HIDITION GAMING T-1 Manual de usuario
IN-EAR GAMING HEADSET
MANUAL
00
Contents
1 / T-1 Package Includes
2 / T-1 Parts Name
3 / Quick Start
4 / How to Connect MMCX Connectors
5 / How to Disconnect MMCX Connectors
6 / How to Connect to PC
7 / How to Manage T-1
8 / Specification
9 / Precautions
1~2 P
3~5 P
6~12 P
13~16 P
17~18 P
19~20 P
21~23 P
24~25 P
26~29 P
01
T-1 Package Includes
T-1 and Accessories
1
Earcaps
S/M/L
Cable tie
Y adapter
for PC
IN-EAR GAMING HEADSET
M M
L L
SS
2
02
T-1 Parts Name
3
MMCX Connectors
Mic Splitter
Adjustable-fit boom mic hanger
Unit
Microphone Head
Mic On/Off Switch
3.5mm 4Pole Plug
OVERALL VIEW
T-1 Parts Name
4
MMCX Connectors
Nozzle
Unit(Left)
Unit(Right)
Earcaps
DETAIL VIEW
T-1 Parts Name
5
03
Quick Start
How to wear T-1
& Adjust the fit again
6
Choose one of the sizes Small, Medium, Large
and replace both sides of the unit.
STEP . 1
STEP . 2
Place the T-1 Adjustable-fit boom mic hanger and
the cable connected to the unit over the ear hooks.
7
① Completely attach the mic splitter into the inside of the earlobes.
② Wrap the left unit around the top of the ear hook.
③ Insert the earbud into the ear in the over-ear-wearing method.
STEP . 3
STEP . 4
① With the microphone splitter fully attached
to the inside of the earlobes,
② Adjustable-fit boom mic hanger Bend down to face down.
8
