W.MACHINE/WASHER-DRYER
31000831 SE234-80
Service Manual
SE 160 E, ASM 160 Wash. M/cs
©2004 GIAS U.K. / Hoover Ltd.
SE160 E
SE 160 E, ASM 160 Wash. M/cs
©2004 GIAS U.K. / Hoover Ltd.
SE 160 E, ASM 160 Wash. M/cs
©2004 GIAS U.K. / Hoover Ltd.
SE 160 E, ASM 160 Wash. M/cs
©2004 GIAS U.K. / Hoover Ltd.
SE 160 E, ASM 160 Wash. M/cs
©2004 GIAS U.K. / Hoover Ltd.
21
211
211
31000831 SE234-80 0442 (12/10/2004)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
2 Programs disc 03841518
8a Buffer with spring service pack 97917116
15 Cam disc 03850314
19 Button 03841445
24 Button protection 03841444
31 Control panel 40002149
32 Dispenser drawer front 04230676
48 R/H side frame 03940686
48a L/H side frame 03940687
49 Top rear frame 03940685
51 Work top 03410167
60 Hinge 91700102
61 Counter ring 91601645
62 Door surround 91601647
63 Door glass 91600903
65 Door catch 91601655
66 Spring 91408713
67 Glass door with frame 91670644
73a Screw 09031030
76 Cabinet assy 04230672
77 Rear panel 97911044
78 Socle 41006148
79 Rear foot 92606474
80 Front foot 92692300
94c Filter knob with gasket 06015493
97d Filt hous w/filter cartridge 91941772
99a Hose 41010982
101 Dispenser drawer 03870775
103 Rack 41005935
109 Dispenser bottom section assy 03870708
110 Dispenser top section 03870774
31000831 SE234-80 0442 (12/10/2004)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
111 Water injector nozzle 92149327
112 Distribution connecting rod 92884212
113 Lever 97910582
114 Driving lever 41000950
114a Hose clip 92470061
116 Cam 06012915
118 Spring 92483148
131 Hose clip 92470020
131a Hose clip 92470194
132 Hose 97910517
133 Hose clip 92470012
134 Solenoid valve 25686057
138 Drain hose 92693373
138a Drain house elbow 92689587
138b Hose clamp 92895051
142 Fill hose 92250869
151a Motorized selector 30 settings 91201337
152f Switch assy (Unipolar) 91201694
153 Pressure switch 28375052
155 Indicator light 91209510
157 Wiring harness 04660497
157d 7 Way connection 97911473
157e 6 Way connecton 97911481
157f 11 Way connecton 97911499
157m Water valve harness 91201486
157n Timer harness 91201360
157p Motor to module harness 91201485
158 Mains block 91623678
161d Drain/recycle pump complete 97922819
162 Door safety device 91201208
164 Anti jamming filter radio 91212795
31000831 SE234-80 0442 (12/10/2004)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
178 Motor connector 27719213
202 Drum 04240181
203 Tub 97923565
204a Front flange 04240184
205 Drum shaft assy 04150062
211 Bolt 97923474
215 Tub gasket 92131689
217 Seal retainer 92445600
219 Bolt 21446068
221 Nut 92424209
225a Gasket 92445626
230 Tub gasket clip 91750458
230a Tub gasket clip 90488603
232 Heater holder 97910301
242 Support spring. 92484492
242a R/H support spring 92484484
244 Washer 92430206
244a Counter weight washer 40001133
246 Bolt 92419472
246a Bolt 97911507
246b Slide 09078825
246c Clamp 97910061
247 Upper balance weight 97910491
248 Lower balance weight 03940700
251a Telescopic shock absorber 92484518
251c Washer 97910509
251d Nut 97915565
259 Support 92673961
271 Door gasket 41008852
272 Discharge pipe 41001597
273 Fill pipe 91620033
31000831 SE234-80 0442 (12/10/2004)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
274 Pressure switch air chamber 06012804
275 5x8 hose 66655731
276 Steam hose 03860457
277 Hose spring 90386137
278a Hose clip d44 92470137
286 Heater 91201546
287m NTC probe 92743616
290 Drum pulley 92723824
292 Drive belt 92130442
292c Clips 92473636
330 Screw x hinge 97917587
473 Commutator motor 41002725
479i Coreboard 32K programmed 09200350
479m Electronic control 32K not programmed 41003803
483a Brush with brush holder 49000466
487 Special bolt 09183567
491c Mains cable x UK 91200201
494 Red window 91611509
500a Hose clip 06012880
526 Sleeve 91601654
535 Knob handle 03841449
547 Module protection 91601842
547a Module protection cover 91601843
558 Support bracket 92884204
588 Siphon 41000762
602 Shock-absorb.conn.bracket 92898790
614 Therm.press.push b. supp. 03870756
618c Unipolar NA+P.A. switch 90489683
632 Control support plate 91802090
643 Door handle assembly 91601653
734 Timer protection 03420083
