ASSEMBLY INSTRUCTIONS
Magne�c Resistance Rowing Machine
Thank you for your purchase of this Harvil Product!
We work around the clock and around the globe to ensure that Harvil products
maintain the highest possible quality. However, in the rare instance that your
product is defective or missing parts, contact your retailer to submit parts requests
or warranty claims. Please read the warranty information at the back of these
assembly instructions for further details.
IMPORTANT! PLEASE READ THESE ASSEMBLY INSTRUCTIONS IN
ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT.
The information contained in this manual is subject to change withouth notice.
2
RM-M
IMPORTANT SAFETY INSTRUCTIONS
1. Before starting any exercise program, you
should consult your physician to determine if you
have any medical or physical conditions that
could put your health and safety at risk or
prevent you from using the equipment properly.
Your physician’s advice is essential if you are
rate, blood pressure, or cholesterol level.
2. Be aware of your body’s signals. Incorrect or
excessive exercise can damage your health. Stop
exercising if you experience any of the following
symptoms: pain, tightness in your chest, irregular
heartbeat, shortness of breath, lightheadedness,
dizziness, or feelings of nausea. If you experience
any of these conditions, you should consult your
physician before continuing with your exercise
program.
3. This equipment is intended for adult use only.
Keep children and pets away from the machine.
DO NOT leave children unattended in the same
room with the equipment.
4.
ensure safety, the equipment should have at least
2 feet of free space all around it.
5. Check if you have all the components and
tools listed. Please note that some components
are pre-assembled to help make the assembly
process quick and easy.
6.
any defective components while assembling or
checking the equipment, or if you hear any unusual
noises coming from the equipment during exercise,
discontinue use immediately and do not use until
7. Always wear appropriate workout clothing when
exercising. Do not wear clothing that can get
tangled in the equipment.
8. Keep hands and other objects away from all
moving parts.
9. The maximum user weight is 264 pounds.
10. Be careful when lifting and moving the
equipment. Always use proper lifting technique and
seek assistance if necessary.
11. Your equipment is intended for use in cool, dry
conditions. You should avoid storage in extreme
cold, hot, or damp areas as this may lead to
corrosion and other related problems.
12. This equipment is designed and intended for
indoor use only, not for commercial use.
SAVE THESE INSTRUCTIONS
WARNING
This product could expose you to one or more chemicals known to the State of California to cause
cancer and birth defects or reproduction harm.
To reduce the risk of electrical shock, always unplug this unit from its power source before cleaning
or performing any maintenance tasks.
3
RM-M
EXPLODED-VIEW DRAWING
4
RM-M
PARTS LIST
No. Name Specications Qty No. Name Specications Qty
1 Volute Spring Wheel 1 32 Bushing 2
2 Adjustable Magnetic Piece 1 33 Rubber Foot Pad 1
3 Fixed Magnetic Piece 1 34 Tension Control Knob 1
4 Meter 1 35 Mesh Belt Pulley 1
5 Sliding Rail 1 36 Foam Grip 2
6 Saddle 1 37 Limit Pad 2
7 Front Stabilizer 1 38 Self Tapping Screw ST4 2x15.0 2
