PARTS LIST

PART NO. PS05240

Homelite®

TrimLite

UT20804

Trim 'n Edge

UT20805

Trim 'n Edge (clutch)

UT20833

Easy Reach

UT20806

Easy Reach (clutch)

UT20832, UT20837

VersaTool

UT20816, UT20838

Trimmers/Brushcutters

Eco Power

IGNITION - ROTOR - STARTER

No. Part No. Description Qty.

3 ....... 30-40 ......... 3.4-4.5 ...... Blue 242

4 .......120-180....... 13.6-20.3

8 .......100-150....... 11.3-16.9

11 ....... 10-20 ......... 1.1-2.3

19 ....... 30-50 ......... 3.4-5.6

20 ....... 30-40 ......... 3.4-4.5

23 ....... 30-50 ......... 3.4-5.6

Warranty Flat Rate

Job Description Time/Hr.

2412

FA11 ... Ignition Mod. ................................ .3

FA12 ... Ground Lead ............................... .3

FG10 .. Starter ......................................... .4

FD12 ... Engine Housing, Rear..................4

FF13 ... Trigger, Throttle cable ................. .3

Torque Specs

Item Required

No. In/Lbs Nm Loctite

1•UP 06784 IGNITION KIT 1

2 UP 03868 TERMINAL & COVER 1

3 UP 03896 SCREW-Taptite (8-32 X 1") 2

4 UP 03883 SPARK PLUG 1

5 UP 04690 LEAD-Electrical 1

6 UP 03009 ROTOR KIT 1

7 UP 04241 WASHER-Flat 1

8 UP 04271 CONNECTOR-Drive (.250) 1

9 UP 06345 SHORT BLOCK (See Engine Internal) 1

10 •UP 04743 COMPLETE STARTER ASSEMBLY 1

11 UP 06910 SCREW-Thread Form (8-16 X 1/2") 3

12 UP 04744 BAFFLE-Air 1

13 UP 03012 PULLEY-Starter 1

14 UP 03912 ROPE-Starter (42") 1

15 UP 03917 SPRING & CONTAINER 1

16 UP 03026 GRIP-Starter (Yellow) 1

17 UP 03111 CLAMP 1

18 •UP 02965 HOUSING-Rear Kit 1

19 UP 03895 SCREW-Truss (10-14 X 7/8") 2

20 UP 03406 SCREW-Taptite (10-24 X 3/4") 4

21 •UP 03091 CONTROL HANDLE ASSY. 1

22 UP 04559 TRIGGER 1

23 UP 03895 SCREW-Truss Hd. (10-14 x 7/8") 9

24 UP 04557 CABLE-Throttle 1

Non-Clutch

TrimLite ....................... (UT20804)

Trim 'n Edge ............... (UT20805)

Easy Reach ............... (UT20806)

6/18/2001

5417

No. Part No. Description Qty.

3 ....... 30-40 ......... 3.4-4.5 ...... Blue 242

4 .......120-180....... 13.6-20.3

16 .......10-20 ........... 1.1-2.3

23 ....... 30-50 ......... 3.4-5.6

24 ....... 30-40 ......... 3.4-4.5

30 ....... 30-50 ......... 3.4-5.6

Warranty Flat Rate

Job Description Time/Hr.

FA11 ... Ignition Mod. ................................ .3

FA12 ... Ground Lead ............................... .3

FG10 .. Starter ......................................... .4

FD12 ... Engine Housing, Rear..................4

FF13 ... Trigger, Throttle cable ..................3

Torque Specs

Item Required

No. In/Lbs Nm Loctite

12 11

IGNITION - ROTOR - STARTER - CLUTCH

No. Part No. Description Qty.

