DS-7200HVI/HFI-SH Series DVR

USER MANUAL

alarm shop

User Manual of DS-7200HVI/HFI-SH Series DVR

Hikvision® Network Digital Video Recorder User’s Manual

This manual, as well as the software described in it, is furnished under license and may be used or copied only in

accordance with the terms of such license. The content of this manual is furnished for informational use only, is subject

to change without notice, and should not be construed as a commitment by Hikvision Digital Technology Co., Ltd.

(Hikvision). Hikvision assumes no responsibility or liability for any errors or inaccuracies that may appear in the book.

Except as permitted by such license, no part of this publication may be reproduced, stored in a retrieval system, or

transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written

permission of Hikvision.

HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,

REGARDING THE HIKVISION SOFTWARE. HIKVISION DOES NOT WARRANT, GUARANTEE, OR MAKE

ANY REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF THE USE OF THE HIKVISION

SOFTWARE IN TERMS OF ITS CORRECTNESS, ACCURACY, RELIABILITY, CURRENTNESS, OR

OTHERWISE. THE ENTIRE RISK AS TO THE RESULTS AND PERFORMANCE OF THE HIKVISION

SOFTWARE IS ASSUMED BY YOU. THE EXCLUSION OF IMPLIED WARRANTIES IS NOT PERMITTED BY

SOME STATES. THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.

IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO

YOU FOR ANY CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES (INCLUDING DAMAGES FOR

LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, AND THE

LIKE) ARISING OUT OF THE USE OR INABILITY TO USE THE HIKVISION SOFTWARE EVEN IF HIKVISION

HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO NOT

ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL

DAMAGES, THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.

alarm shop

User Manual of DS-7200HVI/HFI-SH Series DVR

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and comply

therefore with the applicable harmonized European standards listed under the Low Voltage Directive

2006/95/EC, the EMC Directive 2004/108/EC.

2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper recycling, return this product to your local

supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection

points. For more information see: www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted

municipal waste in the European Union. See the product documentation for specific battery

information. The battery is marked with this symbol, which may include lettering to indicate

cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier

or to a designated collection point. For more information see: www.recyclethis.info.

Description on Laser Specification

The optical disc drive such as DVD Super Multi (Double Layer) Drive 22X that is used in this computer is equipped

with laser. The classification label with the following sentence is affixed to the surface of the drive.

CLASS 1 LASER

PRODUCT TO IEC60825-1

LASER KLASSE 1

The drive with the above label is certified by the manufacturer that the drive complies with the requirement for laser

product on the date of manufacturing pursuant to article 21 of Code of Federal Regulations by the United States of

America, Department of Health & Human Services, Food and Drug Administration.

In other countries, the drive is certified to comply with the requirement pursuant to IEC 60825-1 and EN 60825-1 on

class 1 laser product.

This computer is equipped with the optical disc drive in the following list according to the model.

alarm shop

User Manual of DS-7200HVI/HFI-SH Series DVR

Safety Warnings and Cautions

Please pay attention to the following warnings and cautions:

Hazardous Voltage may be present: Special measures and precautions must be

taken when using this device. Some potentials (voltages) on the device may present a

hazard to the user. This device should only be used by the Employees from our company

with knowledge and training in working with these types of devices that contain live circuits.

Power Supply Hazardous Voltage: AC mains voltages are present within the power supply assembly.

This device must be connected to a UL approved, completely enclosed power supply, of the proper rated voltage

and current. No user serviceable parts inside the power supply.

System Grounding (Earthing): To avoid shock, ensure that all AC wiring is not exposed and that the

earth grounding is maintained. Ensure that any equipment to which this device will be attached is also connected

to properly wired grounded receptacles and are approved medical devices.

Power Connect and Disconnect: The AC power supply cord is the main

disconnect device to mains (AC power).The socket outlet shall be installed near the

equipment and shall be readily accessible.

Installation and Maintenance: Do not connect/disconnect any cables to or perform

installation/maintenance on this device during an electrical storm.

alarm shop

User Manual of DS-7200HVI/HFI-SH Series DVR

Power Cord Requirements: The connector that plugs into the wall outlet must be a grounding-type male

plug designed for use in your region. It must have certification marks showing certification by an agency in your

region. The connector that plugs into the AC receptacle on the power supply must be an IEC 320, sheet C13,

female connector. See the following website for more information http://kropla.com/electric2.htm.

Lithium Battery: This device contains a Lithium Battery. There is a risk of

explosion if the battery is replaced by an incorrect type. Dispose of used batteries

according to the vendor’s instructions and in accordance with local environmental

regulations.

Perchlorate Material: Special handling may apply. See

www.dtsc.ca.gov/hazardouswaste/perchlorate. This notice is required by California Code of Regulations, Title

22, Division 4.5, Chapter 33: Best Management Practices for Perchlorate Materials. This device includes a

battery which contains perchlorate material.

