SETUP GUIDE
Models: EE4034, EE0362, EW3251, GE2913,
GE0177, GE7065, QST015C,
GA4364, GA4956, GA4408QST008A-5WN
GR0692, GR5482,QST008A-5W
SACTIONALS
Sound + Charge System
Read all instructions before using this product.
DANGER – To reduce the risk of electric shock: Always unplug this product from the electrical outlet
before cleaning.
WARNING – To reduce the risk of burns, fire, electric shock, or injury to persons:
• Unplug from outlet before putting on or taking off parts.
• Always disconnect power and audio cords before cleaning or moving your Sactionals pieces.
• Close supervision is necessary when this product is used by, or near children, or those with
disabilities.
• Use this product only for its intended use as described in these instructions. Do not use attachments
not recommended by the manufacturer.
• Verify line voltage before use. The Sactionals StealthTech Sound + Charge System has been
designed for use with 100-240 volt, 50/60 Hz AC current.
• Connect cords to properly grounded outlets only.
• If using the included Lovesac PowerHub ensure total power load on the PowerHub does not exceed
rating.
• Keep all cords away from heated surfaces.
• Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has
been dropped, damaged, or dropped into water. Contact Lovesac Customer Love.
• When disconnecting the power cord from an AC outlet, always pull the plug; never pull the cord.
• Do not run power cords under rugs or carpets, or place heavy objects directly on them.
• Route all power and audio cords away from Sactionals Feet and Shoes using the included clips to
prevent cords from being pinched underneath a Shoe or Seat Frame.
• Do not open electronic units.
• Never drop or insert any object into any opening.
• If water falls inside electronics, disconnect from the AC power source immediately.
• To prevent damage to the wireless charger and/or up-firing speaker, do not place objects more
than 300 lbs on top of the Sound + Charge or Satellite Sides.
• Max Seat Load Rating – 300 lbs.
• Do not use outdoors or in wet locations. Use only in dry locations.
• Do not operate where aerosol (spray) products are being used or where oxygen is being
administered.
When using a Sactionals StealthTech Sound + Charge System, basic
precautions should always be followed, including:
2
Important Safety Instructions
• StealthTech products are not intended for mounting in a permanently installed or stationary
furnishing or as part of a building structure.
• The Sationals StealthTech Sound + Charge System is to be used with Lovesac indoor Sactional
furniture only.
• Subwoofers are only intended to be used with indoor Sactionals Seats and Deep Seats.
Wireless Charger
• Do not put anything with RFID function into the charging area, such as ID cards, credit cards,
deposit cards, security badges, passports, and key fobs while the phone is charging. These RFID
cards run the risk of being damaged by the magnetic field of the wireless charger.
• Do not toss, press, or puncture the wireless charger. High external pressure will cause damage to
the device.
• The magnetic field generated by the wireless charger might interfere with some implanted medical
devices such as pacemakers, cochlear implants, or hearing-aids. Please consult the manufacturers
of the medical devices you are using.
• Do not dismantle or modify the wireless charger or submerge into water or any other liquid.
• Follow the local recycling guidance if you discard this product.
• Use only the power cable provided with the Sactionals StealthTech Sound + Charge Side.
SAVE THESE INSTRUCTIONS
SERVICING OF DOUBLE-INSULATED PRODUCTS
In a double-insulated product, two systems of insulation are provided instead of grounding. No
grounding means is provided on a double-insulated product, nor is a means for grounding to be
added to the product. Servicing a double-insulated product requires extreme care and knowledge of
the system and is to be done only by qualified service personnel. Replacement parts for a
double-insulated product must be identical to the parts they replace. A double-insulated product is
marked with the words “DOUBLE INSULATION” or “DOUBLE INSULATED”. The symbol (square
within a square) is also able to be marked on the product.
Continued
3
Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS.......................................................................................
INTRODUCTION............................................................................................................................
WHAT’S INCLUDED.......................................................................................................................
SYSTEM ENHANCEMENTS...........................................................................................................
PLANNING YOUR LAYOUT..........................................................................................................
INSTALLATION.............................................................................................................................
SOUND MODES...........................................................................................................................
CONNECT TO OTHER DEVICES..............................................................................................
PRODUCT OVERVIEW................................................................................................................
LED INDICATORS........................................................................................................................
HELP & TROUBLESHOOTING...................................................................................................
LIMITED WARRANTY...................................................................................................................
SPECIFICATIONS.........................................................................................................................
LEGAL & COMPLIANCE..............................................................................................................
