Simple Installation Guide

Hitachi Deskstar

3.5 inch ATA/IDE

This document provides instructions to install your Hitachi

Deskstar drive in a system. Additional information can be

found at www.HitachiGST.com/support

Getting Started

IMPORTANT! Back up all data before beginning installation.

Handling Precautions

Caution: Poor handling, physical impact or electrical shock

causes most premature hard disk drive failures.

• Set the drive down gently to prevent damage from

impact or vibration.

• Do not open the ESD bag containing the drive until

needed.

• Handle the drive carefully by the edges. Do not touch

the exposed printed circuit board or any electronic

components.

• Do not press on the top or bottom of the drive.

• Do not cover the drive’s breather hole.

Before handling the hard disk drive, discharge any static

electricity from yourself and your clothing. With one hand,

touch an unpainted, metal surface on your computer chassis,

then touch the ESD bag with the other hand. Remain in con-

tact with the chassis and the bag for a minimum of two sec-

onds.

Tools for Installation:

You may need one or more of the following items to install the

Hitachi Deskstar drive:

• A Phillips head screw driver

• A flat-blade screw driver

• A small needle-nose pliers

• Your system manual

• Operating system (OS) startup CD or diskette

Begin Hardware Install

1. Turn off your computer system.

2. Unplug your system.

3. Discharge static electricity (see above).

4. Remove the cover as specified by your system man-

ual.

5. Find the mounting bracket inside the system where

you will install the Hitachi Deskstar.

6. If you are replacing a hard drive, remove the drive

from the system.

Note: There are many variations of tower and desktop

designs. Below is an example of a typical tower design.

Configure the Jumper settings

1. Remove the drive from the ESD bag.

2. Record the model (HDS......), part number (P/N)

and serial number (S/N).

version 1.3

3. If the new Hitachi Deskstar drive will be the only

hard disk drive on a cable in your system, jumper

the drive to Device 0 (MASTER). If you are adding

the Hitachi drive to a cable with another hard drive,

jumper the Hitachi drive as Device 1 (SLAVE).

Attach the Cables

Note: With some system cases, it may be easier to attach the

cables after the drive is mounted in the system.

1. Attach the blue connector of the ATA IDE cable to

the IDE connector marked "Primary" or "0" on the

motherboard or controller card in your system.

2. Attach a power cable to the hard disk drive.

3. If the Hitachi Deskstar is the Device 0 (MASTER)

drive, attach the BLACK connector of the ATA/IDE

cable to the hard disk drive. If the Deskstar is the

Device 1(SLAVE) drive, attach the GRAY connec-

tor of the ATA/IDE cable to the hard disk drive.

Mount the Drive

There are many variations of system cases. Hitachi Deskstar

drive can be mounted with any side or end vertical or hori-

zontal. Do not mount the drive in a tilted position.

1. Place the drive in an empty drive bay, and line up

the 4-screw holes. Make sure to use all 4 screws

when mounting the drive, as a loose drive may

vibrate when in use and result in drive failure. Con-

sult your system manual for additional information.

2. Check all internal cable connections to ensure they

are securely seated.

3. Replace the system cover.

4. Check all external cable connections to ensure they

are securely seated.

5. Plug in your computer.

Begin the Software Installation

1. Confirm the drive is recognized in the System

BIOS, or, if adding the drive as a Slave, confirm it

is recognized by the Operating System. Key strokes

sequences for accessing your BIOS are often dis-

played at boot, or can be found in your computer

system manual.

2. Locate drive settings in your BIOS. Verify correct

detection of drive capacity. If your BIOS does not

detect the Hitachi Deskstar, shut down your system

and review the installation procedure. If your drive

is still not detected in BIOS, contact the Hitachi

Global Storage Technologies Support Center:

www.HitachiGST.com/support

Install the Operating System

Once the drive is recognized correctly by the BIOS, it is

ready to be partitioned, formatted and the Operating System

installed. Please consult your Operating System manual for

information on how to install the Operating System or see

our Partitioning and Formatting Guide at:

www.HitachiGST.com/support

version 1.3

Hitachi Global Storage Technologies

5600 Cottle Road

San Jose, CA 95193

Produced in the United States

5/04

Hitachi Global Storage Technologies.

Microsoft, Windows XP, and Windows are trademarks of

Microsoft Corporation in the United States, other countries,

or both.

Other product names are trademarks or registered trade-

marks of their respective companies.

References in this publication to Hitachi Global Storage

Technologies products, programs or services do not imply

that Hitachi Global Storage Technologies intends to make

these available in all countries in which Hitachi Global Stor-

age Technologies operates.

Product information is provided for information purposes

only and does not constitute a warranty.

Information is true as of the date of publication and is subject

to change. Actual results may vary.

This publication is for general guidance only. Photographs

may show design models.

21 May 2004
