Operation, maintenance and safety manual

All operators must fully read and understand

this operator’s manual before using the chipper.

Keep this manual for future reference.


Hansa F3 Chaff Cutter O&M Manual - OM-016 Revision B 14/05/2019
© Hansa Products 2019
TABLE OF CONTENTS
WHAT CAN MY HANSA CHAFF CUTTER PROCESS?........................................................................................................................1
INTENDED USES OF THE CHAFF CUTTER .......................................................................................................................................................1
RECEIVING YOUR HANSA CHAFF CUTTER .....................................................................................................................................1
CHAFF CUTTER COMPONENTS...................................................................................................................................................................1
ASSEMBLY............................................................................................................................................................................................2
Steps to assemble the chaff cutter................................................................................................................................................ 2
SAFETY .........................................................................................................................................................................................2
OPERATOR COMPETENCY.........................................................................................................................................................................2
AMBIENT CONDITIONS............................................................................................................................................................................ 3
WORK AREA SAFETY ...............................................................................................................................................................................3
ELECTRICAL SAFETY.................................................................................................................................................................................3
PERSONAL SAFETY.................................................................................................................................................................................. 3
MACHINE USE AND CARE.........................................................................................................................................................................3
SERVICE ...............................................................................................................................................................................................4
IDENTIFYING HAZARDS AND RISKS .............................................................................................................................................................. 4
OPERATION..................................................................................................................................................................................5
SAFE SETUP PROCEDURE..........................................................................................................................................................................5
SAFE OPERATING PROCEDURE...................................................................................................................................................................5
POWER SUPPLY .....................................................................................................................................................................................6
CONTROLS............................................................................................................................................................................................7
Start/Stop...................................................................................................................................................................................... 7
Forward/Reverse........................................................................................................................................................................... 7
Emergency stop............................................................................................................................................................................. 7
STORAGE......................................................................................................................................................................................7
TRANSPORTATION ....................................................................................................................................................................... 7
TROUBLESHOOTING..................................................................................................................................................................... 8
WHAT TO DO IF:.................................................................................................................................................................................... 8
MAINTENANCE............................................................................................................................................................................. 8
BELT REPLACEMENT................................................................................................................................................................................ 8
MAINTAINING THE CHAIN DRIVE................................................................................................................................................................9
GREASING THE BEARINGS.......................................................................................................................................................................10
BASE BLADE/REEL REMOVAL AND SHARPENING ..........................................................................................................................................10
CUTTING MECHANISM CHECKING/ADJUSTMENT .........................................................................................................................................11
TYRE PRESSURE ................................................................................................................................................................................... 13
BOLT TORQUE .....................................................................................................................................................................................13
SPECIFICATIONS ......................................................................................................................................................................... 13
DECALS....................................................................................................................................................................................... 14
HANSA GLOBAL INDUSTRIAL LIMITED WARRANTY..................................................................................................................... 15
COMMISSIONING CHECKLIST AND REGISTRATION ..................................................................................................................... 17


Hansa F3 Chaff Cutter O&M Manual - OM-016 Revision B 14/05/2019

What can my Hansa chaff cutter process?

Intended uses of the chaff cutter

The Hansa F3 chaff cutter is built to process animal feed and light organic material. Do NOT use the machine for any other purpose.

Suitable feed materials include:

Hay

Lucerne

Silage

Chaff

Do NOT process:

Bones

Soil, sand, grit, stones, metal

Sticks and other lignified (woody) plant material

Paper, cardboard

Processing this kind of material can cause damage to the cutting mechanism of the machine.

If you have any questions, contact Hansa or your local authorised dealer.

Receiving your Hansa chaff cutter

You may receive your chaff cutter assembled from your dealer or it may arrive packaged in a crate. Assembly takes approximately

10 minutes.

