Instruction Manual

Model name

DZHV598E

DZHV598ER

Precautions

Safety Instruction

Do not store the camera in intense heat or cold for long periods of time, as this may result in permanent•

damage to the camera.

Do not use or store the product in dusty, dirty, or sandy areas, as its components may be damaged.•

Do not drop, puncture or disassemble the camera. High-voltage internal components create the risk•

of electric shock when exposed.

Use the camera with care. Rough handling may damage the internal components.•

Do not use harsh chemicals, cleaning solvents or strong detergents to clean the product. Clean only•

with a slightly damp soft cloth.

Do not ignite the ﬂash close to eyes, or closer than prescribed minimum distances as this may result•

in damage to vision. When using the ﬂash, the camera should be at least one meter from the eyes of

the subject.

Do not open the battery cover while an image is being recorded. Doing so will not only make storage•

of the current image impossible, it can also corrupt other image data already stored in ﬁle.

Test for proper operation before using the camera•

Operating Environment Conditions

This camera is designed for use in temperatures ranging from 5°C to 35°C (41°F to 95°F).•

Do not use or keep the camera in the following areas:•

- In areas subject to direct sunlight

- In areas subject to high humidity or dust

- Near air conditioners, heaters, or other areas subject to temperature extremes

- Inside of a closed vehicle, especially one parked in the sun.

- In areas subject to strong vibration

Battery Usage and Power Supply

Use only the type of battery that came with your camera. Do not use batteries of different speciﬁcations.•

Doing so may lead to the potential for serious damage.

Insert the battery according to the instructions. Inserting the battery incorrectly can cause damage to•

the product and possibly start a ﬁre.

Remove the battery to avoid the ﬂuid leakage if the camera is not going to be used for an extended•

time.

If the battery is crushed or damaged, remove it immediately to avoid battery ﬂuid leakage and•

abnormal expansion.

The camera may feel warm after long periods of continuous use which is normal and not a malfunction.•

Battery will be in high temperature after long time using (about 1hr), Please be careful while taking

out the battery.

Please be careful if you may need to take out the battery by ﬁnger nail.•

SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT

This equipment has been designed and manufactured to meet international safety standards but, like

any electrical equipment, care must be taken if you are to obtain the best results and safety is to be

assured.

*******************************************

DO read the operating instructions before you attempt to use the equipment.

DO ensure that all electrical connections (including the mains plug, extension leads and inter-connections

between the pieces of equipment) are properly made and in accordance with the manufacturer’s

instructions. Switch off and withdraw the mains plug before making or changing connections.

DO consult your dealer if you are ever in doubt about the installation, operation or safety of your

equipment.

DO be careful with glass panels or doors on equipment.

DO route the mains lead so that it is not likely to be walked on, crushed, chafed, or subjected to excessive

wear and tear or heat.

*******************************************

DON’T remove any ﬁxed cover as this may expose dangerous voltages.

DON’T obstruct the ventilation openings of the equipment with items such as newspapers, tablecloths,

curtains, etc. Overheating will cause damage and shorten the life of the equipment.

DON’T allow electrical equipment to be exposed to dripping or splashing, or objects ﬁlled with liquids,

such as vases, to be placed on the equipment.

DON’T place hot objects or naked ﬂame sources such as lighted candles or nightlights on, or close to

equipment. High temperatures can melt plastic and lead to ﬁres.

DON’T use makeshift stands and NEVER ﬁx legs with wood screws - to ensure

complete safety always ﬁt the manufacturer’s approved stand or legs with the ﬁxings

provided according to the instructions.

DON’T use equipment such as personal stereos or radios so that you are distracted from

the requirements of trafﬁc safety. It is illegal to watch television whilst driving.

DON’T listen to headphones at high volume, as such use can permanently damage your

hearing.

DON’T leave equipment switched on when it is unattended unless it is speciﬁcally stated

that it is designed for unattended operation or has a stand-by mode. Switch off using the

switch on the equipment and make sure that your family know how to do this. Special

arrangements may need to be made for inﬁrm or handicapped people.

DON’T continue to operate the equipment if you are in any doubt about it working

normally, or if it is damaged in any way - switch off, withdraw the mains plug and consult

your dealer.

ABOVE ALL

--- NEVER let anyone especially children push anything into holes, slots or any other opening in the

case - this could result in a fatal electrical shock;

--- NEVER guess or take chances with electrical equipment of any kind

--- it is better to be safe than sorry!

