HKC TM16S Manual de usuario
15.6" (Class) LCD COLOUR TV
Instruction Manual
Contents
Introduction
Warning
Caution
Stand Installation Guide
Remote Control
OSD Basic Adjustment
USB Features
Specifications
T
Car Charger
roubleshooting
Main Unit Description
Introduction
INSTALLATION
ķ
ĸ
Ĺ
ĺ
Ļ
Thank you very much for purchasing our TV. It serves as a normal colour TV
and a PC monitor. To enjoy your set fully from the very beginning, read this manual
carefully and keep it handy for future reference.
Locate the receiver in the room where direct light does not strike the screen. Total
darkness or a reflection on the picture screen can cause eyestrain. Soft and indirect
lighting is recommended for comfortable viewing.
Allow enough space between the receiver and the wall to permit ventilation.
Avoid excessively warm locations to prevent possible damage to the cabinet or
premature component failure.
Please always use the original accessories.
Do not install the TV in a location near heat sources such as radiators, air ducts,
direct sunlight, or in closed compartments and closed areas. Do not cover the
ventilation openings when using the TV.
The indicator light will last for about 30 seconds after the power has been turned off.
Wait until the indicator light goes out before repowering the TV.
Note : It is recommended to plug signal line when the machine is turned off or
standby mode.
ļ
2
Warning
This symbol is intended to alert the user to avoid the risk
of electric shock. This equipment may only be disassembled
by qualified service personnel.
This symbol is intended to alert the user to the presence
of important operation and maintenance instructions in
the literature accompanying the equipment.
Class I structures of equipment should be connected to the grid
power output with a protective earth connection on the socket.
Power plug as a broken applianceˈbroken installations should
be easy to operate.
CAUTION: TO AVOID THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER- SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
３
Caution
Caution
High voltages are used in the operation of this product.
Do not open the product's casing. Refer servicing
to qualified service personnel .
To prevent fire or electrical shock hazard, do not expose
the main unit to rain or moisture, do not place objects
filled with liquids, such as vases, on the apparatus.
Do not drop or push objects into the television cabinet
slots or openings. Never spill any kind of liquid on the
television receiver.
Avoid exposing the main unit to direct sunlight and other
sources of heat. Do not stand the television receiver
directly on other products which give off heat: e. g. video
cassette players and audio amplifiers. Do not block the
ventilation holes in the back cover. Ventilation is essential
to prevent failure of electrical components. Do not squash
the power supply cord under the main unit or other heavy
objects.
Caution
Caution
Caution
4
Caution
Caution
ｃｈｉｌｄｒｅｎ．
Caution
Caution
Caution
Never stand on, lean on or suddenly push the product
or its stand. You should pay special attention to
children.
Do not place the main unit on an unstable cart stand,
shelf or table. Serious injury to an individual and
damage to the television may result if it should fall.
When the product is not used for an extended period
of time, it is advisable to disconnect the AC power
from the AC outlet.
The LED panel used in this product is made of glass and
is therefore breakable. This product must not be dropped
or banged. If the LED Panel breaks be careful of being
injured by broken glass.
5
6
Stand Installation Guide
61x4PA(swercS
mm) 4PCS
Main unit description
Control Panel Button Function
TV Terminal Connections
Volume up.
Volume down.
CH< TV channel up.
CH> TV channel down.
MENU :
:
:
:
:
Press to select the main menu.
: Source switching
: Switch on when in standby mode or to enter the standby mode.
1. DC 12V terminal.
2. VGA input terminal.
3. PC AUDIO input terminal.
4. SCART input terminal.
5. TV(S2) (DVB-S/S2)input terminal.
6. TV (ATV,DVB-T/C/T2)input terminal.
7. COAX out put terminal.
8. HDMI input terminal.
9. USB input terminal.
Important: The USB port is intended only for data transfer only, other devices
cannot be used with this USB connection. The use of USB extension cords is
not recommended.
10. EAR PHONE out put terminal.
Caution : Listening at high power for a long moment could damage users’ ears.
Noted:The angle of monitor can be adjusted.Please bend it slowly.
11. MINI PBPR input terminal.
12. MINI AV input terminal.
13. CI input terminal.
123 4 567
13
89011121
DC IN VGA PC AUDIO SCART TV(S2) TV COAX
G
HDMI USB
EAR
PHONE
MINI
PBPR
MINI
AV
CI
8
Remote control
:Press this button to switch on the TV when at
standby mode or enter standby mode.
:Press this button to mute or restore sound.
0-9: Select and switch to a channel using 0 - 9.
DISPLAY: Display TV information on the screen
such as channel and channel label.
:Switch back and front between the current and
previous channels.
SLEEP: Set the sleep timer.
SOURCE: Press to change signal source.
ENTER: Enter the selected option or execute the
selected operation.
MENU: Press this button to enter the main menu for
various optional adjustable setting.
EXIT: Exit the OSD (On-screen display).
CH-/CH+: Change the channel up and down.
VOL-/VOL+: Adjust the volume.
NICAM/MTS: In the TV condition, press this key to
select the stereo mode.
SUBTITLE/CC: Turns Select the CC function. /
Open or close subtitle. (Used for models with MEDIA
only).
MEDIA: Press to select the USB signal source.
ASPECT: Press to adjust picture ratio.
PMODE: Select picture mode.
SMODE: Select sound mode.
GOTO: Locate the appointed time (accurate to seconds)
in USB mode.
FREEZE: Press this button to hold the picture.
PALY Press to start playing the USB, or to pause
playing. (Used for models with USB function only)
Press to play backward.(Used for models with USB function only)
Press to play forward. (Used for models with USB function only)
Stop playing the USB. (Used for models with USB function only)
Skip to previous chapter. (Used for models with USB function only)
Skip to next chapter. (Used for models with USB function only)
RED, GREEN, YELLOW, BLUE: Corresponds to the different colored subjects
showed on the screen .
9
You can select the type of picture, which best corresponds to your viewing.
1. Press the “MENU” button to enter the OSD menu. Then press “c/d” button to select the
“PICTURE” menu.
2. Press “c/d” button to select “Picture Mode” and Press “e/f” button to select
3. Press “c/d” button to select “Contrast” and press the “e/f” button to enter contrast
adjustment menu to adjust contrast.
4. Press “c/d” button to select “Brightness” and press the “e/f” button to enter brightness
adjustment menu to adjust brightness.
5. Press “c/d” button to select “Color” and press the “e/f” button to enter color
adjustment menu to adjust color.
6. Press “c/d” button to select “Tint” and press the “e/f” button to enter hue adjustment
menu to adjust tint.
Note: The 'Tint' item is used in NTSC mode only.
7. Press “c/d” button to select “Sharpness” and press the “e/f” button to enter sharpness
adjustment menu to adjust sharpness.
8. Press “c/d” button to select “Color Temperature” and Press the “e/f” button to select.
9. Press “c/d” button to select “Aspect Ratio” and Press “e/f” button to select.
10. Press “c/d” button to select “Noise Reduction ” and Press “e/f” button to select.
11. Press the “Menu” button to return to upper-menu.
Return
OSD Basic Adjustment
