PRECISION MOLDED

STAND UP PADDLEBOARD

MANUAL AND WARRANTY

INFORMATION

Thank you for choosing a Hobie

Stand Up Paddleboard

How to Use

• Assume a comfortable stance with your feet positioned roughly shoulder width apart knees

slightly bent in a relaxed upright stance, shoulders back, looking straight ahead.

• Paddle grip. Place your top hand on end of handle and your bottom hand approximately 24” down

the shaft of paddle. Paddle in a comfortable forward motion, with arms slightly bent.

• To turn left concentrate paddling on the right hand side of the board to turn right concentrate

paddling on the left hand side of the board.

Safety

Paddle sports can be dangerous and physically demanding. Users of this product should understand

that participating in stand up paddling can result in serious injury or death. Observe all applicable

watercraft laws, and use common sense

GENERAL PADDLING INFORMATION

Start with an unmatched 63 years of revolutionary board building experience, Add the racing and

surﬁng DNA of Hobie’s team riders. The ﬁnal result is a desire to push development boundaries,

and the results are unequaled.

The Hobie Stand Up Paddle Development Team has worked tirelessly developing a line of

boards that allows everyone the opportunity to explore and experience the sport of stand up

paddleboarding. From the elite racer to the paddle surfer to the family that simply enjoys being

on the water, Hobie’s line up of high quality stand up paddlerboards oers a board to ﬁt your

stand up paddle lifestyle.

Hobie’s simple goal of making things better has never changed, and remains at the core of our

team of professional riders and board designers.

• View more stand up paddle instructional videos on line

http://www.hobie.com/stand-up-paddleboards/support

HEAD HEIGHT

12”-18”

FOWARD

Safety Check list

• Always paddle with others.

• Always wear a leash attaching you to the board.

• Wear a Coast Guard approved personal otation

• device

• Always wear protective clothing.

• Always paddle in safe conditions.

• Be aware of changing weather conditions.

• Avoid paddling in off shore wind or windy

conditions.

• Do not exceed your paddling ability; be aware of

your limitations.

• DO NOT use alcohol or mind altering drugs prior

to or while using this product.

Paddle Height Paddle Position

At Hobie we strive for the best overall strength to weight ratio utilizing our dierent

construction methods to fulﬁll current SUP demands. Our constructions are designed

to ﬁt a variety of styles of SUP paddling and budgets.

Molding our boards is very important to Hobie as it guarantees that the shapes and

designs are replicas of our master shapes. Each molded design has been paired with

the construction we feel the board is best suited for with our eyes always focused in on

Strength, Weight, Price and most important Performance.

Below is our S-W-PR scale that will help you ﬁnd the board and construction that best

meets your needs. All of our boards are very strong and light— most are not over 30

lbs. All ﬁn boxes, handles, hold downs and leash plugs are installed into high density

foam for extra strength in all of our molded boards. In all SUP manufacturing there are

big variations of strength, weight, price and performance.

CONSTRUCTION STRENGTH WEIGHT PRICE RANGE

HCX S4 W3 $

DMX S1 W5 $

BCX S3 W3 $$

BCX4 S2 W3 $$$

BCX4R S5 W1 $$$

STRENGTH-WEIGHT-PRICE RATIO (S-W-PR)

Strength = S1 (Durable) to S5 (less Durable)

Weight = W1 (lighter) to W5 (Heavier)

BOARD CONSTRUCTION

STEP 1

Remove ﬁn screw and

screw base from ﬁn

STEP 2

Screw ﬁn screw and base

together

STEP 3

Slide ﬁn screw and base

into ﬁn slot

STEP 4

Slide ﬁn screw and screw

base to the rear of ﬁn box.

STEP 5

Remove ﬁn screw from

screw base.

STEP 6

Insert ﬁn into ﬁn slot in the

middle of the ﬁn box and

slide forward

STEP 7

Line up the hole in the

base of the ﬁn with the

screw base inside the box

STEP 8

insert screw into ﬁn and

screw base and tighten.

CENTER FIN INSTALLATION

STEP 1

Fin key is located in the

center ﬁn box

STEP 2

Back out the ﬁn screw

until side ﬁn box is clear

STEP 3

Insert ﬁn with ﬂat side

toward the center of the

board and slide the ﬁn fully

back in the box and then

lever the front of the ﬁn

down into the box.

STEP 4

Tighten screw snuggly

“DO NOT OVER TIGHTEN“

SIDE FIN INSTALLATION

TROUBLESHOOTING: CENTER FIN FIT

On Ocaasion, there may be a ﬁt issue with the center ﬁn, either too tight or too loose. This

is not an uncommon problem and can be easily ﬁxed

Tight Fin

Take the center ﬁn as shown, and gently use a sanding block

with 60 grit sandpaper ( recommended) or equivilent.

Sand at a slight angle taking more material o at the base of the

ﬁn until edge becomes slightly beveled. Do this 4-5 times and

then try to insert the ﬁn again. Repeat as necessary. Be sure to

only sand the base area of the ﬁn that ﬁts into the ﬁn box

Loose Fin

Take the center ﬁn as shown, and place a piece of masking tape

or equivilent on the ﬁn as shown.

