Harbor Freight Tools 47664 Manual de instalación

HIGH VOLUME HAND ROTARY

PUMP

Model

47664

SET UP AND OPERATING INSTRUCTIONS

Diagrams within this manual may not be drawn proportionally.

Due to continuing improvements, actual product may differ slightly from the product described herein.

Distributed exclusively by Harbor Freight Tools®.

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our website at: http://www.harborfreight.com

Read this material before using this product.

Failure to do so can result in serious injury.

SAVE THIS MANUAL.

manual or any artwork contained herein may be reproduced in any shape or form

without the express written consent of Harbor Freight Tools.

For technical questions or replacement parts, please call 1-800-444-3353.

Cover revised 07i

Brought to You By Augusta Flint

Page 2SKU 47664 For technical questions, please call 1-800-444-3353.

SPECIFICATIONS

Volume 25 Gallons/Minute

Body Construction Cast Aluminum Handle & Bung

Steel Suction Pipe 38-5/8” L X 1-1/8” I.D. X 1-15/16” O.D.

Outlet/Spout ZE 1-1/8” I.D. X 1-1/4” O.D. X 15” L

Pickup Black PU Plastic Filter Housing with S.S. Filter Mesh, 2” Dia X 4” L

SAVE THIS MANUAL

You will need the manual for the safety warnings and precautions, assembly

instructions, operating and maintenance procedures, parts list and diagram. Keep your invoice

with this manual. Write the invoice number on the inside of the front cover. Keep the manual

and invoice in a safe and dry place for future reference.

SAFETY WARNINGS AND PRECAUTIONS

WARNING: When using tool, basic safety precautions should always be followed to reduce the

risk of personal injury and damage to equipment.

Read all instructions before using this product!

AVOID WORKING ALONE. If an accident happens, an assistant can bring help.

KEEP PRODUCT USAGE AREA CLEAN. Cluttered areas invite injuries.

OBSERVE WORK AREA CONDITIONS. Don’t expose to rain. Keep work area well

lighted.

KEEP CHILDREN AWAY FROM PRODUCT USAGE AREA. Do not allow children to

handle this product.

STORE IDLE EQUIPMENT. When not in use, Pump must be stored in a dry location to

inhibit rust. Always lock up tools and Keep out of each of children.

DO NOT OPERATE THIS PUMP IF UNDER THE INFLUENCE OF ALCOHOL OR

DRUGS.Read warning labels on prescriptions to determine if your judgement or re-

exes are impaired while taking drugs. If there is any doubt, do not use this product.

USE EYE PROTECTION. Wear ANSI-approved safety impact goggles and face shield.

Wear a NIOSH-approved respirator when working with fumes.

DRESS SAFELY. Do not wear loose clothing or jewelry as they can become caught

in moving parts. Wear a protective hair covering to prevent long hair from becoming

caught in the moving parts.

MAINTAIN TOOLS WITH CARE. Inspect Pump periodically. If damaged, have it re-

paired by a qualied technician.

USE THE RIGHT PUMP FOR THE JOB. Do not attempt to force a small Pump to do the

work of a larger industrial Pump. There are certain applications for which this Pump was

10.

Brought to You By Augusta Flint

Page 3SKU 47664 For technical questions, please call 1-800-444-3353.

designed. Do not modify this Pump and do not use this tool for a purpose for which it

was not intended.

STAY ALERT. Watch what you are doing, Use common sense. Do not operate Pump

when you are tired.

DO NOT OVERREACH. Keep proper footing and balance at all times. Do not reach

over Pump.

CHECK FOR DAMAGED PARTS. Before using this Pump, any part that appears dam-

aged should be carefully checked to determine that it will operate properly and perform

its intended function. Check for alignment and binding of moving parts; any broken parts

or mounting xtures; and any other condition that may affect proper operation. Any part

that is damaged should be properly repaired or replaced by a qualied technician.

REPLACEMENT PARTS AND ACCESSORIES. When servicing, use only identical

replacement parts. Use of any other parts will void the warranty. Only use accessories

intended for use with this tool. Approved accessories are available from Harbor Freight

Tools.

MAINTAIN PRODUCT WITH CARE. Keep this product clean and dry, and moving

parts lightly lubricated for better performance. Keep Handle dry, clean and free from oil,

grease, and solvents.

MAINTENANCE. Service and maintenance should be performed regularly by a qualied

technician.

The warnings, cautions, and instructions discussed in this instruction manual cannot

cover all possible conditions and situations that may occur. It must be understood the

operator that common sense and caution are factors which cannot be built into this prod-

uct, but must be supplied by the operator.

Note: This pump is suitable for transferring noncorrosive petroleum based uids, gasoline,

kerosene, and light oils. Do not use with acids, alkaline solutions, trichlene, perchlene,

thinner, etc. Never pump used, dirty oil or uid in this pump. Do not attempt to pump

alcohol-based liquids.

UNPACKING

When unpacking, check to make sure all parts shown on the Assembly List (page #5)

are included. If any parts are missing or broken, (page #6) please call Harbor Freight Tools at

the number shown on the cover of this manual as soon as possible.

