Harman Infinity FUZE 200 Manual de usuario

FUZE 200

User Manual

Warning!

Warranty Card

PORTABLE BLUETOOTH SPEAKER

WELCOME TO HARMAN's FAMILY OF LEGENDARY BRANDS

Input: 5V/1A

What’s in the box

Connections

Buttons

QSG

2.0s

2. Turn off the bluetooth speaker

1. Turn on the bluetooth speaker

Power on / Power off

EQ switching

This speaker comes with dual EQ to enter into various

personal preference, to swtich EQ, short press "+" and "－"

buttons to switch.

2.0s

Bluetooth connection

Music

3. When turn on, the speaker will automatically connect to

the last connected device if available. If not, short press

the " " button to re-enter the pairing.

4. Clean up the pairing information by long press the " "

and " " buttons in the same time.

Choose ”Infinity FUZE 200” to connect

2. Connect to bluetooth device

Settings Bluetooth

Bluetooth

Infinity FUZE 200

DEVICES

Connected

Now Discoverable

1. The speaker will automatically enter into pairing mode

when power on and wait for the device to connect.

3.0s

x 1 x 1

x 2

Phone call

Voice assistant

Bluetooth mode, double press the " " button on the

speaker to activate Siri or Google Now on your phone. Please

make sure the Siri or Google Now is enabled on your phone.

Speaker A Speaker B

3.0s

Speaker A Speaker B

True wireless stereo pairing

2. Enable bluetooth on your device and connect to

"Infinity FUZE 200",stereo sound will play from both speakers.

1. Long press the " " button to enter into the true wireless

stereo pairing mode as a master speaker. If one of them fails,

clean up the pairing information.

Specifications

Bluetooth version: 4.2

Support: A2DP V1.2; GAVDP V1.3; AVRCP V1.6; HFP V1.7

Transducer: 2 x 45mm

Output power: 7.5W *2

Frequency response:75Hz - 20KHz

Signal-to-noise ratio: >70dB

Battery type: Lithium-ion polymer (3.7V, 2500mAh)

Battery charge time: 4 hour @ 5V 1A

Music playing time: up to 10 hours(50% volume level)

Bluetooth transmitter power: -6 ~ 4dBm

Bluetooth transmitter frequency range: 2.402 — 2.480GHz

Bluetooth transmitter modulation: GFSK, 1/4-DQPSK, 8DPSK

Dimensions: Φ88*116(mm)

Weight: 421g

LED Behavior

White

Fast flash

White

Slow flash

White

Flash

White

Fast flash

White

Fast flash

White

true wireless

stereo pairing

mode

true wireless

stereo

connected B

Stand by

Bluetooth

pairing mode

Bluetooth

connected

Dual speaker connect

Warning

IMPORTANT: To ensure that the FUZE 200 is waterproof,

please remove all cable connections and tightly close the

cap; exposing the FUZE 200 to liquids without doing so may

result in permanent damage to the speaker. And do not

expose FUZE 200 to water while charging, as doing so may

result in permanent damage to the speaker or power

source,IPX7 waterproof is dened as the speaker can be

immersed in water up to 1m for up to 30 minutes.

FUZE 200 is IPX7 waterproof.
