HighPoint Rocket 710 Manual de usuario

Rocket 710 (R710)

Rocket 720 (R720)

PCI-Express 3.0 x8 Controller

R710

R720

Quick Installation Guide

V1.00

R710 Kit Contents

•Rocket 710 Controller Card

•Low Profile Bracket

•Quick Installation Guide

R720 Kit Contents

•Rocket 720 Controller Card

•Low Profile Bracket

•Quick Installation Guide

Operating System

•System with a free PCIe 3.0/4.0 x8 or x16 slot

•Windows 11, 10 / Server 2022, 2019, 2016/ Microsoft Hyper-V

•RHEL/Debian/Ubuntu/Fedora/Proxmox (Linux kernel

3.10 and later)

•Arch Linux (Kernel 5.17.5 and above)

Required Accessories

Certified cables are available directly from HighPoint and our

authorized resellers. For more information, please contact our

Sales Department (sales@highpoint-tech.com).

1. In order to use SATA drives with the R710/720 SAS

controller, you will need at least one 8643-4SATA-1M cable.

Each cable can support four SATA hard drives or SSD’ s via

an SFF-8643 port.

2. In order to use SAS/SATA drives with the R710/720 SAS

controller, you will need at least one 8643-4SAS-1M cable.

Each cable can support up to four SAS/SATA hard drives or

SSDs via an SFF-8643 port.

R710 Hardware

Front View

R720 Hardware

Front View

R710/720 Hardware Installation

Note: Make sure the system is powered-off before installing the SAS

Controller.

1. Connect the R710/720 into the PCIe 3.0/ 4.0 x8 or x16 slot

of the motherboard;

2. How to connect disks to the R710/R720 using the 8643-

4SATA-1M cable.

SATA Power

SATA

3. How to connect disks to the R710/R720 using the 8643-

4SAS-1M cable.

Each cable can support up to four SAS/SATA hard drives or

SSDs via an SFF-8643 port.

SAS Power Connector

SATA/SAS Drivers

R710 Channel Layout

R720 Channel Layout

Channels 5-8

Channels 1-4

Channels 13-16

Channels 9-12

Channels 5-8

Channels 1-4

Optional Certified Cable Accessories

Device Cables

8643-4SAS-1M

SFF-8643 SAS to 4x SFF-8482

SAS cable

Length: 1M

8643-4SATA-1M

SFF-8643 SAS to 4x SATA

cable,with Power Connector

Length: 1M

Resources

A variety of manuals, guides and FAQs are available for Rocket

710/720 SAS controllers. In addition, we recommend visiting

the Software Downloads webpage for the latest drivers,

management interfaces, and installation guides.

For Software Downloads, Documentation and more information

about this product, please visit the following website:

https://www.highpoint-tech.com/rocket700-series

FAQ & Troubleshooting:

FAQ - HighPoint Technologies, Inc. (helpjuice.com)

Customer Support

If you encounter any problems while utilizing the SAS

controllers, orhave any questions about HighPoint Technologies,

Inc. products & solutions, feel free to contact our Customer

Support Department.

Web Support:

https://www.highpoint-tech.com/support-and-services

HighPoint Technologies, Inc. websites:

https://www.highpoint-tech.com