****************

Contents

Section 1 Getting to Know Your Camera........................................... 5

Section 2 Getting Started.................................................................... 9

Section 3 Enjoying the Record Mode .............................................. 11

Section 4 Enjoying the Playback Mode........................................... 22

Section 5 Setting Your Camera ....................................................... 27

Section 6 Viewing Photos and Videos on TV.................................. 31

Section 7 Viewing Video & Photo on PC ......................................... 32

Section 8 Uploading Files to Internet .............................................. 33

Section 9 Speciﬁcations and System Requirements..................... 36

Section 10 Troubleshooting ............................................................... 38

Section 11 Additional Information ..................................................... 39

Section 1

Getting to Know Your Camera

Overview

The camera with 5 Mega Pixel sensor can take H.264 videos. By way of using H.264 technology, more

videos can be taken within certain amount of memory. High quality images with up to 16 mega-pixels

can also be delivered smoothly. With a colour LCD monitor, users can compose images and examine

them easily.

The camera features 3” (16:9) LCD touch panel which is an ideal platform for you to operate your

camera. The menu options are accessible with your ﬁnger. With the touch panel, you can select the

options directly and quickly.

The camera also features video recording at HD resolution of 1920x1080. You can also connect it to an

HDTV via an HDMI cable, and easily playback the recorded high-deﬁnition videos on the wide screen

HDTV.

Moreover, the camera has an advanced uploading feature. With the exclusive built-in Internet Direct

application, you can upload the videos captured by the camera to the web site more effortlessly .

ISO sensitivity and colour balance can either be adjusted automatically or changed manually. A 120x

digital zoom helps you to control over the videos and photos you take.

The varied effect options, such as Time Lapse and Slow Motion, make recording more fun.

The built-in memory allows you to take photos and to record videos without a memory card. The memory

card slot allows users to increase the storage capacity.

Hitachi cannot compensate for any damages caused when recording is not made normally or recorded

contents cannot be played back because of a defect in the digital camera device or memory card.

Hitachi cannot be responsible for your recorded video and audio.

If you or a third party make a mistake when handling this digital camera device or memory card, etc.,

the recorded contents may be lost. Hitachi cannot be responsible for compensation for damage due to

loss of recorded contents.

Note

Partial memory of the built-in memory is used for the camera’s Firmware code• and software.

Install the bundled software application on the CD, ArcSoft MediaImpression, for viewing the•

videos correctly on a PC.

Features

23X Optical Zoom•

3” touch LCD (16:9)•

Digital Light•

Stabilization•

Time Lapse•

Slow Motion•

Pre Record•

Pause Record•

ISO 6400•

Motion Detection•

Internet Direct•

Stereo microphone•

Standard Accessories

Unpack the package and make sure all standard accessories listed are included:

Camera•

USB Cable•

AV Cable•

HDMI Cable•

Adaptor•

Lithium-ion Rechargeable Battery•

Quick Guide•

CD-ROM (Software, User’s Manual)•

Pouch•

Lens Cover Set (Lens cover and Strap)•

Front View

Rear View

Lens

Microphone

Photo Button

Tele/Wide Button

Flash

Self-timer LED

LCD Touch Panel

HDMI Port

Mini USB 2.0 Port

Video Button

TV Port

Record LED

Indicator

Playback LED

Indicator

Side View

Bottom View

Speaker

Power Button

Playback Button

Stabilization ButtonDigital Light Button

Pause Button

Tripod Socket Battery/SD card Cover

Section 2

Getting Started

Loading the Battery

Before using the camera, you must load the supplied Lithium-ion

rechargeable battery.

Insert the battery according to the correct polarity marks ( + or1.

-).

Close the battery cover ﬁrmly.2.

Charge your battery

You must use the supplied AC charger or the USB cable.

The camera must be turned OFF; blinking light conﬁrms charging, and the

light becomes constant when the charging has been completed.

In AC charging Mode, the light will turn itself off automatically after 3~5

minutes . The full charge time is about 4 to 5 hours. (Actual charging time

may vary. It depends on the battery conditions.)

The full charge battery usage for continuous Full HD (1080p 30) video

recording is about 1.5~2 hours.

Inserting and Removing an SD Card (Optional)

The camera comes with an internal memory which allows you to store photos and videos. You can

expand the memory capacity by using an optional SD memory card.

Insert the memory card into the slot. Please refer to the ﬁgure on1.

the right side.

To remove an installed SD card, press the card inwards to release2.

it.

When the card pops out, gently remove it from its slot.3.

Recommended memory capacity: 1GB or above.4.

Note

When a memory card is ﬁtted, videos/photos are saved•

on the card rather than on the built-in memory.

