Haygain® HG-2002 Hay Steamer

(TWIN INLETS & TWO PB BOILERS)

User Manual

Contents

2 © Haygain

Contents

Contents..................................................................................................................................2

About your Haygain®HG-2000 hay steamer.........................................................................3

Getting started........................................................................................................................4

Unpacking your Haygain®hay steamer.................................................................................4

Overview...............................................................................................................................5

Where to set up your Haygain®hay steamer.........................................................................6

Connecting the steam generator to the hay chest.................................................................7

Safety ......................................................................................................................................8

General safety.......................................................................................................................8

Electrical safety.....................................................................................................................8

Using your Haygain®hay steamer.......................................................................................10

Filling the steam generator with water.................................................................................10

Loading forage....................................................................................................................11

Steaming forage..................................................................................................................11

Unloading forage.................................................................................................................12

Working in freezing conditions ............................................................................................13

Maintenance..........................................................................................................................15

Cleaning the hay chest........................................................................................................15

Cleaning the steam generator.............................................................................................15

Descaling the steam generator............................................................................................16

Storing your Haygain®hay steamer for long periods of time................................................17

Troubleshooting...................................................................................................................18

Warranty................................................................................................................................21

Contact..................................................................................................................................22

Maintenance records............................................................................................................23

About your Haygain® HG-2000 hay steamer

About your Haygain®HG-2000 hay steamer

Congratulations on purchasing your Haygain®HG-2000 hay steamer!

Mould growth can affect all types of hay and haylage. Moulds produce respirable dust that

when inhaled can cause respiratory allergies. These conditions compromise the ability of your

horse to breathe properly. Mould growth also reduces the nutritional quality of the forage.

Your Haygain®hay steamer is the only system scientifically proven to kill mould spores and

bacteria in forage, and remove the potentially allergenic respirable dust. Steamed hay helps to

protect your horse from harmful dust and microorganisms, which allows your horse to perform

to the best of its ability. Your horse will also love the improved taste of steamed forage.

Here at Haygain®we are committed to improving the health and well-being of your horse. To

see other ways that we can help you and your horse, visit www.haygain.com

About this user manual

This user manual describes how to safely use and maintain your Haygain®hay steamer, and

how to get the best results from it. To watch some helpful videos or see frequently asked

questions, visit www.haygain.com

Read this user manual before use

Before you get started, read this user manual. When you use your

Haygain®hay steamer, follow all instructions carefully and safely.

Disclaimer

We have made every effort to ensure that the information in this user manual is correct at the

time of publishing. However, we reserve the right to change the information at any time without

notice.

Failure to observe the requirements of this user manual may result in the user being held

responsible for the consequences and will invalidate the warranty. We accept no liability for

misuse or unauthorised modifications to your Haygain®HG-2000 hay steamer.

You must always steam forage in the hay steamer for at least 60 minutes and until the

thermometer reads at least 80 °C. The minimum time for steaming is based on an ambient

temperature of 15 °C, a sufficient power supply and a location at sea level.

Getting started

4 © Haygain

Your Haygain®hay steamer details

Before you get started, make a note of serial numbers and the date of delivery. The serial

number for the hay chest is on the inside of the lid. The serial number for the steam generators

is on the label.

Serial number (hay chest)

Serial number (steam generator)

Date of delivery

Getting started

Unpacking your Haygain®hay steamer

Check you have all of the following parts. If you do not have a part, contact your supplier within

7 working days of delivery.

Haygain®HG-2000 hay chest, with a fixed 5-spike steam manifold

Two PB steam generators, with steam hoses with quick release fitting

Funnel

Watering can

Haygain®descaler

User manual

Getting started

Overview

Hay chest

Lid

Thermometer

Lid seal

Rebated handles on both sides of lid

Catch

Internal hose

Drain hole

Handle

Steam manifold plates

Steam hole

Wheel

Manifold spike

Getting started

6 © Haygain

Steam generators

Handle

Heating indicator light (amber)

Safety cap

Empty indicator light (red)

Filler spout

Polycarbonate insulated outer case

Connector for hay chest

Stainless steel tank

Steam hose

Copper-plated nickel heating element

Power button

Power cable and cable restraint

Where to set up your Haygain®hay steamer

Set up your Haygain®hay steamer in a safe place

To prevent hazards and damage to your Haygain®hay steamer, use it in a

location that meets the specifications below.

Take care when moving your Haygain®hay steamer

Before you move the hay chest or steam generator, switch off the steam

generator. Empty the hay chest of forage, and ensure the steam generator

has cooled down.

To move the hay chest, lift it by the handle on the opposite side to the wheels and push or pull

it. The higher you lift the hay chest, the easier it is to move.

To move the steam generator, lift it by the handle.

Set up your Haygain®hay steamer in a location that meets the following specifications:

Getting started

Place

Steam generator: indoors only

Hay chest: indoors or outdoors

Note: Some water will come out of the drain holes in the hay chest.

Not accessible by children or animals

Floor

Level and hard floor that drains well

Clean and free from mould or damp

Ventilation

Well ventilated, to avoid damp conditions

Nothing covering the hay chest or steam generator

Power

Within 4 metres of a power outlet

Not directly under a power outlet, as steam can corrode the power outlet

Complies with the electrical specifications on page 8

Water

Near a source of clean tap water

Connecting the steam generators to the hay chest

When the hay chest and steam generator are in a suitable location, use the steam hose to

connect them.