Taiwan battery recycling:

Please recycle batteries.

Thermal and Mechanical Injury: Some components such as heat sinks,

power regulators, and processors may be hot; care should be taken to avoid contact

with these components.

Electro Magnetic Interference: This equipment has not been tested for compliance with emissions limits

of FCC and similar international regulations. This device is not, and may not be, offered for sale or lease, or sold,

or leased until authorization from the United States FCC or its equivalent in other countries has been obtained.

Use of this equipment in a residential location is prohibited. This equipment generates, uses and can radiate

radio frequency energy which may result in harmful interference to radio communications. If this equipment

does cause harmful interference to radio or television reception, which can be determined by turning the

equipment on and off, the user is required to take measures to eliminate the interference or discontinue the use

of this equipment.

Lead Content:

Please recycle this device in a responsible manner. Refer to local environmental

regulations for proper recycling; do not dispose of device in unsorted municipal

waste.

alarm shop

User Manual of DS-7200HVI/HFI-SH Series DVR

Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact

dealer.

This manual is applicable to DS-7204HVI-SH, DS-7208HVI-SH, DS-7216HVI-SH; DS-7204HFI-SH,

DS-7208HFI-SH and DS-7216HFI-SH series DVR.

This manual may contain several technically incorrect places or printing errors, and the content is subject to

change without notice. The updates will be added into the new version of this manual. We will readily improve

or update the products or procedures described in the manual.

alarm shop

User Manual of DS-7200HVI/HFI-SH Series DVR

Preventive and Cautionary Tips

Before connecting and operating your device, please be advised of the following tips:

•Ensure unit is installed in a well-ventilated, dust-free environment.

•Unit is designed for indoor use only.

•Keep all liquids away from the device.

•Ensure environmental conditions meet factory specifications.

•Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping it

may cause damage to the sensitive electronics within the unit.

•Use the device in conjunction with an UPS if possible.

•Power down the unit before connecting and disconnecting accessories and peripherals.

•A factory recommended HDD should be used for this device.

•Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or

equivalent type only. Dispose of used batteries according to the instructions provided by the battery

manufacturer.

alarm shop

User Manual of DS-7200HVI/HFI-SH Series DVR

Product Key Features

General

PAL/NTSC adaptive video inputs.

H.264 video compression with high reliability and superior definition.

Each channel supports dual-stream.

Independent configuration for each channel, including resolution, frame rate, bit rate, image

quality, etc.

Input and output video quality is configurable.

Normal and event recording parameters configurable per individual camera.

Encoding for both audio/video composite stream and video stream; audio and video

synchronization during composite stream encoding.

Watermark technology.

Local Monitoring

Simultaneous HDMI, VGA and CVBS outputs.

HDMI/VGA output at up to 1920×1080P resolution.

1/4/6/8/9/16-division live view is supported, and the display sequence of screens is adjustable.

Live view screen can be switched in group, and manual switch and automatic cycle view is also

provided, the interval of automatic cycle can be adjusted.

Quick setting menu is provided for live view.

The selected live view channel can be shielded.

Motion detection, tamper-proof, video exception and video loss alarm functions.

Privacy mask.

Multiple PTZ protocols supported; setting and calling of PTZ preset, patrol and pattern.

Zooming in by clicking the mouse and PTZ tracing by dragging mouse.

HDD Management

1 SATA hard disk can be connected to DS-7200HVI-SH and DS-7204HFI-SH, and 2 SATA hard

disks to DS-7208/7216HFI-SH, with a maximum of 4TB storage capacity for each disk.

8 network disks (8 NAS disks, or 7 NAS disks+1 IP SAN disk) can be connected.

HDD group management.

Support HDD standby function.

HDD property: redundancy, read-only, read/write (R/W).

HDD quota management; different capacity can be assigned to different channel.

Recording and Playback

Holiday recording schedule configuration.

Normal and event video encoding parameters.

Multiple recording types: manual, normal, and motion.

8 recording time periods with separated recording types.

Pre-record and post-record for motion detection for recording, and pre-record time for schedule

and manual recording.

Searching record files by event.

Customization of tags, searching and playing back by tags.

Locking and unlocking record files.

Local redundant recording.

alarm shop

User Manual of DS-7200HVI/HFI-SH Series DVR

Searching and playing back record files by channel number, recording type, start time, end time,

etc.

Smart search for the selected area in the video.

Zooming in when playback.

Playing reversely.

Support pause, speed up, speed down, skip forward, and skip backward when playback, locating

by dragging the mouse.

Up to 4/8/16-ch synchronous playback at 4CIF resolution.

Backup

Export video data by USB or SATA .storage device.

Export video clips when playback.

