USE AND CARE GUIDE

PORTER 52-INCH CEILING FAN

Questions, problems, missing parts? Before returning to the store,

call Home Decorators Collection Customer Service

8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday.

1-800-986-3460

HOMEDEPOT.COM/HOMEDECORATORS

THANK YOU

We appreciate the trust and condence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive

to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home

improvement needs. Thank you for choosing Home Decorators Collection!

Item #xxxx xxx xxx

Model #59252

UL Model #52-PORT

To view an instructional video on how to install this product:

1. Go to www.homedepot.com and enter either the Item or Model number, found in the top

right corner of the cover of this instruction manual, in the search eld.

2. Click on your product from the list of search results and click on the video link in the

“Product Overview” section.

Table of Contents ................................................................ 2

Safety Information............................................................... 2

Warranty ............................................................................... 3

Pre-Installation .................................................................... 3

Installation............................................................................ 6

Assembly.............................................................................. 7

Operation ........................................................................... 11

Care and Cleaning............................................................. 12

Troubleshooting................................................................. 12

1. To reduce the risk of electric shock, ensure the electricity has been

turned off at the circuit breaker or fuse box before you begin.

2. All wiring must be in accordance with the National Electrical Code

ANSI/NFPA 70-1999 and local electrical codes. Electrical installation

should be performed by a qualied licensed electrician.

3. The outlet box and support structure must be securely mounted and

capable of reliably supporting 35 lbs. (15.9 kg). Use only UL Listed

outlet boxes marked “Acceptable for Fan Support of 35 lbs. (15.9 kg)

or less.”

4. CAUTION: The fan must be mounted with a minimum of 7 ft (2.1 m)

clearance from the trailing edge of the blades to the oor.

5. Do not operate the reversing switch while the fan blades are in

motion. You must turn the fan off and stop the blades before you

reverse the blade direction.

6. Do not place objects in the path of the blades.

7. To avoid personal injury or damage to the fan and other items, use

caution when working around or cleaning the fan.

8. Electrical diagrams are for reference only. Light kits that are not

packed with the fan must be UL listed and marked suitable for use

with the model fan you are installing. Switches must be UL General

Use Switches. Refer to the instructions packaged with the light kits

and switches for proper assembly.

9. After making electrical connections, spliced conductors should be

turned upward and pushed carefully up into the outlet box. The

wires should be spread apart with the grounded conductor and the

equipment-grounding conductor on one side of the outlet box.

10. All setscrews must be checked and retightened where necessary

before installation.

WARNING: To reduce the risk of personal injury,

do not bend the blade brackets (also referred to as

anges) during assembly or after installation. Do not

insert objects in the path of the blades.

WARNING: To reduce the risk of re or electric

shock, do not use this fan with any solid-state speed

control device.

WARNING: To avoid possible electrical shock,

turn the electricity off at the main fuse box before

wiring. If you feel you do not have enough electrical

wiring knowledge or experience, contact a licensed

electrician.

WARNING: Electrical diagrams are for reference

only. Optional use of any light kit shall be UL-listed

and marked suitable for use with this fan.

Safety Information

Table of Contents

CAUTION: To reduce the risk of personal injury,

use only the screws provided with the outlet box.

CAUTION: To avoid personal injury or damage to the fan

and other items, use caution when working around or

cleaning the fan.

WARNING: To reduce the risk of re, electric shock

or personal injury, mount to outlet box marked

“Acceptable for fan support of 35 lbs. (15.9 kg) or

less”, and use screws provided with the outlet box.

WARNING: To reduce the risk of re or electric

shock, this fan should only be used with fan speed

control part no. AP-8RDL, manufactured by Dawnsun

Electronic Co., LTD.

3HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Pre-Installation

Warranty

SPECIFICATIONS

TOOLS REQUIRED

NOTE: These are approximate measures. They do not

include the amps and wattage used by the light kit.

Phillips

screwdriver

Flat blade

screwdriver

Adjustable

wrench

Electrical

tape

Wire

cutter

Step ladder

The supplier warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a

lifetime after the date of purchase by the original purchaser. The supplier also warrants that all other fan parts, excluding any glass or acrylic

blades, to be free from defects in workmanship and material at the time of shipment from the factory for a period of two years after the date

of purchase by the original purchaser. We agree to correct such defects without charge or at our option replace with a comparable or superior

model if the product is returned. To obtain warranty service, you must present a copy of the receipt as proof of purchase. All costs of removing

and reinstalling the product are your responsibility. Damage to any part such as by accident, misuse, improper installation, or by afxing any

accessories, is not covered by this warranty. Because of varying climatic conditions this warranty does not cover any changes in brass nish,