{

30 28

1 •UP 05270 IGNITION KIT 1

2 UP 03868 TERMINAL & COVER 1

3 UP 03896 SCREW-Taptite (8-32 X 1") 2

4 UP 03883 SPARK PLUG 1

5 UP 04537 LEAD-Electrical 1

6 UP 04536 LEAD-Electrical 1

7 UP 03009 ROTOR KIT 1

8 UP 03906 WASHER-Flat 1

9 •UP 00034 CLUTCH AND DRUM KIT 1

10 UP 04118 SPACER 1

11 UP 04275 WASHER-Flat 1

12 UP 04103 CLUTCH 2

13 UP 04104 CONNECTOR AND DRUM 1

14 UP 07919 SHORT BLOCK (See Engine Internal) 1

15 •UP 02962 COMPLETE STARTER ASSEMBLY 1

16 UP 06910 SCREW-Thread Form (8-16 X 1/2") 3

17 UP 06380 BAFFLE-Air 1

18 UP 03012 PULLEY-Starter 1

19 UP 03912 ROPE-Starter (42") 1

20 UP 03917 SPRING & CONTAINER 1

21 UP 03026 GRIP-Starter (Yellow) 1

22 •UP 02965 HOUSING-Rear Kit 1

23 UP 03895 SCREW-Plastite (10-14 X 7/8") 2

24 UP 03406 SCREW-Taptite (10-24 X 3/4") 4

25 •UP 06755 CONTROL HANDLE ASSY. 1

26 •UP 03207 TRIGGER-Throttle 1

27 UP 03210 SPRING 1

28 UP 03173 THROTTLE INTERLOCK 1

29 UP 05271 SWITCH 1

30 UP 04247 SCREW-Taptite (10-14 X 1") 9

31 UP 03172 CABLE-Throttle 1

32 UP 03174 LEAD-Electrical 1

Clutch

VersaTool .................... (UT20816, UT20838)

Easy Reach ............... (UT20832,UT20837)

915

6/18/2001

1•UP 06345 SHORT BLOCK (Non-Clutch) 1

•UP 07919 SHORT BLOCK (Clutch) 1

2•UP 06347 PISTON & ROD ASSY. 1

3 UP 06346 RING-Piston 1

4•UP 06348 CYLINDER ASSY. 1

5 UP 03857 GASKET-Cylinder 1

6 UP 06339 GASKET-Heat Dam to Cylinder 1

7 UP 06333 GASKET-Adaptor to Heat Dam 1

8 UP 06335 GASKET-Adaptor to Carburetor 1

9 UP 06334 GASKET-Muffler 1

10 UP 04345 SCREW-Sems (12-24 X 3/4") 3

11 •UP 00019 CRANKCASE COVER ASSEMBLY 1

12 UP03862 GASKET-Crankcase Cover (Also 1

included w/short block)

13 UP 04295 SCREW-Sems (10-24 X 1/2") 4

14 •UP 04099 MUFFLER GUARD 3

15 UP 03897 SCREW-Plastite (10-14 X 1/2") 2

ENGINE INTERNAL

OPTIONAL MUFFLER GUARD

No. Part No. Description Qty.

10 .......55-65 ........... 6.2-7.3 ........ Red 262

13 .......35-45 ........... 4.0-5.1 ........ Red 262

15 ....... 5-20 ........... .6-2.3

Warranty Flat Rate

Job Description Time/Hr.

FB10 ... Partial Rebuild ............................. 1.0

FB20 ... Short Block .................................. 1.0

FD25 ... Crankcase Cover ....................... .3

Torque Specs

Item Required

No. In/Lbs Nm Loctite

6/18/2001

Non-Clutch

TrimLite ....................... (UT20804)

Trim 'n Edge ............... (UT20805)

Easy Reach ............... (UT20806)

Clutch

VersaTool.................... (UT20816,UT20838)

Easy Reach ............... (UT20832,UT20837)

Trim 'n Edge ............... (UT20833)

CARBURETOR - FUEL TANK

13 15

No. Part No. Description Qty.

2 .......30-40 ........... 3.4-4.5

5 .......40-50 ........... 4.5-5.6 ........ Red 262

Warranty Flat Rate

Job Description Time/Hr.