Management and maintenance of backup devices.

Alarm and Exception

Configurable arming time of alarm input/output.

Alarm for video loss, motion detection, tampering, abnormal signal, video input/output standard

mismatch, illegal login, network disconnected, IP confliction, abnormal record, HDD error, and

HDD full, etc.

Alarm event triggers full screen monitoring, audio alarm, notifying surveillance center and

sending email.

Automatic restore when system is abnormal.

Other Local Functions

Operable by mouse, or IR remote control.

Three-level user management; admin user is allowed to create many operating accounts and define

their operating permission, which includes the limit to access any channel.

Operation, exceptions and log recording and searching.

Import and export of device configuration information.

Network Functions

1 self-adaptive 10M/100M network interface.

IPv6 is supported.

TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, UPnP™, NFS, and

iSCSI are supported.

TCP, UDP and RTP for unicast.

Remote search, playback, download, locking and unlocking of the record files, and downloading

files broken transfer resume.

Remote parameters setup; remote import/export of device parameters.

Remote viewing of the device status, system logs and alarm status.

Remote locking and unlocking of control panel and mouse.

Remote HDD formatting and program upgrading.

Remote system restart.

RS-485 transparent channel transmission.

Alarm event and exception information can be sent to the remote host.

Remotely start/stop recording.

Upgrade by remote FTP server.

Remote PTZ control.

Two-way audio and voice broadcasting.

alarm shop

User Manual of DS-7200HVI/HFI-SH Series DVR

Embedded WEB server.

Development Scalability:

SDK for Windows and Linux system.

Source code of application software for demo.

Development support and training for application system.

alarm shop

Otros manuales para DS-7200HVI

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de DVR de HIK VISION

HIK VISION

HIK VISION DS-MP7516 Series Manual de usuario

HIK VISION

HIK VISION DS-9204/08/16HWI-ST Manual de usuario

HIK VISION

HIK VISION DS-7200HGHI-K1 Series Manual de usuario

HIK VISION

HIK VISION DS-8000AHI-S/AHLI-S Series Manual de usuario

HIK VISION

HIK VISION ds-7200HVI-sh series Manual de usuario

HIK VISION

HIK VISION DS-7204HI-S Series Manual de usuario

HIK VISION

HIK VISION C Series Manual de usuario

HIK VISION

HIK VISION DS-9100HFI-SH Series Manual de usuario

HIK VISION

HIK VISION DS-96000NI-I16/H Series Manual de usuario

HIK VISION

HIK VISION DS-8000 Series Manual de usuario

HIK VISION

HIK VISION DS-7100HQHI-K1 Series Manual de usuario

HIK VISION

HIK VISION iDS-7204AHQHI-M1 Manual de usuario

HIK VISION

HIK VISION DS-7316HUI-K4 Manual de usuario

HIK VISION

HIK VISION iDS-E08HQHI-B Manual de usuario

HIK VISION

HIK VISION DS-8104AHGHLI-E4 Manual de usuario

HIK VISION

HIK VISION DS-7304HFI-SE Manual de usuario

HIK VISION

HIK VISION DS-77 NI-SP Series Manual de usuario

HIK VISION

HIK VISION DS-7104HGHI-SH Manual de usuario

HIK VISION

HIK VISION AE-MD5043 Manual de usuario

HIK VISION

HIK VISION 9100HFI-ST Series Manual de usuario

HIK VISION

HIK VISION DS-9000-ST Manual de usuario

HIK VISION

HIK VISION DS-7204HI-S Series Manual de usuario

HIK VISION

HIK VISION DS-9000HFI-ST Manual de usuario

HIK VISION

HIK VISION DS-5504HMI series Manual de usuario

Manuales populares de DVR de otras marcas

FLIR

FLIR M3100E Series Manual de usuario

VTRACKPRO

VTRACKPRO FPRO300 Manual de usuario

Swann

Swann NVR-7085 models Manual de usuario

XtendLan

XtendLan DVR-1670C Manual de usuario

urmet domus

urmet domus 1093/004AHD Manual de usuario

Holux

Holux M1 Manual de usuario

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manual de usuario

Whistler

Whistler D16VRS Manual de usuario

Defender Security

Defender Security 82-20235 Manual de usuario

MISUMI

MISUMI MP-WF100M Manual de usuario

Speco

Speco D8HU Manual de usuario

UST

UST DDR-E04AA Instrucciones de uso

Consolidated

Consolidated Digital Video Recorder Manual de usuario

Mace

Mace DVR0404RW Guía de inicio rápido

RCA

RCA RTD315W Manual de usuario

FSM

FSM Colibri Grande PRO Manual de usuario

Hauppauge

Hauppauge HD PVR 2 Manual de usuario

Identivision

Identivision ICR-PH161i PIONEER Manual de usuario