To connect the steam generators to the hay chest

Find the quick release fitting at the end of the steam hose.

Pull back the barrel of the quick release fitting on the hose, and push it firmly onto one

of the hose connectors of the hay chest.

Release the barrel of the quick release fitting on the hose, so that it slides into the

locked position. To check that the steam hose is securely connected, pull the hose.

Ensure the hose is not kinked or restricted.

Repeat for the second steam generator.

Safety

8 © Haygain

Safety

General safety

Use your Haygain®hay steamer in a safe place

Set up your Haygain®hay steamer in a location that meets the

specifications on page 6.

Hot steam and temperatures can cause burns

When the steam generator is switched on, it produces hot steam that

comes out of it and the hay chest. Before you open the cap of the steam

generator, allow it to cool down.

Areas of the hay chest, for example the manifold spikes, can get very hot.

Take care when you steam forage and unload it.

Handle with care

Take care not to damage your Haygain®hay steamer. Do not use sharp

objects, for example hay forks, inside the hay chest.

If any part of your Haygain®hay steamer is damaged, including the steam

hose, electrical cable or thermometer, do not use it. Contact us for help.

Keep children and animals safe

Keep children and animals away from your Haygain®hay steamer.

Maintain your Haygain®hay steamer

Follow the maintenance instructions in this user manual. If you do not

maintain your Haygain®hay steamer, it may stop working or become

dangerous. Use only genuine Haygain®spare parts and approved

accessories.

Electrical safety

Electrical equipment can be dangerous

Ensure your electrical setup meets the specifications for the steam

generator. If you have any questions about your electrical setup, contact a

qualified electrician.

Electrical specifications

The steam generator is an electrical device. Before you use the steam generator, check there

is no damage to the plug, cable, and cable restraint.

Safety

Ensure your electrical circuit meets the following specifications for the steam generators:

2 different sockets on different 2750 W power circuits

50/60 Hz

220-240 V

The steam generators must be earthed.

The plugs, cables, cable restraints and power outlets are not damaged.

The plugs and cables are clean and dry when you plug them into the power outlets.

We recommend you plug the steam generator into a power outlet that is RCD (residual-current

device) protected.

Extension cables

We advise not to use extension cables as a permanent electrical supply. If you plug a steam

generator into an extension cable, ensure the cable meets the electrical specifications on

page 8.

Extension cables can be an electrical hazard

Ensure extension cables meet the required electrical specifications and

are not damaged. To prevent the extension cable from overheating, fully

unwind it when the steam generator is switched on.

Wall timers

To switch on or off the steam generator at a certain time, you can use a wall timer.

If you plug the steam generator into a wall timer, ensure the wall timer meets the electrical

specifications on page 8. Ensure the steam generator is securely fitted into the wall timer and

the wall timer is securely fitted into the power outlet.

Using your Haygain® hay steamer

10 © Haygain

Using your Haygain®hay steamer

Read the safety chapter

Before you use your Haygain®hay steamer, read the Safety chapter in this

user manual.

After you set up your Haygain®hay steamer and make sure it is safe, you can start steaming

forage. You can feed steamed forage to your horse immediately or ideally up to 24 hours after

steaming.

To steam forage, complete the following tasks in this chapter:

1. Fill the steam generators with water.

2. Load forage in the hay chest.

3. Steam forage in the hay chest.

4. Unload forage from the hay chest.

If you are working in freezing conditions, see page 13.

Filling the steam generator with water

Before you can start steaming forage, you need to fill the steam generator with water.

To fill the steam generator with water

Warning: Do not open the cap on the steam generator when the steam generator is

hot. Ensure the steam generator has cooled down.

Unscrew the cap on the steam generator.

To ensure the steam generator is empty, hold it by the handle and tilt it. Empty the

water through the filler spout into a drain or container.

Place the funnel in the filler spout.

Carefully pour up to 8 litres of clean tap water into the steam generator. If you are only

steaming one bale, we recommend you use 6 litres of clean tap water.

Warning: Take care not to overfill the steam generator with water. Never add

anti-freeze or other additives to the water.

Tabla de contenidos

Otros manuales de Electrodoméstico de cocina de HAYGAIN

HAYGAIN

HAYGAIN HG-ONE Manual de usuario

HAYGAIN

HAYGAIN HG-600 Manual de usuario

HAYGAIN

HAYGAIN HG-600 Manual de usuario

Manuales populares de Electrodoméstico de cocina de otras marcas

Tayama

Tayama TYG-35AF Manual de usuario

AEG

AEG 43172V-MN Manual de usuario

REBER

REBER Professional 40 Guía del usuario

North American

North American BB12482G / TR-F-04-B-NCT-1 Manual de usuario

Presto

Presto fountain popper Manual de usuario

Westmark

Westmark 1035 2260 Manual de usuario

Zanussi

Zanussi ZCG64396XA Manual de usuario

HOFFEN

HOFFEN SM-9302M Manual de usuario

Philips

Philips HD3133 Manual de usuario

Ronco

Ronco Beef Jerky Manual de usuario

Hendi

Hendi 470411 Manual de usuario

Livoo

Livoo MEN386 Manual de usuario

Vogue

Vogue D446 Manual de usuario

croydon

croydon WR-10313-700 Manual de usuario

ADE

ADE AUTOMATIC-L Manual de usuario

Chefman

Chefman RJ43-SQ Series Manual de usuario

Vacmaster

Vacmaster VP680 Manual de usuario

Jetmaster

Jetmaster 900HG Manual de usuario
