Honeywell HC09CESAWK Manual de usuario

Model / Modèle / Modello / Modell:

HC09CESAWK

HC09CESVWK

www.honeywellaircomfort.com

info@honeywellaircomfort.com

Portable Local Air Conditioner

User Manual

Read and save these instructions before use

Mobiele Lokale Airconditioner

Gebruiksaanwijzing

Lees de gebruiksaanwijzing zorgvuldig en

bewaar deze goed

Condizionatore d'aria Locale Portatile

Manuale Utente

Leggere attentamente le istruzioni prima

dell'utilizzo dell'apparecchio

Tragbare Lokale Klimaanlage

Benutzerhandbuch

Lesen sie die anleitung vor dem gebrauch

und heben sie sie auf

Aire Acondicionado Local Portátil

Manual de Instrucciones

Lea y guarde estas instrucciones antes de

usar la unidad

Climatiseur Portable Local

Mode d'emploi

Lire ces instructions avant l'utilisation et

les conserver

Ar Condicionado Local Portátil

Manual do Utilizador

Leia e guarde estas instruções antes da

utilização

Klimatyzator przenośny lokalny

Instrukcja obsługi

Przeczytaj i zachowaj tę instrukcję przed użyciem

For HC09CESVWK only

The Smart Portable Local Air Conditioner has added features to allow you to operate the

Air Conditioner remotely using a smart device and to use voice commands through an

Amazon Echo and Google Home device to control the unit.

Set up the Honeywell Air Comfort App on your smartphone or tablet to connect the

Honeywell Smart Portable Local Air Conditioner for Wi-Fi and Voice Control (only

available for Smart Portable Local Air Conditioner models).

1. Download the Honeywell Air Comfort App User Manual from the below link:

2. Download the Honeywell Air Comfort App on your smartphone or tablet.

IMPORTANT: A 2.4 GHz Wi-Fi network is required for proper connection and operation

between the Portable Local Air Conditioner and the App. You only need a 2.4 GHz net-

work. It will not connect to a 5 GHz network. However, If you are having trouble connect-

ing to your 2.4 Ghz network and have a 5 GHz network, try temporarily disabling your 5

GHz network.

NOTE: The Smart Portable Local Air Conditioner does not have to be connected to the

Honeywell Air Comfort App to function. You can still operate it manually using the unit’s

control panel.

iOS 9.0 or later

Android 4.3 or later

SEARCH “HONEYWELL AIR COMFORT”

SMART PORTABLE LOCAL AIR CONDITIONER WITH WIFI CONNECTIVITY & VOICE

CONTROL

http://honeywellaircomfort.com/HCSmartPACAppManual.pdf

•

DO NOT operate the unit with a damaged plug or loose wall

outlet. If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualiﬁed persons in

order to avoid a hazard.

DO NOT cover the air intake and exhaust when in use.

DO NOT place objects on or sit on the unit.

Always turn off and unplug the unit when cleaning or servicing.

DO NOT use the appliance if it is damaged.

If service is needed contact an authorized service agent.

Unplug the unit when stored or not in use.

DO NOT pull or carry the appliance by the power cord.

DO NOT pinch the power cord in the door and DO NOT pull it

along edges or sharp corners.

DO NOT run the power cord under carpeting and rugs.

Use caution to prevent tripping on cord.

DO NOT use the device in the following cases:

- Near a ﬁre source

- In areas where gasoline, paint or other ﬂammable

goods are stored

- In an area where the water can be projected

DO NOT touch the plug or the device with wet hands.

Basic safety precautions should always be followed when using

electrical appliances.

This appliance has been manufactured for use in domestic

environments and should not be used for other purposes.

SAFETY

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS. READ CAREFULLY AND

KEEP FOR FUTURE REFERENCE. IN CASE THERE IS ANY

INCONSISTENCY OR CONFLICT BETWEEN THE ENGLISH

VERSION AND ANY OTHER LANGUAGE VERSION OF THE

CONTENT OF THIS MATERIAL, THE ENGLISH VERSION SHALL

PREVAIL.

WARNING:

SAFETY (CONTINUED)

Only use the installation kit provided to install this unit.

DO NOT attempt to extend the hose or install this unit using

other methods other than that shown in this manual. Improper

installation will void any existing warranties.

DO NOT use an extension cord with this unit.

This appliance can be used by children aged from 8 years and

above, and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children above 8 years old

without supervision.

Never insert your ﬁngers or rods into the air outlet. Take special

care to warn children of these dangers.

The manufacturer is not liable for injury caused to persons or

property damage due to non-compliance with maintenance

instructions and improper use of the appliance.

