Hobart Hood XVX Manual de usuario

Expert Series Auto-Darkening Helmets

Model: XVX

OM-240 362B

2008−11

For more information, visit www.HobartWelders.Com

TABLE OF CONTENTS

SECTION 1 −SAFETY PRECAUTIONS −READ BEFORE USING 1. . . . . . . . . . . . . . . . . . . . . . . .

1-1. Symbol Usage 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-2. Hazards 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 2 −SPECIFICATIONS 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 3 −OPERATING INSTRUCTIONS 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-1. Helmet Controls 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-2. Reset Button And Low Battery Indicator 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-3. Lens Delay Control 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-4. Variable Shade Control (No. 9 −13) 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-5. Sensitivity Control 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 4 −ADJUSTING HEADGEAR 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 5 −REPLACING THE LENS COVERS 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-1. Replacing Outside Lens Cover 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-2. Replacing Inside Lens Cover 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 6 −REPLACING THE BATTERY 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 7 −INSTALLING OPTIONAL MAGNIFYING LENS 11. . . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 8 −MAINTENANCE 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 9 −TROUBLESHOOTING 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 10 −PARTS LIST 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 11 −LIMITED WARRANTY 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

OM-240 362 Page 1

SECTION 1 −SAFETY PRECAUTIONS −

READ BEFORE USING

Protect yourself and others from injury — read and follow these precautions.

1-1. Symbol Usage

This group of symbols means Warning! Watch

Out! ELECTRIC SHOCK, MOVING PARTS,

and HOT PARTS hazards. Consult symbols

and related instructions below for necessary

actions to avoid the hazards.

.Indicates special instructions.

DANGER! −Indicates a hazardous

situation which, if not avoided, will

result in death or serious injury. The

possible hazards are shown in the

adjoining symbols or explained in

the text.

NOTICE −Indicates statements not related to

personal injury.

Indicates a hazardous situation

which, if not avoided, could result in

death or serious injury. The possible

hazards are shown in the adjoining

symbols or explained in the text.

1-2. Hazards

ARC RAYS can burn eyes and skin.

Arc rays from the welding process produce intense visible and invisible (ultravio-

let and infrared) rays that can burn eyes and skin. Sparks fly off from the weld.

DWear a welding helmet fitted with a proper shade of filter to protect your

face and eyes when welding or watching (see ANSI Z49.1 and Z87.1 listed

in Safety Standards). Refer to Shade and Sensitivity charts in Sections 3-4

and 3-5.

DWear approved safety glasses with side shields under your helmet.

DUse protective screens or barriers to protect others from flash and glare;

warn others not to watch the arc.

DWear protective clothing made from durable, flame-resistant material

(leather and wool) and foot protection.

WELDING HELMETS do not provide unlimited eye, ear and

face protection.

DUse impact resistant safety spectacles or goggles and ear protection at all

times when using this welding helmet.

DDo not use this helmet while working with or around explosives or

corrosive liquids.

DDo not weld in the overhead position while using this helmet.

DInspect the auto-lens frequently. Immediately replace any scratched,

cracked, or pitted cover lenses or auto-lenses.

NOISE can damage hearing.

Noise from some processes or equipment can damage hearing.

DWear approved ear protection if noise level is high.

OM-240 362 Page 2

SECTION 2 −SPECIFICATIONS

Viewing Field 97 x 60mm/3.875 x 2.375 in

Reaction Time 0.0000500sec (1/20,000)

Available Shades Darkened State: No. 9 −No. 13 / Light State: No. 4

provides continuous UV and IR protection

Sensitivity/Grind Mode Control Adjusts for varying ambient light and welding arc

Delay Control Slows lens dark-to-light state between 0.1 and

1.0 seconds

Automatic Power Off Shuts lens Off 15−20 minutes after last arc is struck

Low Battery Indicator Red LED light illuminates to indicate 2−3 days

remaining battery life

Power Supply CR2450 Lithium Batteries (Hobart Part No. 770 284)

Sensors Independent/Redundant (Four)

Operating Temperature 14_F to 131_F / −10_C to +55_C

.When stored in extremely cold temperatures, warm

helmet to ambient temperature before welding.

Storage Temperature −4_F to 158_F / −20_C to +70_C

.When stored in extremely cold temperatures, warm

helmet to ambient temperature before welding.

