BlackHills
Mechanical Safe Lock
Operating Instructions:
1. Turn the dial counterclockwise (to the left) until the first number of your
combination aligns with the 12 o’clock opening index 4 times, be sure to
stop on the first number of your combination the fourth time.
2. Turn the dial clockwise (to the right) until the second number of your
combination aligns with the 12 o’clock opening index 3 times, be sure to
stop on the second number of your combination the third time.
3. Turn the dial counterclockwise (to the left) until the third number of
your combination aligns with the 12 o’clock opening index 2 times, be
sure to stop on the third number of your combination the second time.
4. Turn the dial clockwise (to the right) until the dial comes to a complete
stop, and then turn the safe handle to gain access.
5. Locking your safe; Close the safe door and then spin the safe dial to the
left at least 4 full turns.
If you do not successfully gain access repeat steps 1-4.
Ozarks
Mechanical Safe Lock
Operating Instructions:
1. Turn the dial counterclockwise (to the left) until the first number of your
combination aligns with the 12 o’clock opening index 4 times, be sure to
stop on the first number of your combination the fourth time.
2. Turn the dial clockwise (to the right) until the second number of your
combination aligns with the 12 o’clock opening index 3 times, be sure to
stop on the second number of your combination the third time.
3. Turn the dial counterclockwise (to the left) until the third number of
your combination aligns with the 12 o’clock opening index 2 times, be
sure to stop on the third number of your combination the second time.
4. Turn the dial clockwise (to the right) until the dial comes to a complete
stop, and then turn the safe handle to gain access.
5. Locking your safe; Close the safe door and then spin the safe dial to the
left at least 4 full turns.
Bolt Down Instructions:
Steps:
1. Place the safe in the location desired.
Note that it is desirable to have at least 1” clearance to the wall on the back and
sides.
2. Mark the floor at the two front corners of the safe. This will help in relocating the safe
after drilling the mount holes in the floor.
3. From inside the safe, mark the floor through the mount holes in the bottom of
the safe.
4. Move the safe to the side and drill the floor at the marks with the masonry drill
bit. Be sure to drill the holes deeper than the length of the anchors.
5. Vacuum the concrete dust out of and from around the holes in the floor.
6. Move the safe back into position using the corner marks to help align the safe.
7. Insert the anchor through the safe floor and into the concrete floor until the
washer touches the safe floor, and then tighten the nuts from inside the safe.
8. Tighten first to a barely snug level on each bolt before tightening up all bolts
·Drill Motor
·Anchors
·Masonry Drill Bit
·Wrench to fit nuts on anchors
·Marker to mark the floor