FF17 ... Manifold ....................................... .3

FF10 ... Carburetor Rep........................... .3

FF16 ... Fuel Tank..................................... .3

FF12 ... Fuel/Return Line ......................... .3

Torque Specs

Item Required

No. In/Lbs Nm Loctite

No. Part No. Description Qty.

1 UP 06339 GASKET-Heat Dam to Cylinder 1

2 UP 04307 SCREW-Shoulder 2

3 • UP 06344 HEAT DAM Complete 1

4 UP 06337 TUBE-Tuned 1

5 UP 04140 SCREW-Sems (10-24 x 1") 3

6 UP 06338 ADAPTOR 1

7 • UP 06343 CARBURETOR KIT (Non Clutch)1

8 UP 06333 GASKET-Adaptor to Heat Dam 1

9 UP 06335 GASKET-Carburetor to Adaptor 1

10 UP 06342 LEVER-Choke 1

7 • UP 06825 CARBURETOR KIT (Clutch)1

8 UP 06333 GASKET-Adaptor to Heat Dam 1

9 UP 06335 GASKET-Carburetor to Adaptor 1

10 UP 06357 LEVER-Choke 1

11 UP 06336 TUBE-Rubber 1

12 •UP 06692 FUEL TANK ASSY. 1

13 UP 03871 FILTER-Fuel 1

14 UP 06935 TUBING-Rubber (5.5") 1

15 01439 29 TUBING-Rubber (7.25") 1

16 UP 04708 FUEL CAP 1

17 UP 03501 BUMPER-Rubber 3

18 UP 03913 CLAMP 1

6/18/2001

Non-Clutch

TrimLite ....................... (UT20804)

Trim 'n Edge ............... (UT20805)

Easy Reach ............... (UT20806)

Clutch

VersaTool.................... (UT20816,UT20838)

Easy Reach ............... (UT20832,UT20837)

Trim 'n Edge ............... (UT20833)

No. Part No. Description Qty.

MUFFLER - AIR CLEANER

*See Engine Internal page.

Warranty Flat Rate

Job Description Time/Hr.

2 .......25-35 ........... 2.8-4.0

5 .......50-60 ........... 5.6-6.8

8 .......30-40 ........... 3.4-4.5

FB18 ... Muffler-Replace .......................... .3

FF42 ... Air Filter Assy.............................. .2

Torque Specs

Item Required

No. In/Lbs Nm Loctite

1•UP 06340 MUFFLER ASSY. 1

2 UP 04248 SCREW, Taptite- (8-32 X 3/8") 3

3 UP 04629 SCREEN-Spark 1

4 UP 06334 GASKET-Muffler 1

5 UP 06941 SCREW, Truss Hd. - (10-24 X 2.188) 2

6•UP 06349 AIR FILTER KIT 1

7 UP 04270 FILTER-AIR 1

8 UP 03885 NUT-Hex (10-24) 2

9 UP 04235 SCREW-Slotted Tr. Hd (8-16 x 1

For Non-Clutch models

10 UP 04082 SCREW-Thread Form (6-19 x 1/2") 1

11 UP 04690 LEAD-Electrical 1

12 UP 04716 SPRING-Compression 1

13 UP 06341 BUTTON-Switch 1

6/18/2001

Non-Clutch

TrimLite....................... (UT20804)

Trim 'n Edge ............... (UT20805)

Easy Reach ............... (UT20806)

Clutch

VersaTool.................... (UT20816,UT20838)

Easy Reach ............... (UT20832,UT20837)

Trim 'n Edge ............... (UT20833)