Chaff cutter components

Hansa F3 Chaff Cutter O&M Manual - OM-016 Revision B 14/05/2019

Assembly

Tools required for assembly (not supplied):

•6 mm Allen key –to secure the wheels to the axles

•13 mm spanner –to secure the rubber feet to the legs of the machine

•Square drive bit with drill/driver –to separate the chaff cutter from the

pallet

The chaff cutter will come with two wheels detached from the shafts, and a pack

containing a number of fasteners:

1. Two m8x16 hex bolts

2. Two m8x20 cap screws

3. Four m8 spring washers

4. Two large m8 washers

5. Two small m8 washers

6. Two rubber feet

Steps to assemble the chaff cutter

Using a 13mm spanner, fasten the rubber feet to the bottom of the

front legs of the machine. Use an m8x16 bolt (item no. 1), spring

washer (item no. 3) and small washer (item no. 5) to fasten each

foot.

Using a 6 mm Allen key, fasten the wheels to the axles on the

bottom of the back legs of the machine. Use an m8x20 cap screw

(item no. 1), spring washer (item no. 3) and large washer (item no.

4) to fasten each wheel to the axles. Ensure the air valve is facing

outward.

Safety

Preventing accidents is the responsibility of every equipment operator. Ensure every operator is familiar with the safe operation

procedures of the machinery, how to identify hazards and the steps required to avoid injury while handling and operating the

machine. Relevant information is contained in this manual.

Do NOT modify the design of the chaff cutter

Operator competency

Only people over the age of 16 are to operate the chaff cutter. Ensure that every person operating the chaff cutter understands

and follows the safe operating procedures as specified in this manual.

Do NOT allow persons to operate the machine without full and proper instruction in the use and safe operation of the

chaff cutter and maintenance as detailed in this manual.

Hansa F3 Chaff Cutter O&M Manual - OM-016 Revision B 14/05/2019

Ambient Conditions

Only use the chaff cutter in an environment that is between -5°C and 40°C. Do not use the chaff cutter in the rain or in wet

environments. Processing wet material may result in blockages inside the machine.

Work area safety

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.

b) Do not operate machines in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Machines

create sparks which may ignite the dust or fumes.

c) Keep children and bystanders away while operating a machine. Distractions can cause you to lose control.

Electrical safety

a) Machine plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded)

machines. Unmodified plugs and matching outlets will reduce risk of electric shock.

b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased

risk of electric shock if your body is earthed or grounded.

c) Do not expose machines to rain or wet conditions. Water entering a machine will increase the risk of electric shock.

d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the machine. Keep cord away from heat, oil,

sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.

e) When operating a machine outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use

reduces the risk of electric shock.

f) If operating a machine in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD

reduces the risk of electric shock.

Personal safety

a) Stay alert, watch what you are doing and use common sense when operating a machine. Do not use a machine while you are

tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating machines may result in

serious personal injury.

b) Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask, non-skid safety

shoes, hard hat or hearing protection used for appropriate conditions will reduce personal injuries.

c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack,

picking up or carrying the machine. Carrying machines with your finger on the switch or energising machines that have the switch

on invites accidents.

d) Remove any adjusting key or wrench before turning the machine on. A wrench or a key left attached to a rotating part of the

machine may result in personal injury.

e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the machine in unexpected

situations.

f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair and clothing away from moving parts. Loose clothes,

jewelry or long hair can be caught in moving parts.

g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly

used. Use of dust collection can reduce dust-related hazards.

h) Do not let familiarity gained from frequent use of machines allow you to become complacent and ignore machine safety

principles. A careless action can cause severe injury within a fraction of a second.

Machine use and care

a) Do not force the machine. Use the correct machine for your application. The correct machine will do the job better and safer at

the rate for which it was designed.

b) Do not use the machine if the switch does not turn it on and off. Any machine that cannot be controlled with the switch is

dangerous and must be repaired.