including rusting, pitting, corroding, tarnishing, or peeling. Brass nishes of this type give their longest useful life when protected from varying

weather conditions. A certain amount of “wobble” is normal and should not be considered a defect. Servicing performed by unauthorized persons

shall render the warranty invalid. There is no other express warranty. Home Decorators Collection hereby disclaims any and all warranties,

including but not limited to those of merchantability and tness for a particular purpose to the extent permitted by law. The duration of any

implied warranty which cannot be disclaimed is limited to the time period as specied in the express warranty. Some states do not allow a

limitation on how long an implied warranty lasts, so the above limitation may not apply to you. The retailer shall not be liable for incidental,

consequential, or special damages arising out of or in connection with product use or performance except as may otherwise be accorded by

law. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion or limitation may not apply to you.

This warranty gives specic legal rights, and you may also have other rights which vary from state to state. This warranty supersedes all prior

warranties. Shipping costs for any return of product as part of a claim on the warranty must be paid by the customer.

Contact the Customer Service Team at 1-800-986-3460 or visit www.HomeDepot.com/homedecorators.

Size Speed Volts Amps Watts RPM CFM Net

Weight

Gross

Weight Cu. Ft.

52 in.

Low

120

xxx xx xx xxxx

xx.xxlbs.

(x.x kg.)

xx.xx lbs

(x.x kg) x.xx cu.ft.Medium xxx xx xxx xxxx

High xxx xx xxx xxxx

Part Description Quantity

AA Blade attachment screws 16

BB Plastic wire connector 3

HARDWARE INCLUDED

NOTE: Hardware not shown to actual size.

Pre-Installation (continued)

AA BB

5HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Part Description Quantity

A Mounting plate 1

B Trim ring 1

C Fan-motor assembly 1

D Blade 5

Part Description Quantity

E Light kit tter assembly 1

F Light kit pan 1

G Glass bowl 1

H Receiver 1

I Remote control (battery included) 1

IMPORTANT: This product and/or components are

governed by one or more of the following U.S. Patents:

5,947,436; 5,988,580; 6,010,110; 6,046,416; 6,210,117

and other patents pending.

PACKAGE CONTENTS

Pre-Installation (continued)

Installation

MOUNTING OPTIONS

WARNING: To reduce the risk of re, electric shock or

personal injury, mount to outlet box marked “Acceptable

for fan support of 35 lbs. (15.9 kg) or less”, and use

screws provided with the outlet box. An outlet box

commonly used for the support of lighting xtures may

not be acceptable for fan support and may need to be

replaced. If in doubt, consult a qualied electrician.

If your ceiling fan does not have an existing UL-listed mounting

box, then install one using the following instructions:

□Disconnect the power by removing the fuses or turning off

the circuit breakers.

□Secure the outlet box directly to the building structure. Use

the appropriate fasteners and materials. The outlet box and

support structure must be securely mounted and capable of

reliably supporting 35 lbs. (15.9 kg). Use only UL Listed outlet

boxes marked “Acceptable for Fan Support of 35 lbs. (15.9 kg)

or less.” Do not use a plastic outlet box.

The illustrations below show two different ways to mount the

outlet box.

To hang your fan where there is an existing xture but no ceiling joist,

you may need an installation hanger bar as shown above

(available at any Home Depot store).

Outlet Box

Hanger Bar

7HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Assembly - Hanging the Fan

Hanging the fan-motor assembly

Attaching the fan to the electrical

box

□Turn the power off.

□Loosen the two mounting screws (GG) supplied with

the outlet box (EE), but do not remove the screws.

□Securely attach the mounting plate (A) to the outlet

box (EE) by sliding the mounting plate (A) over the

two mounting screws (GG) supplied with the outlet

box (EE). Pull the 120-volt supply wires (the black,

white and ground wires) out of the outlet box (GG)

and through the hole in the mounting plate (A) and lay

them to the side.

□Attach the trim ring (B) to the fan motor assembly (C)

from the opening of the motor housing. Make sure the

slots of trim ring (B) are on top.

□Carefully lift the fan-motor assembly (C) and hang the fan

motor assembly (C) on the hook of the mounting plate (A)

by utilizing one of the holes at the outer rim of the motor

housing so that it is securely suspended. Then connect

the wiring to your fan according to step 4 “Making the

Electrical Connections”.

NOTE: For better fan performance, make sure the

mounting plate is level. Additional washers (FF)

(not included) may be needed to insert between the

outlet box and mounting plate.

WARNING: To avoid possible electrical shock,

turn the electricity off at the main fuse box before

wiring. If you feel you do not have enough electrical

wiring knowledge or experience, contact a licensed

electrician.

