Horizon Hobby SPMR14000EU Manual de usuario

Instruction Manual

NOTICE

All instructions, warranties and other collateral documents are subject to change

at the sole discretion of Horizon Hobby,LLC. For up-to-date product literature,

visit www.horizonhobby.com or www.towerhobbies.com and click on the support

or resources tab for this product.

MEANING OF SPECIAL LANGUAGE

The following terms are used throughout the product literature to indicate various

levels of potential harm when operating this product:

WARNING: Procedures, which if not properly followed, create the probability

of property damage, collateral damage, and serious injury OR create a high

probability of superﬁcial injury.

CAUTION: Procedures, which if not properly followed, create the probability of

physical property damage AND a possibility of serious injury.

NOTICE: Procedures, which if not properly followed, create a possibility of

physical property damage AND a little or no possibility of injury.

WARNING: Read the ENTIRE instruction manual to become familiar with

the features of the product before operating. Failure to operate the product

correctly can result in damage to the product, personal property and cause

serious injury.

This is a sophisticated hobby product. It must be operated with caution and

common sense and requires some basic mechanical ability. Failure to operate

this Product in a safe and responsible manner could result in injury or damage

to the product or other property. This product is not intended for use by

children without direct adult supervision. Do not attempt disassembly, use with

incompatible components or augment product in any way without the approval of

Horizon Hobby, LLC. This manual contains instructions for safety, operation and

maintenance. It is essential to read and follow all the instructions and warnings

in the manual, prior to assembly, setup or use, in order to operate correctly and

avoid damage or serious injury.

SAFETY PRECAUTIONS

• Always ensure all batteries have been properly charged prior to using the model.

• Always check all servos and their connections prior to each run.

• Never operate your model near spectators, parking areas or any other area that

could result in injury to people or damage of property.

• Never operate your model during adverse weather conditions. Poor visibility can

cause disorientation and loss of control of your model.

• Never point the transmitter antenna directly toward the model. The radiation pat-

tern from the tip of the antenna is inherently low.

• If, at any time during the operation of your model, you observe any erratic or ab-

normal operation, immediately stop operation of your model until the cause of the

problem has been identiﬁed and corrected.

Age Recommendation: Not for children under 14. This is not a toy.

CHARGING WARNINGS

CAUTION: All instructions and warnings must be followed exactly.

Mishandling of Li-Po batteries can result in a ﬁre, personal injury and/or

property damage.

• NEVER LEAVE CHARGING BATTERIES UNATTENDED.

• NEVER CHARGE BATTERIES OVERNIGHT.

• By handling, charging or using the included Li-Po battery, you assume all risks as-

sociated with lithium batteries.

• If at any time the battery begins to balloon or swell, discontinue use immediately. If

charging or discharging, discontinue and disconnect. Continuing to use, charge or dis-

charge a battery that is ballooning or swelling can result in ﬁre.

• Always store the battery at room temperature in a dry area for best results.

• Always transport or temporarily store the battery in a temperature range of

40–120º F (5–49° C). Do not store the battery or model in a car or direct sunlight. If

stored in a hot car, the battery can be damaged or even catch ﬁre.

• Always charge batteries away from ﬂammable materials.

• Always inspect the battery before charging.

• Always disconnect the battery after charging and let the charger cool between charges.

• Always constantly monitor the temperature of the battery pack while charging.

• ONLY USE A CHARGER SPECIFICALLY DESIGNED TO CHARGE LI-PO BATTERIES.

Failure to charge the battery with a compatible charger may cause a ﬁre resulting in

personal injury and/or property damage.

• Never discharge Li-Po cells to below 3V under load.

• Never cover warning labels with hook and loop strips.

• Never charge batteries outside recommended levels.

• Never charge damaged batteries.

• Never attempt to dismantle or alter the charger.

• Never allow minors to charge battery packs.

• Never charge batteries in extremely hot or cold places (recommended between

40–120° F [5–49° C]) or place in direct sunlight.

WARNING AGAINST COUNTERFEIT PRODUCTS: If you ever need to

replace your Spektrum receiver found in a Horizon Hobby product, always

purchase from Horizon Hobby, LLC or a Horizon Hobby authorized dealer to ensure

authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support

and warranty with regards, but not limited to, compatibility and performance of

counterfeit products or products claiming compatibility with DSM or Spektrum

technology.

NOTICE: This product is only intended for use with unmanned, hobby-grade,

remote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability outside

of the intended purpose and will not provide warranty service related thereto.

TABLE OF CONTENTS

How To Use the Manual

Navigating the Pages

Return To Spektrum AirWare App

Using the Table of Contents

Box Contents

Basic Operation

Setting Up A New Model overview

Transmitter Functions

Spektrum LED

Charging

Physical Transmitter Adjustments

Gimbal Adjustment Screws

Transmitter Mode Change

Stick Tension

Throttle Strap Adjustment

Control Sticks

Control Stick Length Adjustment

Android Operating System

Android Navigation Icons

Android Home Screen Elements

Notiﬁcation Screen

Spektrum AirWare Navigation

Volume Control

Telemetry Reset

Model Image Selection

Model Type Defaults

Acro Defaults

Heli Defaults

Sail Defaults

Multi Defaults

Model Utilities

Select A Different Model

Add A New Model

Sort Model List

Import Models

Export Models

Edit Categories

Search the Model List

Model Details

Model Name

Model Image

Monitor Channel Count

Model Category

Expanded Model Details

Reset Model Timer

Duplicate Model

Reset Model

Delete Model

Import Audio

Export Model

Save As Template

Model Note
