General Information
This section familiarizes the operator ith the features and specifications of the
VLF Series of Very Low Frequency AC Hipots manufactured by HIGH VOLTAGE, INC.
Features and Specifications
The VLF-12011CM hipot test set provides true sine ave AC output voltage for the test of high
voltage cables and other capacitive loads.
Standard features of the VLF-12011CM AC Hipot
•
Sine ave output, 0.1, .05, .02 and .01Hz frequencies standard.
•
Continuously adjustable output voltage
•
Continuous duty rating
•
Fixed primary overload
•
“Zero Start” and External Interlock provision
•
Single-range voltmeter
•
Single range current meter ith capacitance measuring scale for determining best test frequency
•
Dual operating mode- Hipot/Burn for either hipotting ith an overload or burning ith current limiting
•
Three piece design, mounted on one Trolley.
•
Transit protected meter prevents damage bet een test sites in vehicle mounted installations
•
20 ft. interconnect cables ith grounds
•
100 ft. shielded X-Ray output cable AND 100 ft. Ground an Cable Reel
