IN04004 Sensor_Guide.qxd 7/19/05 12:24 PM Page 2

PIR Motion Sensors ....................................Page 2

DUAL TEC®Motion Sensors ......................Page 7

Glassbreak Detectors ..................................Page 12

Hold-Up Switches ........................................Page 17

Photoelectric Beams ....................................Page 18

Selected Magnetic Contacts ......................Page 19

Other Key Products......................................Page 20

All trademarks are properties of their respective owners

TABLE OF CONTENTS

Competitive Cross Reference Chart...Inside Back Cover

IN04004 Sensor_Guide.qxd 7/19/05 12:25 PM Page 6

IS-2260

Pet Immune PIR

"The only pet immune

PIR with range extended

to 60 ft."

Accessories

• Long Range Lens 100’x20’, 0-900-053-02

• 10’ mtg. height lens 60’x120’, 0-900-053-01

• Swivel Bracket - SMB10

• Ceiling Bracket - SMB10C

• Tampered Swivel Bracket - SMB10T

Features

• 60’ x 120’ coverage, plus lookdown zone

• Pet immunity to 40 lbs.

• ASIC signal processing

• Bi-directional temp comp

• Ultra-low current (<4mA)

• Uniform Sensitivity Optics

• Totally silent relay

• Zero Clearance black bug guard

• 7.5 or 10’ mounting height

• Available with tamper as IS-2260T

Specifications:

• Range: 60’ x 120’

• Detectable walk rate: 0.5’ - 10’/sec

• Signal Proc.: Intermediate, Std, Harsh

• Temp comp: Advanced dual-slope

• Alarm relay: Form A

• Input voltage: 8-14VDC

• Standby current: 4mA

• Indicators: Red LED

• Operating temp: 14°F to 122°F

• Dimensions: 4-3/8"L x

2-1/4"W x 1-1/2"D

AURORA

Pet Immune PIR

"Pet immunity with

distinctive styling."

Accessories

• Long Range Lens 75’x10’ - Aurora-LR

Features

• Pet immunity to 40 lbs.

• ASIC signal processing

• Bi-directional temp comp

• Ultra-low current (<4mA)

• Split-Zone Optics

• Totally silent relay

• Bug guard

• 6.5 - 9’ mouting height

• Available with tamper as AURORA-T

• Available in 6-pack as AURORA-PK

Specifications:

• Range: 35’ x 45’

• Detectable walk rate: 0.5’ - 10’/sec

• Signal Proc.: Intermediate, Std, Harsh

• Temp comp: Advanced dual-slope

• Alarm relay: Form A

• Input voltage: 8-14VDC

• Standby current: 4mA

• Indicators: Red LED

• Operating temp: 14°F to 122°F

• Dimensions: 2.9"W x 4.1"H x 1.5"D

PIR Motion Sensors

IN04004 Sensor_Guide.qxd 7/19/05 12:26 PM Page 7

IS-215T

Entry Level PIR

“Basic space protection at

an economical price.”

Features

• Selectable pulse count

• Uniform Sensitivity Optics

• Patented lookdown mirror

• Zero Clearance black bug guard

• Tamper switch

Accessories

• Swivel Bracket - SMB10

• Ceiling Bracket - SMB10C

• Tampered Swivel Bracket - SMB10T

Specifications:

• Range: 40’ x 40’

• Detectable walk rate: 0.5’ - 10’/sec

• Signal Proc.: High and low sensitivity

• Alarm relay: Form A

• Input voltage: 10-14VDC

• Standby current: 20mA

• Indicators: Red LED

• Operating temp: 14°F to 122°F

• Dimensions: 3.43”H x 2.44”W x 1.57”D

IS-310/IS-320

Request-To-Exit PIR

“Basic and fully-featured

RTEs for every access

control application.”

