HAWK ENTERPRISES MINI-VACTOR Manual de usuario
1
HAWK
MINI-VACTOR
OWNER’S
MANUAL
2
INDEX
Specifications.................. 1
Safety Alert Symbols . . . . . . . . . . . . 2
Grounding Instructions . . . . . . . . . . . 3
Return Goods Policy . . . . . . . . . . . . . 4
Important Safety Instructions . . . . . . 5
Preparing for Use and . . . . . . . . . . . . 6
Operating the Machine
Know Your Machine . . . . . . . . . . . . 7
Troubleshooting . . . . . . . . . . . . . . . . 12
Warranty.....................13
Introduction
This manual is designed to make your job easier. However, there is nothing more important than
the safety aids and instructions that are found throughout this document. The Safety Alert
Symbol is used to identify topics of primary safety concern. Further, a separate section has been
included, “Important Safety Instruction,” which deals with accident prevention concepts.
User experience provides the best feedback. We, at Hawk Enterprises of Elkhart, Inc., welcome
your comments and suggestions.
Purpose of this Manual
This instruction manual is intended to familiarize operators with safety and maintenance
procedures for products of Hawk Enterprises of Elkhart, Inc.
SPECIFICATIONS
200ْF heated solution tank (110ْF water heats to 200ْF in 8 minutes).
Ready to use when dwell time on pre-spray is completed.
1 ½-gallon solution tank capacity.
2-gallon recovery tank capacity.
Vacuum lift: 102.”
Piston pump delivers 60 PSI.
1600-watt heating element.
Amber lights indicates when heating is in process and turns off when operating temperature
is reached.
Water stays warm in tank for up to 3 hours before reheating is required.
Power requirement is less than 15 amps.
Single power cord.
10-ft., 1¼” ID flexible vacuum hose.
10-ft., 3/16” ID spray hose.
Spotter weight w/o solution: 18 lbs.
Maneuvers easily on 2” casters.
Easily accessible to fill, empty, and clean.
Spotter dimensions: H-17”, L-18”, W-13.”
Spotter furnished with transparent 3” upholstery detail tool.
Applications include auto detailing, and commercial and household carpet and upholstery
cleaning.
3
SAFETY ALERT SYMBOL
The above symbol is used to call your attention to instructions concerning your personal safety.
Watch for this symbol. It means “ATTENTION! Become alert! Your personal safety is
involved!” Read the message that follows and be alert to the possibility of personal injury or
death.
4
GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should electrically malfunction, grounding provides a
path of least resistance for electrical current to reduce the risk of electric shock. This appliance
is equipped with a cord having an equipment grounding conductor and grounding plug. The plug
must be plugged into an appropriate outlet that is properly installed and grounded in accordance
with all local codes and ordinance.
DANGER!
Improper connection of the equipment grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or service person if you are in doubt as to whether the outlet is
properly grounded. Do not modify the plug provided with the appliance. If it will not fit the
outlet, have a proper outlet installed by a qualified electrician. This appliance is for use on a
nominal 120-volt circuit, and has a grounding plug that looks like the plug illustrated in Figure 1
below.
5
RETURN GOODS POLICY
As a Hawk customer, you are aware that the equipment we design and build is both innovative
and unique. Therefore, in order to troubleshoot our equipment, we heavily rely on returned
defective or failed parts so that we can examine firsthand the causes of failure. While this may at
first be an inconvenience, ultimately, you benefit from safer and better-designed machine
components. Please give us the opportunity to serve you better by following these RGA rules.
1. We maintain the serial number, date of shipment or sale, and customer name on each piece of
equipment sold. If you were the purchaser, please reference that information on your request for
replacement or repair. If you purchased the equipment through a distributor, please contact them
first. If you are not satisfied, contact Hawk Enterprises of Elkhart, Inc. and give us the
distributor name, purchase date, and the serial number of the product.
2. Order the replacement parts from your distributor. We will ship warranted parts at our
expense.
3. When dealing with Hawk Enterprises, ask for an RGA number when you are ordering the
replacement part. Return the failed part to us within 30 days, freight prepaid, exactly as it was at
the time of failure. Our inspection and evaluation will attempt to determine the probable cause
of failure.
4. If our inspection reveals that the failed part was defective, we will credit your account for the
entire amount of the part including your cost of return freight. When incomplete parts are
returned for credit, their condition or state of incompletion will be assessed against the credit
claim at the sole discretion of Hawk Enterprises.
5. We also offer to do warranty related repairs free of charge at our facility. Arrangements
must be made in advance as outlined above. We will not accept freight collect returns or returns
that do not indicate the RGA number on the packing list.
Your satisfaction in all of your dealings with Hawk Enterprises is extremely important to us. We
intend to be reasonable on any matter that is related to our warranted service or other wear-
related problems which our customers feel need attention. Please help us to help you. Before
assuming that a part is defective, check the repair manual to see if the problem might be
something that you or one of your employees might be capable of correcting. If it is not, follow
the above policy and depend on us to respond quickly and responsibly.
