JBL EON305 REV C

PACKAGE WIRING DIAGRAM

09-10

Technical Manual

JBL EON305

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:

• Nominal Impedance: 8 Ohms

• System Power Rating: 250W continuous, 500W program,

1000W peak

• Frequency Response: 50 Hz – 18 kHz (± 3 dB)

• Frequency Range: 38 Hz – 20 kHz (-10 dB)

• Maximum SPL: 128 dB

• Sensitivity: 98 dB, 1 watt at 1 meter

• Crossover Frequency: 1.9 kHz

SYSTEM COMPONENTS:

• Baffle/Grille: 441955-001

• Low Frequency M115-8A, 380 mm (15 in.) cone

Transducer: transducer

• DC Resistance: 5.5 ohms

• High Frequency 2414H-1 25.4 mm (1 in.) polymer

Transducer: diaphragm compression driver

• DC Resistance: 3.60 ohm ±0.2%

SYSTEM COMPONENTS:

(CONT’D)

• Input Connection: Parallel Neutrik NL4 1/4” combo

connection

• Suspension / Mounting: 36 mm pole socket with stabilizing

screw, 4 x M10 suspension points

AURAL SWEEP TEST SPECIFICATIONS:

A. System Aural Sweep Test: 7V Input, 20 Hz to 20 kHz

Sweep duration: 5 seconds

B. L.F. Aural Sweep Test: 6.0V Input, 20 Hz to 200 Hz

C. H.F. Aural Sweep Test: 0.75V Input, 500 Hz to 1.5 kHz

PHYSICAL SPECIFICATIONS:

• Enclosure Dimensions: 685 x 438 x 366 D

(27 x 17.3 x 14.4 in D)

• Shipping Weight: 33 lb (15 kg)

WARRANTY INFORMATION:

• Refer to Warranty Statement packed with each product.

Network Assembly

364903-001

Driver, High Freq

2414H-1

(363858-001X)

SEE NETWORK SCHEMATIC PAGE

Driver, Low Freq.

M115-8A

(124-67001-01X)

GRN

YEL

GRN/BLK

YEL/BLK

Fillers, (2)

364823-001

Bag

322591-001

19” x16” x 42” LG

.003 THKLDPE CLR

Carton

364824-003

Warranty 59660

Owners Manual

364822-001

NOTE: INDIVIDUAL PARTS FOR THE ABOVE CROSSOVER ARE NOT AVAILABLE.

A COMPLETE REPLACEMENT ASSEMBLY SHOULD BE ORDERED.

JBL EON305

SCHEMATIC 364903-001 JBL EON305

0.50mH

0.50 ohm

1.80mH

0.30 ohm

4uF

100V 7uF

100V

17.5uF

100V

16.0 ohm

10W

8.0 ohm

10W

2.70 ohm

25W

SK3 SK3

JBL EON305

COMPONENT EXPLODEDVIEW JBL EON305

Driver,Low Freq

M115-8A

(124-67001-01X)

Screw (8)

804-01110-16

10-32 x 1

FIL,PH,BLK

ZINC.LCS

Rubber Foot (2)

364802-001 Thumb Screw

364983-001

Network Assembly

364903-001

Screw (7)

814-01100-10

M4 x 10MM

FL,PH,CLR ZINC,

LCS

Input Plate

Gasket

365401-001

Badge,Cover

364937-001

Side Hanlde (2)

364938-001

Screw (4)

814-01100-25

M4 x 25MM

FL,PH,CLR ZINC

LCS

Enclosure Assembly

EON305 (Not

Available for Sale)

Gasket,Enclosure

364835-001

Upper Handle

364654-002

Cover, Bolt (2)

364805-002

Fly Bolt (5)

364616-001

Nut (5)

838-00800-00

M14,REG,CLR

ZINC, RH

Washer (5)

848-00100-02

M14,REG,CLR ZINC

Driver,High Freq

2414H-1

(363858-001X)

Screw (8)

365270-001

M4 x 65

Screw (2)

365270-002

M4-35mm

Screw (12)

862-41410-10

6 x 5/8

PAN,PH,HIGHLO,

BLK ZC,LCS

Baffle/Grille Assembly

441955-001

Logo Assembly

365400-001

Screw

813-21300-10

M3.5X 10MM,

RND, PH, CLR

ZINC,LCS

JBL PROFESSIONAL

CUSTOMER SERVICE DEPARTMENT

EON210P, EON 300, EON 500 SERIES REFERENCE CHART

Revision A - October 11, 2012 Page 1 of 1

MODEL LOW HIGH NETWORK AMPLIFIER WIRE LAST

FREQUENCY FREQUENCY ASSEMBLY ASSEMBLY HARNESS YR

MFD

EON210P 443639-001 (328H) 2414H-1 (363858-001X) 444944-001 445356-001 10/5/2012

EON305

M115-8A (124-67001-01X

2414H-1 (363858-001X) 364903-001

EON315 M115-2 (365153-001) 2414H-1 (363858-001X) 365375-001

EON510 261F (364742-003X) 2414H-1 (363858-001X) 364836-001

EON515 261F-1 (363837-001X) 2414H (342423-002X) 364836-001 6/30/2011

EON515XT/230 261F-1 (363837-001X) 2414H (342423-002X) 364836-001

EON518S 268G (364481-001X)
