Honeywell HM Series Manual de usuario

Model / Modèle / Modelo：

HM Series

www.HoneywellAirComfort.com

E-mail: [email protected]

Portable Air Conditioner

User Manual

Read and save these instructions before use

Climatiseur portatif

Mode d’emploi

Lire ces consignes avant l’utilisation de l’appareil et les conserver

Aire Acondicionado Portátil

Manual del Usuario

Lea y guarde estas instrucciones antes de usar la unidad

•

DO NOT operate the unit with a damaged plug or loose wall

outlet. If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualiﬁed persons in

order to avoid a hazard.

DO NOT cover the air intake and exhaust when in use.

DO NOT place objects on or sit on the unit.

Always turn off and unplug the unit when cleaning or servicing.

DO NOT use the appliance if it is damaged.

If service is needed contact an authorized service agent.

Unplug the unit when stored or not in use.

DO NOT pull or carry the appliance by the power cord.

DO NOT pinch the power cord in the door and DO NOT pull it

along edges or sharp corners.

DO NOT run the power cord under carpeting and rugs.

Use caution to prevent tripping on cord.

DO NOT use the device in the following cases:

- Near a ﬁre source

- In areas where gasoline, paint or other ﬂammable

goods are stored

- In an area where the water can be projected

DO NOT touch the plug or the device with wet hands.

Basic safety precautions should always be followed when using

electrical appliances.

This appliance has been manufactured for use in domestic

environments and should not be used for other purposes.

SAFETY

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS. READ CAREFULLY AND

KEEP FOR FUTURE REFERENCE. IN CASE THERE IS ANY

INCONSISTENCY OR CONFLICT BETWEEN THE ENGLISH

VERSION AND ANY OTHER LANGUAGE VERSION OF THE

CONTENT OF THIS MATERIAL, THE ENGLISH VERSION SHALL

PREVAIL.

WARNING:

SAFETY (CONTINUED)

Only use the installation kit provided to install this unit.

DO NOT attempt to extend the hose or install this unit using

other methods other than that shown in this manual. Improper

installation will void any existing warranties.

DO NOT use an extension cord with this unit.

This appliance can be used by children aged from 8 years and

above, and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

Never insert your ﬁngers or rods into the air outlet. Take special

care to warn children of these dangers.

The manufacturer is not liable for injury caused to persons or

property damage due to non-compliance with maintenance

instructions and improper use of the appliance.

The appliance shall be installed in accordance with national

wiring regulations.

The appliance is not to be used by persons (including children)

with reduced physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they have been given

supervision or instruction.

Children should be supervised to ensure that they do not play

with the appliance.

Electrical equipment and installations regulated by national

legislation must be followed.

The appliance should be transported upright.

DO NOT turn on the appliance for at least one hour before

starting it.

It is essential that the appliance is connected to an efficient

ground connection checked by a qualiﬁed electrician.

•

SAFETY (CONTINUED)

•

Stagnation of possible leaks of refrigerant gas in unventilated

rooms could lead to fire or an explosion hazard should the

refrigerant come in contact with electric heaters, stoves or other

sources of ignition.

Use care when storing the appliance to prevent mechanical

faults.

Only persons authorized by an accredited agency certifying their

competence to handle refrigerants in compliance with sector

legislation should work on refrigerant circuits.

DO NOT use means to accelerate the defrosting process or to

clean, other than those recommended by the manufacturer.

Flammable substances or pressurized containers (eg. aerosol

cans) should be kept a minimum of 50cms away from heat or

ﬁre.

Use only implements recommended by the manufacturer for

defrosting or cleaning.

DO NOT operate your air conditioner in a wet room such as a

bathroom or laundry room.

This appliance should be used in a room that allows for good

ventilation between the unit and any walls/furniture or other

objects. The room size should correspond to the room area as

specified for operation by the manufacturer and the appliance

should be well kept to prevent mechanical damage.

A warning to keep ventilation openings clear of obstruction.

Do not pierce or burn the refrigerants.

Be aware that refrigerants may not contain an odor.

Do not modify this appliance in any way to avoid danger.