Assembly - Hanging the Fan (continued)

Making the electrical connection

IMPORTANT: Use the plastic wire connectors (BB) supplied with

your fan. Secure the connectors with electrical tape and ensure

there are no loose strands or connections.

WARNING: Each wire nut supplied with this fan is designed to

accept up to one 12-gauge house wire and two wires from the

fan. If you have larger than 12-gauge house wiring or more

than one house wire to connect to the fan wiring, consult an

electrician for the proper size wire nuts to use.

□Spread the wires apart so that the green and whites are

one side of the outlet box and the black wire is on the other

side.

□Connect the green fan wires to the household ground

wire(this may be a green or bare wire) using a wire

connecting nut (BB).

□Connect the receiver (H) red or black wire to the household

black (hot) wire using a wire connecting nut (BB).

□Connect the receiver (H) white wire to the household white

(neutral) wire using a wire connecting nut (BB).

□Secure each wire connecting nut using electrical tap.

□Wire the receiver (H) to the fan wires by connecting the

molded adaptor plug from receiver (H) with molded adaptor

of the fan motor assembly (C) together.

Outlet box

in the ceiling (EE)

Green or bare wire

Receiver(H)

Red or Black

Black

White

Setting the code on the remote

control and receiver

NOTE: The frequencies on your receiver and hand unit have

been preset at the factory. Before installing the receiver,

make sure the dip switches on the receiver and hand unit

are set to the same frequency. The dip switches on the

hand unit are located inside the battery compartment.

NOTE: The battery will weaken with age and should be

replaced before leaking takes place as this will damage

the hand unit. Dispose of used battery properly and keep

the battery out of the reach of children.

□Remove the remote control (I) battery cover by pressing

rmly on the arrow and sliding the cover off.

□Slide the dip switches (ZZ) to your choice of either up or

down. The factory setting is up.

□Slide the dip switches (ZZ) on the receiver (H) to the same

position as set on the remote control (I).

□Install the 23A 12V battery (included).

□Replace the battery cover on the remote control (I).

□Insert the silicone rubber stopper (TT) into the hole on the

receiver (H) to cover the dip switches.

1 2 3 4

ON DIP

1 2 3 4

9HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

□Attach a blade (D) to the fan motor assembly (C) by inserting the

blade (D) into slots in the side of the fan motor assembly (C) and

aligning the three screws holes in the blade with the holes in

the center ywheel and secure with screws (AA).

□Make sure all the screws are rmly tightened.

□Repeat these steps for the remaining blades.

Installing the motor assembly

□Remove two of the four screws (located diagonally from

each other) (NN) from the top of the mounting plate (A)

and loosen the other two screws (NN).

□Align the two key slots in the top of the fan motor

assembly (C) with the two loosened screws (NN) on the

mounting plate (A). Push the fan motor assembly (C) up

and turn it clockwise to lock in the mounting plate (A).

Tighten the two screws.

□Install the two screws that were removed at the beginning

of this step into the remaining two holes and tighten the

four screws rmly.

□Install the trim ring (B) by aligning the ring’s slots with

the screws on the mounting plate (A). Rotate the ring

clockwise to lock in place.

Attaching the blades

Assembly - Attaching the Blades

Assembly - Hanging the Fan (continued)

Installing the receiver

□Push the receiver (H) into the bracket on the mounting

plate (A) (as shown, at side towards the ceiling).

WARNING: To reduce the risk of re or electrical shock,

remember to disconnect power. The electrical wiring must meet

all local and national electrical code requirements. The electrical

source and fan must be 110/120 volt, 60HZ. Do not use this

product in conjunction with any variable wall control. Incorrect

wire connection can damage this receiver.

CAUTION: If other fan wires are different color, have this unit

installed by a licensed electrician.

CAUTION: Do not install the receiver in a damp location or

immerse in water (For indoor use only). Do not pull on or cut

the receiver leads shorter. Do not drop or bump the unit.

Receiver (H)

Assembly - Attaching the Light Kit

Attaching the light kit tter assembly Installing the glass bowl

□Remove one screw (PP) from the light kit pan (F) and loosen

but do not remove the other two screws.

□Connect the wires from the light kit tter assembly (E) to the

wires from the light kit pan (F) by connecting the molded

adaptor plugs together. Carefully tuck all wires and splices into

the switch cup.

□Push the light kit tter assembly (E) up to the light kit fan

(F) so that the two loosened screw heads t into the keyhole

slots. Turn the light kit tter assembly (E) clockwise.

□Re-install the screw (PP) that was removed in step 1.