Hansa F3 Chaff Cutter O&M Manual - OM-016 Revision B 14/05/2019

c) Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the machine before making

any adjustments, changing accessories, or storing machines. Such preventive safety measures reduce the risk of starting the

machine accidentally.

d) Store idle machines out of the reach of children and do not allow persons unfamiliar with the machine or these instructions

to operate the machine. Machines are dangerous in the hands of untrained users.

e) Maintain machines and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other

condition that may affect the machine’s operation. If damaged, have the machine repaired before use. Many accidents are

caused by poorly maintained machines.

f) Keep cutting machines sharp and clean. Properly maintained cutting machines with sharp cutting edges are less likely to bind

and are easier to control.

g) Use the machine, accessories and machine bits etc. in accordance with these instructions, taking into account the working

conditions and the work to be performed. Use of the machine for operations different from those intended could result in a

hazardous situation.

h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow

for safe handling and control of the machine in unexpected situations.

Service

a) Have your machine serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety

of the machine is maintained.

Identifying hazards and risks

Identify hazards and risks, and take preventative steps to avoid accidents and minimise risk. Possible hazards include, but are not

limited to, moving parts, thrown objects, weight of chaff cutter and components, and the operating environment.

Below is a list of hazards and actions required to prevent injury.

Hazard

Risk

Corrective action

Dust

Injury or irritation of the

eyes

Respiratory irritation

Wear safety glasses

Process freshly cut materials and/or wear a dust mask

Belt drive

Skin pinching and/or

abrasions

Ensure that the belt guard is in place, and properly secured

by bolts with spring washers.

When performing maintenance on the machine, ensure that

it is disconnected from its power supply

Rollers and cutting reel

Pinching, crushing, cutting,

severing

Keep hands clear from the infeed rollers

Use a stick or push block to push materials into the

feed rollers

Do NOT push material in with your hands past the

edge of the safety screen

Discharge material

Eye injury, minor cuts

Always wear safety glasses when operating the machinery

Do NOT look in to, or put your face near the outlet,

even when the machine is turned off

Do NOT put the machinery in a place where

material output might be obstructed

Hansa F3 Chaff Cutter O&M Manual - OM-016 Revision B 14/05/2019

Feeding material

Cuts and scrapes, pricks

Wear safety gloves

Wear tight fitting long sleeves to cover bare skin when

operating the machinery

Weight of the machine

Straining, crushing

Operate the machinery on level ground

Take care when moving the machine around, especially

when going up/down slopes

Ensure the inlet chute is properly secured before operating

the machine

Electric cable

Electric shock

Ensure you use a residual current device (RCD). Ensure

power supply cords are in good condition

If a wire is cut or damaged in any way, turn off the machine

immediately and disconnect the power supply

Operation

Safe setup procedure

Before you start:

Ensure the chaff cutter is positioned on level ground

Ensure that the outlet discharge is directed toward a suitable area or catcher bag

Do NOT allow the flow of material through the chaff cutter to be obstructed

Keep children and spectators clear of the work area at all times

Do NOT allow any person under the age of 16 to operate the chaff cutter

Check:

That all screws, nuts, bolts, and other fasteners are properly secured

That the belt guard and the safety screen on the inlet chute are in place and in good condition.

That the inlet chute and housing are clear of any leftover material or other obstructions that could block or

prevent start-up of the machine

That all labels are in good condition and easily legible

Replace damaged or unreadable warning and operating

View photos of labels in the ‘Decals’ section

Safe operating procedure

Wear safety equipment: Safety glasses must be worn at all times

Wear work gloves: Wearing work gloves is optional but highly recommended

Teasing hay/chaff can result in cuts/pricks to bare hands

Tie long hair up

Long hair could be pulled into the machine

Wear clothes that sit tightly

Avoid scarves and clothes with loose sleeves and any items that can get caught in the rollers of the machine

Tease densely packed hay/chaff or other material out on the inlet chute before switching on the machine

Doing so will reduce the chances of the machine stalling and increase the life of the cutting components

Separate unsuitable feed material from what is being fed into the machine.