6
IMPORTANT SAFETY INSTRUCTIONS
Please read all instructions before using this appliance. When using an electrical appliance, basic
precautions should always be followed, including the following:
WARNING! To reduce the risk of fire, electrical shock, or injury:
Do not leave the appliance when it is plugged in. Unplug the unit from the outlet when
not in use and before servicing.
To avoid electric shock, do not expose to rain. Store indoors.
Do not allow to be used as a toy. Close attention is necessary when used near children.
Use only as described in this manual. Use only the manufacturer’s recommended
attachments.
Do not use with damaged cord or plug. If the appliance is not working as it should be,
has been dropped, damaged, left outdoors or dropped into water, return it to a service
center.
Do not pull or carry by the cord, use the cord as a handle, close a door on the cord, or pull
the cord around sharp edges or corners.
Do not run the appliance over the cord.
Keep the cord away from heated surfaces.
Do not unplug by pulling on the cord; to unplug, grasp the plug, not the cord.
Do not handle the plug, cord or appliance with wet hands.
Do not put any object into openings. Do not use if any opening is blocked; keep free of
dust, lint, hair, and anything that may reduce air flow.
Keep loose clothing, hair, fingers, and all body parts away from openings and moving
parts.
Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot
ashes, or any health-endangering dusts.
Turn off all controls before unplugging.
Use extra care when cleaning on stairs.
Do not use to pick up flammable or combustible liquids such as petrol, or use in areas
where they may be present.
Anyone designated to operate this equipment must, without fail, read and understand
these instructions before attempting to operate the equipment.
Always disconnect electrical cable from outlet before attempting adjustments or repairs.
Always use a grounded electrical outlet.
Never use out of doors or in the rain!
Never put flammable or explosive materials in this equipment; never operate equipment
in an environment where these materials are present.
Never use equipment as a toy.
Do not allow the unit to freeze.
Do not operate in standing water.
Do not operate if power cords, hoses, etc., are cracked, frayed, leaking or otherwise in
need of repair.
Do not operate under any unsafe conditions.
7
PREPARING FOR USE AND OPERATING THE MACHINE
SPOTTING PROCEDURES PRIOR TO OPERATING MACHINE
1. Soak up excess liquids with a towel.
2. Test cleaner on a small, inconspicuous area to make sure it will not damage the carpet fibers.
3. Apply appropriate spotter; follow directions on bottle.
4. Start at outside edges of stain and work toward the center; use a dabbing, not rubbing, action.
5. Repeat steps 3-4 if needed.
OPERATING THE MACHINE
WARNING! Use only non-flammable commercial chemicals intended for extraction
machine application.
1. UNPLUG the machine before attempting to fill with water and position switch to the middle
“OFF” position.
2. Pour 1½ gallons of the warmest water possible to shorten heating time (Solution tank must be
full to activate heating element).
3. Toggle the power switch to “HEAT.” The amber light will come on indicating the heating
cycle has begun.
4. When the water temperature reaches maximum degree of heat, the amber light will turn off to
indicate that the machine is ready for use.
5. Toggle the power switch to “VACUUM” (This will shut off heating element, turn on the
vacuum pump, and activate the solution pump).
6. Release water from nozzle until hot water transfers through the length of the vacuum hose.
Remember, the initial water in the hose will be cold.
CAUTION! Do not continue to use the machine after the Recovery Tank is FULL. This will
damage the vacuum motor and any damage is NOT COVERED UNDER WARRANTY. Be
sure to empty and clean recovery tank after each full tank of water.
******************************************************************************
BE AWARE / WATER TEMPERATURE
HOT WATER!!! MAY EXCEED 200 DEGREES F.
USE CAUTION WHEN USING THIS MACHINE.
******************************************************************************
NOTE: ONCE THE WATER IN THE CLEAN SOLUTION TANK HAS BEEN USED,
HEATING ELEMENT WILL NOT COME BACK ON UNTIL THE TANK HAS BEEN
REFILLED WITH CLEAN WATER AND THE SWITCH HAS BEEN TOGGLED TO
THE ‘HEAT’ POSITION.
8
AFTER USE
WARNING! To reduce the risk of electric shock or injury, unplug the power cord before
servicing.
1. Toggle the Power Switch to the MIDDLE position to turn off both the vacuum motor and
solution pump.
2. DISCONNECT THE POWER CORD.
3. Move the machine to designated waste water “DISPOSAL SITE” (Such as a sink, floor
drain, or bucket).
4. Disconnect the Hose Assembly from the machine.
5. Tip the Recovery Tank upright and drain the dirty solution through the hose connection port
on the top rear of the machine.
6. Tip the Solution Tank and drain unused water or solution. Thoroughly rinse the tank if any
cleaning chemical was used.
7. Check and clean lint filter on inside center of recovery tank. Pull filter up and out, rinse
clean and be sure to replace the filter element.
