4K Arcana 18Gbps
User Manual 4K Arcana Rev 1.20
Disclaimer: 3rd party and/or custom firmware providing extra features are not covered in this manual.
2
4K Arcana –User Manual
Disclaimer: 3rd party and/or custom firmware providing extra features are not covered in this manual.
3
4K Arcana –User Manual
Table of content
Arcana Overview.......................................................................................................................................5
Connecting Cables to Arcana ....................................................................................................................6
Arcana Power/Status OLED.......................................................................................................................7
Arcana Up/Down/Select Button ...............................................................................................................8
Arcana Info pages......................................................................................................................................9
Arcana OLED Menu.................................................................................................................................10
Arcana Audio sub-menu..........................................................................................................................11
Arcana Scaler sub-menu .........................................................................................................................12
Arcana eARC sub-menu ..........................................................................................................................13
Arcana HDR sub-menu............................................................................................................................14
Arcana LLDV>HDR sub-menu..................................................................................................................15
Arcana OSD sub-menu............................................................................................................................16
Arcana FW/RESET sub-menu ..................................................................................................................17
Arcana EXIT sub-menu............................................................................................................................18
Arcana Firmware Update........................................................................................................................19
Arcana Config Export ..............................................................................................................................21
RS232 Command List ..............................................................................................................................23
FAQ..........................................................................................................................................................27
FAQ CEC/ARC ..........................................................................................................................................29
FAQ ATV4K..............................................................................................................................................31
FAQ LLDV>HDR10....................................................................................................................................33
FAQ SONOS Arc.......................................................................................................................................36
FAQ NVIDIA SHIELD.................................................................................................................................37
FAQ XBOX................................................................................................................................................38
FAQ AUDIO..............................................................................................................................................39
FAQ VIDEO ..............................................................................................................................................40
FAQ ARC <> HDMI input switching .........................................................................................................41
FAQ TV Remote for Volume Control on SONOS Arc...............................................................................42
Highlight Features:..................................................................................................................................43
Main Specifications.................................................................................................................................45
Certifications...........................................................................................................................................47
Disclaimer: 3rd party and/or custom firmware providing extra features are not covered in this manual.
4
4K Arcana –User Manual
Pro Tips ...................................................................................................................................................48
Credits.....................................................................................................................................................49
Disclaimer: 3rd party and/or custom firmware providing extra features are not covered in this manual.
5
4K Arcana –User Manual
Arcana Overview
Team HDfury would like to thank you personally for purchasing the 4K Arcana!
This unique HDMI2.0b device supports true full 4K60 4:4:4 600MHz 18Gbps bandwidth signals. It will
allow you to solve any HDCP error, extract full HDMI audio from any HDMI sources up to Atmos HBR
over TrueHD to feed any eARC sound system and extract ARC sound from ARC TVs as well as passing CEC
commands between all involved equipment. Arcana supports any SD/HD/FHD/UHD/HDR/DV/LLDV/HLG
or PC signals up to 600MHz. It can downscale UHD to FHD, display relevant information on OLED/OSD,
select between multiple converting options. Inject, replace or translate HDR metadata. Display DV
content on HDR10 display. Control can be completed via OLED menu with rotary switch or via RS-232
(MAC/WIN/Linux) and an optional USB control is available if needed in future update.
Disclaimer: 3rd party and/or custom firmware providing extra features are not covered in this manual.
6
4K Arcana –User Manual
Connecting Cables to Arcana
• Connect USB-C Power connector from Power supply (110-240V 1.2A IN & 5V 2A OUT).
• Connect a source via HDMI input cable to the HDMI input.
• Connect any other HDMI, sound or RS232 cable that you might need (optional)
• HDMI cable must support 18Gbps if any 18Gbps source/sink is connected (except for Audio Out)
•Make sure that you are using
600MHz certified or tested
HDMI 4K cable if you plan to set
up a 4K60 4:4:4 8b / 4K60 4:2:2
12b 600MHz/18Gbps link in your
setup.
More details available online.
For more options and recommendations
regarding connecting Arcana in your setup,
you can refer to the Getting Started section
of the Arcana product page on HDfury.com
Direct Link here.
Disclaimer: 3rd party and/or custom firmware providing extra features are not covered in this manual.
7
4K Arcana –User Manual
Arcana Power/Status OLED
The Arcana OLED will turn ON when power supply is applied; Arcana Logo will be displayed followed by a
similar default infopage to the one represented below.
If any active input is connected, Arcana will process handshake with the active input and once
completed the signal information will be displayed.
IN: 4K59.94 371MHz 420 BT2020 10b HDR on above pic.
If any sink is connected at TX0 output, T0 section of the default OLED infopage will display the current
signal going to it.
[OLED OFF]: Insufficient power or OLED timer expired (default 30s). Use the Arcana power supply or
press any button if OLED timer expired.
[OLED ON]: The Arcana unit is receiving power and is ready to accept an HDMI signal.
Disclaimer: 3rd party and/or custom firmware providing extra features are not covered in this manual.
8
4K Arcana –User Manual
Arcana Up/Down/Select Button
The 4K Arcana offers 2 main navigation functions via its rotary switch.
[UP/DOWN] Navigate Up or Down in OLED menu or cycle info page.
[PRESS/CLICK] Valid a choice or selection while in OLED menu.
Note: You can also control and change settings with RS232 for MAC/WIN/Linux.
Disclaimer: 3rd party and/or custom firmware providing extra features are not covered in this manual.
9
4K Arcana –User Manual
Arcana Info pages
When you have not entered the Arcana menu (by clicking the rotary switch button), the above info
pages are available to scroll and cycle through using UP or DOWN direction of the rotary switch.
[UP]Wake up from sleep/fade mode or Cycle OLED infopage: INFO > RX INFO > HDR INFO > …
[DOWN] Wake up from sleep/fade mode or Cycle OLED infopage: INFO > UNIT INFO > HDR INFO > …
Default info page
•Display incoming signal info, outgoing signal info and Audio
routing (HDMI or eARC) and Audio format types.
Incoming signal info page
•Display resolution, frame rate, color depth, color space,
chroma, hdcp, bandwidth in MHz and Gpbs, HDR type and
Audio type.
Incoming HDR info page
•Display EOTF, WP, Max Lum, Min Lum, max CLL, maxFALL.
Unit info page
•Display Serial and Firmware version.
Outgoing signal info page
•Display TV MAX cap, resolution, frame rate, color depth, color
space, chroma, HDR/DV mode and Audio type.
Disclaimer: 3rd party and/or custom firmware providing extra features are not covered in this manual.
10
4K Arcana –User Manual
Arcana OLED Menu
By clicking the Rotary button on the 4K Arcana, you can enter the OLED menu.
[CLICK] Enter OLED menu, validate a selection in sub-menu.
[UP]Cycle through the available sub-menus or options.
[DOWN] Cycle through the available sub-menus or options.
Note: You can also control and change settings with RS232 for MAC/WIN/Linux.
Audio
SCALER
eARC
HDR
LLDV>HDR
OSD
FW/RESET
EXIT