Woody stems/roots can stall/jam the machine or result in damage or accelerated wear on the machine’s cutting

mechanism

Exercise caution when feeding material into the machine, especially when the length of material is short

Do NOT use your hands to feed material in past the safety guard

DO:

Hansa F3 Chaff Cutter O&M Manual - OM-016 Revision B 14/05/2019

It is recommended to use either a push block, a short stick, or simply more material to feed from a

comfortable distance

Turn the machine off when material is not being processed

Running the machine for more than 3 seconds without any material being fed into it will dull the cutting

components inside the machine

Keep the outlet area free of blockage

If a blockage occurs, turn the machine off and disconnect it from its power supply. Open the bonnet and remove

material until the inside of the machine is clear of excess material

As the discharge material piles up

Move the processed material to avoid blocking, or, if using a feed bag, adjust or replace the bag

Turn off the motor whenever you leave the work area

Ensure that the outlet discharge is directed toward a suitable area or catcher bag

Do NOT allow the flow of material to be obstructed

If using a bag to catch output material, periodically check the bag to ensure it is not full and causing the machine to choke

Operate the machine wearing loose clothing and untied long hair

Put soil, sand, grit, stones, woody material or pieces of metal into the machine

This will damage the sharp edge of the cutting reel and could stall the machine.

Overload the chaff cutter

Ensure material is suitable for the chaff cutter and that it is teased out before feeding the machine

Allow processed material to build up in the discharge area as this can:

Prevent proper discharge

Result in the machine stalling

Leave the machine running while no material is being processed

This will damage the sharp edge of the cutting reel

Move the chaff cutter while the motor is running

Put hands or any other part of the body or clothing:

Inside the feed chute past the safety screen

Inside or near the outlet area

Near any moving part

Remove any guards on the machine unless its cable is unplugged from an electrical outlet

Leave the chaff cutter connected to a power supply while it is unattended

Power supply

The F3 chaff cutter requires a 220-240V AC 50Hz earthed power connection. The chaff cutter is rated at 8.4 A. It is recommended

that the chaff cutter is only connected to a power socket which is protected by a circuit-breaker that would activate with a residual

current not more than 30 mA. It is also recommended that the chaff cutter is always used with an RCD (residual current device)

having a rated residual current of 30 mA or less. Always check and test your RCD every time you use it.

If extension cords are used, they must meet these requirements:

Rated at 10 A minimum

Minimum conductor cross section is 1.0 mm2

Maximum length of all cords connected must be less than 40 m

Comply with H05VV-F or H07VV-F

Be in good condition

Used away from sharp edges and water

Ensure the power supply cable is kept away from moving hazardous parts

Ensure the power supply cable is kept away from any sources of water

If the power supply cable becomes damaged, do NOT attempt to operate the chaff cutter

If the power supply cable becomes damaged, do NOT touch the damaged cable unless it has been disconnected from its

power source

Do NOT attempt to repair any damaged cables unless you are competent to do so

DO NOT:

Hansa F3 Chaff Cutter O&M Manual - OM-016 Revision B 14/05/2019

Controls

Before proceeding, ensure the ‘safe setup procedure’ has been followed on page 3 of this

manual.

Start/Stop

Plug the power supply cable into a suitable power socket.

To start the chaff cutter, press the green power button on the control panel.

To stop the chaff cutter, press the red power button on the control panel.

Forward/Reverse

To change from forward to reverse operation (or vise-versa), flick the rotary switch either

left or right to the desired setting. While set to reverse, the green power button must be

held down in order to run the machine. Note that there is also a time delay of 3 seconds

when switching the feed direction to allow the motor to slow down before switching

direction.

Emergency stop

The F3 Chaff cutter comes with an emergency stop, which acts as an immediate kill

switch to the machine. To engage the emergency stop, push the red button. To

disengage the emergency stop, twist the red button clockwise until it releases outwards.

Use it when foreign matter such as sand, stones, woody material or metal enter

the inlet of the machine

Use it in response to an immediate hazard/danger to an operator or onlooker

Inspect the machine before resetting the emergency stop

Storage

Store the chaff cutter out of the reach of children

Store the chaff cutter out of the rain

Water can rust the steel body of the chaff cutter

If necessary, the inlet chute of the machine can be folded down for storage. To do so, undo the wingnut (anticlockwise)

on the outside of the machine, lift the inlet chute up slightly while pushing forward on the wingnut, then drop the inlet.