The appliance shall be installed in accordance with national

wiring regulations.

The appliance is not to be used by persons (including children)

with reduced physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they have been given

supervision or instruction.

Children should be supervised to ensure that they do not play

with the appliance.

Electrical equipment and installations regulated by national

legislation must be followed.

The appliance should be transported upright.

DO NOT turn on the appliance for at least one hour before

starting it.

It is essential that the appliance is connected to an efﬁcient

ground connection checked by a qualiﬁed electrician.

•

SAFETY (CONTINUED)

•

Stagnation of possible leaks of refrigerant gas in unventilated

rooms could lead to ﬁre or an explosion hazard should the

refrigerant come in contact with electric heaters, stoves or other

sources of ignition.

Use care when storing the appliance to prevent mechanical

faults.

Only persons authorized by an accredited agency certifying their

competence to handle refrigerants in compliance with sector

legislation should work on refrigerant circuits.

DO NOT use means to accelerate the defrosting process or to

clean, other than those recommended by the manufacturer.

Flammable substances or pressurized containers (eg. aerosol

cans) should be kept a minimum of 50cms away from heat or ﬁre.

Use only implements recommended by the manufacturer for

defrosting or cleaning.

DO NOT operate your air conditioner in a wet room such as a

bathroom or laundry room.

This appliance should be used in a room that allows for good

ventilation between the unit and any walls/furniture or other

objects. The room size should correspond to the room area as

speciﬁed for operation by the manufacturer and the appliance

should be well kept to prevent mechanical damage.

A warning to keep ventilation openings clear of obstruction.

Do not pierce or burn the refrigerants.

Be aware that refrigerants may not contain an odor.

Do not modify this appliance in any way to avoid danger.

All working procedure that affects safety means shall only be

carried by competent persons.

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or

lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a

person responsible for their safety. Children should be supervised

to ensure that they do not play with the appliance.

ENEN

SYMBOL NOTE EXPLANATION

WARNING

This symbol shows that this

appliance uses a ﬂammable

refrigerant. If the refrigerant

is leaked and exposed to

an external ignition source,

there is a risk of ﬁre.

CAUTION

This symbol shows that the

operation manual should be

read carefully.

CAUTION

This symbol shows that a

service personnel should be

handling this equipment with

reference to the installation

manual.

CAUTION

This symbol shows that

information is available, such

as the operating manual or

installation manual.

R290 SAFETY

R290

R290 SAFETY

Read the instruction carefully before using the appliance.

R290 refrigerant gas complies with EN60335-2-40 .

This appliance contains a certain number of grams (see rating

label at the back of the unit) of R290 refrigerant gas. The

maximum refrigerant charge amount is not greater than R290

0.304kg based on EN60335-2-40.

When defrosting or cleaning, do not use any method other than

those recommended by the manufacturer.

Do not place the appliance in a room with continuous sources

of ignition (e.g. open ﬂame, operating gas appliance or working

electrical heater).

Do not pierce and do not burn.

Do not perforate any part of the refrigerant circuit.

Refrigerant gas may be odorless.

The appliance must be installed, used and stored in an area that

is greater than R290 gas: 12 m².

The minimum rated airﬂow is 85 m³/h.

Accumulation of possible refrigerant leaks in an unventilated

room could lead to ﬁre or explosion should the refrigerant

come in contact with electric heaters, stoves or other sources of

ignition.

The appliance must be stored in a way to prevent mechanical

damage and in a well-vented area.

Only individuals authorized by an accredited organization

certifying their competence to handle refrigerants in compliance

with industry legislation should work on the refrigerant circuit.

Servicing shall be performed only as recommended by

the manufacturer. Maintenance should only be done by

professionals.

All working procedure that affects safety means shall only be

carried by competent persons.

Additional warnings for appliances with R290 refrigerant gas.

•

Repair must be performed based on the recommendations from the manufacturer.

Maintenance and repair that requires the assistance of other qualiﬁed personnel must be

performed under the supervision of specialists in the use of ﬂammable refrigerants.

This marking indicates that this product should not be disposed with other

household waste. To prevent possible harm to the environment or human health from

uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse

of material resources. To return your used device, please use return and collection

systems or contact the retailer where the product was purchased. They can take this

product for environmentally safe recycling.

Transport of equipment containing ﬂammable refrigerants must

comply with local transport regulations.

Marketing of equipment using signs must comply with local

regulations.

Disposal of equipment using ﬂammable refrigerants must

comply with national regulations.

The storage of equipment should be in accordance with the

manufacturer’s instructions.