Protecting Data on an SD Card: SD Card is read-only•

when it is locked. No photos or videos can be recorded

when the SD card is locked. Make sure the lock is on

the writeable position before recording any media.

Writeable

position

Write-Protected

Position

Turning the Camera On

To turn on the camera:•

Flip out the LCD panel; the camera will turn on automatically.1.

Or press [Power Button2. ] for one second to turn it on.

Conﬁguring the Initial Date and Time Setup

The time setting screen appears to allow you to setup date and time:•

Operation Display Screen

Touch Year, Month, Day, Hour, Minute, and AM/PM to set.1.

Adjust the numeric value by touching2.

Touch the [OK] icon to validate the setting.3.

Touch the Exit icon4. ( ) to exit.

Getting Started

To record video:• Press [Video Button] to record video. To stop recording, press it again.

To pause recording:• Press [Pause Button] to pause recording. To continue the recording, press it

again.

To take a photo during video recording: When recording video, press [Photo Button] to capture the•

image. The Dual record icon ( ) appears on the LCD monitor.

To take a• photo: Press [Photo Button] halfway down until the focusing frame turns from white to green.

Then, press it fully down to take photo.

Focusing Frame: White Focusing Frame: Green

To view stored videos and photos: Press [Playback Button] or touch• on the screen to switch to

the Playback mode.

Turning the Camera Off

To turn off the camera: You can either press [Power Button] for one second, or you can place the LCD•

panel back to its original position.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Videocámara de Hitachi

Hitachi

Hitachi VME-555LA - Camcorder Manual de usuario

Hitachi

Hitachi DZ-HS301E Manual de usuario

Hitachi

Hitachi DZMV580A - 1MP DVD Camcorder Manual de usuario

Hitachi

Hitachi DZ-HS500E Manual de usuario

Hitachi

Hitachi VME-54A - Camcorder Manual de usuario

Hitachi

Hitachi SK-HD1500-S2 Manual de usuario

Hitachi

Hitachi VM-975LA - Camcorder Manual de usuario

Hitachi

Hitachi VMH-845LA - Camcorder Manual de usuario

Hitachi

Hitachi DZ-GX5060E UK Manual de usuario

Hitachi

Hitachi VME-625LA - Camcorder Manual de usuario

Hitachi

Hitachi DZ-MV350A - Camcorder Manual de usuario

Hitachi

Hitachi VMH-39A - Camcorder Manual de usuario

Hitachi

Hitachi MV730A - DZ Camcorder - 680 KP Manual de usuario

Hitachi

Hitachi DZ-GX5040E Manual de usuario

Hitachi

Hitachi VM-H835LA Manual de usuario

Hitachi

Hitachi DZ-HS903A - DVD Video Camera Manual de usuario

Hitachi

Hitachi DZ-MV230A - Camcorder Manual de usuario

Hitachi

Hitachi VMH-57A - Camcorder Manual de usuario

Hitachi

Hitachi DZ-MV380A(K) Manual de usuario

Hitachi

Hitachi DZ-GX5020AK Manual de usuario

Hitachi

Hitachi VM-8480LE Manual de usuario

Hitachi

Hitachi VME535LE Manual de usuario

Hitachi

Hitachi DZMV200EUK Manual de usuario

Hitachi

Hitachi VMH-825LA - Camcorder Manual de usuario

Manuales populares de Videocámara de otras marcas

Toshiba

Toshiba CAMILEO Z100 Manual de usuario

Panasonic

Panasonic NV-VS40B Manual de usuario

Canon

Canon RC 260 Manual de usuario

Sony

Sony Handycam DCR-DVD7E Manual de usuario

Brinno

Brinno TimeLapse TLC200 Manual de usuario

JVC

JVC GR-SXM68AC Guía de inicio rápido

Panasonic

Panasonic AG-HMC152EN Manual de usuario

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Manual de usuario

MYDLINK

MYDLINK DCS-6100LH Manual de usuario

Sony

Sony video Hi8 Handycam CCD-TR555 Manual de usuario

SECURECOM

SECURECOM V-5014B Manual de usuario

Panasonic

Panasonic HDC-SD100 Manual de usuario

Sharper Image

Sharper Image U-VIDEO Manual de usuario

JVC

JVC AA-V15EG Manual de usuario

Canon

Canon LEGRIA HV40 Manual de usuario

Sony

Sony Handycam DCR-VX2000 Manual de usuario

RCA

RCA CC616 Manual de usuario

Panasonic

Panasonic NVM40 Manual de usuario
