETTING ->input

password -> , to enter into the Freeze/harvest

interface.

Longest water dump: According to the water

quality, choose the suitable draining time (0 ~

15 seconds).

安全提示

8/ 16 File No：JT190100004 Version：A

Note：Subsequent updated versions of this manual will not be noticed, thank you.

Operation

11.1.5 Clean

Press CLEAN icon in main interface to start

clean process .

Press ESC icon in to stop clean process .



Clean pocess flow：

11.1.6 Network Setup

Press SETUP -> NETWORK SETTINGS

Choose WiFi and enter password。

11.1.7 Check the Equipment Information

Press SETUP ->MACHINE INFO enter the

interface.

RESTART option:

Select: When power supply is restored

after power failure, the ice maker

automatically starts to make ice.

No select: When power supply is

restored after power off. The ice maker

will stand by. Customers need to press

ICE MAKING icon to start making ice.

11.1.8 Maintenance reminder setting

Press SETUP -> USER SETUP ->

MAINTENANCE INFO to the Maintenance

reminder page

When the machine works exceed the settled

working time, the machine will remind for

maintenance.

安全提示

File No：JT190100004 Version：A 9/ 16

Note：Subsequent updated versions of this manual will not be noticed, thank you.

Operation

11.1.9 Restore Factory Settings (Default mode,

suitable for any condition)

Press SETUP -> DEFAULT MODE.

Press the hand shape icon to restore factory

settings

11.2 Service (When need repair or maintenance, this

function is for repair/maintenace person)

When the ice machine can not work properly,

press SETUP -> SERVICE icon to enter the service

page.

11.2.1 Fault Record

Fault record can provide information like fault

time and code, it can help the maintenance

person to accurately determine the fault point.

Error Code:

E1：Ice making time more than 40 minutes

E2：Ice defrost time more than 4 minutes

E3：Water Shortage Protect

E4：Ice Making System Error

E5：Ice defrost System Error

E6：High Pressure Protect

E7：High Temperature Protect

E8：N/A

E9：N/A

E10：T2 Condenser T sensor Short Out

E11：T2 Condenser T sensor Disconnection

E12：Magnet Switch Error

E13：Defrost Probe Error

11.2.2 Electric components Function Check

(This can turn on or off main electric components to

help the serviceman to check the elements function）

Press SETUP -> SERVICE -> OUTPUT

CHECK .

Click the corresponding icon to start the

corresponding electrical work; judge whether

the component works through vision, hearing

and touch to determine whether the electrical

component is damaged.

安全提示

10 / 16 File No：JT190100004 Version：A

Note：Subsequent updated versions of this manual will not be noticed, thank you.

Operation

11.2.3.Sensor Function Check

Press SETUP -> SERVICE -> INPUT CHECK

Harvest Probe and water level probe:

The icon reflects the actual state of the water

level probe and water level.

Door Magnetic Switch: Turn on or off the

water baffle, the display shows the magnetic

switch on or off, if not, the switch maybe

problem

11.2.4 Manually harvest ice (When the ice is too

thick or defrost function problem, it request harvest ice

manually):

11.3 Advanced Setup (This process is protected

by password, only authorized person can use this

function.

Press SETUP -> ADVANCE SETUP to this page.

11.3.1 Freeze/harvest time set

Longest Freeze: This parameter specifies the

maximum ice making time. When the ice making time is

greater than this value, the ice maker forces de icing. If

the time-out is 3 times in succession, the ice maker will

stop working and give a fault alarm

Longest harvest: This parameter specifies the

maximum deicing time. When the deicing time is

greater than this value, the ice maker will automatically

enter the ice making procedure; if the time-out is 3

times insuccession, the ice maker will stop working and

give a fault alarm.

Icethickness adju: (Range 3 ~ -3) This is for adjust

the ice thickness, the range is -3 to 3, original is 0.

Ice can only adjusted to be thinner when it’s 3 (rduce

ice making time from 0 to 6 minutes) and only thicker

when it is -3 (increaseing ice making time from 0 to 6

minutes)

Harvest delay: N/A

11.3.2 Water Inlet/dump Time Set

Do not change this page, it is determined by lab

test!

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Máquina de hielo de Hoshizaki

Hoshizaki

Hoshizaki KM-900MRH50 Manual de usuario

Hoshizaki

Hoshizaki KM-450MAB Manual de usuario

Hoshizaki

Hoshizaki KM-1800SAH Manual de usuario

Hoshizaki

Hoshizaki KM-461MAH Manual de usuario

Hoshizaki

Hoshizaki DCM-270BAH Manual de usuario

Hoshizaki

Hoshizaki KMD-850MAH Manual de usuario

Hoshizaki

Hoshizaki FM-150KE Manual de usuario

Hoshizaki

Hoshizaki KM-1600MRH Manual de usuario

Hoshizaki

Hoshizaki FM-600ALKE-CO2-SB Manual de usuario

Hoshizaki

Hoshizaki CUBELET ICEMAKER/DISPENSER DCM-750BAH-OS Manual de usuario

Hoshizaki

Hoshizaki KML-600MAF Manual de usuario

Hoshizaki

Hoshizaki KML-250MAH Manual de usuario

Hoshizaki

Hoshizaki KM-150BWF Manual de usuario

Hoshizaki

Hoshizaki F-500BAJ Manual de usuario

Hoshizaki

Hoshizaki KM-250BAC Manual de usuario

Hoshizaki

Hoshizaki DIM-40DE-HC Manual de usuario

Hoshizaki

Hoshizaki KM-1301SAH Manual de usuario

Hoshizaki

Hoshizaki IM-212U-21 Manual de usuario

Hoshizaki

Hoshizaki F-450MAH Manual de usuario

Hoshizaki

Hoshizaki KM-250BAB Manual de usuario

Hoshizaki

Hoshizaki IM-21CLE Manual de usuario

Hoshizaki

Hoshizaki KMD-700MRH Manual de usuario

Hoshizaki

Hoshizaki DKM-500BWH Manual de usuario

Hoshizaki

Hoshizaki FM-120EE Guía

Manuales populares de Máquina de hielo de otras marcas

Sub-Zero

Sub-Zero 315I Instrucciones de uso

Unold

Unold 48945 Manual de usuario

Kenmore

Kenmore 2217402A Manual de usuario

Cornelius

Cornelius WM600 Instrucciones de funcionamiento

GE XPIO43SCSS Manual de usuario

Whynter

Whynter FIM-450HA Manual de usuario

U-Line

U-Line UMCR014-SC01A Manual de instalación

Andrew James

Andrew James AJ000522 Manual de usuario

Scotsman

Scotsman CME1356 Manual de usuario

Scotsman

Scotsman ACM 25 Manual de usuario

Kärcher

Kärcher IP 120 Manual de usuario

U-Line

U-Line SS1095 Manual de usuario

Maytag

Maytag MIM1554WRS - Ice Maker Manual de usuario

Princess

Princess Yonanas Manual de usuario

Unold

Unold 48946 Manual de usuario

Electrolux

Electrolux E15IM60GP Manual de usuario

Cornelius

Cornelius UC150 ICE ONLY Manual de usuario

Bunn

Bunn BUNN-O-MATIC ULTRA-1 Manual del propietario