SAFETY (CONTINUED)

All working procedure that affects safety means shall only be

carried by competent persons.

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or

lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a

person responsible for their safety. Children should be supervised

to ensure that they do not play with the appliance.

•

SYMBOL NOTE EXPLANATION

WARNING

This symbol shows that this

appliance uses a ﬂammable

refrigerant. If the refrigerant

is leaked and exposed to

an external ignition source,

there is a risk of ﬁre.

CAUTION

This symbol shows that the

operation manual should be

read carefully.

CAUTION

This symbol shows that a

service personnel should be

handling this equipment with

reference to the installation

manual.

CAUTION

This symbol shows that

information is available such

as the operating manual or

installation manual.

R290/R32 SAFETY

R290

R32

A2L

R290/R32 SAFETY

Read the instruction carefully before using the appliance.

R290/R32 refrigerant gas complies with UL60335-2-40 /

UL60335-1.

This appliance contains a certain number of grams (see rating

label at the back of the unit) of R290/R32 refrigerant gas. The

maximum refrigerant charge amount is not greater than R290

0.304kg / R32 1.84 kg based on UL60335-2-40.

When defrosting or cleaning, do not use any method other than

those recommended by the manufacturer.

Do not place the appliance in a room with continuous sources

of ignition (e.g. open ﬂame, operating gas appliance or working

electrical heater).

Do not pierce and do not burn.

Do not perforate any part of the refrigerant circuit.

Refrigerant gas may be odorless.

The appliance must be installed, used and stored in an area that

is greater than R290 gas: 15 m²; R32 gas: 4 m².

Accumulation of possible refrigerant leaks in an unventilated

room could lead to ﬁre or explosion should the refrigerant

come in contact with electric heaters, stoves or other sources of

ignition.

The appliance must be stored in a way to prevent mechanical

damage and in a well-vented area.

Only individuals authorized by an accredited organization

certifying their competence to handle refrigerants in compliance

with industry legislation should work on the refrigerant circuit.

Servicing shall be performed only as recommended by the

manufacturer.

All working procedure that affects safety means shall only be

carried by competent persons.

Additional warnings for appliances with R290/R32 refrigerant gas.

•

Repair must be performed based on the recommendations from the manufacturer.

Maintenance and repair that requires the assistance of other qualiﬁed personnel must be

performed under the supervision of specialists in the use of ﬂammable refrigerants.

This marking indicates that this product should not be disposed with other household

throughout the US. To prevent possible harm to the environment or human health

from uncontrolled waste disposal, recycle it responsibly to promote the sustainable

reuse of material resources. To return your used device, please use the return and

collection systems or contact the retailer where the product was purchased. They can

take this product for environmental safe recycling.

Transport of equipment containing ﬂammable refrigerants.

Compliance with the transport regulations.

Marking of equipment using signs.

Compliance with local regulations.

Disposal of equipment using ﬂammable refrigerants.

Compliance with national regulations.

Storage of equipment/appliances.

The storage of equipment should be in accordance with the

manufacturer’s instructions.

Storage of packed (unsold) equipment.

Storage package protection should be constructed such that

mechanical damage to the equipment inside the package will

not cause a leak of the refrigerant charge.

The maximum number of pieces of equipment permitted to be

stored together will be determined by local regulations.

Transportation, marking and storage for units.

R290/R32 SAFETY

THANK YOU

Congratulations on your purchase of this Honeywell Portable Air Conditioner.

Regarding the information pertaining to the installation, handling, servicing, cleaning and disposal

of the appliance, please refer to the below paragraph of the manual.

USER TIPS

Portable Air Conditioners are ideal for spot cooling. The compressor, condenser and evaporator

are housed in a compact unit. The air is dehumidiﬁed and cooled while a ﬂexible hose sends heat

outside. The Portable Air Conditioner includes a window venting kit.

No permanent installation is needed. The unit is easy to move from room to room and offers a truly

ﬂexible air conditioning solution.

Auto Evaporation System - The unit automatically evaporates the condensate through the hose.

