HOMCOM 830-407 Guía de instalación

ASSEMBLY & INSTRUCTION MANUAL

IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY

INbkd003_US_830-407_830-407V01_830-407V02

INbkd003_US_830-407_830-407V01_830-407V02

PART

LIST

A

B

CD

E

F

G

I

H

01

D

D

D

B

A

AA

A

02

C

03

E

F

I

MODE

Transmission distance: 20M

G

H

Done

Change the timing function with press button on remote

controller:

Change the timing function with press button on remote controller:

No automatic timing function after power-on the lighting chain.

There are 2 different modes:

1) press 1 x TIMER: the product will ﬂashing in red color for 3 times, then enter timer

mode (4 hrs on + 20hrs off), the light on continuously for 4 hrs then turn off

automatically, it will light on again after 20 hrs by itself.

2) press 2 x TIMER: the product will ﬂashing in green color for 3 times, then enter

timer mode (6 hrs on + 18hrs off), the light on continuously for 6 hrs then turn off

automatically, it will light on again after 18 hrs by itself.

Caution: Timing function without memory, Need to re-set the timing function after power

off.

Function list:

1) ON/OFF

2) AUTO MODE

3) TIMER

4) MODE : there are 18 different light

functions with the press button of MODE

1.Auto changes in 6 colors

2.Gradual change + crazy ﬂashing in 6 colors

3.color rotation in 4 colors

4.Auto stacking (4 different ways)

5.Stacking and Whirling

6.Stacking in 2 colors

7.Alternate ﬂashing in 2 colors

8.color rotation in 2 colors

9.Alternate chasing

10.Alternate chasing in 2 colors

11.color rotation in 3 colors

12.4 colors rotation with stacking effect

13.Auto diffusing and contracting

14.Dripping

15.Flash

16.Beating

17.Alternate ﬂashing

18.Gradual change with 7 colors
