Harbor Freight Tools Quantum 58070 Instrucciones de montaje
58070
Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 21c
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2021 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly an d se rv ic e may n ot b e in cl uded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 58070
Specifications
Battery 3.7V 750mAh Rechargeable
Li-Ion Battery
Lumens 135 Lumens (Flashlight)
200 Lumens (LED Strip)
Bulb Type LED
Charge Time 2.5 hours*
Run Time 5 hr (Flashlight)
11 hr (LED Strip low)
3 hr 30 min (LED Strip high)
Range Up to 100 ft
*Note: Charge time will vary depending on the amp rating of the power source.
IMPORTANT SAFETY INFORMATION
To prevent serious injury, FIRE, and EXPLOSION:
1. Keep dry.
2. Only use included charging adaptors. Other
adaptors may damage tool or cause fire.
3. Do not submerge Light.
4. Do not operate in explosive atmospheres, such as in
the presence of flammable liquids, gases, or dust.
5. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
6. Not a toy. Keep out of reach of children.
7. Contains Li-Ion battery. Battery must be recycled
or disposed of properly. Do not open, crush,
heat above 140° F (for Li-Ion) or incinerate.
Components
Magnetic Base
Power Button LED Strip
Black Light
Carrying Clip
Micro USB Input
Flashlight
Charging Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document
including all text under subheadings therein before set up or use of this product.
Note: Do not charge flashlight while in use.
1. Lift USB Port cover.
2. Insert the provided USB cable into USB port.
3. Insert the other end of the cable into power source.
4. After approximately 2.5 hours, the Flashlight is fully
charged and ready for use. Unplug the Adaptor.
Page 3For technical questions, please call 1-888-866-5797.Item 58070
NOTICE: Do not leave the Battery in a discharged
state. Charge the Battery every 3 months if the
Flashlight is not in use. This will keep the Battery
from wearing down and add to its life. Do not charge
the Flashlight at temperatures below 40° F.
Operation Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document
including all text under subheadings therein before set up or use of this product.
NOTE: Before using Flashlight for the
first time, fully charge the Battery.
1. Press Power Button to turn Flashlight on.
2. Press Power Button again to switch
to LED strip (low) mode.
3. Press Power Button again to switch
to LED strip (high) mode.
4. Press Power Button again to
switch to black light mode.
5. Press Power Button once more to turn flashlight off.
6. When finished using the Flashlight,
store indoors away from children.
Battery Removal
1. Remove the caps on both ends of the flashlight.
2. Remove battery compartment from
the flashlight housing.
3. Remove battery from the battery
compartment by cutting wires.
4. Li-Ion BATTERY MUST BE RECYCLED
OR DISPOSED OF PROPERLY.
Battery
Record Serial Number Here:
Note: If product has no serial number, record
month and year of purchase instead.
Note: Reference UPC 193175431462.
26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
