HiTi Digital 640 DL Manual de usuario

Quick Start

Contents in Carton

Setting Your Printer

Installing Ribbon Cartridge

Installing Paper/Card

System Requirement

Installing Driver

Customer Service Claim

Contact Information

About PhotoDesiree

Installing Software

User Interface

Printing a Photo

About CardDesiree

Installing Software

User Interface

DesignYourTemplate

Print Your ID Card

 Quick Start

Contents in Carton

Before you begin to install your printer, check if you have the following

items.

 HiTi Photo Printer 640DL-Amphi x 1

 Plastic Card Cassette x 1

 Power Cord x 1

 USB Cable x 1

 CD (Windows Driver, PhotoDesiree, CardDesiree) x 1

 Printer/Software User Manual x 1

 Trial Clean Kit (2 sheets clean paper) x 1

 Warrantee Card x 1

HiTi Photo Printer 640DL-Amphi Plastic Card Cassette

Power CordUSB Cable

CD Printer/Software

User Manual

 Quick Start

Setting Your Printer

You may setup your HiTi 640DL-Amphi printer by following steps.

1. Connect the power cord to the power connection.

2. Connect the printer to your computer using the

USB cord.

3. Insert the ribbon cartridge into the printer, please see P.XX for more

information.

4. Place paper or plastic card into the paper cassette, please see P.XX for

more information.

5. Turn the printer power switch on. The green led light blinks and becomes

stable after 5 seconds. Before you turn on the power switch, make sure

the printer driver software is installed in your personal computer, please

see P.XX for more information about driver installation.

6. The New Hardware Found message box appears on the screen of your

computer. Windows starts to install the printer driver software by copying

files to your computer.

Notice!!

Always turning power switch off before connecting or disconnecting power

cord to AC source.

 Quick Start

Installing Ribbon Cartridge

You may install ribbon cartridge by following process.

1. Move the slider to open the top cover of the printer.

2. Hold the ribbon cartridge as the figure illustrated.

Be sure to point the arrow sign towards the

left-hand side of the printer.

3. Insert the cartridge all the way into the printer until

it is completely installed.

4. Close the top cover.

Notice!!

1. Make sure the purple parts on ribbon cartridge and printer are touched,

then you may close ribbon door.

2. Check LED is green after door closed, if LED is orange, try to close door

again.

 Quick Start

Installing Paper/Card

You may install photo paper or plastic card by following process.

1. Open the cover of the paper cassette.

2. Place a stock card into the paper cassette, make

sure the mis-corner is close to left-bottom side,

please refer to illustration.

3. Insert the paper cassette back into the printer.

Notice !!

1. Maximum paper capacity of 640DL-Amphi is 100

sheets, and maximum plastic card capacity is 25

sheets.

2.Please make sure the wider blank part of photo

paper is close to cassette exit, please see

instruction on paper package for more information.

3.Before thin plastic card printing, please make

“HiTi” logo up when printing front side of card, and

“iTiH” logo up when printing backside of card.

 Quick Start

System Requirement

Please check your PC conformed with following items.

 Pentium or compatible PC

 Operate only on Windows 98/ME/2000/XP

 128MB RAM or greater

 Available USB port

 100MB or greater free hard disk space

 CD-ROM Drive

Notice!!

1. Microsoft, MS, MS-DOS and Windows are registered trademarks of

Microsoft Corporations.

2. Pentium is a U.S. registered trademark of Intel Corporation.

3. Brands and product names are trademarks or registered trademarks of

their respective companies.

 Quick Start

Installing Driver

You may install 640DL-Amphi driver into your PC by following steps.

1. Insert “Driver CD” into CD-ROM drive, if disk doesn’t auto start, execute

file “autorun.exe” in the disk.

2. Select “Install HiTi 640DL-Amphi Driver” and install.

3. Press button “Start” for installation.

4. Connect printer to PC through USB cable and power it on.

5. In system Windows 2000 or Windows XP, if there’s message dialog

shows “Digital Signature Not Found ” or “Driver Incompatibility”, please

press “Yes” to continue installing driver.

 Quick Start

Customer Service Claim

 WEB Support

If you cannot find the answer and help from manual, you can visit HiTi’s

website. You can get new driver, updated application and more e-Frames

there.

 Customer Support Center

If your HiTi products cannot operate function normal, and the products are

in one-year period from the time you purchase, free service is provided.

Before placing a call for help, please make sure that:

1. You have checked your User Guide for these procedures.

2. You have checked this Manual for troubleshooting tips.

3. You have checked HiTi website for help.

4. If you buy this product from distributors, you need to contact them to get

help.

Please support following information, and we can solve your problem in the

fastest way.

1. Printer S/N.

2. Printer Model No.

3. Printer driver version (you can get it from "Control Panel/Printer/HiTi

640Amphi/Properties/About")

4. PhotoDesiree version. (you can get version number from PhotoDesiree)

5. Brand name/Model/System configuration of your PC.

6. Windows version (such as Windows 98 SE)

7. Application name and version (such as PhotoShop 6.0), when you used

this printer and occurred error at the same time.

 Quick Start

Contact Information

 Headquarter

Hi-Touch Imaging Technologies

Address: 3F, 31, Shuang-Shih Rd. Sec.3, Pan-Chiao City, Taipei County 220,

Taiwan

Tel: +886-2-82583060

FAX: +886-2-82583062

Web: http://www.hi-ti.com

E-mail: csd@hi-ti.com

 USA Office

Hi-Touch Imaging Technologies (America)

Address: 285 S, Dupont Ave. Suite#104 Ontario, CA 91761

Tel: +1-909-974-0099

FAX: +1-909-974-0011

Web: http://www.hitouchimaging.com

 Europe Office

Hi-Touch Imaging Technologies Netherlands B.V.

Address: Goudenheuvel 13, 5234 GA's -Hertogenbosch, The Netherlands

TEL: +31-73-6450897

FAX: +31-73-6431366

Web: http://www.hi-ti.nl

 UK Office

Hi-Touch Imaging Technologies (UK) Limited.

Address: Unit 7, Centurion Court, Brick close, Kiln Farm

Milton Keynes, Buckinghamshire, United Kingdom, MK11 3JB

TEL: +44-1908-266-677

FAX: +44-1908-266-678

Web: http://www.hi-ti.co.uk

 China Office

Hi-Touch Imaging Technologies (SuZhou)

Address: No 18, QunXing Road One, SuZhou Industrial Park, China

TEL: +86-512-67601688

FAX: +86-512-67601186

Web: http://www.hi-ti.com.cn
