Hilintec C09 Series Manual de usuario
Copyright © Chengdu Hilin Technology Co., Ltd.
..
C09 Flow Control Vacuum Pump series
User Guide
Issue
15
Date
2020-6-19
Copyright © Chengdu Hilin Technology Co., Ltd.
Copyright © Chengdu Hilin Technology Co., Ltd. 2020. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means
without prior written consent of Chengdu Hilin Technology Co., Ltd.
Trademarks and Permissions
is a trademark of Chengdu Hilin Technology Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of
their respective holders.
Notice
The purchased products, services and features are stipulated by the contract made
between Chengdu Hilin Technology Co., Ltd. and the customer. All or part of the products,
services and features described in this document may not be within the purchase scope or
the usage scope. Unless otherwise specified in the contract, all statements, information,
and recommendations in this document are provided "AS IS" without warranties,
guarantees or representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has
been made in the preparation of this document to ensure accuracy of the contents, but all
statements, information, and recommendations in this document do not constitute a
warranty of any kind, express or implied.
Chengdu Hilin Technology Co., Ltd.
Address:
No.3663 Section 2 Muhua Road
Shuangliu District
Chengdu Sichuan China 610000
Website:
http://www.hilintec.com
Tel:
+86-28-62567958
C09 Flow Control Vacuum Pump Series User Guide
Copyright © Chengdu Hilin Technology Co., Ltd.
1
About This Document
Purpose
This document is related to the C09 flow control micro vacuum
pump products,which is used to guide relevant technical personnel
to initially understand the characteristics of the product.
Intended Audience
This document is intended for technical personnel. You should have
a good understanding of your product and have a clear concept of
the relevant parameters, specifications, and other information of the
applications of the micro pump.
Keyword
Speed control function, anti-loosening connectors, working status
indicator, related parameters, wiring instructions
C09 Flow Control Vacuum Pump Series User Guide
Copyright © Chengdu Hilin Technology Co., Ltd.
2
Change History
The change history accumulates each update of this document. The
latest version of the document contains all the previous updates.
Issue
Date
Product
Version
Issuer
Modification
01
2018-7
1.0
XX
First official release
06
2018-12
1.0
XX
Revise the lifetime test
description and
warning 2
07
2018-12
1.0
XX
Add description of state
memory function of the
knob speed control
version
08
2019-2
1.0
XX
Modify the curve graph
09
2019-3
1.0
XX
Add note 3 in the
parameter description
10
2019-3
1.0
XX
Add description in the
protection function
11
2019-9
1.0
LYZ
Modify the document
format
12
2019-12
1.0
LJ
Add description of
key specifications
testing
13
2020-5
1.0
LJ
Replacement of flow
curve and product
outline drawing; add
starting current curve
14
2020-5
1.0
LJ
Replacement of
product assembly
drawing
15
2020-6
1.0
LJ
Add medium and
related notes
C09 Flow Control Vacuum Pump Series User Guide
Copyright © Chengdu Hilin Technology Co., Ltd.
3
Contents
About This Document...............................................................................................1
Change History...........................................................................................................2
Contents.......................................................................................................................3
1Characteristics........................................................................................................1
1.1 Compact Size..................................................................................................................................... 1
1.2 Speed Control Function..................................................................................................................... 1
1.3 Anti-loosening Connectors................................................................................................................ 1
1.4 Working Status Indicator....................................................................................................................2
1.5 Brushless Motor................................................................................................................................. 2
1.6 Protection........................................................................................................................................... 2
1.7 Digital Signal Control........................................................................................................................ 2
1.8 Closed Loop Speed Control............................................................................................................... 2
2Special Features.....................................................................................................3
2.1 Speed Control Function..................................................................................................................... 3
2.2 Warning Function...............................................................................................................................3
3Technical Specifications...................................................................................... 4
3.1 Key Specifications............................................................................................................................. 4
3.2 Description of Versions......................................................................................................................5
3.3 Life-time Test Conditions.................................................................................................................. 5
3.4 Working Conditions........................................................................................................................... 6
3.5 Materials.............................................................................................................................................6
3.6 Filtration.............................................................................................................................................6
3.7 Parameter Curve.................................................................................................................................7
3.8 Starting Current..................................................................................................................................8
4Product Model Description................................................................................. 9
4.1 Brief Description of Model Naming.................................................................................................. 9
C09 Flow Control Vacuum Pump Series User Guide
Copyright © Chengdu Hilin Technology Co., Ltd.