There is no need to empty the drainage tank except in humid conditions. Read and follow the

instructions carefully.

To ensure optimal efﬁciency of the product, keep doors and windows closed when it is used as an air

conditioner or dehumidiﬁer. If the product is being used with the fan function only, an open window

could improve air circulation.

Important:

Before installing the unit, place it UPRIGHT for 1 hour before use to allow the refrigerant to stabilize.

Air outlet automatically opens when the unit is turned on, and automatically closes when the unit is

turned off. Manually adjust the air vent located at the top of the unit to adjust the direction of air ﬂow.

Follow installation instructions to set up the unit.

Plug the unit into a properly grounded circuit. DO NOT plug into an extension cord.

•

Cooling and Dehumidifying

Operation Fan Operation

PARTS DESCRIPTION

1) Louver 8) Upper Rubber Drain Plug

(Dehumidifying Mode)

2) Control panel 9) Drain Tube

(For Continuous Drain)

3) Handle 10) Power Cord Winder

4) Casters 11) Lower Dust Filter

5) Remote Control 12) Lower Rubber Drain Plug

(Air Conditioning / Heating Mode*)

6) Hose Connector 13) Storage Plug for Power Cord

7) Upper Dust Filter 14) Power Supply Cord

1 2

*Applicable for models with Heating feature only.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Acondicionador de aire de Honeywell

Honeywell

Honeywell HL10CESWW Manual de usuario

Honeywell

Honeywell CO301PC Manual de usuario

Honeywell

Honeywell MN12CES Manual de usuario

Honeywell

Honeywell Perfect Climate Comfort Center PC8900 Manual de usuario

Honeywell

Honeywell MN09CES Manual de usuario

Honeywell

Honeywell MM14CCS Manual de usuario

Honeywell

Honeywell CL60PM Series Manual de usuario

Honeywell

Honeywell MM14CCSBB Manual de usuario

Honeywell

Honeywell CO301PC Manual de usuario

Honeywell

Honeywell CL60PM Series Manual de usuario

Honeywell

Honeywell CL48PM Manual de usuario

Honeywell

Honeywell CL30XC Manual de usuario

Honeywell

Honeywell TC09PEU Manual de usuario

Honeywell

Honeywell CL25AE Manual de usuario

Honeywell

Honeywell CL48PM Manual de usuario

Honeywell

Honeywell HW2CESAWW9 Manual de usuario

Honeywell

Honeywell MF08CESWW Manual de usuario

Honeywell

Honeywell CO25MM Manual de funcionamiento

Honeywell

Honeywell TC09PCE Manual de usuario

Honeywell

Honeywell HW2CESVWW9 Manual de usuario

Honeywell

Honeywell MP09 Series Manual de usuario

Honeywell

Honeywell CL48PM Manual de usuario

Honeywell

Honeywell DLC203AE Series Manual de usuario

Honeywell

Honeywell HL10 Series Manual de usuario

Manuales populares de Acondicionador de aire de otras marcas

Spheros

Spheros CC 355 Manual de usuario

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manual de usuario

Panasonic

Panasonic CS-E12HKEW Manual de usuario

nedis

nedis ACMB1WT7 Manual de usuario

Samsung

Samsung AR KV Series Guía

Daikin

Daikin FCFV50A Manual de usuario

Fujitsu

Fujitsu Inverter ASBA30JFC Manual de usuario

Toshiba

Toshiba RAS-M10SMUV-E Manual de usuario

Daikin

Daikin FXLQ20MAVE Manual de usuario

Hitachi

Hitachi RAS-E24CAK Manual de usuario

CIAT

CIAT Magister 2 Series Guía

Bestron

Bestron AAC6000 Manual de usuario

Hisense

Hisense 7K Manual técnico

Frigidaire

Frigidaire FFRE0533S1E0 Manual de usuario

Samsung

Samsung AS09HM3N Manual de usuario

Frigidaire

Frigidaire CRA073PU11 Manual del propietario

Soleus Air

Soleus Air GB-PAC-08E4 Manual de usuario

McQuay

McQuay MCK020A Manual de usuario
