BLOWTORCH

WITH PIEZO START

MODEL 91061

ASSEMBLY AND OPERATING INSTRUCTIONS

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our Web site at http//www.harborfreight.com

manual or any artwork contained herein may be reproduced in any shape or form

without the express written consent of Harbor Freight Tools.

For technical questions, please call 1-800-444-3353.

PRODUCT SPECIFICATIONS

SAVE THIS MANUAL

You will need this manual for the safety warnings and precautions, assembly,

operating, inspection, maintenance and cleaning procedures, parts list and as-

sembly diagram. Keep your invoice with this manual. Write the invoice number

on the inside of the front cover. Keep this manual and invoice in a safe and dry

place for future reference.

GENERAL SAFETY WARNINGS AND PRECAUTIONS

1. Keep work area clean and dry. Cluttered, damp, or wet work areas invite

injuries.

2. Keep children away from work area. Do not allow children to handle this

product.

3. Store idle equipment. When not in use, tools and equipment should be stored

in a dry location to inhibit rust. Always lock up tools and equipment, and keep out

of reach of children.

4. Do not use this product if under the influence of alcohol or drugs. Read

warning labels on prescriptions to determine if your judgement or reflexes

SKU 91061 PAGE 2

Item Description

Product Compatibility D esigned for use with Standard

16.4 Oz. (465 g) (1.02 Lb.) Propane Bottles.

Heat Output 3200° Fahrenheit.

Features Electronic Start.

Adjustable Gas Flow Thumb Wheel.

3-1/4” Long Brass Valve.

General Application For Sweating and Thawing Pipes,

Soldering, and Burning Weeds; (example:

Weeds on the side of a driveway; only use

in a well controlled safe environment).

Always have a fire extinguisher present.

Overall Length 9-5/8”.

Weight 0.85 Pounds.

6. Dress safely. Do not wear loose clothing or jewelry, as they can become caught

in moving parts or come in contact with open flames. Wear a protective hair

covering to prevent long hair from becoming caught in moving parts or coming in

contact with open flames.

7. Do not overreach. Keep proper footing and balance at all times to prevent

tripping, falling, back injury, etc.

8. Industrial applications must follow OSHA requirements.

9. Stay alert. Watch what you are doing at all times. Use common sense. Do not

use this product when you are tired or distracted from the job at hand.

10. Check for damaged parts. Before using this product, carefully check that it will

operate properly and perform its intended function. Check for damaged parts

and any other conditions that may affect the operation of this product. Replace

or repair damaged or worn parts immediately.

11. Replacement parts and accessories: When servicing, use only identical re-

placement parts. Only use accessories intended for use with this product. Ap-

proved accessories are available from Harbor Freight Tools.

12. Maintain this product with care. Keep this product clean and dry for better and

safer performance. For your safety, service and maintenance should be per-

formed regularly by a qualified technician.

13. Use the right tool for the job. Do not attempt to force a small tool to do the

work of a larger industrial tool. There are certain applications for which this tool

was designed. It will do the job better and more safely at the capacity for which it

was intended. Do not modify this tool, and do not use this tool for a purpose for

which it was not intended.

14. WARNING! The warnings, precautions, and instructions discussed in this

manual cannot cover all possible conditions and situations that may occur. The

operator must understand that common sense and caution are factors, which

cannot be built into this product, but must be supplied by the operator.

SKU 91061 PAGE 3

are impaired while taking drugs. If there is any doubt, do not attempt to use this

product.

5. Use eye and hand protection. Wear ANSI approved safety impact eye goggles

and flame retardant gloves and clothing when using this product. ANSI approved

safety impact eye goggles and flame retardant gloves are available from Harbor

Freight Tools. Always wear heavyduty leather work shoes.

SPECIFIC PRODUCT WARNINGS AND PRECAUTIONS

1. Maintain a safe working environment. Keep the work area well lit. Make sure

there is adequate surrounding work space. Always keep the area free of obstruc-

tions, grease, oil, trash, and other debris. Do not use the Blow Torch in areas

near flammable chemicals, dusts, and vapors. Be aware of wind blown sparks.

Do not use the Blow Torch around or near buildings and structures.

2. The BlowTorch is for outdoor use only. Use the Blow Torch only in well

ventilated areas. Inhalation of propane fumes may result in carbon monoxide

poisoning, injury and/or death.

3. Before each use, always check all propane connections and joints to make

sure no leaks are present.

4. If while using the BlowTorch you notice the odor of propane, immediately

shut off the propane fueling theTorch. Extinguish all open flames, and care-

fully check for leaks by using soapy water. Never use a flame to check for leaks.

If the odor continues, do not use the Torch. Call your local propane supplier for

assistance.