Features

• Adjustable relay time

• Micro-based signal processing

• Adjustable shutters provide precise

target area

• Advanced features on IS-320 include:

• Piezo sounder

• Door contact input

• Reader/keypad/keyswitch input

• Remote arming and sounder inputs

• Monitor Door and Fail Safe/Secure

modes

• Available in white or black

Specifications:

• Range: From 5.5’ x 2’ up to 8.4’ x 15.8’

depending on mounting height

• Mounting height: 7’ to 15’

• Detectable walk rate: 0.5’ - 10’/sec

• Signal Proc.: RTE and Security modes

• Temp comp: Advanced dual-slope

• Alarm relay: Form C

• Input voltage: 12-28 volts AC or DC

• Standby current: 35mA

• Indicators: Green (ready) LED

• Operating temp: 14°F to 122°F

• Dimensions: 7”L x 2”H x 2”D

Accessories

• IS-310WHTP - single gang trim plate for

IS-310/320 white

• IS-310BLTP - single gang trim plate for

IS-310/320 black

PIR Motion Sensors

New

IN04004 Sensor_Guide.qxd 7/19/05 12:29 PM Page 10

997

Ceiling Mount PIR

“Easy installation with a

twist-off cover.”

Features

• Twist off cover for easy removal

• Local and remote control of LED

• Low profile

• Cover tamper

Specifications:

• Range: 23’ diameter @ 8’ mounting

height

• 36’ diameter @ 12’ mounting height

• Mounting height: 12’ maximum

• Detectable walk rate: 0.5’ - 5’/sec

• Signal Proc.: 1- or 2-event

• Alarm relay: Form A

• Input voltage: 12VDC nominal

• Standby current: 17mA

• Indicators: Red LED

• Operating temp: 32°F to 122°F

• Dimensions: 3-1/2”diameter x 1”high

PIR Motion Sensors

995

Flush Mount PIR

“Single gang-box

installation with years of

proven performance.”

Accessories

• Long Range Lens - 70’x8.5’ - 995LR

• Pett alley - 40’x56’ - 995PA

Features

• Fits single gang box

• “Signature Analysis” pulse count

• Horizontal and vertical adjustment

• Optional long range and pet

alley lenses

Specifications:

• Range: 40’ x 56’

• Detectable walk rate: 0.5’ - 5’/sec

• Signal Proc.: 1- or 2-event

• Alarm relay: Form A

• Input voltage: 12VDC nominal

• Standby current: 15mA

• Indicators: Red LED

• Operating temp: 32°F to 122°F

• Dimensions: 2.75”W x 4.53” H x 0.8”D

IN04004 Sensor_Guide.qxd 7/19/05 12:29 PM Page 11

PIR Motion Sensors

IS-280CM

360° Ceiling

Mount PIR

“Commercial features and

performance for overhead

installations.”

Features

• Mounting heights from 8’ to 12’

• Low profile housing

• Microprocessor-based signal

processing

• Sealed optics chamber

• Can be mounted on a single gang-box

• Cover tamper

.• Range: 45’ dia. @ 10’ mounting height

50’ dia. @ 12’ mounting height

• Detectable walk rate: 0.5’ - 10’/sec

• Signal Proc.: 1, 2, 3, or 4 pulse count

• Temp comp: Advanced dual-slope

• Alarm relay: Form A

• Input voltage: 9-30VDC

• Standby current: 17mA

• Indicators: Three red LEDs for 360°

viewing

• Operating temp: 14°F to 122°F

• Dimensions: 4.9” Diameter x 1.5”H

IS-290CM-W/IS-290CM-N

Ceiling Mount PIR

“Ideal for commercial

installations where wall

mounting is difficult.”

