Hitachi 50PD960DTA Instrucciones de instalación

Hitachi Australia Pty Ltd (ABN 34 075 381 332) Page 1/3

Hitachi Australia continues to set the standards for picture quality

and connectivity with the launch of their 50 inch High Definition

integrated TV

5 January 2007

Continuing their rollout of Integrated High

Definition TV models, Hitachi has now entered

the growing 50 inch screen segment with the

introduction of the 50PD960DTA plasma TV.

The 50PD960DTA, an elegant solution for the High Definition era

Hitachi High Definition Digital TV’s (HDTV) offer breathtaking picture quality. Compared to

both the analogue and Standard Definition digital formats, HDTV delivers outstanding detail,

crisp edges, natural colours and stark contrasts culminating in an enthralling life like picture.

Thanks to its superior resolution HDTV is ideally suited to large screen Home Cinema screens;

delivering every nuance and detail of the original image. For the ultimate High Definition

home cinema experience, Hitachi has added a 50 inch screen size to their line up with the

introduction of the 50PD960DTA. The built-in High Definition tuner makes the HDTV viewing

experience elegant and simple as there is no need to purchase an external set top box

decoder.

When you think High Definition and connectivity, think Hitachi

High Definition digital broadcasting is now available to the majority of Australians and the

amount of content being broadcast is increasing all the time. Currently there are over 100

hours of top rating shows, news programmes and sporting events broadcast each week.

Current High Definition (HD) broadcasts in Australia have a maximum vertical resolution of

1080 scanning lines (e.g. 1080i). The 50PD960DTA features Hitachi’s latest generation

proprietary ALIS panel which has a full 1080 lines of vertical resolution, therefore there is no

need for the image to be compressed in the vertical domain. Combined with its remarkable

1.3 million display pixels, the 50PD960DTA can easily display Australian HD broadcasts

without loss of picture quality.

Hitachi Australia Pty Ltd (ABN 34 075 381 332) Page 2/3

A wide range of digital and analogue inputs provides for the connection of up to 6 separate

video sources and a PC. There are two HDMI terminals for connecting the latest generation

HD hard drive recorders, DVD players and game consoles as well as two component video

inputs for sources such as cable TV or video cameras. To ensure compatibility with the next

generation of HD products, the 50PD960DTA can accept 1080P high definition signals from

Blu Ray players and other 1080P capable devices.

Easy input switching from the remote control

Each of the six inputs has a dedicated button on the remote control, which means there is no

need for tedious scrolling to find the right input as is the case with the majority of competitor

models. This feature is very handy, especially when the TV is the hub of a Home Theatre

system where programmable remotes are used, or where there are many sources connected.

The 50PD960DTA completes the roll out of Hitachi’s competitive line up of integrated High

Definition panels for first half 2007. Also included in the range are two 42 inch plasmas and a

32 inch LCD.

The 50PD960DTA plasma TV will be available in store late January 2007. For more

information, visit www.hitachi.com.au/australia.

- Ends -

For media enquiries, please contact:

Celine Herit

Hitachi Ltd

Tel. +61 2 9888 4160

Email: [email protected]

For consumer enquiries, please contact:

Hitachi Customer Service centre

Tel. 1800 448 224

Web: www.hitachi.com.au/australia

About Hitachi

Setting the benchmark for quality performance and design, Hitachi has utilised its major

investments in research and development to bring a unique, technologically advanced product

design that is set to challenge other players in the highly competitive home entertainment

market. 2006 marks both the 50th anniversary of television manufacturing for Hitachi and the

50th anniversary of television broadcasting in Australia. From strong beginnings in Plasma

technology in 1999, Hitachi has become renowned for world leading technology and can boast it

is one of the most technologically advanced brands on the market. Hitachi satisfies all audiences

by providing superior technology in the areas of design, colour, definition and sound, on both

the LCD and plasma platforms and remains one of few genuine manufacturers for both.

Hitachi Australia Pty Ltd (ABN 34 075 381 332) Page 3/3

Product specifications

Model 50PD960DTA


Effective display area (HxV)mm 1,106 x 626.4 (1271 diagonal)

Aspect ratio 16 : 9

Number of pixels (HxV) 1,280 x 1,080

Pixel pitch (HxV)mm 0.864 x 0.580

Panel Bringtness ( at white peak ) cd/m2 1300

Typical Contrast ratio (Panel) 10,000:1

Tuner

DVBHigh Definition Tuner integrated Yes

Analogue Tuner Integrated Yes

Analogue RFreception (NTSC-M) (SECAMB/G/D/K1) (PAL B,G,H/I/D,K)

Analogue RF Audio reception A2/NICAM

Video Formats

Video signal PAL, SECAM, NTSC3.58, NTSC4.43, PAL60, N-PAL, M-PAL

Component signal 480i/p, 576i/p, 720p(50/60), 1080i(50/60)

HDMI signal (video mode) 480i/p, 576i/p, 720p(50/60), 1080i(50/60), VGA, 1080p

Analogue RGBsignal VGA-SXGA (fH:30 to 64kHz, fV:60Hz to 70Hz)

Input & outputs

Total number of connectable video sources 6

Video connection configurations

Front or side input Front

Composite video with analogue audio (RCA) 3 + (1 front)

S video with analogue audio (RCA) 1 + (1 front)

Component video with analogue audio (RCA) 2

HDMI input 2

Analogue audio for HDMI/DVI (RCA) 1

Other connections

USB Photo -

SD card slot -

RGBanalogue (PC input) RGB : Mini D-sub 15P

Headphone socket (3.5mm) yes

A/V output 1x Composite video with analogue audio (RCA)

Subwoofer output (RCA) yes

Sound

Surround sound SRS WOW

Automatic Volume Level yes

Sound modes 4 (Movie, Music, Speech, Favourite)

Audio Power 20W

picture aspect modes

TV/Video (input signal dependent) Panoramic1 / 2, Zoom, Cinema, Full, 4:3, Full 1080

PC Full, Normal, Zoom

Other Functions

On / Off Timer Yes

Picture in Picture -

Teletext 1000 page

Remote control functions

Multi Brand control for DVD Yes

One touch input switiching Yes

Power swivel base -

General

Dimensions excluding stand (WxHxD)mm 1240x836x105

Dimensions including stand (WxHxD)mm 1240x900x423

Weight excluding stand (kg) 40.7

Weight including stand (kg) 46.5

Power Supply 240V (50Hz)

Power consumption 480W

Power consumption standby mode <1W
