Hisense U1 Manual de usuario

Content

Getting ready for use....................................1

Part name and function...........................1

Inserting the USIM/SIM card....................3

Inserting SD card ....................................4

Installing the battery................................4

Removing the battery..............................5

Charging the battery................................5

Battery performance................................6

Turning your phone on and off.................7

Desktop manager....................................8

Making a call.........................................10

Main Function............................................11

Alarms ..................................................11

Browser ................................................12

Calculator..............................................12

Calendar...............................................13

Call log..................................................13

Camera.................................................14

Contacts................................................14

Downloads............................................15

Email ....................................................15

Firewall.................................................16

FM Radio..............................................16

Gallery..................................................16

Messaging ............................................16

Music....................................................17

My files .................................................18

Note pad...............................................18

Phone...................................................19

III

Recorder...............................................19

Settings.................................................20

Stopwatch.............................................24

Voice Dialer...........................................25

Voice search.........................................25

World time.............................................25

Safety information......................................26

Warranty Terms and Conditions:Error! Bookmark not defined.

Getting ready for use

Part name and function

Name

Function

MultiTouch

Quick and easy

operation.

Menu key

Press to present a

main menu.

Home key

Press to return to

home screen.

Return key

Return to previous

menu.

Fast

search key

Enter Google

interface.

Power key

When powered on

press to darken or

lighten the screen

or hold to pop up

option menu. When

powered off hold to

turn on the phone.

Camera

Take pictures.

Volume

keys

Press to

accommodate the

volume and start up

silence mode when

there is an

incoming call.

USB port

Insert data cable.

Earphone

jack

Insert earphone.

Inserting the USIM/SIM

card

Your phone must work with a card

provided by your service provider.

Your card contains all your

subscription information.

Insert USIM/SIM card with the metal

contacts facing down and the cut

corner aligned with that of the slot.

Notes:

1. If no card is installed, or there are

errors in the insertion, or your

card is damaged, the string of

“Please insert a sim card” will

display on the screen after your

phone is powered on.

2. If your card is PIN-locked your

phone will display “unlock PIN”.

You must enter PIN before the

phone can start working. Please

contact your network service

provider if you need.

3. When inserting card, please

keep it away from possible

damage caused by static,

scratch and bend, and put it

where is not available for

children.

Inserting SD card

Insert SD card with the metal contacts

facing down and the cut corner

aligned with that of the slot;

Installing the battery

You must install and charge the

battery to use your phone. Insert the

ridge at the top of the battery into the

base of the phone, make sure to touch

the metal contact on the phone, then

push the battery down and snap it into

place.

Note:

Your phone is designed to be used

only with original batteries and

chargers. Use of other batteries or

chargers may cause damage to your

phone and the warranty will be void.

Removing the battery

Make sure your phone is powered off

to avoid the important information

getting lost.

Hold battery bottom and remove the

battery from the phone.

Charging the battery

New batteries are shipped partially

charged. Before you can use your

phone, you need to charge the battery.

Some batteries will have best

performance after several full

charge/discharge cycles.

1. Connect data cable and charger,

plug one end into your phone’s

data port.

2. Plug the other end of the charger

into the appropriate electrical

outlet (100~240V AC).

3. When your phone indicates that

the battery is fully charged,

remove the charger.

Notes:

1. Before charge, make sure the

battery is installed in the phone.

2. You need longer charging period

with the lower voltage.

3. You need longer time as

operation as charging.

4. The nomal charge temperature is

during 0℃-40℃.

Battery performance

1630mAh (standard

battery)

Standby

time*

120hours

Talk time*

300 minutes

Many conditions can affect

battery’s standby time, such as

local network conditions, phone’s

settings, frequent operations,

using data services, etc.

The battery performance is also

affected by charge state and

temperature.

The special explanation

about single-pass dual

card dual standby use

You can’t use two cards talking or net

playing at the same time when your

phone inserted two cards. If one card

is talking or net playing, the other

card must turn off the network.

Basic operations

Turning your phone on

and off

Turn on the phone: Press and hold

Power key for more than 3 seconds to

turn on your phone.