11.

12.

13.

14.

15.

16.

17.

REV 06b

Brought to You By Augusta Flint

Page 4SKU 47664 For technical questions, please call 1-800-444-3353.

REV 03k

ASSEMBLY

Part descriptions below refer to the Main Features illustration on page 5.

Note: When threading Suction Pipe (D) and other threaded connections, use pipe thread seal

tape (not included) to prevent leakage and to assure a tight t.

Attach the Handle (C) to the Pump Body (B) using the included set-bolt.

Slip the Bung-Fitting (E) over the pick-up end of the Suction Pipe (D). Tighten with Wing

Nut (G).

Attach the Suction Pipe to the Inlet of the Pump-Body (B).

Attach the Pickup (F) to the end of the Suction Pipe (D).

Attach Oil Outlet Spout (A) to the Pump Body (B).

Remove the Oil Plug (26) from the pump Gear Box (31).

Fill the Gear Box with gear oil until the oil just starts to come out of the plug hole. Use a

multi-purpose gear lube (80W-90).

Replace Oil Plug (26) and check for leaks.

Brought to You By Augusta Flint

Page 5SKU 47664 For technical questions, please call 1-800-444-3353.

OPERATION

WARNING! Fire hazard! Keep the Pump and uids away from all ignition sources and am-

mable materials.

Figure 1

To reach the bottom of a standard 55 gallon drum, slide the Bung Fitting (E) all the way

up to the top of the Suction Pipe (D) assembly. Slide the Suction Pipe (D) into the 55 gal-

lon drum through opening on the drum cover. Slide Bung Fitting (E) so it is resting on top

of the drum cover. Tighten Wing Nut (G, Figure 1).

Run the Oil Outlet Spout (A) hose into a container. If the hose isn’t long enough, attach a

longer hose (not included) with a hose clamp (not included).

Make sure the Pickup (F) is submerged in the fuel or oil you are planning to transfer.

Turn the Crank-Handle (C) steadily and the liquid will begin to transfer.

If pump does not pump uid when the handle is turned clockwise, reverse the installation

of the Outlet/Spout (3) and Suction Tube (33) on the Pump Body.

When nished transferring, pump unit until the Pump runs dry. Remove the Pump from

the container and wipe it dry.

Note: If the bottom of the 55 gallon drum has water or residue, you want to avoid running it

through the pump. Adjust the Wing Nut (G) on the Bung Fitting (E) so that the Pickup (F,

Figure 1) raises above the water or residue.

Note: This unit accommodates most 15, 30 and 55 gallon drums.

MAINTENANCE

Periodically, use a light oil lubricant on the Handle (C) assembly.

Keep Pickup (F) and Oil Outlet Spout (A) clean of dirt or debris.

Wipe down unit after each use and store in a dry place.

REV 07i

Brought to You By Augusta Flint

Page 6SKU 47664 For technical questions, please call 1-800-444-3353.

ASSEMBLY PARTS LIST

Assembly Description Q’ty

A Oil Outlet Spout 1

B Pump Body 1

C Crank-Handle 1

D Suction Pipe 1

E Bung Fitting 1

F Pickup 1

G Wing Nut 1

MAIN FEATURES

Brought to You By Augusta Flint

Page 7SKU 47664 For technical questions, please call 1-800-444-3353.

PARTS DIAGRAM

Brought to You By Augusta Flint

Page 8SKU 47664 For technical questions, please call 1-800-444-3353.

PARTS LIST

Part Description Q’ty

1 Plastic Hose 1

2 Hose Clamp 1

3 Outlet / Spout 1

4 Front Cover 1

5 Pump Case 1

6 Impeller 2

7 Set Screw M6x10 2

8 Round Head Bolt M5x12 1

9 Washer O5 1

10 Gear - 1 1

11 Gear-2 2

12 Sprint Pin O5x26 2

13 Gasket without Frame 4

14 Bearing - 1 4

15 Axle - 1 1

16 Axle - 2 1

17 Nylon Handle 1

18 Nut M10 1

19 Inner Hex. Bolt M10x80 1

20 Hex/ Bolt M8x20 1

21 Handle Arm 1

Part Description Q’ty

22 Gasket Cover - 1 1

23 Gasket with Frame 1

24 Bearing - 2 2

25 Sleeve 1

26 Oil Plug 1

27 Inner Hex. Bolt M6x30 4

28 Inner Hex. Bolt M6x30 16

29 Thick Washer 1

30 Gear - 3 1

31 Gear Box 1

32 Filter Housing 1

33 Suction Tube 2

34 Bung Adaptor 1

35 Tension Plate 1

36 Lock Knob 1

37 Rear Cover 1

38 Fix Pin 4

39 Gasket Cover - 2 1

40 Rubber Ring 1

41 Connection Sleeve 1

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURERAND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL

AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY

REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO

MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS

OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT

ALL REPAIRSAND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIEDAND LICENSED

TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING

OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO,

OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Brought to You By Augusta Flint