8 Main Frame 1 39 Hexagon Bolt M6x45 3
9 Rear Support 1 40 Bolt M8x60 2
10 Compression Spring 1 41 Hexagon Nut M6 1
11 Axle for Volute Spring Wheel 2 42 Hexagon Nut M10 2
12 Spacer 2 43 Nylon Nut M6 5
13 Pedal Shaft Core 1 44 Hexagon Nut M10 2
14 Pedal Strap 2 45 Cap Nut M8 2
15 Surface Plate 2 46 Allen Screw M8x15 2
16 Front End Cover 1 47 Arc Washer Φ8.4*Φ19.0*T1.5*R20.0 2
17 Back End Cover 1 48 Allen Screw M8x25 8
18 Plug 2 49 Hexagon Bolt M6x12 4
19 Mesh Belt Pulley 1 50 Screw M6x20 1
20 Left Chain Cover 1 51 Self Tapping Screw ST4.2x15.0 8
21 Right Chain Cover 1 52 Self Tapping Screw ST4.2x20.0 3
22 Handle Bar Seat Cover 1 53 Flat Washer Φ6.4*Φ13.0*T1.5 7
23 Rail Cover 1 54 Flat Washer Φ8.4*Φ19.0*T1.6 8
24 Right Pedal 1 55 Spring Washer Φ6.1*Φ9.3*T1.6 6
25 Left Pedal 1 56 Spring Washer Φ8.4*Φ13.5*T2.5 8
26 Foot Pad 1 57 Screw M5x20 1
27 Handle Bar 1 58 Screw M6x15 3
28 Screw 2 59 Meter Truck Wire 1
29 U Shape Seat 2 60 Sensor Wire 1
30 End Cap 2 61 Spanner 1
31 Round Plug 2 62 S5 Allen Wrench 2
5
RM-M
HARDWARE PACKAGE
6
RM-M
ASSEMBLY INSTRUCTIONS
STEP 1:
Attach the Front Stabilizer (No. 7) to the Main Frame (No. 8) using 2 Bolts (No.
40), 2 Arc Washers (No. 47), 2 Spring Washers (No. 56), and 2 Cap Nuts (No. 45).
Tighten with Spanner (No. 61).
Make sure wheels are facing outwards and up.
7
RM-M
ASSEMBLY INSTRUCTIONS
STEP 2:
Insert the Pedal Shaft Core (No. 13) into the Main Frame (No. 8), then attach the
L/R Pedal (No. 25 & 24) to Pedal Shaft Core (No. 13) using 2 Allen Screws (No. 46)
and 2 Flat Washers (No. 54). Tighten with Allen Wrench (No. 62).
8
RM-M
ASSEMBLY INSTRUCTIONS
STEP 3:
Insert the Saddle (No. 6) onto the Sliding Rail (No. 5). Attach the Rear Support
(No. 9) to the Sliding Rail (No. 5). Tighten the Sliding Rail (No. 5) with Surface
Plate (No. 15), 2 Flat Washers (No. 54), 2 Spring Washers (No. 56), and 2 Allen
Screws (No. 48). Lastly, secure with 2 Allen Screws (No. 48) and 2 Limit Pads (No.
37).
9
RM-M
ASSEMBLY INSTRUCTIONS
Figure A
Figure B
STEP 4:
Put the Decoration Cover (No. 23) on the Sliding Rail (No. 5) as shown in gure A.
Connect the Sensor Wire (No. 60) with the Meter Trunk Wire (No. 59). Attach the
Sliding Rail (No. 5) to the Main Frame (No. 8) and secure using 2 Allen Screws
(No. 48), 2 Springs Washers (No. 56) and 2 Flat Washers (No. 54). Attach the Sur-
face Plate (No. 15) to the Sliding Rail (No. 5) using 2 Allen Screws (No. 48), 2
Spring Washers (No. 56) and 2 Flat Washers (No. 54). Tighten with Allen Wrench
(No. 62). Lastly, press down on the Rail Cover (No. 23) as shown in the gure B.
Assembly is complete!
10
RM-M
ADJUSTMENT GUIDE
PEDAL ADJUSTMENT
The pedal strap is adjustable and can be
personalized to t the user’s foot size.
To adjust the pedal strap, remove the
Velcro end of the strap from the mesh side
by pulling it upward then to the left.
Once removed, you may increase the
opening of the pedal strap by pulling the
mesh end up and to the right.
To tighten, pull the Velcro end of the pedal
strap upward then to the right and down
to secure it to the mesh side of the strap.
MOVING THE MACHINE
To move the machine, lift up the rear stabilizer
until the transportation wheels on the front
stabilizer touch the ground. With the wheels on
the ground, you can transport the bike to the
desired location with ease.