5. Propane fuel is extremely flammable and under pressure. Do not store

propane fuel in temperatures exceeding 120 degrees fahrenheit. Keep the

propane cylinder upright when using and storing. Never puncture or set fire to an

empty propane cylinder. Contact local solid waste authorities for instructions on

correct disposal or recycling of a propane cylinder.

6. Do not aim the BlowTorch’s Burner (1) at yourself, others, or animals.

Keep spectators clear of the work area.

7. Maintain a firm grip with both hands on the BlowTorch while in use.

8. Never reach across the BlowTorch while in use. Be aware that parts of the

Blow Torch become extremely hot during operation.

9. Always allow sufficient time for the BlowTorch to completely cool down

before storing. Do not store flammable liquids or materials in the area

surrounding the Blow Torch.

10. Maintain labels and nameplates on the BlowTorch. These carry important

information. If unreadable or missing, contact Harbor Freight Tools for a replace-

ment.

SKU 91061 PAGE 4

22. WARNING! The brass components of this product contain lead, a chemical

known to the State of California to cause birth defects (or other reproductive

harm).

(California Health & Safety Code 25249.5, et seq.)

23. WARNING! This product, when used with propane fuel, produces chemicals

known to the State of California to cause cancer and birth defects (or other repro-

SKU 91061 PAGE 5

11. Never use gasoline, kerosene, or other highly volatile fluids as a starter as

they can explode.

12. Dress safely. Do not wear loose clothing such as hanging shirt tails and coats.

Wear a protective hair covering to keep long hair away from heat and flames.

Use ANSI approved safety impact goggles and flame retardant gloves and

clothing to avoid burns.

13. Never leave the BlowTorch unattended once it is lit.

14. Keep a fire extinguisher handy. Always keep a commercial fire extinguisher

nearby the Blow Torch in case of accidental fire.

15. Do not clean the Blow Torch with cleaners that are combustible or cor-

rosive.

16. Do not paint any part of the Blow Torch.

17. Make sure theThumbWheel (7) is turned to its“OFF”position and the pro-

pane tank (not included) is removed when the BlowTorch is not in use.

18. Do not use the BlowTorch in the rain.

19. Never smoke while using the Blow Torch. Make sure all surrounding flames

are extinguished.

20. Never use a propane tank if it shows signs of: Dents, corrosion, gouges,

bulges, fire damage, leakage, excessive rust, or any other form of visual external

damage.

21. When work is complete, only set the BlowTorch on a non-flammable

surface like concrete, until the tool is completely cool to the touch.

UNPACKING

When unpacking, check to make sure all the parts shown on the Parts List (page 8) are

included. If any parts are missing or broken, please call Harbor Freight Tools at the

number shown on the cover of this manual as soon as possible.

ASSEMBLY AND OPERATING INSTRUCTIONS

NOTE: For additional references to the parts listed in the following pages, refer to the

Assembly Diagram (page 8).

1. Make sure theThumb Wheel (7) is turned completely clockwise to the “OFF”

position. (See Figure A.)

2. Screw the 16.4 ounce propane bottle (not included) tightly onto the Cylinder

Connector (11). Do not remove the propane bottle until it is completely empty.

3. The Thumb Wheel (7) regulates the propane gas flow. Release the propane gas

flow by slightly turning the Hand Wheel counterclockwise. (See Figure A.)

4. Make sure the Burner (1) is pointing in a safe direction and, with the Blow Torch

in a vertical position, push the Piezo Button (16) to activate the electric start. It

may be necessary to push the Piezo Button several times to activate the flame.

(See Figure A.)

5. Adjust the flame to the desired level by turning the Thumb Wheel (7)

counterclockwise. (See Figure A.)

6. NOTE: The lit Blow Torch should operate with a blue flame with a small yellow

tip. If necessary, adjust the Thumb Wheel (7) if there is sputtering or popping.

(See Figure A.)

PRODUCT FEATURES

1. The Blow Torch is ideal for sweating and thawing pipes, soldering, and

burning weeds in a well controlled safe environment. In addition, the Blow Torch

easily attaches to standard 16.4 Oz. (465 g) (1.02 Lb.) propane tanks.

SKU 91061 PAGE 6

THUMB WHEEL (7)

PIEZO BUTTON (16)

BURNER (1)

CYLINDER CONNECTOR (11)

FIGURE A

7. To extinguish the flame, close the Thumb Wheel (7) by turning it completely clock-

wise. (See Figure A.)

8. Allow sufficient time for the Blow Torch to completely cool. Then, store the Blow

Torch in a safe location and out of reach of children.

SKU 91061 PAGE 7

INSPECTION, MAINTENANCE, AND CLEANING

1. Before each use, inspect the general condition of the Blow Torch. Check the

Blow Torch for loose connections and joints, cracked, bent, or broken parts,

damaged propane bottle, and any other condition that may affect the safe opera-

tion of the Blow Torch. If a problem occurs, have the problem corrected before

further use. Do not use damaged equipment.

