BATTERY POWERED
LED SECURITY LIGHT
the bright way to do home security.
securit y
ES06572G
INSTALLATION INSTRUCTIONS
Mounting Screw
Light fixture
Mounting plate
Mounting Anchors
1
What's in the box
Parameter
1Illumination output: approx. 1000 lumens / 5000K
2Power supply: 3pcs D size dry batteries (not included)
3Detect distance: up to 30ft
x 2x 2
x 2
x 2
2
Warning
1. The packing contains small parts that could be swallowed by
children.
2. Keep the packaging material away from children and pets.
3. Do not look directly at the LED lights for any length of time.
4. This light fixture is NOT A TOY and is not suitable for use by
children.
5. We do not take responsibility if the instruction manual is not
followed correctly or if the product is handled improperly
resulting in damage to person or property.
Fixture can be wall mounted.
Recommended installation height: 6 - 8 feet above the ground.
Environment will affect the sensor range. It is recommended not to
mount the fixture near a heat source like an air conditioner, vent, or
furnace exhaust, or in a direction facing a light reflecting object.
The sensor detection distance may decrease lower than 15 feet in
certain special environments.
Location
Tools required for assembly (not included): phillips screwdriver,
safety goggles, power drill, and ladder.
Preparation
3
Installation
1Remove the mounting plate from the light fixture by pressing
down on the mounting plate tab. Slide the bracket down off the
light fixture.
2Open the battery case cover by loosening the screw (anticlock-
wise) of the battery case cover.
push down
4
3Insert three D size batteries (not included). Then close the battery
case cover and screw it tightly (clockwise)
Note: Make sure the polarity of the batteries is correct.
4If mounting to brick or concrete, drill two holes using a power drill
(not included) into the mounting surface.
Use the included mounting screws and anchors to fix the bracket
on the wall.
5
5Line up the light fixture with the mount bracket and slide the light
into the grooves.
1. Use only new alkaline D size batteries with 1.5V rating for
replacement.
Note: Replace batteries around every four months.
· Non-rechargeable batteries are not to be recharged.
· Do not mix old and new batteries.
· Do not mix alkaline, standard (carbon-zinc) or rechargeable
batteries.
· Exhausted batteries are to be removed from the product.
· Do not dispose of batteries in fire.
· Batteries should be recycled or disposed of as per state and local
guidelines.
· Batteries are to be inserted with the correct polarity.
Battery Replacement
FCC
6
Cleaning and Maintenance
To prolong the original appearance, clean the light fixture with a
soft, damp cloth. Do not use paints, solvents, or other chemicals
on this light fixture. They could cause a premature deterioration
of the finish.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
This device complies with FCC Part 15 of FCC Rules.
Warning
: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE
: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Get exclusive offers and deals
when you subscribe!
Thank you for choosing Home Zone Security!
We are here to support you every step of the way.
Please be sure to contact our customer support for troubleshooting
and register your product for additional benefits. Products must be
sold by an authorized reseller or distributor to be valid.
• Receive your extended warranty
• Get professional warranty support
• Be the first to hear the latest product news.
• Get exclusive deals delivered to you email.
Scan below for link:
homezonesecurity.com
support@homezone-usa.com
US: +1 888-782-5618
Register & Subscribe today to protect your investment and join our email list!
Why Register?
securit y