Total Weight 510.3 g (1 lb 2oz)

Standards ANSI Z87.1-2003 and DIN/CSA/TUV

Warranty 2 years from date of purchase (see Section 11)

.The helmets in this manual are covered by one or more of the following patents:

U.S. Patent −No. 6,552,316, No. 6,483,090, No. 6,614,409

U.S. Patent Application −No. 29/223,100, No. 11/053,977

DE. Patent −No. 199 59 944 C2, No. 199 59 945 C2

FR. Patent −No. 9916004

OM-240 362 Page 3

SECTION 3 −OPERATING INSTRUCTIONS

3-1. Helmet Controls

1 Reset Button (See Section 3-2)

2 Low Battery Indicator

(See Section 3-2)

3 Variable Shade Control (See

Section 3-4)

4 Sensitivity Control

(See Section 3-5)

5 Lens Delay Control

(See Section 3-3)

123 4 5

804 847

OM-240 362 Page 4

3-2. Reset Button And Low Battery Indicator

.The auto-darkening lens turns on

(darkens) automatically when

welding begins and turns off 15 −

20 minutes after welding stops.

1 Reset Button

Press Reset button to check if the lens

is working properly.

When the Reset button is pressed, the

lens should darken twice and return to

the clear state. Do not use the helmet

if the lens does not function as de-

scribed. (See Section 9, Trouble-

shooting.)

2 Low Battery Indicator

The low battery indicator lights when

2−3 days of battery life remain.

If battery power is low, replace with

CR2450 lithium batteries (2 required)

(Hobart Part No. 770 284) (see Sec-

tion 6).

1 2

3-3. Lens Delay Control

1 Lens Delay Control

The lens delay control is used to ad-

just the time for the lens to switch to

the clear state after welding.

The delay is particularly useful in

eliminatingbright after-rays present

in higher amperage applications

where the molten puddle remains

bright momentarily after welding.

Lens delay adjusts from min (0.10

second) to max (1.0 second.).

OM-240 362 Page 5

3-4. Variable Shade Control (No. 9 −13)

1 Variable Shade Control

(No. 9 −13)

Use the control to adjust the lens

shade in the darkened state. Use

the table below to select proper

shade control setting based on

your welding process.

Start at shade 12 and adjust lighter

to suit the welding application and

your personal preference.

Application Welding Arc Current in Amperes Protective Shade No.

Stick Electrodes Less than 40

40−80

80−175

175−300

300−500

MIG Less than 100

100−175

175−300

300−500

Gas Tungsten Arc Welding

(TIG)

Less than 50

50−100

100−200

200−400

Air Carbon Less than 500

500−700

Plasma Arc Cutting 60−150

150−250

250−400

Plasma Arc Welding Less than 50

50−200

200−400

OM-240 362 Page 6

3-5. Sensitivity Control

1 Sensitivity Control

Weld Mode

Use control to make the lens more respon-

sive to different light levels in various weld-

ing processes. Use a Mid-Range or

30−50% sensitivity setting for most ap-

plications.

It may be necessary to adjust helmet sensi-

tivity to accommodate different lighting con-

ditions or if lens is flashing On and Off. Ad-

just helmet sensitivity as follows:

.Adjust helmet sensitivity in lighting con-

ditions helmet will be used in.

STurn sensitivity control to lowest

setting.

SPress Reset button to turn helmet On.

Helmet lens will darken twice and then

clear.

SFace the helmet in the direction of use,

exposing it to the surrounding light con-

ditions.

SGradually turn sensitivity setting clock-

wise until the lens darkens, then turn

sensitivity control counterclockwise

until slightly past setting where lens

clears. Helmet is ready for use. Slight

readjustment may be necessary for

certain applications or if lens is flashing

on and off.

Grind Mode

.Do not weld in the Grind mode; the lens

will not darken.

To use the Grind mode, turn the Sensitivity

control clockwise to the far right position

(Grind). To resume welding, return the con-

trol to the desired sensitivity setting.

Recommended Sensitivity Settings

Stick Electrode Mid-Range

Short Circuiting (MIG) Low/Mid-Range

Pulsed & Spray (MIG) Mid-Range

Gas Tungsten Arc (TIG) Mid/High-Range

Plasma Arc Cutting/Welding Low/Mid-Range

Grind Mode Grind Position −Far Right (Clockwise)

OM-240 362 Page 7

SECTION 4 −ADJUSTING HEADGEAR

.There are four headgear adjust-

ments: headgear top, tightness,

angle adjustment, and distance

adjustment.