SHAFT - SPOOL & STRING - GRASS DEFLECTOR

1 •UP 03010 HANDLE-Anti-Vibe 1

2 UP 04262 NUT-Wing, Washer Faced (1/4-20) 1

3 UP 06523 SCREW-Cap Hex Hd. 1

4 •UP 04555 DRIVESHAFT HOUSING ASSY. 1

5 UP 03031 SHAFT-Flexible 1

6 UP 04137 CLAMP 1

7 UP 04256 SCREW-Sems Hex Hd. (#10-24 X 3/8") 1

8 •UP 06710 DEFLECTOR & BLADE KIT (55 Deg.) 1

9 UP 06523 SCREW-Cap Hex Hd. (10-24 X 2") 1

10 UP 03415 WASHER-Flat (1/4") 1

11 UP 03409 WASHER-Lock (1/4") 1

12 UP 04262 NUT-Wing, Washer Faced (1/4-20) 1

13 •UP 04119 BLADE-Cut-Off 1

14 UP 04159 SCREW-Mech. Hex Hd. (10-24 X 7/8") 2

15 UP 04150 NUT-Hex (10-24) 2

16 •DA 03001 A STRINGHEAD-Complete (.080") 1

17 UP 06567 HOUSING & EYELET (Dual Line) 1

18 •UP 00145 SPOOL & STRING (.080") 1

19 UP 06526 SPRING-Compression 1

20 UP 04273 RETAINER-Spool (R.H. Thread, Black) 1

No. Part No. Description Qty.

Warranty Flat Rate

Job Description Time/Hr.

2 ....... 5-25 ........... .6-2.8

7 .......15-25 ........... 1.7-2.8

12 ....... 5-25 ........... .6-2.8

15 .......30-40 ........... 3.4-4.5

FM10 .. Stringhead Assy. ......................... .2

FN12... Driveshaft.................................... .3

FN13... Driveshaft Hsg............................ .3

FN16... Deflector-Grass.......................... .2

FD20... Front Handle ............................... .2

Torque Specs

Item Required

No. In/Lbs Nm Loctite

TrimLite ....................... (UT20804)

6/18/2001

SHAFT - SPOOL & STRING - GRASS DEFLECTOR

1 •UP 06959 HANDLE-Anti-Vibe 1

2 UP 04262 NUT-Wing, Washer Faced (1/4-20) 1

3 UP 06523 SCREW-Cap Hex Hd. 1

4 •UP 04555 DRIVESHAFT ASSY. 1

•UP 07813 DRIVESHAFT ASSY. (

UT20833

5 UP 03031 SHAFT-Flexible 1

6 UP 04137 CLAMP 1

7 UP 04256 SCREW-Sems Hex Hd. (#10-24 X 3/8") 1

8 •UP 06710 DEFLECTOR & BLADE KIT (55 Deg.) 1

9 UP 06523 SCREW-Cap Hex Hd. (10-24 X 2") 1

10 UP 03415 WASHER-Flat (1/4") 1

11 UP 03409 WASHER-Lock (1/4") 1

12 UP 04262 NUT-Wing, Washer Faced (1/4-20) 1

13 •UP 04119 BLADE-Cut-Off 1

14 UP 04159 SCREW-Mech. Hex Hd. (10-24 X 7/8") 2

15 UP 04150 NUT-Hex (10-24) 2

16 •DA 03001 A STRINGHEAD-Complete (.080") 1

17 UP 06567 HOUSING & EYELET (Dual Line) 1

18 •UP 00145 SPOOL & STRING (.080") 1

19 UP 06526 SPRING-Compression 1

20 UP 04273 RETAINER-Spool (R.H. Thread, Black) 1

No. Part No. Description Qty.

Warranty Flat Rate

Job Description Time/Hr.

2 ....... 5-25 ........... .6-2.8

7 .......15-25 ........... 1.7-2.8

12 ....... 5-25 ........... .6-2.8

15 .......30-40 ........... 3.4-4.5

25 ....... 5-25 ........... .6-2.8

FM10 .. Stringhead Assy. ......................... .2

FN12... Driveshaft.................................... .3

FN13... Driveshaft Hsg............................ .3

FN16... Deflector-Grass.......................... .2

FD20... Front Handle ............................... .2

Torque Specs

Item Required

No. In/Lbs Nm Loctite

21 •UP 00008 EDGER GUIDE KIT 1

22 UP 04148 SCREW-Hex Hd. (1/4-20 X 2 1/2") 1

23 UP 03415 WASHER-Flat (1/4") 2

24 UP 03409 WASHER-Lock (1/4") 2

25 UP 04262 NUT-Wing, Washer Faced (1/4-20) 2

26 UP 04158 SCREW-Hex Hd. (1/4-20 X 1") 1

No. Part No. Description Qty.

