ELECTRIC TOOL PARTS LIST

LIST NO.

DRILL

Model D 13VG

2001

•

(E2)

0197

501

502

503

--- 2 --- 8 -- 01

D 13VG

602

612

602

613

605

603

604

605

606

609

610

611

608

*ALTERNATIVE PARTS --- 3 ---

ITEM

NO. CODE NO. DESCRIPTION REMARKS

NO.

USED

PARTS D 13VG

8 -- 01

1 311-959 SPECIAL SCREW (LEFT HAND) M6X23 1

2 319-527 CHUCK WRENCH 13VLR-J 1

3 950-288 VINYL BAND 1

* 4 319-303 DRILL CHUCK 13VLR-J 1 INCLUD.2

* 4 319-304

DRILL CHUCK 13VLRD-N (W/O CHUCK WRENCH)

5 319-346 SPINDLE (A) 1

6 948-001 RETAINING RING FOR D32 HOLE 1

7 600-2VV BALL BEARING 6002VVCMPS2L 1

8 939-544

RETAINING RING FOR D15 SHAFT (10 PCS.)

9 305-701 TAPPING SCREW (W/FLANGE) D5X60 2

10 319-345 GEAR COVER (A) 1

11 627-VVM BALL BEARING 627VVC2PS2L 1

12 319-305 FINAL GEAR (C) 1

13 319-548 SECOND PINION (C) 1

14 319-544 FIRST GEAR 1

15 606-ZZM BALL BEARING 606ZZC2PS2L 1

16 316-458 TAPPING SCREW D5X40 (BLACK) 1

17 319-344 INNER COVER 1

18 608-DDM BALL BEARING 608DDC2PS2L 1

* 19 360-543U ARMATURE ASS’Y 110V-120V 1 INCLUD.18,23,24

* 19 360-543E ARMATURE 220V-230V 1

* 19 360-543F ARMATURE 240V 1

20 319-329 FAN GUIDE 1

21 981-421 HEX. HD. TAPPING SCREW D4X55 2

* 22 340-494C STATOR 120V 1

* 22 340-504E STATOR 230V-240V 1

23 982-631 WASHER (A) 1

24 608-VVM BALL BEARING 608VVC2PS2L 1

25 319-328 HOUSING 1

26 NAME PLATE 1

27 319-331 HANDLE (B) 1

28 303-694 TAPPING SCREW (W/FLANGE) D4X35 2

29 301-653

TAPPING SCREW (W/FLANGE) D4X20 (BLACK)

30 319-332 GRIP COVER 1

31 319-337 SCREW (PLASTIC TIE) D4X25 2

32 HITACHI LABEL 1

33 319-330 HANDLE (A) 1

34 955-203 BRUSH HOLDER 2

* 35 319-341 INTERNAL WIRE (BLUE) 86L 1 FOR USA,CAN

* 35 320-197 CHOKE COIL (BLUE) 220V-240V 1 FOR AUS,NZL,EUROPE

36 999-041 CARBON BRUSH (1 PAIR) 2

* 37 319-340 INTERNAL WIRE (BROWN) 86L 1 FOR USA,CAN

* 37 320-196 CHOKE COIL (BROWN) 220V-240V 1 FOR AUS,NZL,EUROPE

38 316-166 PUSHING BUTTON 1

* 39 319-302 SWITCH (1P SCREW TYPE) W/LOCK 1 FOR USA,CAN

* 39 320-195 SWITCH (1P SCREW TYPE) W/LOCK 1 FOR AUS,NZL,EUROPE

40 984-750 TAPPING SCREW (W/FLANGE) D4X16 2

*ALTERNATIVE PARTS

--- 4 ---

ITEM

NO. CODE NO. DESCRIPTION REMARKS

NO.

USED

PARTS

41 937-631 CORD CLIP 1

42 981-373 TUBE (D) 2 FOR CORD

43 953-327 CORD ARMOR D8.8 1 FOR CORD

* 44 500-240Z CORD 1 (CORD ARMOR D8.8) FOR USA,CAN

* 44 500-439Z CORD 1 (CORD ARMOR D8.8) FOR AUS,NZL

* 44 500-247Z CORD 1

(CORD ARMOR D8.8) FOR NOR,DEN,SWE,FIN

* 44 500-409Z CORD 1 (CORD ARMOR D8.8) FOR EUROPE

* 45 320-198 NOISE SUPPRESSOR 1 EXCEPT USA,CAN

8 -- 01

D 13VG

*ALTERNATIVE PARTS --- 5 ---

STANDARD ACCESSORIES

OPTIONAL ACCESSORIES

ITEM

NO. CODE NO. DESCRIPTION REMARKS

NO.

USED

ITEM

NO. CODE NO. DESCRIPTION REMARKS

NO.

USED

D 13VG

501 981-205 SIDE HANDLE FOR M10 1

502 319-550 HANDLE JOINT 1

503 319-543 CASE 1

601 319-528 ANGLE ATTACHMENT ASS’Y 1 INCLUD.603-614

602 670-714 NEEDLE BEARING (HK0810) 2

603 986-149 PINION 1

604 630-1VV BALL BEARING 6301VVCMPS2L 1

605 986-147 RETAINING RING FOR D37 HOLE 2

606 932-819 WOODRUFF KEY 3X10 1

607 986-146 SPINDLE 1

608 986-143 COUPLING 1

609 986-142 JOINT SLEEVE 1

610 949-632 BOLT M8X45 (10 PCS.) 2

611 949-426 WASHER M8 (10 PCS.) 2

612 986-144 ANGLE HEAD ASS’Y 1 INCLUD.602

613 986-156 SPINDLE AND GEAR SET 1

614 949-168 WRENCH 13/17MM 1

615 317-676 HOOK (A) 1

8 -- 01

*ALTERNATIVE PARTS

--- 6 ---

ITEM

NO. CODE NO. DESCRIPTION REMARKS

NO.

USED

PARTS D 13VG

Printed in Japan

(010821N)

8 -- 01