Features

• Mounting heights from 8’ to 12’

• Fully adjustable mirror optics

• Low profile housing

• Microprocessor-based signal

processing

• Can be mounted on a single gang-box

• Cover tamper

Specifications:

• Range: 40’ x 45’ (IS-290CM-W)

65’ x 7’ (IS-290CM-N)

@ 10’ mounting height

• Detectable walk rate: 0.5’ - 10’/sec

• Signal Proc.: 2 or 4 pulse count

• Temp comp: Advanced dual-slope

• Alarm relay: Form A

• Input voltage: 10-30VDC

• Standby current: 25mA

• Indicators: Red (alarm), yellow (alarm

memory) LEDs

• Operating temp: 14°F to 122°F

• Dimensions: 6” Diameter x 1.81”D

IN04004 Sensor_Guide.qxd 7/19/05 12:32 PM Page 14

PIR Motion Sensors

998MX

V-Plex PIR

Motion Sensor

“The V-Plex motion sensor

with both DIP switch and

serial number programming.”

Features

• DIP switch and serial number

addressable

• EZ-Mount features for rapid installation

• Long range and pet alley lenses

included

• Automatic temperature compensation

• 1 mA current with LED disabled

• Tamper

Accessories

• Mounting Bracket - 998SB

Specifications:

• Range: 50’ x 50’

• Detectable walk rate: 0.5’ - 5’/sec

• Signal Proc.: 1-, 2-, or 3-event

• Temp comp: Standard

• Alarm relay: Polling Loop

• Input voltage: 8-11VDC

• Standby current: 1mA

• Indicators: Red LED

• Operating temp: 14°F to 122°F

• Dimensions: 2-5/8” W x 4-3/8” H x 2”D

5894PI

Wireless Pet Immune PIR

for 5800

“End-user replaceable

battery operation.”

Features

• Up to 10 year battery life

• Pet immune to 80 lbs.

• Uniform Sensitivity Optics

• Easy mount/dismount bracket for

end-user replaceable batteries

• Cover and rear tamper

• Patented black bug guard

• Install 5890PI or 5890 until 5894PI

is available.

Specifications:

• Range: 35’ x 45’

• Detectable walk rate: 0.5’ - 10’/sec

• Signal Proc.: Intermediate, Std, Harsh

• Temp comp: Standard

• Batteries: Three CR123A or equivalent

• Battery life: Up to 10 years

• Indicators: Red LED

• Operating temp: 32°F to 122°F

• Dimensions: 3.5”W x 5.2”H x 1.75”D

Coming Soon!

IN04004 Sensor_Guide.qxd 7/19/05 12:34 PM Page 15

DUAL TEC

Motion Sensors

DT-7235T

DUAL TEC®Motion Sensor

“Economical sensor

combines K-Band, pet

immunity and error-free

installation.”

Accessories

• Swivel Bracket - SMB10

• Ceiling Bracket - SMB10C

• Tampered Swivel Bracket - SMB10T

Features

• Pet immune to 100 lbs.

• Exclusive K-Band microwave

technology

• Fast and simple installation with no

adjustments

• Microwave supervision

• Uniform Sensitivity Optics

• Zero Clearance black bug guard

• Tamper

Specifications:

• Range: 35’ x 35’

• Microwave Freq: K-Band, 24.125GHz

• Detectable walk rate: 0.5’ - 10’/sec

• Signal Proc.: No adjustments required

• Temp comp: Standard

• Alarm relay: Form A

• Input voltage: 7.5-16VDC

• Standby current: 25mA

• Indicators: Red LED

• Operating temp: 14°F to 131°F

• Dimensions: 4.685”H x 2.795”W

x 1.654”D

DT-7435

DUAL TEC®Motion Sensor

“Pet immune protection that

incorporates the latest

processing technology.”

Accessories

• Swivel Bracket - SMB10

• Ceiling Bracket - SMB10C

• Tampered Swivel Bracket - SMB10T

Features

• Pet immune to 100 lbs.