2. When cleaning, use only water and a mild detergent. Do not use cleaners that

are combustible or corrosive.

3. When storing, always allow sufficient time for the Blow Torch to completely cool

down before storing. Do not store flammable liquids or materials in the area

surrounding the BlowTorch. Make sure the Blow Torch’s Tumb Wheel (7) is in its

“OFF” position.

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND

ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE

MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF

ANY KIND TOTHE BUYERTHAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRSTO THE

PRODUCT, ORTHAT HE ORSHE ISQUALIFIEDTO REPLACE ANY PARTSOFTHE PRODUCT.

IN FACT, THE MANUFACTUER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL

REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND

LICENSEDTECHNICIANS, AND NOT BYTHE BUYER. THE BUYER ASSUMES ALL RISK AND

LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR

REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF

REPLACEMENT PARTSTHERETO.

PARTS LIST

SKU 91061 PAGE 8

NOTE: Some parts are listed and shown for illustration purposes only, and are not

available individually as replacement parts.

ASSEMBLY DIAGRAM

Part # Description

1 Burner (020 Piezo)

2 Gas-Air Mixer (014 x 40)

3 Nozzle (00.28)

4 Handle

5 Body Tap

6 Nut Key 14 Needle Stop

7 Thumb Wheel

8 Nut (M4)

9 Needle

10 O-Ring (102)

11 Cylinder Connector

12 O-Ring (108)

13 Gas Intake

14 Gasket (022 x 2.5)

15 Screw, and Nut (M4)

16 Piezo Button

17 Piezo Ignition

18 Copper Coated Electrode

19 Self-Threading Screw (03 x 19)

20 Ceramic Insulated Electrode

21 Clamp

Tabla de contenidos

Otros manuales de Herramientas eléctricas de Harbor Freight Tools

Harbor Freight Tools

Harbor Freight Tools Central Machinery 61487 Manual de instrucciones original

Harbor Freight Tools

Harbor Freight Tools Bauer 1925C-B Instrucciones de montaje

Harbor Freight Tools

Harbor Freight Tools 44836 Manual de usuario

Harbor Freight Tools

Harbor Freight Tools Chicago Electric 91082 Manual de usuario

Harbor Freight Tools

Harbor Freight Tools CENTRAL MACHINERY 46199 Manual de usuario

Harbor Freight Tools

Harbor Freight Tools CENTRAL PNEUMATIC 39170 Guía de referencia rápida

Harbor Freight Tools

Harbor Freight Tools PITTSBURGH 61411 Instrucciones de montaje

Harbor Freight Tools

Harbor Freight Tools 95329 Manual de usuario

Harbor Freight Tools

Harbor Freight Tools U.S. General 54425 Manual de usuario

Harbor Freight Tools

Harbor Freight Tools 47951 Manual de usuario

Harbor Freight Tools

Harbor Freight Tools Central Machinery 33497 Instrucciones de montaje

Harbor Freight Tools

Harbor Freight Tools CentralPneumatic 60801 Instrucciones de montaje

Harbor Freight Tools

Harbor Freight Tools PITTSBURGH PRO 63882 Instrucciones de montaje

Harbor Freight Tools

Harbor Freight Tools 40939 Instrucciones de montaje

Harbor Freight Tools

Harbor Freight Tools 46099 Manual de usuario

Harbor Freight Tools

Harbor Freight Tools Central Hydraulics 65330 Manual de instalación

Harbor Freight Tools

Harbor Freight Tools 93691 Manual de usuario

Harbor Freight Tools

Harbor Freight Tools 179cc Instrucciones de montaje

Manuales populares de Herramientas eléctricas de otras marcas

AEG

AEG OMNI-JS Manual de usuario

SIP

SIP 01533 Manual de usuario

Ribimex

Ribimex PRS499 Manual de usuario

3M Fiber Optic Connector Crimp Tool Manual de usuario

Ryobi

Ryobi P524 Manual de usuario

ROJEK

ROJEK FSN 300A Manual de usuario

Kemper

Kemper 1740PRO Manual de usuario

WABCO

WABCO OptiTire Manual de usuario

EINHELL

EINHELL TE-MS 18/210 Li Manual de usuario

Orgapack

Orgapack OR-T 85 Guía rápida

TOUGHCUT

TOUGHCUT Diamond 400 Manual de usuario

Yaros

Yaros PB-3603 Manual de usuario

Fein

Fein BSS 2.0 E Guía de configuración

Baileigh Industrial

Baileigh Industrial SS-2725 Manual de usuario

Milwaukee

Milwaukee 2674-20 Manual de usuario

Fein

Fein BLs 1.6 Manual de usuario

Princess

Princess Electric Multi Sharpener Manual de usuario

FOREDOM

FOREDOM K.1050 Manual
