Hisense FSN535A20D Instrucciones de montaje

FSN535A20D

Contents

Safety and warning information.........2

Installing your new appliance............8

Description of the appliance............12

Display controls...............................13

Using your appliance.......................17

.......................21

.......................23

Troubleshooting...............................25

Disposal of the appliance................27

Cleaning and care....

Helpful hints and tips

This appliance is produced in accordance with the following EU guidelines:

2006/95/EC, 2004/108/EC, 2009/125/EC, EC.643/2009 and 2002/96/EC.

Safety and warning information

For your safety, before installing

and first using the appliance,

read this user manual carefully,

including its hints and warnings.

To avoid unnecessary mistakes

and accidents, it is important to

make sure that all people using

the appliance are thoroughly

familiar with its operation and

safety features. Save these

instructions and be sure that

they remain with the appliance if

it is moved or sold, so that

anyone using it, throughout its

life, will be properly informed on

its usage and safety notices.

For the safety of life and

property, keep the warnings

contained within these user's

instructions as the manufacturer

is not responsible for damages

caused by omission.

Safety for children and

others who are vulnerable

This appliance can be used

by children aged from 8 years

and above and persons with

reduced physical, sensory or

mental capabilities or lack of

experience and knowledge if

they have been given

supervision or instruction

concerning use of the

appliance in a safe way and

understand the hazards

involved. Children shall not

play with the appliance.

Cleaning and user

maintenance should not be

carried out by children without

supervision.

Keep all packaging away

from children as there is risk of

suffocation.

If you are discarding the

appliance, pull the plug out of

the socket, cut the connection

cable (as close to the appliance

as you can) and remove the

door to prevent children playing

from suffering an electric shock

or from closing themselves

inside the unit.

General safety

WARNING —This

appliance is intended

to be used to be used in

domestic households and not

intended for use in retail or

commercial environments;

WARNING — The water

supply line should only be

connected to a potable water

supply.

WARNING — Do not store

explosive substances such as

aerosol cans with a flammable

propellant in this appliance.

WARNING — If the supply

cord is damaged, it must be

replaced by a qualified

electrician in order to avoid the

risk of electric shock.

WARNING — Keep

ventilation openings, in the

appliance enclosure or in any

built-in structure clear of

obstruction.

WARNING — Do not use

mechanical devices or other

means to accelerate the

defrosting process, other than

those recommended by the

manufacturer.

WARNING — Do not damage

the refrigerant circuit.

WARNING — Do not use

electrical appliances inside the

food storage compartments of

the appliance, unless they are

of the type recommended by

the manufacturer.

WARNING — The refrigerant

and insulation are flammable.

When disposing of the

appliance, do so only at an

authorized waste disposal

center. Do not expose to flame.

Refrigerant

The refrigerant isobutene

(R600a) is contained within the

refrigerant circuit of the

appliance. This is a natural gas

with a high level of

environmental compatibility,

which is nevertheless

flammable. During

transportation and installation

of the appliance, ensure that

none of the components of the

refrigerant circuit becomes

damaged. The refrigerant

(R600a) is flammable.

Caution:risk of fire

If the refrigerant circuit is

damaged:

-Avoid naked flames and

sources of ignition.

-Thoroughly ventilate the room

in which the appliance is

situated. It is dangerous to alter

specifications or modify this

product in any way. Any

damage to the cord may cause

a shortcircuit, fire, and/or

electric shock.

Electrical safety

3. Make sure that you can

access the main plug of the

appliance.

4. Do not pull the main cable.

5. If your wall socket is loose,

do not insert the power plug.

There is a risk of electric shock

or fire.

6. You must not operate the

appliance without the interior

lighting lamp cover.

7. The fridge should only be

supplied with single phase

alternating current of

220~240V/50Hz. If the supply

fluctuates outside this range an

automatic A.C. voltage

regulator of more than 350W

should be used. The fridge

should be plugged into an

adequately earthed supply.

1. The power cord must not be

lengthened.

2. Make sure that the power

plug is not crushed or

damaged. A crushed or

damaged power plug may

overheat and cause a fire.

Daily use

Do not store flammable gas

or liquids in the appliance,

There is a risk of an explosion.

Do not operate any electrical

appliances in the appliance

(e.g. electric ice cream makers,

mixers etc.).

When unplugging always pull

the plug from the mains socket.

Do not pull on the cable.

Do not place hot items near

the plastic components of this

appliance.