(Some boards do not have side ns)

2 WAY V - VENTING SYSTEM

Hobie has created a unique two-way vent system that equalizes

pressure due to temperature or altitude variation. Hassle free, no

unplugging, screwing or unscrewing required.

• Upon ﬁrst use, be sure to check that the vent cap is tight.

Tighten vent using a quarter or large screwdriver

• THERE IS NO NEED TO UNSCREW VENT PRIOR, DURING OR

AFTER USE.

Attachment points are

molded into the surface of

the board

Be sure that all loops or

hooks are securley under

the metal bar inside of the

attachment point

MOLDED ATTACHMENT POINTS

Some molded epoxy SUPs come with built in attachment points

These inserts are molded in the boards to allow the user to attach or tie down items such as

coolers, ﬁshing equipment, etc

These attachment points are intended on tying items down to your board.

DO NOT USE THESE TO TIE BOARD TO VEHICLES OR TO TOW

HOBIE 3:1 INTEGRATED HANDLE

HHOBIE 3:1

INTEGRATED

HANDLE 3 in 1 Design

2 Way V Vent

Ergonomic Hand Hold

Integrated Security

Bar

for locks INTEGRATED SECURITY BAR

A high strength stainless steel bar has been built in to the H3

handle. This allows the board to be secured using a simple

cable lock

ERGONOMIC HAND HOLD

Contour molded hand hold designed for easy access and a

secure and comfortable grip.

Ergonomic Hand Hold

Contour molded handhold designed for easy

access and a secure and comfortable grip

HOBIE STAND UP PADDLEBOARD REGISTRATION AND INFORMATION CARD

First Name Last Name

Address

Store Where Purchased Date Purchased

State / Province Zip / Postal CodeCity

EmailCountry

Model

Age of Primary User

Gender M F

• After use rinse with fresh water.

• Keep the board clean and dry for

extended storage of board.

• Store indoors in a dry environment.

• Store the board pad down avoiding

direct sunlight.

• Avoid extreme heat or extreme cold for

extended periods of time.

• Avoid hitting sharp objects; this may

cause damage to the skin and core of

the board. If this occurs remove board

immediately from water and consult a

professional epoxy repair person.

• Do not stand on the board on land or

run the ﬁns or board into the sand or

obstacles while in use.This can cause

severe damage to the board and in box.

WARRANTY REGISTRATION FORM

Hobie Stand Up Paddleboards is collecting this information in order to serve our customers

better. We will not sell or trade your personal information with any other business or

organization. Void in any state where prohibited

• Online Registration - http://www.hobie.com/stand-up-paddleboards/support

• Mail in Registration - Remove completed card at perforation, ax postage and mail

Warning! Repair with Epoxy Resin only.

DO NOT USE Polyester Resins or Bondo for repairs.

BASIC CARE AND MAINTENANCE

Hobie Stand Up Paddleboards provides a limited one year board warranty.

Your warranty registration card is packaged with this owner’s manual or available online and should be completed

and returned within 30 days of the date of purchase. If you have problems with your board contact your dealer rst.

If you need further assistance, contact Hobie Stand Up Paddleboards. To help process any warranty problems,

please complete your warranty card on line or mail it directly to Hobie Stand Up Paddleboards.

Hobie warrants each stand up paddlboard to be free from defects in materials and workmanship for the period listed

below. Hobie Stand Up Paddleboards will repair or, at its discretion, replace defective parts.

The warranty period for the board is one year

This warranty does not cover:

• Normal wear and discoloration.

• Damage caused by abuse or failure to perform normal maintenance.

• Damage caused by hitting submerged objects or beaching

• Damage caused by mooring or storing board in water.

• Damage caused by alterations or modications.

• Transportation of board or parts to Hobie Stand Up Paddleboards or its dealers.

• Any board used as a rental or placed in commercial service.

• Any other consequential damage, incidental damages or incidental expenses, including damage to property.

Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above

limitation may not apply to you.

To Obtain Warranty Service: Within 30 days of discovering a defect, take your board, along with the proof of

purchase (sales receipt) to the authorized Hobie Stand Up Paddleboard dealer from whom you purchased your

board, unless you have moved or are traveling. In that case, take it to the nearest authorized Hobie Stand Up

Paddleboard Dealer.

Implied Warranties: Any implied warranties, including implied warranty of merchantability and tness for a particular

purpose, shall be no longer than the duration of this expressed warranty. Some states do not allow limitations on

how long an implied warranty lasts, so the above limitations may not apply to you. Hobie Stand Up Paddleboards

makes no expressed warranties in addition to this limited warranty. Hobie Dealers have no authority to make

warranties on behalf of Hobie Stand Up Paddleboards in addition to, or inconsistent with, those stated herein.

To the extent any provision of this warranty is prohibited by Federal, State or Municipal law and cannot be

preempted, it shall not be applicable. This warranty gives you specic legal rights.

WARRANTY

HOBIE STAND UP PADDLEBOARDS

32921 Calle Perfecto #B

San Juan Capistrano, CA 92675

USA

Place

Postage

Here