Trim 'n Edge ............... (UT20805)

Trim 'n Edge ............... (UT20833)

6/18/2001

SHAFT - SPOOL & STRING - GRASS DEFLECTOR

1 • UP 06959 HANDLE-Anti-Vibe 1

2 UP 04262 NUT-Wing, Washer Faced (1/4-20) 1

3 UP 06523 SCREW-Cap Hex Hd. 1

4 • UP 04891 DRIVESHAFT ASSY. 1

5 UP 04717 SHAFT-Flexible 1

4 • UP 05071 DRIVESHAFT ASSY. (

UT20832

5 UP 05072 SHAFT-Flexible 1

6 • UP 06970 GEARHEAD 1

8 UP 04404 Screw, Taptite Hex Hd. (10-24 x 1/2") 5

7 UP 04233 Screw-Hex Hd. (10-24 x 5/8") 2

9 UP 04126 WASHER-Flanged 1

10 UP 04128 ADAPTER-Shaft 1

11 • UP 04888 GRASS DEFLECTOR KIT 1

12 UP 04893 WING NUT 1

13 • UP 04890 BLADE-Cut-off 1

14 UP 03900 SCREW-Plastite. (10-14 X 3/4") 2

15 UP 04892 SCREW-Square Head 1

16 • DA 03001 A STRINGHEAD-Complete (.080") 1

17 UP 06567 HOUSING & EYELET (Dual Line) 1

18 • UP 00145 SPOOL & STRING (.080") 1

19 UP 06526 SPRING-Compression 1

20 UP 04273 RETAINER-Spool (R.H. Thread, Black) 1

No. Part No. Description Qty.

Warranty Flat Rate

Job Description Time/Hr.

2 .......Hand Tight

7 .......15-20 ........... 1.7-2.3

8 .......40-50 ........... 4.5-5.6

10 .......100-120 ....... 11.3-13.6

12 .......Hand Tight

14 .......30-40 ........... 3.4-4.5

FM10 .. Stringhead Assy.......................... .2

FN12... Driveshaft.................................... .3

FN13... Driveshaft Hsg. ........................... .3

FN15... Gearhead .................................... .3

FD20... Front Handle ............................... .2

Torque Specs

Item Required

No. In/Lbs Nm Loctite

Easy Reach ............... (UT20806)

Easy Reach ............... (UT20832,UT20837)

6/18/2001

1 •UP 06959 HANDLE-Anti-Vibe 1

2 UP 04262 NUT-Wing, Washer Faced (1/4-20) 1

3 UP 06523 SCREW-Cap Hex Hd. 1

4 • UP 05136 DRIVESHAFT ASSY. (Upper) 1

5 UP 06960 FLEXSHAFT 1

6 • UP 03839 COUPLER ASSEMBLY 1

7 UP 05137 KNOB 1

8 • UP 03851 DRIVESHAFT HOUSING (Lower) 1

9 UP 04541 SHAFT-Flex 1

10 UP 04352 DECAL-Warning 1

11 UP 04137 CLAMP 1

12 UP 04256 SCREW-Sems Hex (10-24 X 3/8") 1

13 •UP 06710 DEFLECTOR & BLADE KIT (55 Deg.) 1

14 UP 06523 SCREW-Cap Hex Hd. (10-24 X 2") 1

15 UP 03415 WASHER-Flat (1/4") 1

16 UP 03409 WASHER-Lock (1/4") 1

17 UP 04262 NUT-Wing, Washer Faced (1/4-20) 1

18 •UP 04119 BLADE-Cut-Off 1

19 UP 04159 SCREW-Mech. Hex Hd. (10-24 X 7/8") 2

20 UP 04150 NUT-Hex (10-24) 2

No. Part No. Description Qty.