1 Headgear Top

Adjusts headgear for proper depth

on the head to ensure correct bal-

ance and stability.

2 Headgear Tightness

To adjust, push in the adjusting knob

located on the back of the headgear

and turn left or right to desired tight-

ness.

.If adjustment is limited, it may be

necessary to remove the com-

fort cushion.

3 Distance Adjustment

Adjusts the distance between the

face and the lens. To adjust, loosen

both outside tension knobs and

press inward to free from adjustment

slots. Move forward or back to de-

sired position and retighten. (Both

sides must be equally positioned for

proper vision.)

4 Angle Adjustment

Four pins on the right side of the

headband top provide adjustment

for the forward tilt of the helmet. To

adjust, loosen the right outside ten-

sion adjustment knob then lift on the

control arm tab and move it to the de-

sired position. Retighten tension ad-

justment knob.

.When using the back distance

adjustment positions, only the

back three angle adjustment

pins can be used.

804 118

OM-240 362 Page 8

SECTION 5 −REPLACING THE LENS COVERS

5-1. Replacing Outside Lens Cover

!Never use the auto-darkening

lens without the inside and

outside lens covers properly

installed. Welding spatter will

damage the auto-darkening

lens and void the warranty.

1 Front Lens Holder

2 Release Points

3 Lens Cover

4 Gasket

Remove front lens holder by press-

ing release points and pulling the

holder away from the helmet.

Remove lens cover and gasket from

the holder. Replace lens cover and

reinstall gasket and lens in holder.

Reinstall holder in helmet.

.Be sure the flat side of lens

cover gasket faces the lens cov-

er holder.

8804 814 / 804 816

Be sure flat side of gasket

faces lens cover holder.

Tabla de contenidos

Otros manuales de Sistema de soldadura de Hobart

Hobart

Hobart Handler 125 Manual de usuario

Hobart

Hobart HSW 15 Manual de usuario

Hobart

Hobart H-9 Gun Manual de usuario

Hobart

Hobart Handler 140 Manual de usuario

Hobart

Hobart Handler 125 Manual de usuario

Hobart

Hobart Beta Mig 151 Manual de usuario

Hobart

Hobart 0 Manual de usuario

Hobart

Hobart H-9B Manual de usuario

Hobart

Hobart H100S2-10 Manual de usuario

Hobart

Hobart Handler 135 Manual de usuario

Hobart

Hobart AirForce 750 Manual de usuario

Hobart

Hobart Handler 130 XL Manual de usuario

Hobart

Hobart Stickmate 160i Manual de usuario

Hobart

Hobart IronMan 230 Manual de usuario

Hobart

Hobart Handler 210 Manual de usuario

Hobart

Hobart Handler 125 EZ Manual de usuario

Hobart

Hobart Handler 190 Manual de usuario

Hobart

Hobart Handler 125 EZ Manual de usuario

Hobart

Hobart TREK 180 Manual de usuario

Hobart

Hobart Beta-Mig 200 Manual de usuario

Hobart

Hobart AirForce 250A Manual de usuario

Hobart

Hobart STICKMATE LX Manual de usuario

Hobart

Hobart AirForce 400 Manual de usuario

Hobart

Hobart AirForce 625 Manual de usuario

Manuales populares de Sistema de soldadura de otras marcas

Berner

Berner PLASMACUT 54 Manual de usuario

Pro Spot

Pro Spot PR-155 Manual de usuario

Forney

Forney 210 Manual de usuario

Thermal Arc

Thermal Arc 400S Manual de usuario

Lincoln Electric

Lincoln Electric HANDYMIG 170I Manual de usuario

GYS

GYS PROTIG 201 AC/DC Manual de usuario

TAFA

TAFA 30*8B35 Manual de usuario

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Manual de usuario

ESAB

ESAB Buddy Arc 145 Manual de usuario

CIGWELD

CIGWELD 636804 Guía rápida

Red-D-Arc

Red-D-Arc DC-400 Manual de usuario

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 Manual de usuario

Elettro

Elettro HI-MIG 3000 SYNERGIC Manual de usuario

WIA

WIA Weldmatic 270 CP132-2 Manual de usuario

Sonics

Sonics H520T Manual de usuario

Miller

Miller Big Blue 400D Manual de usuario

NewArc

NewArc RT2000 Guía de inicio rápido

Hypertherm

Hypertherm powermax1000 Manual de usuario
