Hawking HAWNU1 Manual de usuario
HAWNU1
START HERE
QUICK INSTALLATION GUIDE
Hi-GainTM Wireless-150N
USB Network Adapter with Range Amplifier
Mac OS X Windows XP Windows 7 & Vista
Check Package Contents
- One Hi-Gain Wireless-150N USB Adapter with Cap
- One External Dipole Antenna
- CD (Drivers and User’s Manual)
Installation Instructions are divided into three sections
(Windows 7 & Vista, Windows XP, and Mac OS X):
- Windows 7 & Vista Installation: page 2.
- Windows XP Installation: page 9.
- Mac OS X Installation: page 15
This document only contains quick setup instructions. For more
settings, please refer to the User’s Manual located on the CD.
Support is available via website, email, and telephone:
Website: www.hawkingtech.com/support
E-mail: suppor[email protected]
Tel (Toll Free US & Canada): 888-202-3344
Tel (International): +949-206-6900
- page 1 -
OVERVIEW
Windows 7 & Vista
Installation Instructions for Windows 7 & Vista
IMPORTANT! Do not connect the Wireless-N USB Adapter into
the USB port until you have installed the driver from the CD and
are instructed to do so. Otherwise, the Adapter may not operate
properly.
1. Driver & Utility Setup:
a. Insert the Setup CD.
Select “Run autorun.exe”
b. If the autorun doesn’t
come up, go to “open
folder to view les”, then
select “autorun.exe”.
2. Select START HERE from
the Setup Wizard.
- page 2 - Setup Instructions: Windows 7/Vista
Computer DVD/CD-RW Drive (D:) HAWNU1 Setup CD
HAWNU1 - Autoload.cdr
Windows 7 & Vista
3. User Account Control: Select ‘Allow’ to continue. Then, wait for
the InstallShield Wizard to guide you through the setup.
4. Read through the License
Agreement. Select “I
accept the terms of the
license agreement” and
“Next”.
5. Select the Default option
and click “Next”.
Setup Instructions: Windows 7/ Vista - page 3 -
Windows 7 & Vista
6. Select “Install” to
continue.
7. The install wizard will prompt you to
insert the USB Adapter into your PC.
IGNORE the message for now. Select
“OK” to continue. (It is recommended
to nish installing the driver before
plugging in the Adapter.)
8. You are now nished
installing the software
driver. Select “Finish.”
Then, go to Step 9.
- page 4 - Setup Instructions: Windows7/ Vista
Windows 7 & Vista
9. Now, insert the Adapter into an
available USB Port.
Wait a few seconds until your
system detects the new hardware
(Adapter). A Found New
Hardware screens may show
up at this point, select “Locate
and Install driver software
(recommended)”.
It will automatically locate the
software and complete the driver
installation process.
Set up Your Wireless Connection for Windows 7
[Win 7] Step 1
Click on the Network and
Sharing Center icon from
your system tray (bottom
right on your screen). A list of
available wireless networks
will appear. Select a wireless
network that you wish to
connect to.
Setup Instructions: Windows 7/ Vista - page 5 -
Windows 7 & Vista
[Win7 ]Step 2:
If you are connecting to a
Security-enabled Network,
your system will prompt you to
enter your security key. If you
don’t have the security key,
please contact your network
administrator or the person
who set up the selected wireless
network.
If you are not connected to a
security enabled network, you
system will proceed to the next
step and connect automatically.
Setup Your Wireless Connection (Windows Vista)
[Win Vista] Step 1:
Double click on the bottom
“network icon”
If you can’t locate the Network
icon, go to Start menu and
select “Connect To”. )
- page 6 - Setup Instructions: Windows7/ Vista
Windows 7 & Vista
[Win Vista] Step 2:
Select a Network and click Connect. Please wait until the
adapter connects.
[Win Vista] Step 3:
If you are connecting to an
unsecured networking, se-
lect ‘Connect Anyway’. (See
the right image)
If you are connecting to a
security-enabled Network,
type in the network security
key or passphrase. If you do
not have the security key or
passphrase, please obtain it
from your network adminis-
trator.
Setup Instructions: Windows 7/Vista - page 7 -
Windows 7 & Vista
- page 8 - Setup Instructions: Windows 7/Vista
[Win Vista] Step 4
You are now connected to
a wireless network. To save
this specic network for fu-
ture access, select Save this
network.
Select a location or you
may customize the name
and location type, etc.
Close the Set Network
Location when you are
done.
Congratulations! You
are now connected.
Windows XP
Installation Instructions for Windows XP
Important: Do Not connect the Network Adapter into the USB port
until you have installed the driver from the CD and are instructed to
do so. Otherwise, the Adapter may not operate correctly.
1. Driver & Utility Setup:
Insert the Setup CD. The
Setup Wizard will load
up automatically, select
START HERE.
The InstallShield Wizard will initialize
automatically
2 Setup will prompt you
to accept the Licensing
Agreement. Select “Yes”
to continue.
Setup Instructions: Windows XP - page 9 -