To raise the inlet back up to its operating position, lift the inlet up until the wingnut clicks into place, then tighten

(clockwise) the wingnut to secure it in place.

Transportation

The F3 Chaff Cutter is designed to be moved by one person using the handles at the top of the inlet chute to lean the machine

backwards and transfer its weight onto the wheels. The chaff cutter can then be wheeled to and from the work location.

Ensure the power supply cable is properly secured when moving the chaff cutter around

Do NOT use the wheels to move the chaff cutter up and down stairs or kerbs.

Take care when wheeling the chaff cutter up slopes. The mass of the machine is approximately 150 kg.

For long distance transport by means of a vehicle, the chaff cutter has two tie-down points on both the front and back of the

machine. When using a strap to secure the machine, ensure the straps are sufficiently tight around these points, but not too tight

so as to flex the body of the chaff cutter.

Hansa F3 Chaff Cutter O&M Manual - OM-016 Revision B 14/05/2019

Troubleshooting

What to do if:

The chaff cutter won’t start

•The power source might be switched off

Check that the power supply cable is plugged in and switched on

Check that the power supply cable is undamaged

Do NOT attempt to use the chaff cutter if the cable is damaged.

The chaff cutter slows down and stalls

•The feed material is unsuitable for the chaff cutter

•Too much material is being fed into the chaff cutter

Reduce volume of material, tease material out more, or feed the chaff cutter slower

•The cutting reel or base blade is blunt

Contact Hansa to arrange sharpening of the cutting components

Discharge slows down/stops

•The chaff cutter is clogged up

Turn the machine off, disconnect from the power source, open bonnet and clear excess material.

The output material is not being cut finely enough

•The position of the reel might need adjustment

Move the reel closer to the base blade (see ‘cutting mechanism adjustment’ under the maintenance

section of this manual.

•The reel and/or base blade might be blunt

Inspect and sharpen/replace base blade as required. If base blade is sharp then inspect/sharpen reel.

Maintenance

Maintain the chaff cutter with care and keep it clean at all times.

To service or inspect the machine, or to change an accessory, you must first disconnect the chaff cutter from its power source

Belt replacement

If the belts in your chaff cutter look similar to any of the following images or are clearly broken, then they need to be replaced. The

chaff cutter uses two Z51v-belts. To inspect the belts, remove the pulley guard (see step 1 of ‘Maintaining the chain drive’ below).

WARNING! Do NOT open the bonnet unless the chaff cutter is turned off and disconnected from its power source

Cracked underside of belt

Sidewall belt wear

Soft, swollen belt

Worn cover on back of belt

Split belt cover

Tabla de contenidos

Manuales populares de Maquinaria agrícola de otras marcas

GSi

GSi PNEG-2314 Manual de usuario

Checchi & Magli

Checchi & Magli TEXDRIVE Manual de usuario

Amazone

Amazone Cenius 4003-2TX Manual de usuario

MASSEY FERGUSON

MASSEY FERGUSON MF 9313S Manual de usuario

Cima

Cima BLITZ Instrucciones de funcionamiento y mantenimiento

Amazone

Amazone CombiDisc 3000 Instrucciones de instalación

HE-VA

HE-VA Disc-Roller XL Contour Manual de usuario

AGT

AGT AGT-SSFM Manual de usuario

Milestone

Milestone 72-84 Manual de usuario

KUHN

KUHN Hector 3000 Manual de usuario

Krone

Krone X-Disc 6200 Manual de usuario

Eliet

Eliet DZC450 Manual de usuario

Taarup

Taarup BIO+ B4000 Manual de usuario

Garland

Garland SHAKER 310 DPG Manual de usuario

stable comfort

stable comfort StableWall System Manual de usuario

Raven

Raven AccuBoom Manual de usuario

International

International 710 Manual de usuario

Ashland

Ashland HDW-3217-14 Manual de usuario