Do not place food products

directly against the air outlet on

the rear wall.

Store pre-packed frozen food

in accordance with the frozen

food manufacture’s instructions.

The manufactures storage

recommendations should be

strictly adhered to. Refer to

relevant instructions for

storage.

Do not place carbonated or

fizzy drinks in the freezer

compartment as it creates

pressure on the container,

which may cause it to explode,

resulting in damage to the

appliance.

Do not place food directly

against the air outlet on the rear

wall cause it to explode,

resulting in damage to the

appliance.

Frozen food can cause frost

burns if consumed straight from

the freezer compartment.

Do not place the appliance in

direct sunlight.

Keep burning candles, lamps

and other items with naked

flames away from the

appliance.

The appliance is only

intended for keeping food stuff

and/or beverages for normal

household consumption as

explained in this instruction

booklet.

The appliance is heavy. Care

should be taken when moving it

Do not remove nor touch

items from the freezer

compartment if your hands are

damp/wet, as this could cause

skin abrasions or frost/freezer

burns.

Never use the base, drawers,

doors etc. to stand on or as

supports.

Frozen food must not be

refrozen once it has been

thawed out.

To avoid items falling and

causing injury or damage to the

appliance, do not overload the

door racks or put too much food

in the crisper drawers.

Caution!

Care and cleaning

Before performing

maintenance, switch off the

appliance and disconnect the

mains plug from the mains

socket.

Do not clean the appliance

with metal objects, steam

cleaner, ethereal oils, organic

solvents or abrasive cleansers.

Do not use sharp objects to

remove frost from the

appliance. Use a plastic

scraper.

Installation Important!

It is advisable to wait at least

four hours before connecting

the appliance to avoid

damaging the compressor.

Adequate air circulation

should be provided around the

appliance. To achieve sufficient

ventilation, please follow the

instructions relevant to

installation.

Wherever possible the back

of the product should not be too

close flammable materials as

some components are hot in

normal operation.

The appliance must not be

locate close to radiators or

cookers.

Make sure that the mains

plug is accessible following

installation of the appliance.

For electrical connection

carefully, follow the instructions

given in this manual.

Unpack the appliance and

check for damage. Do not

connect the appliance if it is

damaged. Report possible

damage immediately to your

retailer. In this case retain

packing.

Service

This product must be serviced

by an authorized Service

Center or Service Agent, and

only genuine spare parts must

be used.

130°

140°

≥100

≥75

Installing your new appliance

Before using the appliance for the first

time, you should the

following tips.

Ventilation of appliance

In order to improve efficiency of

the cooling system and save

energy, it is necessary to maintain

good ventilation around the appliance

. For this reason, suf

clear space should

around the refrigerator .

It is advisable for there to

be 75mm of space from the back to

the wall, at least 100mm from its top,

at least 100mm from its side to the

wall and a clear space upfront to allow

the freezer door to open 130℃ and

the refrigerator door to open 140℃ .

See in follow diagrams.

This appliance performs well in the

climate class from SN to T. It may not

work properly if left at a

above or below the

for a long period.

Note:

Keep the appliance out of direct

sunlight, rain or frost. Stand the

appliance away from heat sources

such as stoves, fires or heaters.

WW1 W2 DD1

908 417.5 277 600 1142.5

review

ficient

be available

Please see the following diagrams.

Space required (mm)

temperature

indicated range

Stand your appliance in a dry place

to avoid moisture damage.

adjusta e bottom f etbl e

Warning!

For proper installation, this refrigerator

must be placed on a level surface of

hard material that is the same height

as the rest of the flooring. This surface

should be strong enough to support a

fully loaded refrigerator.

The rollers,

forward or

Moving the

may damage your floor and the rollers.

Leveling of appliance

For sufficient leveling and air

circulating in the lower rear section of

the appliance, the bottom feet may

need to be adjusted. Please use a

suitable spanner.

To allow the doors to self-close, tilt

the top backwards about

15mm or 0.5°by turning the

adjustable feet.

Whenever you want to move the

appliance, remember to turn the feet

back up, so that the appliance can roll

freely. Reinstall the appliance when

relocating.

0.5

15mm

Fixing the handle

Before you use the product, please

check the handle of the refrigerator. If

the handle is loose, you should fix it

with the hexangular screwdriver in the

clockwise direction, then it can be

used normally.

by should be only used for

backward movement.

refrigerator sideways

Installing the water lines and filter

Installing the water filter

Installing the filterthe water lines of

Note!