4
5Electrical Connection..........................................................................................10
5.1 Brief Description of Types............................................................................................................... 10
5.2 Knob Speed Control Type................................................................................................................10
5.3 PWM Speed Control Type............................................................................................................... 12
5.4 Frequency Speed Control Type........................................................................................................14
6Cautions................................................................................................................. 16
7Dimensions............................................................................................................17
8Appearance............................................................................................................18
C09 Flow Control Vacuum Pump Series User Guide
Copyright © Chengdu Hilin Technology Co., Ltd.
1
1Characteristics
1.1 Compact Size
The product weighs about 90g, and the overall size is about
64x43x48mm (this size does not include shock-absorb feet).
1.2 Speed Control Function
There are three types of speed control functions available for this
series of pumps: knob speed control, PWM speed control and
frequency speed control.
1.3 Anti-loosening Connectors
The plug is connected with a buckle to make the connection part
more tight and not easy to fall off.
C09 Flow Control Vacuum Pump Series User Guide
Copyright © Chengdu Hilin Technology Co., Ltd.
2
1.4 Working Status Indicator
Integrated speed indication function, visually understand the
running status of the pump according to the flashing frequency of
the indicator light.
1.5 Brushless Motor
This model is driven by brush-less motors which have the
advantages of long service life, low interference and high reliability.
1.6 Protection
Equipped with overheating protection, overload protection, power
supply under-voltage, over-voltage protection and reverse
connection protection function to prevent accidental damage to the
pump.
1.7 Digital Signal Control
The circuit input adopts all digital signal control with strong
anti-interference ability, stable and reliable work.
1.8 Closed Loop Speed Control
The internal closed-loop control algorithm is used to monitor and
adjust the motor speed in real time to keep the speed and output
stable.
C09 Flow Control Vacuum Pump Series User Guide
Copyright © Chengdu Hilin Technology Co., Ltd.
3
2Special Features
2.1 Speed Control Function
The flow rate of the pump can be changed by adjusting the motor
speed. There are three types of speed control functions available for
this series of pumps: knob speed control type, PWM speed control
type and frequency speed control type. Please refer to Chapter 5
Electrical Connection for specific usage of different speed
adjustment methods.
2.2 Warning Function
Feed back the working status through working status indicator light.
1. When the light remains green, it means that the power supply is
normal and the pump is not working;
2. When the green light flashes, it means the pump is working
normally; the faster the green light flashes, the higher the pump
speed, the greater the output flow;
3. When the light remains red, it means the pump is working
abnormally;
4. When the positive and negative poles are reversed, the indicator
light is off, the pump does not work, but it will not damage the
pump.
C09 Flow Control Vacuum Pump Series User Guide
Copyright © Chengdu Hilin Technology Co., Ltd.
4
3Technical Specifications
3.1 Key Specifications
（Standard atmospheric pressure 101kpa）
Model
Version
Rated
Voltage
（V DC）
Load
Current
（mA）
Average
Flow
（L/min）
Peak
Flow
（L/min）
Relative
Vacuum
（-kpa）
Weight
（g）
C09L
Premium
Version
24
≤200
≥2.0
≥2.0
≥37
≈90
Standard
Version
24
≤200
≥1.7
≥1.8
≥37
Simplified
Version
24
≤200
≥1.3
≥1.5
≥37
Note: 1.The input voltage requires 24V±10%.The change of working voltage will
affect the load current, while the flow rate and vacuum degree are basically
unchanged;
2.Unless otherwise specified, the technical parameters are measured under the
conditions of temperature 25℃ and standard atmospheric pressure of
101kPa.
3.The parameters in the table are measured at the maximum speed of the
motor. When the motor speed changes, the vacuum level is basically
unchanged.
4.The peak flow rate in the table refers to the flow value measured with a
rotameter, and the average flow rate is measured with a soap film flow-meter.