Storage package protection should be constructed such that

mechanical damage to the equipment inside the package will

not cause a leak of the refrigerant charge.

The maximum number of pieces of equipment permitted to be

stored together will be determined by local regulations.

Compliance with national gas regulations should be observed.

Transportation, marking, and storage for units.

R290 SAFETY

1EN

THANK YOU

USER TIPS

Congratulations on your purchase of this Honeywell Portable Local Air Conditioner.

Regarding the information pertaining to the installation, handling, servicing, cleaning, and disposal

of the appliance, please refer to the below section of the manual.

Portable Local Air Conditioner are ideal for spot cooling. The compressor, condenser, and evaporator

are housed in a compact unit. The air is dehumidiﬁed and cooled while a ﬂexible Hose sends heat

outside. The air conditioner includes a window venting kit. No permanent installation is needed. The

unit is easy to move from room to room and offers a truly ﬂexible air conditioning solution.

Auto Evaporation System - The unit automatically evaporates the condensate through the Hose.

There is no need to empty the drainage tank except in very humid conditions.

To ensure optimal efﬁciency of the product, keep doors and windows closed when it is used as an air

conditioner or dehumidiﬁer. If the product is being used with the Fan function only, an open window

could improve air circulation.

Important:

Before installing the unit, place it UPRIGHT for 1 hour before use to allow the refrigerant to stabilize.

Manually adjust the air vent located at the front of the unit to adjust the direction of airﬂow.

Follow installation instructions to set up the unit.

Plug the unit into a properly grounded circuit. DO NOT plug into an extension cord.

•

Cooling and Dehumidifying

Operation Fan Operation

PARTS DESCRIPTION

1) Air Outlet 7) Power Supply Cord

2) Control Panel 8) Upper Grill

3) Handle 9) Exhaust Outlet

4) Casters 10) Lower Grill

5) Dust Filter 11) Lower Drain Plug

6) Remote Control

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Acondicionador de aire de Honeywell

Honeywell

Honeywell MM14CHCS Manual de usuario

Honeywell

Honeywell HG Series Manual de usuario

Honeywell

Honeywell CL60PM Series Manual de usuario

Honeywell

Honeywell CO70PE Manual de usuario

Honeywell

Honeywell CL25AE Manual de usuario

Honeywell

Honeywell MM14CCS Manual de usuario

Honeywell

Honeywell CL25AE Manual de usuario

Honeywell

Honeywell MN10CED Series Manual de usuario

Honeywell

Honeywell CL30XC Manual de usuario

Honeywell

Honeywell HWAC-1217S Manual de usuario

Honeywell

Honeywell CS10XE Series Manual de usuario

Honeywell

Honeywell CL60PM Series Manual de usuario

Honeywell

Honeywell CS10PE Manual de usuario

Honeywell

Honeywell CO301PC Manual de usuario

Honeywell

Honeywell MF08CESWW Manual de usuario

Honeywell

Honeywell CS04XE Manual de usuario

Honeywell

Honeywell CL201AEWW Manual de usuario

Honeywell

Honeywell HL12CES Series Manual de usuario

Honeywell

Honeywell HN Series Manual de usuario

Honeywell

Honeywell HM2CESSWK8 Manual de usuario

Honeywell

Honeywell MM14CCS Manual de usuario

Honeywell

Honeywell MM14CCS Manual de usuario

Honeywell

Honeywell CL201AE Manual de usuario

Honeywell

Honeywell TC10PM Series Manual de usuario

Manuales populares de Acondicionador de aire de otras marcas

Spheros

Spheros CC 355 Manual de usuario

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manual de usuario

Panasonic

Panasonic CS-E12HKEW Manual de usuario

nedis

nedis ACMB1WT7 Manual de usuario

Samsung

Samsung AR KV Series Guía

Daikin

Daikin FCFV50A Manual de usuario

Fujitsu

Fujitsu Inverter ASBA30JFC Manual de usuario

Toshiba

Toshiba RAS-M10SMUV-E Manual de usuario

Daikin

Daikin FXLQ20MAVE Manual de usuario

Hitachi

Hitachi RAS-E24CAK Manual de usuario

CIAT

CIAT Magister 2 Series Guía

Bestron

Bestron AAC6000 Manual de usuario

Hisense

Hisense 7K Manual técnico

Frigidaire

Frigidaire FFRE0533S1E0 Manual de usuario

Samsung

Samsung AS09HM3N Manual de usuario

Frigidaire

Frigidaire CRA073PU11 Manual del propietario

Soleus Air

Soleus Air GB-PAC-08E4 Manual de usuario

McQuay

McQuay MCK020A Manual de usuario