The water lines must be fully

inserted into the filter to prevent water

leaking.

Filter Holder Screw

To ,

follow the instructions of installing

steps below that referring to the

figures supplied.

install the water lines of the filter

Second,

mount the external filter. (Note: The

water filter should be mount on the

wall where it is convenient to be

replaced, and do not mount on the

wall behind the refrigerator.)

determine the location to

Third,

between the filter and the tap, and the

distance from the filter to the fridge.

Prepare lines as required lengths.

(Cut the proper lengths of water lines

which you determine to connect with

the filter inlet or outlet.)

determine the distance

Fourth, mount the filter holder onto

the wall by using a screwdriver and

attach the water filter.

Warning!

The water filter must be held upright

as shown in the figure above. It is

critical to connect the water inlet and

outlet hoses on the filter correctly.

Never mount the filter onto the

refrigerator. Coolant pipes might be

pierced.

Filter Holder

Filter

Inlet

Outlet

FLOW

First, take out the water filter and

water lines from the fridge door rack.

To , follow the

installing steps below.

fit the water filter

First, the 2 clips out, then pull out

the 2 stopper of the water filter.

take

Clip

Stopper

Water Filter

It is recommended to have a

suitably qualified person to install the

product.

The line length should be less than

5m. If the water line is too long(>5m),

the ice and cold water content may be

affected due to insufficient water

pressure.

Cut the water line as required length

and avoid overbending the water

lines.

Clip

Connector

Water line Water line

The water lines must be connected

with the potable water only.

Note:

To operate properly, the ice maker

requires a water pressure of 207~689

Kpa.

Connect filter outlet line to the fridge

The outlet line of the water filter

should be connected with the inlet line

of the refrigerator by a Two-Way

Connector.

The water lines must be fully inserted

into the center of the connector to

prevent water leaking.

Insert the 2 clips in the install pack as

shown in the diagram, and then

confirm that each clip holds the line

firmly.

Connecting the filter inlet line to

the water supplier

Screw the adaptor firmly onto a

suitable 3/4” BSP connector water

outlet. Fully insert the water line into

the plastic adaptor. Then insert the

clip in the install pack as the figure

shown below.

The initial dark discoloration of

water is normal.

After installed the filter, please open

the water valve to flush the filter for 5

minutes before use.

Third,

position as the figure shown below,

and confirm that each clip holds the

water line firmly.

insert the 2 clips in the proper

Clip

Water line

FLOW

Water line

Water Filter

Water line

Outlet

Inlet

Clip

Connector

Filter inlet line

Water valve

FLOW

Water

Second, fully insert the water lines

into the Inlet and Outlet of the water

filter.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Refrigerador de Hisense

Hisense

Hisense RC33 Instrucciones de montaje

Hisense

Hisense RF632N4BBF Instrucciones de montaje

Hisense

Hisense RB329N4AWE Instrucciones de montaje

Hisense

Hisense AEH-BW2H1 Instrucciones de montaje

Hisense

Hisense RS694N4IBF Manual de usuario

Hisense

Hisense RF540N4WFE Instrucciones de montaje

Hisense

Hisense RQ560N4WC1 Instrucciones de operación

Hisense

Hisense RR55D4AW1 Instrucciones de montaje

Hisense

Hisense RL170D4AWE Instrucciones de montaje

Hisense

Hisense BCD-560 Instrucciones de montaje

Hisense

Hisense HR6BF121 Instrucciones de montaje

Hisense

Hisense RQ689N4AC1 Instrucciones de montaje

Hisense

Hisense RF210N6AHE Manual de usuario

Hisense

Hisense HRSBS632BW Instrucciones de montaje

Hisense

Hisense H230RRE-WD Instrucciones de montaje

Hisense

Hisense HRF266N6CSE Manual de usuario

Hisense

Hisense RB438N4E Instrucciones de montaje

Hisense

Hisense RS-19DL4SQ Manual de usuario

Hisense

Hisense RQ5P470SAFE Instrucciones de montaje

Hisense

Hisense RT393D4AW1 Manual de usuario

Hisense

Hisense H120RWH Instrucciones de montaje

Hisense

Hisense HQD20 Series Manual de usuario

Hisense

Hisense RF632N4WFF Instrucciones de montaje

Hisense

Hisense RR197D4AGN Instrucciones de montaje

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