□Make sure all the screws are rmly tightened.

□Place the glass bowl (G) into the light kit pan (F), aligning the

three at areas on the top ange of the glass bowl (G) with the

raised dimples in the light kit pan.

□Turn the glass bowl (G) clockwise until it stops.

9 10

CAUTION: To reduce the risk of electric shock, disconnect

the electrical supply circuit to the fan before installing the

light kit.

WARNING: Allow the glass bowl to cool completely before

removing.

CAUTION: Make sure the power is off before attaching or

removing the glass bowl.

□Remove one screw (OO) from the black bracket below the fan

motor assembly (C), and loosen but do not remove the other two

screws.

□Connect the 9-pin plug exiting the bottom of the fan motor

assembly (C) to the 9-pin plug from the light kit pan (F). Be sure

the plug connections snap together completely.

□Push the light kit pan (F) up to the fan motor assembly (C) so that

the two loosened screw heads t into the keyhole slots. Turn the

light kit pan (F) clockwise.

□Re-install the screw (OO) that was removed in step 1.

□Make sure all the screws are rmly tightened.

Installing the light kit pan

IMPORTANT: It is critical to attach the light kit pan

using quick connector. The fan will not operate unless

the light kit pan is connected to the fan.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Admirador de Home Decorators Collection

Home Decorators Collection

Home Decorators Collection EMSWELL 52-INCH Manual de usuario

Home Decorators Collection

Home Decorators Collection BETHEL 52-BETL Manual de usuario

Home Decorators Collection

Home Decorators Collection AM909-NI Manual de usuario

Home Decorators Collection

Home Decorators Collection KYLAND YG612-BN Manual de usuario

Home Decorators Collection

Home Decorators Collection EASTON N381B-BN Manual de usuario

Home Decorators Collection

Home Decorators Collection PINE MEADOWS 52-ALLE Manual de usuario

Home Decorators Collection

Home Decorators Collection Chartwell Manual de usuario

Home Decorators Collection

Home Decorators Collection GRENADA YG522-BN Manual de usuario

Home Decorators Collection

Home Decorators Collection REINHARDT 59204 Manual de usuario

Home Decorators Collection

Home Decorators Collection DANIEL 52179 Manual de usuario

Home Decorators Collection

Home Decorators Collection PRATT 56044 Manual de usuario

Home Decorators Collection

Home Decorators Collection MOLIQUE AM128-NI Manual de usuario

Home Decorators Collection

Home Decorators Collection NORTHAMPTON AM592-EB Manual de usuario

Home Decorators Collection

Home Decorators Collection 68681 Manual de usuario

Home Decorators Collection

Home Decorators Collection YG825C-BN Manual de usuario

Home Decorators Collection

Home Decorators Collection RYLAND AK433A-MBK Manual de usuario

Home Decorators Collection

Home Decorators Collection SANDY COVE 52-GLH Manual de usuario

Home Decorators Collection

Home Decorators Collection 56006 Manual de usuario

Home Decorators Collection

Home Decorators Collection PADGETTE Manual de usuario

Home Decorators Collection

Home Decorators Collection MONTEL Manual de usuario

Home Decorators Collection

Home Decorators Collection HERALD AM429-BN Manual de usuario

Home Decorators Collection

Home Decorators Collection Kayden 52060 Manual de usuario

Home Decorators Collection

Home Decorators Collection CARRINGTON YG419-BN Manual de usuario

Home Decorators Collection

Home Decorators Collection AVONBROOK 59256 Manual de usuario

Manuales populares de Admirador de otras marcas

ELTA FANS

ELTA FANS H03VV-F Manual de usuario

Hunter

Hunter 20714 Manual de instrucciones

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manual de usuario

Hunter

Hunter Caraway Manual de instrucciones

Panasonic

Panasonic FV-15NLFS1 Manual de usuario

Kompernass

Kompernass KH 1150 Manual de usuario

VES

VES FALA100/12V/TR Manual de usuario

Vertiv

Vertiv Liebert DCD Manual de usuario

Westinghouse

Westinghouse GFP Series Manual de usuario

Venmar

Venmar KUBIX HRV PLUS Series Manual de usuario

Maico

Maico ECR 31 Manual de usuario

Sonnenkonig

Sonnenkonig Dinky Manual de usuario

S&P

S&P ECOWATT HXBR Manual de usuario

Wider

Wider IMP03369BH Manual de usuario

Panasonic

Panasonic F-60DHN Manual de usuario

Hinkley

Hinkley HIGHLAND Manual de usuario

Broan

Broan 766BN Manual de usuario

Premium

Premium PFS16022 Instrucciones de montaje