SHAFT - SPOOL & STRING - GRASS DEFLECTOR

14 13

21 •DA 03001 A STRINGHEAD-Complete (.080") 1

22 UP 06567 HOUSING & EYELET (Dual Line) 1

23 • UP 00145 SPOOL & STRING (.080") 1

24 UP 06526 SPRING-Compression 1

25 UP 04273 RETAINER-Spool (R.H. Thread, Black) 1

No. Part No. Description Qty.

Warranty Flat Rate

Job Description Time/Hr.

2 ....... 5-25 ......... .6-2.8

12 ....... 15-25 ......... 1.7-2.8

17 ....... 5-25 ......... .6-2.8

20 ....... 30-40 ......... 3.4-4.5

FM10 .. Stringhead Assy.......................... .2

FN12 ... Driveshaft (Upper)...................... .3

FN13 ... Driveshaft Housing ..................... .3

FN16 ... Deflector...................................... .2

CD98 .. Coupler-Shaft .............................. .3

Torque Specs

Item Required

No. In/Lbs Nm Loctite

24 21

VersaTool .................. (UT20816,UT20838)

6/18/2001

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Recortadora de Homelite

Homelite

Homelite UT32601 Guía de configuración rápida

Homelite

Homelite VERSALITE UT41002 Manual de usuario

Homelite

Homelite VERSATOOL UT20811 Manual de usuario

Homelite

Homelite Trim N' Edge UT20833 Manual de usuario

Homelite

Homelite Easy Reach UT20749 Manual de usuario

Homelite

Homelite UT20739 Manual de usuario

Homelite

Homelite UT70123A Guía de configuración rápida

Homelite

Homelite UT22600A Manual de usuario

Homelite

Homelite UT32000 Guía de configuración rápida

Homelite

Homelite F3040 UT70131A Manual de usuario

Homelite

Homelite MightyLite UT21046 Manual de usuario

Homelite

Homelite UT21546 Manual de usuario

Homelite

Homelite UT32600 Cómo utilizar

Homelite

Homelite UT70127 Manual de usuario

Homelite

Homelite UT32600 Manual de usuario

Homelite

Homelite UT32600 Manual de usuario

Homelite

Homelite UT44180 Manual de usuario

Homelite

Homelite Easy Reach UT20837 Manual de usuario

Homelite

Homelite UT40502 Manual de usuario

Homelite

Homelite HLT26CD Manual de usuario

Homelite

Homelite UT20006 Guía de configuración rápida

Homelite

Homelite hht2655 Manual de usuario

Homelite

Homelite UT33601 Manual de usuario

Homelite

Homelite UT44121A Guía de configuración rápida

Manuales populares de Recortadora de otras marcas

MTD

MTD HT 51 E Manual de usuario

McCulloch

McCulloch T22 LS Manual de usuario

COCKRAFT

COCKRAFT PRO HL36-S Manual de usuario

Grizzly

Grizzly CT 1800 Li Manual de usuario

Peco

Peco Z Trimmer ZT-3000 Manual de usuario

Solo

Solo 116 Manual de usuario

Stiga

Stiga ST 1200 Manual de usuario

Echo

Echo GT-225 - 10-09 Manual de usuario

RedMax

RedMax BT17 Manual de usuario

GreenWorks

GreenWorks STA806 Manual de usuario

Parkside

Parkside PHSL 900 A3 Manual de usuario

Gardeo

Gardeo PRO GPTHT2560 Manual de usuario

Park

Park DT-810870 Manual de usuario

Worx

Worx WG209 Manual de usuario

Gardenline

Gardenline 43671/HTKS26 Manual de usuario

Makita

Makita 3710 Manual de usuario

Champion

Champion 100683 Manual de usuario

Stihl

Stihl FS 311 Manual de usuario