• Exclusive K-Band microwave

technology

• DualCore micro-based processing

• Concurrent Diagnostics

• Digital microwave adaptive thresholds

• Digital fluorescent light filter

• Uniform Sensitivity Optics

• Zero Clearance black bug guard

• Tamper

• Also available with Form C

as DT-7435C

Specifications:

• Range: 35’ x 35’

• Microwave Freq: K-Band, 24.125GHz

• Detectable walk rate: 0.5’ - 10’/sec

• Signal Proc.: Intermediate, Standard

• Temp comp: Advanced dual-slope

• Alarm relay: Form A

• Input voltage: 7.5-16VDC

• Standby current: 25mA typical

• Indicators: Tri-color LED

• Operating temp: 14°F to 131°F

• Dimensions: 4.685”H x 2.795”W

x 1.654”D

IN04004 Sensor_Guide.qxd 7/19/05 12:35 PM Page 18

DUAL TEC

Motion Sensors

DT-7450

DUAL TEC®Motion Sensor

“Commercial protection

that incorporates the latest

processing technology.”

Accessories

• Swivel Bracket - SMB10

• Ceiling Bracket - SMB10C

• Tampered Swivel Bracket - SMB10T

Features

• Exclusive K-Band microwave

technology

• DualCore micro-based processing

• Concurrent diagnostics

• Digital microwave adaptive threshholds

• Digital fluorescent light filter

• Uniform Sensitivity Optics

• Zero Clearance black bug guard

• Tamper

• Also available with Form C

as DT-7450C

Specifications:

• Range: 50’ x 60’

• Microwave Freq: K-Band, 24.125GHz

• Detectable walk rate: 0.5’ - 10’/sec

• Signal Proc.: Intermediate, Standard

• Temp comp: Advanced dual-slope

• Alarm relay: Form A

• Input voltage: 7.5-16VDC

• Standby current: 25mA typical

• Indicators: Tri-Color LED

• Operating temp: 14°F to 131°F

• Dimensions: 4.685”H x 2.795”W x

1.654”D

DT-7550C

DUAL TEC®

with Anti-Mask

“Opens new high

security opportunities.”

Features

• Includes all features of the DT-7450, plus

• MaskAlert processing

• Form C relay

• Trouble output relay

• No rear pattern leakage

• K-Band

• Microprocessor controlled dual slope

temperature comp.

Accessories

• Swivel Bracket - SMB10

• Ceiling Bracket - SMB10C

• Tampered Swivel Bracket - SMB10T

Specifications:

• Range: 50’ x 60’

• Microwave Freq: K-Band, 24.125GHz

• Detectable walk rate: 0.5’ - 10’/sec

• Signal Proc.: Intermediate, Standard

• Temp comp: Advanced dual-slope

• Alarm relay: Form C

• Trouble Relay: Form B

• Input voltage: 7.5-16VDC

• Standby current: 30mA typical

• Indicators: Tri-Color LED

• Operating temp: 14°F to 131°F

• Dimensions: 4.685”H x 2.795”W x

1.654”D

IN04004 Sensor_Guide.qxd 7/19/05 12:37 PM Page 19

DUAL TEC

Motion Sensors

DT-515

MiniTek™

Motion Sensor

“Economic alternative to a

DUAL TEC®that’s more than

just a PIR.”

Features

• ASIC-based PIR with S-Band

microwave

• Versatile mounting options

• Wall, corner or ceiling mount

• Surface or flush mount

• Totally silent relay

• Selectable pulse processing

Specifications:

• Range: 15’ x 15’ or 360° x 15’

• Microwave Freq: S-Band, 2.45GHz

• Detectable walk rate: 0.5’ - 5’/sec

• Signal Proc.: Intermediate, Std, Harsh

• Temp comp: Advanced dual-slope

• Alarm relay: Form A

• Input voltage: 10-14.5VDC

• Standby current: 20mA

• Indicators: Red LED

• Operating temp: 14°F to 122°F

• Dimensions: 4.25”H x 2.125”W

x 1.25”D

DT-7360

Ceiling Mount

DUAL TEC®

“K-Band technology is now

available in a ceiling mount

sensor.”