2
5
6
7
8
16
31
32
33
39
43
45
46
47
4
Table Of Contents
The Sactionals StealthTech Sound + Charge System combines premium surround sound by
Harman Kardon and integrated wireless charging completely hidden from view. The unique
proximity and placement of speakers, combined with patented tuning technology for passing
sound through fabric and upholstery, delivers an unparalleled audio experience. And, with
wireless charging capabilities available where it’s needed most, remaining connected is never a
problem. When it comes to technology, invisible is beautiful.
We encourage you to read through this manual which describes the StealthTech products and
includes step-by-step instructions to help you get started.
Read and understand all the safety instructions before using this product.
If you have any questions about these products, their installation, or their operation, please
You can also visit www.lovesac.com for additional resources.
5
Introduction
AUX
Cable
Angled
Sound + Charge Side: Left
Angled
Sound + Charge Side: Right
Standard
Sound + Charge Side: Left
Standard
Sound + Charge Side: Right
Roll Arm
Sound + Charge Side: Left
Roll Arm
Sound + Charge Side: Right
Remote
Control, 2 AAA
Batteries
Sound + Charge Center Channel
Wall-Mount Bracket and Template
HDMI
Cable
Optical
Cable
Sound + Charge Subwoofer
Mounting Brackets
4 Thumb Screws
Power
Cord
2 Stud
Screws,
1 Driver Bit
4 Screws
& Drywall
Anchors
Firmware
USB
Stick
Power Adapter
Sactionals StealthTech Sound + Charge System
Audio Cables: R and L
8 Cord Clips
6
What’s Included
IMPORTANT: Please place
Firmware USB Stick in a
safe space. This will be
needed to complete any
future firmware updates.
Mounting Brackets 4 Thumb Screws Power Adapter
These products are optional pieces sold separately to further enhance your StealthTech experience.
Sactionals StealthTech Sound + Charge System Enhancements
7
Sound + Charge Satellite Subwoofer
Audio Cable:
R/L 25ft
System Enhancements
4 Cord Clips
Standard
Sound + Charge
Satellite Side
Angled
Sound + Charge
Satellite Side
Sound + Charge 25ft
Audio Cable: R/L
Sound + Charge 25ft
Audio Cable: Satellite
This pillow uses a unique foam
and fabric with enhanced, acoustically
transparent properties. This allows
sound to pass through in high fidelity
for an optimized listening experience.
Included
Audio Cable:
Satellite
Sound + Charge
Arm Pillow
A longer audio cable for larger setups that can
be used to replace:
The Sound + Charge Audio Cable R/L that is
included with your Sound + Charge Sides.
A longer audio cable that
can be used to replace the
Sound + Charge Audio
Cable: R/L that is included
with your Sound + Charge
Sides.
AUX Cable
Satellite Subwoofer Placement
Spread Subwoofers out so that bass is distributed throughout your configuration. Subwoofer Seats and
any Seat in direct contact with a Subwoofer Seat will experience the most bass.
Right
Sound + Charge Side: Right
Placed on right of configuration.
Left
Sound + Charge Side: Left
Placed on left of configuration.
Optional
Sound + Charge Satellite Side
“Left” and “Right” are identical and
determined only by placement.
Satellite Right
Satellite Left
Sound + Charge Subwoofer
Placed in the center of your
most used seating area.
Configuration Key
Optional
Sound + Charge Satellite Subwoofer
See placement suggestions below.
Using the key below, the diagrams on the following pages show the optimal layout for the best sound
experience for your configuration.
8
Planning Your Layout
Choose the configuration shape that most closely matches your setup.
Straight Configurations
Number of
Seats can vary
Right
Left
Center Channel
TV
Center Channel
TV
Right
Left
Satellite Right
Satellite Left
Satellite Left
4 or more Seats
Optimal Experience for 3 Seats or Fewer: 6 Speaker Immersive Sound + Charge System
Optimal Experience for 4 Seats or More: 8 Speaker Immersive Sound + Charge System - incorporates 2 Satellite Sides
9
Planning Your Layout
Left L Configurations
Number of
Seats can vary
Right
Left
Satellite Left
Satellite Right
Choose the configuration shape that most closely matches your setup.
*If you often watch TV/Movies from rear seats, consider using an optional setup found on page 15.
Optimal Experience: 9 Speaker Immersive Sound
+ Charge System - incorporates 3 Satellite Sides
8 Speaker Immersive Sound + Charge System -
incorporates 2 Satellite Sides
7 Speaker Immersive Sound + Charge System -
incorporates 1 Satellite Side
6 Speaker Immersive Sound + Charge System
Center Channel
TV
Right
Left
Satellite Left
Satellite Left Satellite Right
Center Channel
TV
Right
Left
Right
Left
Satellite Left
Center Channel
TV
Center Channel
TV
10
Planning Your Layout
Este manual sirve para los siguientes modelos
