Hohem ISteady MT2 Manual de usuario

User Manual • Uživatelský manuál •

Užívateľský manuál • Használati utasítás •

Benutzerhandbuch

English

3 –26

Čeština

27 –50

Slovenčina

51 –74

Magyar

75 –98

Deutsch

99 –122

Warning & Disclaimer

Thank you for purchasing this product. By using this product, you herby signify that you

have read this disclaimer and warning carefully. In addition, you understand and agree

to abide by the terms and conditions herein. You acknowledge that you are solely

responsible for your own conduct while interacting with this product, and for any

consequences thereof. You agree to use this product only for purposes that are proper

and in accordance with all applicable laws, rules, and regulations, and all terms,

precautions, practices, policies, and guidelines Alza has made and may make available.

Alza accepts no liability for damage, injury, or any legal responsibility incurred directly or

indirectly from the use of this product. The user shall observe safe and lawful practices

including, but not limited to, those set forth in this document.

This document and all other collateral documents are subject to change at the sole

discretion of Alza. For up-to-date product information, visit www.alza.cz and click on the

product page for this product.

In case you need assistance with the product, feel free to contact Alza using the

provided means:

󲐜󲐝󲐞󲐟󲐠www.alza.co.uk/kontakt

✆+44 (0)203 514 4411

Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz

Important notes:

•Mount your mobile phone before powering on iSteady V2S.

•If no mobile phone is detected or the motor is overloaded because phone is not

balanced well, the gimbal will shut down after a warning beeping.

Package Contents

Before using this product, please carefully check that all the following items are included

in the product package. In case that any item is found missing, please contact Alza

customer line.

iSteady MT2

Fill light with AI sensor

(sold separately)

Tripod

L-Bracket (Arca-Swiss)

Camera quick release plate

(arca-swiss)

Mobile phone quick

release plate (arca-swiss)

Adapter for action camera

Thumb screw wrench

Thumb screw ×2

Type-A to Type-C stabilizer

charging cable

Type-C to Type-C camera

charging & control cable

Type-C to Micro USB

camera charging & control

cable

Type-C to Mini USB camera

charging & control cable

Type-C to Multi camera

control cable

Type-C to TRRS (2.5mm)

camera control cable

Type-C to TRS (2.5mm)

camera control cable

Type-C to TRS (3.5mm)

camera control cable

Storage bag

iSteady V2S Overview

1. Support mount

2. Pan axis arm

3. Pan axis arm latch

4. Pan axis motor

5. Roll axis arm

6. Roll motor

7. Multifunctional control wheel

8. Buttons for A-B motion

9. Joystick

10. Handle

11. ¼”-20 UNC port

12. Type-C reverse charging port

13. Type-C camera control port

14. Roll axis arm latch

15. Roll axis motor lock switch

16. OLED display

17. M (Mode) button

18. Zoom lever & shutter button

19. ¼”-20 USC port

20. Tilt motor

21. Tilt motor lock switch

22. Tilt axis arm

23. Vertical tilt lock

24. USB-C charging port

25. Positioning hole

26. Power button

27. ¼”-20 UNC port

28. Magnetic fill light with AI vision

sensor (sold separately)

29. Mount safety lock

30. Mount latch

31. Pan motor lock switch

32. Trigger

33. Strap hole

Battery & Charging

Please, fully charge the iSteady MT2 before using it for the first time.

To charge the iSteady MT2, connect a USB adapter (not included, choose 5V/2A for

better results) into the charging port with the provided Type-A to USB-C charging cable.

Charging display: Charging is completed once the light stops flashing and the OLED

screen shows the battery icon is full.

Reverse Charging

For smartphones, cameras, and action cameras. Connect the charging cable to Type-C

reverse charging port of iSteady MT2.

Download Hohem Joy app

Scan the QR code or search “Hohem Joy” in the App Store or Google Play. The Hohem Joy

app required iOS 11.0 or later, or Android 6.0 or later.

Mounting & Balancing

Attaching the Tripod

Attach the tripod to the bottom of the iSteady MT2 handle. Unfold the tripod and place

the iSteady MT2 on a flat surface.

Mounting the Camera

Before mounting a camera, please unlock the roll and tilt motor lock switched to unlock

the axes. Unfold the support mount base and roll axis arm. Then lock roll motor and tilt

motor for installation of a camera.

Next, mount the quick release plate. Mount the camera onto the camera quick release

plate and tighten the screw.

If you are using a long-focus lens and the camera is front-heavy, you can mount the

screw with the camera at the end of the slot (as shown on the right), which makes sure

more space to adjust the centre of gravity for horizontal balancing. It is required to

righten the screw in case of stabilizer shaking when the stabilizer is powered on.

After that, loosen the L-bracket with the thumb screw

wrench (magnetically attached to the L-bracket). Adjust the L-

bracket according to the width of the camera and tighten the

screw after fitting properly.

Attach the camera with the quick release plate onto the L-bracket. Align the short arm of

L-bracket against the handle side of the camera.

Next comes mounting onto the stabilizer.

Unlock the mount latch and install the camera with L-bracket on the mount. Lock the

mount latch to ensure that the camera is tightly installed on the stabilizer.

How to quickly detach the camera from stabilizer:

Unlock the mount latch and remove the camera and quick release plate as a whole while

holding down the mount safety lock.

1. Unlock the

mount latch.

2. Holding down the

mount safety lock.

Connect the stabilizer to the camera with a control cable to enable control of the shutter

and other functions from the stabilizer.

•Type-C to Type-C, Type-C to Micro USB, and Type-C to Mini USB are camera

charging cables. These cables can also be used for camera control.

•Type-C to Multi is the control cable exclusively for Sony cameras, it allows to

control certain Sony cameras to start/stop the filming.

•Type-C to TRRS (2.5mm), Type-C to TRS (2.5mm), and Type-C to TRS (3.5mm) are

camera control cables.

Rotate the camera with L-bracket 90° to switch to vertical shooting mode. Insert the L-

bracket into the mount slot and lock the mount latch.

iSteady MT2 offers dual-directional vertical installation with the L-bracket, allowing you

to install it in the desired orientation based on your specific requirements.

Scan the QR code to check the list of

camera compatibility and control

operations.

Install the L-bracket on the left side. You can use the flip-out screen to view the

composition.

Install the L-bracket on the right side. You can attach accessories to the hot shoe facing

outward.

Mounting a Phone

Mounting in Landscape Mode

Mount the phone on the phone quick release plate in the middle. Attach the phone with

the quick release plate onto the L-bracket and lock the quick release plate latch. Insert

the L-bracket into the mount slot, and lock the mount latch.

Mounting in Portrait Mode

Rotate the phone with L-bracket 90° to switch to vertical shooting mode. Insert the L-

bracket into the mount slot, and lock the safety lock latch.
