Hidral PH-300 Manual de usuario
ASSEMBLY INSTRUCTIONS
IM-560en
Vers. 05
22/09/2021
PH-300
VERTICAL LIFTING PLATFORM
ORIGINAL INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
PH-300 VERTICAL LIFTING PLATFORM
IM-560en
Vers. 05
Page 1
Contents
1. Tools and equipment............................................................................................................... Page 2
2. Shaft check............................................................................................................................. Page 3
3. Guide assembly...................................................................................................................... Page 12
4. Assembly of the machine cabinet ........................................................................................... Page 15
5. Hydraulic installation............................................................................................................... Page 16
6. Electrical installation ............................................................................................................... Page 17
6.1. Guide electrical installation........................................................................................ Page 17
6.2. Machine cabinet electric installation.......................................................................... Page 17
7. Vehicle installation .................................................................................................................. Page 18
8. Landing push button panels.................................................................................................... Page 24
9. Upper landing door assembly................................................................................................. Page 26
10. Protective bellows (optional)................................................................................................. Page 35
11. Electrical adjustment............................................................................................................. Page 36
11.1. Adjustment of the circuit breaker ............................................................................. Page 36
11.2. Adjustment of the stop nal limit switches ............................................................... Page 36
11.3. Adjustment of the opening angle of the automatic door........................................... Page 37
12. Hydraulic adjustment ........................................................................................................... Page 38
12.1. Description of the group .......................................................................................... Page 38
12.2. Hydraulic diagram.................................................................................................... Page 38
12.3. Adjustment of the descent speed ............................................................................ Page 39
13. Adjustment of the overload detection system ....................................................................... Page 39
14. Final tests ............................................................................................................................. Page 40
IM-560en
Vers. 05
Page 2
ASSEMBLY INSTRUCTIONS
VERTICAL LIFTING PLATFORM PH-300
1. Tools and equipment
●Safety goggles
●Gloves
●Safety boots
●Drill with several bore bits for concrete Ø6, Ø10 and Ø16
●Manual resin aplicator HILTI HDM330 for the supplied anchorages
●Spirit level
●Bob plumb
● Complete at spanner or star spanner set
●Torque wrench for 5 Nm
●Star screwdriver
●Slot head screwdriver
●Funnel
●Ruler with a 1.5 m aproximate length
Personal protection
Tools and equipment
ASSEMBLY INSTRUCTIONS
PH-300 VERTICAL LIFTING PLATFORM
IM-560en
Vers. 05
Page 3
2. Shaft check
1 Install suitable protections to prevent risks of falling during assembly.
2 Check that the supplied anchorages are appropriate for the type of wall the guide
shall be xed upon. The chemical anchorages are appropriate for walls made of
structural concrete, solid bricks or hollow brick.
3 Verify the characteristics of the wall to which the guide shall be xed. The guide is
designed to be xed to the oor, to the slab of the upper landing level and on the
upper end of the guide. In case a resistant enough support is not available for the
xation on the upper end of the guide the two upper xations may be moved to the
central xation plate to the slab. The reaction forces of the guide assembly on the
oor and xation wall are indicated in the following drawing.
With xation on the upper
end of the guide
Only with xation to the slab
of the upper landing level
2.5 kN
2 kN
2 kN
0.6 kN
2 kN
0.6 kN
2 kN
R 1100
2.5 kN
2 kN
2 kN
20 kN
20 kN
R 1100
20 kN
20 kN
IM-560en
Vers. 05
Page 4
ASSEMBLY INSTRUCTIONS
VERTICAL LIFTING PLATFORM PH-300
4 Check that the following dimensions are within the specied limits. Should this not
be case, get in touch with our aftersales department.
- R Platform travel. Permissible deviation of ± 50 mm
- E0 Minimum space for access on lower level: ≥2040
Upper
level
Lower
level
R
E0
- E1 Minimum space on upper level with 180º access: ≥1200
Upper levelLower level
E1
d
- E1 Minimum space on upper level with 90º access: ≥1200
Upper level
Lower level
E1
d
ASSEMBLY INSTRUCTIONS
PH-300 VERTICAL LIFTING PLATFORM
IM-560en
Vers. 05
Page 5
5 Check adjacent surface requirements:
- Upper access side. Vertical, continuous, solid and without projections; throughout
the dimension of the platform
- Guide side. Vertical, continuous, solid and without projections
- Side without access. According to the value of the travel (R) and the distance to the
platform (d):
R≤500 R>500 Surface
- d=20 Vertical, continuous, solid and without projections;
throughout the dimension of the platform
20≤d<120 80≤d<120 Vertical, continuous, solid and without projections
120≤d<400 Vertical, continuous and solid
d≥400 No specic requirements
Vertical, continuous and solid, throughout the dimension of the platform, for R>500 (d=20)
Permitted projection dimensions for
wall without projections
d=20A
1100
d=20
1.5÷5≤1.5
≤15º
IM-560en
Vers. 05
Page 6
ASSEMBLY INSTRUCTIONS
VERTICAL LIFTING PLATFORM PH-300
Vertical, continuous and solid, for R>500 (d= 80÷400)
1.5÷5≤1.5
≤15º
d=80÷400A
40
d=80÷400
1100
Permitted projection dimensions
for wall without projections
(for d=80÷120 only)
Vertical, continuous and solid, for R≤ 500 (d= 20÷400)
1.5÷5≤1.5
≤15º
Permitted projection dimensions
for wall without projections
(for d=20÷120 only)
d=20÷400
d=20÷400A
ASSEMBLY INSTRUCTIONS
PH-300 VERTICAL LIFTING PLATFORM
IM-560en
Vers. 05
Page 7
No specific requirements (d≥400)
d≥400A
40 (for R>500 only)
d≥400
IM-560en
Vers. 05
Page 8
ASSEMBLY INSTRUCTIONS
VERTICAL LIFTING PLATFORM PH-300
6 For the lower protection option, check that the pit dimensions are correct.
- F Pit depth
R (mm) F (mm)
≤ 400 ≥30
400< ≤ 700 ≥45
700< ≤1000 ≥60
1000< ≤1300 ≥75
1300< ≤1500 ≥90
Upper
level
Lower
level
F
- Pit dimensions for 180º access: (A+255) x 1220
Upper levelLower level
1220
A+255
A
- Pit dimensions for 90º access: (A+255) x 1150
Upper level
Lower level
1150
A+255
A