Features

• Exclusive K-Band microwave

technology

• DualCore micro-based processing

• Concurrent Diagnostics

• Digital microwave adaptive thresholds

• Digital fluorescent light filter

• Trouble output

• Surface mount or flush mount

• Front and rear tamper switches

Specifications:

• Range: 50’ diameter 360° coverage

• Microwave Freq: K-Band, 24.125GHz

• Detectable walk rate: 0.5’ - 5’/sec

• Signal Proc.: Intermediate, Standard

• Temp comp: Advanced dual-slope

• Alarm relay: Form C

• Input voltage: 7.5-16VDC

• Standby current: 30mA typical

• Indicators: Separate red, green,

yellow LEDs

• Operating temp: 14°F to 131°F

• Dimensions: 5.0”H x 5.0”W x 2.5”D

NEW!

IN04004 Sensor_Guide.qxd 7/19/05 12:38 PM Page 22

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sensor de seguridad de Honeywell

Honeywell

Honeywell Notifier FSP-951AUS Manual de usuario

Honeywell

Honeywell C7061A1020 Manual de usuario

Honeywell

Honeywell Gamewell FCI 2151 Manual de usuario

Honeywell

Honeywell IntelliSense FG-1625RFM Manual de usuario

Honeywell

Honeywell Miller TurboLite Series Manual del operador

Honeywell

Honeywell 5800CO Instrucciones de montaje

Honeywell

Honeywell Ex-Or MLS2401CDR Manual de instalación y operación

Honeywell

Honeywell PEHA D-LS1000R Manual de usuario

Honeywell

Honeywell Connected Home DO8EZS Manual de usuario

Honeywell

Honeywell Minipeeper C7027A Manual de operación

Honeywell

Honeywell ADEMCO 5821 Manual de usuario

Honeywell

Honeywell Miller Titan TR50 Manual de usuario

Honeywell

Honeywell C7061 A Manual de usuario

Honeywell

Honeywell Connected Home CAMIR-8EZS Manual de usuario

Honeywell

Honeywell Peha D MLS2001AF Manual de instalación y operación

Honeywell

Honeywell 2110B30 0 Series Manual de usuario

Honeywell

Honeywell 5800PIR-COM Manual de usuario

Honeywell

Honeywell FS24X Manual de usuario

Honeywell

Honeywell 5800-OD Manual de usuario

Honeywell

Honeywell PEHA LightSpot Mid Range Series Manual de instalación y operación

Honeywell

Honeywell Miller QuickPick Rescue Kits Manual del operador

Honeywell

Honeywell Miller 8172 Manual del operador

Honeywell

Honeywell 5800FLOOD Manual de usuario

Honeywell

Honeywell 5898 Manual de usuario

Manuales populares de Sensor de seguridad de otras marcas

THORLABS

THORLABS PDA10JT Manual de usuario

Waeco

Waeco UV-DETECT Manual de usuario

Intermatic

Intermatic IOS-DSIMF Manual de usuario

urmet domus

urmet domus 1083 Manual de usuario

Siemens

Siemens AZL66 Series Manual de usuario

BTI

BTI Profiline Multi Finder Manual de usuario

Challenger

Challenger SL01 Manual de usuario

DMP Electronics

DMP Electronics 1122INT Manual de usuario

Rielta

Rielta Ladoga MK-RK Manual de usuario

Mirion Technologies

Mirion Technologies ACCURAD PRD Manual de usuario

Bosch

Bosch DS835 Manual de usuario

DBI SALA

DBI SALA EZ Stop Manual del operador

Lamptime

Lamptime ST05C Manual de usuario

Ubiquiti

Ubiquiti MFI-MSC Manual de usuario

Subsite

Subsite 910R Instrucciones de instalación

Satel

Satel OPAL Pro Manual de usuario

Aleph

Aleph XC-1XTEU Manual de usuario

Pima

Pima LARIS QUAD Manual de usuario
